INSTRUCTION MANUAL
MODEL : SB-3716
S-Video Distribution Amplifier
4 Way S-Video Distribution Amplifier
1 x 4 S-Video (Y/C)/Stereo Audio (AR,AL)
S-Video / Stereo Audio Splitter Series
Thank you for purchasing the SB-3716 S-Video 4 Way Distribution Amplifier. You will find this unit easy to install
and highly reliable but it is essential that you read this manual thoroughly before attempting to use this amplifier.
MULTIMEDIA AUDIO AND VISUAL

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
flow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualified service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports first, then remove the power cable; finally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF AGENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL

CONFORMANCE TEST REPORT
FOR
EN 55013 / EN 55020
EN 55013 / EN 55020
REPORT NUMBER: ET93S-06-168-1
FOR
FCC 47 CFR/Part 15 Subpart B
FCC 47 CFR/Part 15 Subpart B
Report Number: ET93S-06-168-02
FOR
VCCI
VCCI
REPORT NUMBER: ET93S-06-168-03
Model Number: SB-3716
Comment Number :
SB-3704, SB-3705, SB-3706, SB-3708, SB-3709, SB-3710,
SB-3714, SB-3716, SB-3730, SB-3733, SB-3737
Input: Video: S-Video (Y/C)
Audio: Stereo Audio System (R/L)
Output: Video:S-Video (Y/C)
Audio: Stereo Audio System (R/L)
Power Input: +DC12V, @300mA~660mA
TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow
for sufficient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update or
to keep current the information contained in this document.
We reserve the right to make improvements to this document and/
or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed,stored in aretrieval system,or anyof itspart translated
into any language or computer file, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise — without express written permission and consent
© Copyright 1997. All Rights Reserved.
Version 1.2 SEPT 2013
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
CONTENTS
TABLEOFCONTENTS......................................................1
PACKAGE CONTENTS .................................................... 1
FEATURES ....................................................................... 2
SPECIFICATIONS ............................................................ 2
TYPICAL HOOKUP AND OPERATION ............................ 3
INTRODUCTION
Congratulations on your purchase of one of the SB-3716. The 1x4
S-Video/Stereo Audio Distribution Amplifier is designed to work
as a splitter for S-Video/Stereo Audio applications. Capable of
splitting a S-Video and Stereo Audio signal from one source to
four devices with compatible inputs. A built in amplifier will boost
the signal to the needed level, to prevent signal loss and picture
degradation. A maximum bandwidth of 100MHz will support a
sharp and highly defined video in multiple resolutions of up to 576i.
The 1x4 Distribution Amplifier works with satellite and cable set-
top boxes, DVD players, D-VHS players and all other equipment
that is equipped with proper Audio/Video Connections.
PACKAGE CONTENTS
Check that you have the following components;
• SB-3716 Distribution Amplifier
• 1 2R/S-2R/S Cable (RCA/Mini-4p Connector), 6 feet
• Users Guide
• AC/DC Adapter: 12VDC, @300mA~660mA
AC/DC Adaptor Types : CE/UL/SAA/BS
1

FEATURES & SPECIFICATIONS
FEATURES
• Input: 1x S-Video (Y/C), 1x StereoAudio (RCA)
• Output: 4x S-Video (Y/C), 4x StereoAudio (RCA)
• On/Off Power Switch
• Video Bandwidth >110 Mhz
SPECIFICATIONS
Input - Video x 1: S-Video (Y/C), on Min-Din-9p Connectors, 75 0hms,1Vpp
Input - Audio x 1: Stereo Audio (R/L), -20db 50K 0hms, RCA Connectors
Output-Video x 4: S-Video (Y/C), on Min-Din-9p Connectors, 75 0hms,1Vpp
Output - Audio x 4: Stereo Audio (R/L), -20db 50K 0hms, RCA Connectors
Video Bandwidth: >50MHz
Video Distrotion: <1.2db (+/- 3db)
Audio Input Impedance: 10K Ohms
Scan Rates Accepted: 50Hz or 60Hz (NTSC or PAL)
Channel Isolation: >50db
S/N Ratio: >50db
Dimensions (WxDxH): 5.1 in x 3.7 in x1.5 in
Power Consumed: 50mA Max
Power Source: DC 12 Volts, @300mA~660mA
As product improvements are continuous, specifications are subject to change without notice.
2

TYPICAL HOOKUPAND OPERATION
SB-3716
Inputs: 1 x S-Video /Audio (R/L)
Outputs: 4 x S-Video /Audio (R/L)
DC Input: 12V @300mA~660mA
Power SW: on/off
Safeguards and Precautions
A. Keep this unit away from fire, extremely hot areas, water or moisture of any kind.
B. Do not place this unit on any support that is not firm, level and strong.
C. Do not service the unit yourself. Opening the unit’s housing will void the warranty.
D. Servicing must be by Shinybow or by an authorized technician.
C. Illegal duplication of copyrighted material is strictly prohibited by Federal Laws.
4X S-VIDEO DISTRIBUTION AMPLIFIER
S-Video System: S-Video (Y/C), Stereo Audio
Applications: DVD’s, VCR’s, VCD’s
3

4
LIMITED WARRANTY
PLEASE READ THE FOLLOWINGTERMSAND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED
BY,THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your
agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to SHINYBOWUSA,
Inc. at the return address set forth on the Product’s packing label at your expense. SHINYBOWUSA, Inc. may modify these Terms and Conditions at anytime,
without notice to you.
RESTRICTIONS ON USE OF THE PRODUCT
It is your responsibility to read and understand the installation and operation instructions, both verbal and in writing, provided to you with respect to the Product.
You are authorized to use the Product solely in connection with such instructions. Any use of the Product not in accordance with such instructions shall void any
warranty pertaining to the Product. Any and all damages that may occur in the use of the Product that is not strictly in accordance with such instructions shall be
borne by you and you agree to indemnify and hold harmless SHINYBOWUSA, Inc. from and against any such damage.
The Product is protected by certain intellectual property rights owned by or licensed to SHINYBOWUSA. Any intellectual property rights pertaining to the Product
arelicensed to youby SHINYBOWUSA, Inc. and/or itsaffiliates, including anymanufacturers or distributorsof the Product(collectively, “SHINYBOWUSA”) for your
personal use only, provided that you do not change or delete any proprietary notices that may be provided with respect to the Product.
The Product is sold to you and any use of any associated intellectual property is deemed to be licensed to you by SHINYBOWUSA for your personal use only.
SHINYBOWUSA does not transfer either the title or the intellectual property rights to the Product and SHINYBOWUSA retains full and complete title to the
intellectual property rights therein.All trademarks and logos are owned by SHINYBOWUSAor its licensors and providers of the Product, and you may not copy or
use them in any manner without the prior written consent of SHINYBOWUSA, which consent may be withheld at the sole discretion of SHINYBOWUSA.
ThefunctionalityandusabilityoftheProductiscontrolledbySHINYBOWUSA,Inc.fromitsofficeswithintheStateofTexas,UnitedStatesofAmerica.SHINYBOWUSA
makesnorepresentation that materialspertainingto theProductare appropriateoravailablefor useinother locationsotherthan theshippingaddress you provided
with respect thereto. You are advised that the Product may be subject to U.S. export controls.
Disclaimers and Limitation of Liability
SHINYBOWUSAmay change or modify the Product at any time, from time to time.
THE PRODUCT IS PROVIDED “AS IS”AND WITHOUT WARRANTIES OFANY KIND EITHER EXPRESS OR IMPLIED. SHINYBOWUSADOES NOT WARRANT
ORMAKEANYREPRESENTATIONSREGARDINGTHEUSEORTHERESULTSOFTHEUSEOFTHEPRODUCT’SCORRECTNESS,ACCURACY,RELIABILITY,
OR OTHERWISE.
SHINYBOWUSA has no duty or policy to update any information or statements pertaining to the Product and, therefore, such information or statements should
not be relied upon as being current as of the date you use the Product. Moreover, any portion of the materials pertaining to the Product may include technical
inaccuracies or typographical errors. Changes may be made from time to time without notice with respect to the Product.
TO THE FULLEST EXTENT PERMISSIBLE PURSUANT TO APPLICABLE LAW, SHINYBOWUSA DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSEAND NON-INFRINGEMENT.
SHINYBOWUSADOES NOT WARRANT THEACCURACY, COMPLETENESS OR USEFULNESS OFANY INFORMATION WITH RESPECT TOTHE PRODUCT.
SHINYBOWUSADOESNOTWARRANTTHATTHEFUNCTIONSPERTAININGTOTHEPRODUCTWILLBEERROR-FREE,THATDEFECTSWITHRESPECTTO
THEPRODUCTWILLBECORRECTED, ORTHATTHEMATERIALSPERTAININGTHERETOAREFREE OFDEFECTS OROTHER HARMFULCOMPONENTS.
SHINYBOWUSA WILL USE ITS REASONABLE EFFORTS TO CORRECT ANY DEFECTS IN THE PRODUCT UPON TIMELY WRITTEN NOTICE FROM YOU
NOT TO EXCEED 10 BUSINESS DAYS AFTER RECEIPT BY YOU OF THE PRODUCT, BUT YOU (AND NOTSHINYBOWUSA) ASSUME THE ENTIRE COST
OFALL NECESSARY SERVICING, REPAIR AND CORRECTIONTHAT WAS CAUSED BY YOU UNLESS OTHERWISEAGREED TO INASEPARATE WRITING
BYSHINYBOWUSA.
UNDER NO CIRCUMSTANCES, INCLUDING, BUT NOT LIMITED TO, NEGLIGENCE, SHALL SHINYBOWUSA BE LIABLE FOR ANY SPECIAL OR
CONSEQUENTIALDAMAGESTHATRESULTFROMTHEUSEOF,ORTHEINABILITYTOUSETHEPRODUCTINACCORDANCEWITHITSSPECIFICATIONS,
EVEN IFSHINYBOWUSA OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL
SHINYBOWUSA’S TOTAL LIABILITY TO YOU FROM ALL DAMAGES, LOSSES, AND CAUSES OF ACTION (WHETHER IN CONTRACT, OR OTHERWISE)
EXCEED THEAMOUNTYOU PAID TO SHINYBOWUSA, IFANY, FOR THE PRODUCT.
END OF DOCUMENT
