Shintaro SH-XCRUSB3 User manual

SHINTARO EXTERNAL USB 3.0 CARD READER
1. GENERAL INFORMATION
The Shintaro USB 3.0 External Card Reader
is ideal for high speed data transmitting.
If the host PC does not feature a USB 3.0
controller, Shintaro’s PCI-E (SHUSB3PCIE) and
ExpressCard (SHUSB3EX) adapters are available
from your Shintaro stockist.
The five available memory card slots offer support
for more than fifty types of memory cards and can
accept the most popular small form factor flash
cards directly; such as Mini SD, RS-MMC, MS-
Duo and MS Micro (M2). It also supports all the
popular full-size memory cards such as Secure
Digital (SD), MultiMedia Card (MMC), Compact
Flash (CF), Memory Stick (MS), Memory Stick Pro,
xD picture card (xD) and other compatible memory
cards.
2. PACKAGE CONTENTS
SOHOUSB external card reader•
One USB 3.0 cable•
Drive disc with user manual•
3. KEY FEATURES
Supports SDXC/SD 3.0 UHS-1; CF UDMA6;•
xD; Micro-SD/M2
SDXC’s extended capacity up to 2 TB•
Provided USB 3.0 interface is backwards•
compatible USB 2.0 and 1.1 standards
This device is Bus-powered; no external power•
supply required
Hot swappable and Plug & Play capability•
Five card slots can accept up to 50 types of•
media card formats.
Adapter-less media storage card reader•
Stand-alone / palm size / SuperSpeed / High-•
speed / full-speed / adapter-less media storage
card reader.
Portable, light, durable, slim, compact and•
easy to use.
4. NOTICES
Secure Digital (SD)•
Note 1: After inserting SDXC/SDHC...etc
memory card, be mindful the memory card’s
lock switch may have shifted slightly (see
below).
Note 2: When inserting the Mini SD memory
card, you should align it to the left of the slot
Compact Flash (CF)•
Note: If the CF 64GB UDMA 6 memory card
is formatted as NTFS in Win VISTA/7 before
using, it can not be formatted again in Win XP.
5. SPECIFICATIONS
Five Card Slots SD; CF; MS; xD; Micro-SD/M2
Memory Card
Support
Compact Flash Card Series:•
CF UDMA 6, CF Type I, CF
Type II, CF Ultra II, Micro Drive,
MagicStor, etc
xD Picture Card series:• xD, xD
M-series, xD H-series, etc
Secure Digital Card series:• SD,
SD 3.0 UHS-I, SDXC, SDHC,
SD Ultra II, mini SD, mini SDHC,
Micro-SD, Micro-SDHC, etc
MMC card series:• MMC-I, MMC-
II, MMC 4.0, MMC Dual Voltage,
MMC Mobile, MMC 4.0 Dual
Voltage, RS-MMC, RS-MMC
Dual Voltage, RS-MMC Mobile,
RS-MMC 4.0, RS-MMC 4.0 Dual
Voltage, MMC Micro(*), etc
Memory Stick card series:• MS,
M2, MS PRO-HG Duo, MS HG
Micro, MS Select, MS ROM, MS
PRO, MS Magic Gate, MS PRO
Magic Gate, MS-Duo Magic
Gate, MS PRO Duo , MS micro,
etc
(*): accepted by card adapter
Indicator Blue LED: Power(holding on light) &
Access(flash)
System
Requirements
Win XP, Win Vista 32/64, Win 7
Mac OS (USB 2.0 only)
Linux Kernel (USB 2.0 Only)
* Win XP does not support Exfat format.
* Specifications are subject to change without notice.

SHINTARO EXTERNAL USB 3.0 CARD READER
SHINTARO
USB 3.0
EXTERNAL
CARD READER
SH-XCRUSB3
QUICK START GUIDE
Click “OK” to complete the installation.4.
Installation complete!5.
6. ICON PROGRAM INSTALLATION
After you install the external card reader you
need to install the Shintaro USB 3.0 Card
Reader Icon Program.
Windows XP/VISTA/7
Insert the program disc into the CD-ROM/1.
DVD-ROM drive.
Click the folder “IconMan_R_V1.20_(xD)”.2.
Click the file “IconMan_R_V1.20_(xD)”.3.
