ZKTeco BR1200 Series User manual

Installation Guide
BR1200 Series
Version: 1.0
Date: January 2019

Touch screen(BR1200)
Display screen(BR1200s)
1
Card swiping area
(The standard card is ID
card. Mi-fare card is optional)
QRcodecamera
Palmdetectionarea
(optional)
Wires
1.Overview
Frontview
Rearview
Fingerprintsensor
Screws fixing hole
Used to adjust the
horizontal position of
BR1200/BR1200s

2
BR1200 supports ID/Mifare card, fingerprint/palm and QR code recognition methods. It is mainly
used as a master device embedded in the barrier. It can be used for data collection and verification. It
has a 2.8-inch touch screen (187mmx105mmx66mm) and good human-machine interaction.
BR1200s is mainly used as a slave device for BR1200 or other access control devices by RS232. It can be
used for verification. It has the same appearance as BR1200 but with a non-touch display type, whereas
BR1200 has touch display. 
2. Introduction
Steps:
1.Place the device horizontally inside the rectangular holeon the fixed bracket of the barrier.
2.Adjust the horizontal position of the device to make sure it completely flushes with the barrier.
3.Tighten and fix the device with M3 screws.
Rectangular
hole
3. Installation
①
②
③

3
User verifies the card/fingerprint/palm/QR code
Verified successfully
Barriergateopens
Data comparison
4. Verification Process
Power Connection
12V/3A Power supply
Ethernet Connection
Computer
Cable ZKBioSecurity
5.Connection (BR1200)

4
BarrierConnection
(By relaysignaltoopenthebarriergate)
NC2
COM2
NO2
NC1
COM2
NO1
Barrier
Connection with BR1200s
BR1200s
Note:
BR1200s can be connected with other access control device which supports RS232
communication. The connection method is same as above.

5
BR1200 is installed at the entrance as a master device and is connected with ZKBioSecurity software
through TCP/IP. BR1200s is installed at the exit and communicates with the master device via RS232
communication.
6. Application
TCP/IP
Barrier Barrier
In
BR1200
ZKBioSecurity
Out
BR1200s
RS232
Notes:
ŸTo connect the master and slave device by RS232 communication, the following ports should be
connected correspondingly.
MasterdeviceBR1200s
TXD-------------------------------RXD
RXD-------------------------------TXD
GND-------------------------------GND
ŸBR1200s can only pass the verification if the serial port of BR1200 is set as master.
ŸBR1200will open theLOCK1 after the verification, and BR1200swill open theLOCK2.
ŸTo set the verification mode of the master device, enter the menu, click ‘Access Control’--> ’Access
ControlOptions’--> ’VerificationMode’.The option ‘VerifyMode byRS232’canbe used to setthe
verificationmodeoftheslavedevicewhichisconnectedbyRS232 communication.
