SHOR-LINE 903.3220.10 User manual

A guide for:
The Grooming Table
{Save This Guide For Future Reference}
PN: 006.3220.00
Updated: 11.13.2015
To reduce the risk of injury, the user must read and understand this guide before installation of this product.
This product is for animal use only. Pour les animaux uniquement.
We do not condone this product for other uses.

{2} Shor-Line | 800.444.1579 | www.shor-line.com
Introduction
Thank you for purchasing Shor-Line products. As a leader in animal care equipment, our commitment to you is
exactly the same as it was in 1927.
We hope this guide answers any questions you might have in regards to use, care or installation. If you can’t nd the
answers to your questions, have further questions or would like to purchase additional products, please contact us at
800.444.1579 or 913.281.1500. If in Europe phone [phone].
Consider keeping this guide in a safe and convenient place for future assistance.
IMPORTANT: DO NOT ATTEMPT TO DISASSEMBLE TABLE WITHOUT CONTACTING SHOR-LINE.
For your safety, please follow the instructions on these labels:
This product is for animal use only. Pour les animaux uniquement.
We do not condone this product for other uses.
To reduce the risk of injury, the user must read and understand this guide before installation of this product.
Do not leave animal on the table top
unattended. Use a grooming loop
around animal's neck. Do not use a
choke-type lead or collar.
Ground fault circuit interrupter
(GFCI) and proper electrical
grounding are recommended
for this product.
Shor-Line products are designed for
animal use only. Never allow a person
on your Grooming Table.
{Shor-Line}
Schroer Manufacturing Company
511 Osage Ave.
Kansas City, Kansas 66105, USA
phone [phone] fax [phone]
email [email protected]
www.shor-line.com
{Shor-Line Limited}
Vale Business Park
Llandow,
Vale of Glamorgan CF71 7PF
United Kingdom
phone [phone] fax [phone]
email [email protected]
www.shor-line.co.uk

{3}
{Contents}
Section 1: Unpacking & Inspecting Shipment
Unpacking & Inspecting Steps ...................................................................................................................5
Grooming Table Parts List..........................................................................................................................5
Grounding Instructions...............................................................................................................................6
Features.....................................................................................................................................................7
Section 2: Installing the Leveling Feet & Scuff Pads
Procedure...................................................................................................................................................9
Section 3: Installing the Grooming Arm (Elite Models)
Procedure.................................................................................................................................................10
Section 4: Grooming Arm Adjustments (Elite Models)
Procedure.................................................................................................................................................11
Section 5: Optional Grooming Arms
Fixed Arm - Elite Models ..........................................................................................................................12
Clamp On Arm - Classic Models ..............................................................................................................12
Section 6: Raising & Lowering the Grooming Table
Elite Grooming Tables, Electric Lift ..........................................................................................................13
Elite Grooming Tables, Hydraulic Lift .......................................................................................................13
Classic Grooming Tables, Electric Lift......................................................................................................13
Section 7: Specifications
Elite Grooming Tables, Electric Lift ..........................................................................................................14
Elite Grooming Tables, Hydraulic Lift .......................................................................................................14
Classic Grooming Tables, Electric Lift......................................................................................................14
Big Top Grooming Tables, Electric Lift .....................................................................................................14
Big Top Grooming Tables, Hydraulic Lift ..................................................................................................14
Section 8: Dimensions
Elite Grooming Tables, Electric & Hydraulic Lift.......................................................................................15
Classic Grooming Tables, Electric Lift......................................................................................................15
Big Top Grooming Tables, Electric & Hydraulic Lift ..................................................................................16
Section 9: Stainless Steel Care & Cleaning
Quality & Life of Your Product ..................................................................................................................17
Care & Cleaning Best Practices...............................................................................................................17
Protecting Against Disease & Infection ....................................................................................................17
Section 10: Services, Terms & Conditions, Warranty
Terms & Conditions..................................................................................................................................18
Order & Acceptance.................................................................................................................................18
Entire Agreement .....................................................................................................................................18
Terms Of Payment ...................................................................................................................................18
Prices & Quotes .......................................................................................................................................18
Taxes........................................................................................................................................................18
Deliveries .................................................................................................................................................18
Inspection.................................................................................................................................................18
Product Satisfaction .................................................................................................................................19
Limited Warranty ......................................................................................................................................19
Return Policy............................................................................................................................................19
Indemnity..................................................................................................................................................19
Unlawful Use............................................................................................................................................19
Regulations And Codes............................................................................................................................19
Seller’s Remedies ....................................................................................................................................19
Miscellaneous ..........................................................................................................................................19
See the following page for Grooming Tables included in this guide.

{4} Shor-Line | 800.444.1579 | www.shor-line.com
• Elite Grooming Table, Electric Lift, Silver Vein, 120V Item # 903.3220.10
• Elite Grooming Table, Electric Lift, Silver Vein, 230V Item # 903.3220.04
• Elite Grooming Table, Electric Lift, Plum Perfect, 120V Item # 903.3220.19
• Elite Grooming Table, Electric Lift, Plum Perfect, 230V Item # 903.3220.28
• Elite Grooming Table, Electric Lift, Screamin’ Green, 120V Item # 903.3220.20
• Elite Grooming Table, Electric Lift, Screamin’ Green, 230V Item # 903.3220.29
• Elite Grooming Table, Electric Lift, Burnt Orange, 120V Item # 903.3220.21
• Elite Grooming Table, Electric Lift, Burnt Orange, 230V Item # 903.3220.30
• Elite Grooming Table, Electric Lift, Electric Pink, 120V Item # 903.3220.22
• Elite Grooming Table, Electric Lift, Electric Pink, 230V Item # 903.3220.31
• Elite Grooming Table, Electric Lift, Shor-Line Blue, 120V Item # 903.3220.42
• Elite Grooming Table, Electric Lift, Shor-Line Blue, 230V Item # 903.3220.43
• Elite Grooming Table, Hydraulic Lift, Silver Vein Item # 903.3220.11
• Elite Grooming Table, Hydraulic Lift, Plum Perfect Item # 903.3220.36
• Elite Grooming Table, Hydraulic Lift, Screamin’ Green Item # 903.3220.37
• Elite Grooming Table, Hydraulic Lift, Burnt Orange Item # 903.3220.38
• Elite Grooming Table, Hydraulic Lift, Electric Pink Item # 903.3220.39
• Elite Grooming Table, Hydraulic Lift, Shor-Line Blue Item # 903.3220.44
• Classic Grooming Table, Electric Lift, Silver Vein Item # 903.3220.27
• Classic Grooming Table, Electric Lift, Plum Perfect Item # 903.3220.23
• Classic Grooming Table, Electric Lift, Screamin’ Green Item # 903.3220.24
• Classic Grooming Table, Electric Lift, Burnt Orange Item # 903.3220.25
• Classic Grooming Table, Electric Lift, Electric Pink Item # 903.3220.26
• Classic Grooming Table, Hydraulic Lift, Silver Vein Item # 903.3220.52
• Classic Grooming Table, Hydraulic Lift, Plum Perfect Item # 903.3220.32
• Classic Grooming Table, Hydraulic Lift, Screamin’ Green Item # 903.3220.33
• Classic Grooming Table, Hydraulic Lift, Burnt Orange Item # 903.3220.34
• Classic Grooming Table, Hydraulic Lift, Electric Pink Item # 903.3220.35
• Big Top Grooming Table, Electric Lift, Plum Perfect, 120V Item # 903.3220.53
• Big Top Grooming Table, Electric Lift, Plum Perfect, 230V Item # 903.3220.54
• Big Top Grooming Table, Electric Lift, Screamin’ Green, 120V Item # 903.3220.55
• Big Top Grooming Table, Electric Lift, Screamin’ Green, 230V Item # 903.3220.56
• Big Top Grooming Table, Electric Lift, Burnt Orange, 120V Item # 903.3220.57
• Big Top Grooming Table, Electric Lift, Burnt Orange, 230V Item # 903.3220.58
• Big Top Grooming Table, Electric Lift, Electric Pink, 120V Item # 903.3220.59
• Big Top Grooming Table, Electric Lift, Electric Pink, 230V Item # 903.3220.60
• Big Top Grooming Table, Electric Lift, Silver Vein, 120V Item # 903.3220.61
• Big Top Grooming Table, Electric Lift, Silver Vein, 230V Item # 903.3220.62
• Big Top Grooming Table, Electric Lift, Shor-Line Blue, 120V Item # 903.3220.63
• Big Top Grooming Table, Electric Lift, Shor-Line Blue, 230V Item # 903.3220.64
• Big Top Grooming Table, Hydraulic Lift, Plum Perfect Item # 903.3220.65
• Big Top Grooming Table, Hydraulic Lift, Screamin’ Green Item # 903.3220.66
• Big Top Grooming Table, Hydraulic Lift, Burnt Orange Item # 903.3220.67
• Big Top Grooming Table, Hydraulic Lift, Electric Pink Item # 903.3220.68
• Big Top Grooming Table, Hydraulic Lift, Silver Vein Item # 903.3220.69
• Big Top Grooming Table, Hydraulic Lift, Shor-Line Blue Item # 903.3220.70
Grooming Table Products

{5}
Section 1: Unpacking & Inspecting Shipment
{Unpacking & Inspecting Steps}
Step 1
Locate the Packing Slip that describes the parts and quantities shipped. Your Grooming Table should be carefully
examined upon arrival for possible damage in shipment. If any damage is found, notify Shor-Line immediately.
Step 2
Review Section 10: Shor-Line’s Warranty Information. For more information visit: www.shor-line.com/warranty.
Then click the Damages/Returns/Repairs link on the left.
Step 3
Remove and separate all contents from the shipping containers. Use the Packing Slip to ensure nothing has been
lost.
Step 4
Check content for concealed damage.
If Concealed Damage:
Follow instructions within Section 10: Shor-Line’s Warranty Information. For more information visit:
www.shor-line.com/warranty. Then click the Damages/Returns/Repairs link on the left.
Call Shor-Line immediately so we can expedite replacements or repairs.
IMPORTANT: After fteen (15) calendar days of receipt of merchandise, this policy becomes void.
{Grooming Table Parts List}
Elite Grooming Table, Electric Elite Grooming Table, Hydraulic
Part Number Description Part Number Description
062.3715.20 Leveling Screw 062.3715.20 Leveling Screw
051.0000.00 Scuff Pad 051.0000.00 Scuff Pad
058.3008.00 Tapered Handle 058.3008.00 Tapered Handle
085.1018.00 Handle Spring 085.1018.00 Handle Spring
310.1066.00 Handle Plunger 310.1066.00 Handle Plunger
089.0013.03 Linak Actuator, 120V 181.0068.00 Pump, Modied, Hydraulic
089.0013.09 Linak Actuator, 230V

{6} Shor-Line | 800.444.1579 | www.shor-line.com
Classic Grooming Table, Electric Classic Grooming Table, Hydraulic
Part Number Description Part Number Description
062.3715.20 Leveling Screw 062.3715.20 Leveling Screw
051.0000.00 Scuff Pad 051.0000.00 Scuff Pad
089.0013.03 Linak Actuator, 120V 181.0068.00 Pump, Modied, Hydraulic
089.0013.09 Linak Actuator, 230V
{Grounding Instructions}
This table is for use on a nominal 120 V circuit, and has a grounding plug that looks like the plug illustrated in the
gure below labeled A. A temporary adaptor, which looks like the adaptor illustrated in the gure below, labeled B
& C, may be used to connect this plug to a 2-pole receptacle as shown by label B if a properly grounded outlet is
not available. The temporary adaptor should be used only until a properly grounded outlet can be installed by a
qualied electrician. The green colored rigid ear, lug and the like, extending from the adaptor must be connected to
a permanent ground such as a properly grounded outlet box cover. Whenever the adaptor is used, it must be held in
place by the metal screw. A qualied electrician should be consulted if there is any doubt as to whether an outlet box
is properly grounded.

{7}
{Features of the Classic, Elite and Big Top Grooming Tables, Electric}
Elite Grooming Table, Electric Big Top Grooming Table, Electric
Pivoting grooming arm travels 180° around the end of the table.
The arm locks into ve positions horizontally, any position
between 22″ and 39″ vertically. The loop hook has six position
choices.
Pivoting grooming arm travels 180° around the end of the table.
The arm locks into ve positions horizontally, any position
between 22″ and 39″ vertically. The loop hook has six position
choices.
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Smooth and quiet lifting system can be operated from both
sides of the table.
Smooth and quiet lifting system can be operated from both
sides of the table.
40″L x 26″W table top. New, super-sized 48″L x 26″W table top.
Actuator lifts up to 250 lbs. from 20″ to 41″ high. Actuator lifts up to 250 lbs. from 20″ to 41″ high.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Comes in six colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, Silver Vein and Shor-Line Blue.
Comes in six colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, Silver Vein and Shor-Line Blue.
The ONLY CSA/UL certied grooming table on the market. The ONLY CSA/UL certied grooming table on the market.
Classic Grooming Table, Electric
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Smooth and quiet lifting system can be operated from both
sides of the table.
40″L x 26″W table top.
Actuator lifts up to 250 lbs. from 20″ to 41″ high.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Comes in ve colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, and Silver Vein.
The ONLY CSA/UL certied grooming table on the market.

{8} Shor-Line | 800.444.1579 | www.shor-line.com
{Features of the Classic, Elite and Big Top Grooming Tables, Hydraulic}
Elite Grooming Table, Hydraulic Big Top Grooming Table, Hydraulic
Pivoting grooming arm travels 180° around the end of the table.
The arm locks into ve positions horizontally, any position
between 22″ and 39″ vertically. The loop hook has six position
choices.
Pivoting grooming arm travels 180° around the end of the table.
The arm locks into ve positions horizontally, any position
between 22″ and 39″ vertically. The loop hook has six position
choices.
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Smooth and quiet lifting system can be operated via
hydraulic pump.
Smooth and quiet lifting system can be operated via
hydraulic pump.
40″L x 26″W table top. New, super-sized 48″L x 26″W table top.
Hydraulic unit lifts up to 250 lbs. from 20″ to 41″ high. Hydraulic unit lifts up to 250 lbs. from 20″ to 41″ high.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Comes in six colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, Silver Vein and Shor-Line Blue.
Comes in six colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, Silver Vein and Shor-Line Blue.
Classic Grooming Table, Hydraulic
Proprietary polyurethane coated table top provides a secure
and comfortable surface for the pet. Plus, it’s very durable and
easy to clean.
Smooth and quiet lifting system can be operated via
hydraulic pump.
40″L x 26″W table top.
Hydraulic unit lifts up to 250 lbs. from 20″ to 41″ high.
Other features include leveling legs and powder coated heavy
gauge steel construction.
Comes in ve colors: Plum Perfect, Screamin’ Green, Burnt
Orange, Electric Pink, and Silver Vein.

{9}
Section 2: Installing the Leveling Feet & Scuff Pads
{Procedure}
Step 1
After removing the grooming table and arm from the shipping carton, turn table on either side and install the leveling
feet with scuff pads (from the plastic bag) in the appropriate locations on the table legs. (Fig. 2A & 2B)
IMPORTANT: The leveling feet with scuff pads must be installed or the table will not function properly.
Leveling Foot & Scuff
Pad
Fig. 2A
Leveling Foot & Scuff
Pad
Fig. 2B
Hydraulic Grooming Table ViewElectric Grooming Table View

{10} Shor-Line | 800.444.1579 | www.shor-line.com
Section 3: Installing the Grooming Arm (Elite Models)
{Procedure}
Step 1
Remove safety stop (screw, 2 spacers & Nut) (Fig. 3A)
Step 2
Slide up/down adjustment bracket over support arm (Fig. 3A)
Step 3
Slide grooming arm through adjustment bracket & support arm
(Fig. 3B)
Step 4
Replace safety stop (screw, 2 spacers, nut and tighten) (Fig. 3C)
Adjustment Bracket
Prior To Installation
Adjustment Bracket
After Installation
Fig. 3B
Replace Safety Stop
Fig. 3C
Grooming Arm
Remove Safety Stop
Support
Arm
Slide Up/Down
Adjustment Bracket
Over Support
Arm
Fig. 3A

{11}
Section 4: Grooming Arm Adjustments (Elite Models)
{Procedure}
Step 1
Locate rotating arm adjustment Lock-Handle under the front side of the Grooming Table. (Fig. 4A & 4B)
Step 2
Pull Handle Down To Rotate Arm. Arm locks in ve different snap-in positions. (Fig. 4C)
Table
Top
Grooming Arm rotates 90º from this position
in either direction. Will lock in 5 Positions as
shown.
Fig. 4C
Rotating Arm Adjustment
Lock-Handle
Fig. 4B
Hydraulic Grooming Table View
Rotating Arm Adjustment
Lock-Handle
Fig. 4A
Electric Grooming Table View

{12} Shor-Line | 800.444.1579 | www.shor-line.com
Section 5: Optional Grooming Arms
{Fixed Arm - Elite Models}
The Fixed Arm does not rotate and is used in addition
to the adjustable grooming arm that comes with all Elite
Model Grooming Tables. (Fig. 5A)
{Clamp On Arm - Classic Models}
The Clamp On Arm is available for the Classic Model
Grooming Tables and does not rotate. (Fig. 5B)
NOTE: For questions regarding an additional purchase,
dial 800.444.1579 or 913.281.1500. Or if in Europe dial
[phone].
Rotating
Arm
Fixed
Arm
Fig. 5A
Fig. 5B

{13}
Foot Pedal
Fig. 6A
Section 6: Raising & Lowering the Grooming Table
{Classic and Elite Grooming Tables, Electric Lift}
Step 1
Be sure the power cord is plugged in.
Step 2
To Raise the table step on the foot pedal with the arrow pointing
up. (Fig. 6A)
Step 3
To Lower the table step on the foot pedal with the arrow pointing
down. (Fig. 6A)
{Elite and Classic Grooming Tables, Hydraulic Lift}
Step 1
To Raise the table push the foot pedal down, about ½ way from
the bottom , and release. Continue this until the top is at desired
height. (Fig. 6B)
Step 2
To Lock the table top at the desired height, Lift the foot pedal up
as far as it will go and release. (Fig. 6B)
Step 3
To Lower the table top, Push the foot pedal down as far as it will
go and hold. (Fig. 6B)
Fig. 6B
Foot Pedal

{14} Shor-Line | 800.444.1579 | www.shor-line.com
Section 7: Specifications
{Classic and Elite Grooming Tables, Electric Lift}
Grooming Table Actuator Grooming Table
24 Volt DC Motor Maximum Height (Floor To Top of Table) - 41 Inches (1041 mm)
2.7 AMPS Maximum at 250 lbs (1112 Newton) Load Minimum Height (Floor To Top of Table) - 20 Inches (508 mm)
Maximum Shaft Travel - 6 Inches (152 mm) Time From Minimum to Maximum Height (No Load) - 14 Seconds
120 Volt AC Power Cord For 120 V Model Time From Maximum to Minimum Height (No Load) - 13 Seconds
230 Volt AC Power Cord For 230 V Model Max. Dimensions - Standard Table - 80 Inches (2032 mm) High
x 54.5 Inches (1384 mm) Long x 27.43 Inches (697 mm) Wide
DC Control Module Mounted To Actuator Min. Dimensions - Standard Table - 42.25 Inches (1073 mm) High
x 46.5 Inches (1184 mm) Long x 27.43 Inches (697 mm) Wide
{Classic and Elite Grooming Tables, Hydraulic Lift}
Grooming Table Hydraulic Unit Grooming Table
Manual Hydraulic Pump, Foot Pedal Actuated. Maximum Height (Floor To Top of Table) - 41 Inches (1041 mm)
Maximum at 250 lbs (1112 Newton) Load Minimum Height (Floor To Top of Table) - 20 Inches (508 mm)
Maximum Shaft Travel - 6 Inches (152 mm) Max. Dimensions - Standard Table - 80 Inches (2032 mm) High
x 54.5 Inches (1384 mm) Long x 27.43 Inches (697 mm) Wide
Min. Dimensions - Standard Table - 42.25 Inches (1073 mm) High
x 46.5 Inches (1184 mm) Long x 27.43 Inches (697 mm) Wide
{Big Top Grooming Tables, Electric Lift}
Grooming Table Actuator Grooming Table
24 Volt DC Motor Maximum Height (Floor To Top of Table) - 41 Inches (1041 mm)
2.7 AMPS Maximum at 250 lbs (1112 Newton) Load Minimum Height (Floor To Top of Table) - 20 Inches (508 mm)
Maximum Shaft Travel - 6 Inches (152 mm) Time From Minimum to Maximum Height (No Load) - 14 Seconds
120 Volt AC Power Cord For 120 V Model Time From Maximum to Minimum Height (No Load) - 13 Seconds
230 Volt AC Power Cord For 230 V Model Max. Dimensions - Standard Table - 80 Inches (2032 mm) High
x 54.5 Inches (1384 mm) Long x 27.43 Inches (697 mm) Wide
DC Control Module Mounted To Actuator Min. Dimensions - Standard Table - 42.25 Inches (1073 mm) High
x 46.5 Inches (1184 mm) Long x 27.43 Inches (697 mm) Wide
{Big Top Grooming Tables, Hydraulic Lift}
Grooming Table Hydraulic Unit Grooming Table
Manual Hydraulic Pump, Foot Pedal Actuated. Maximum Height (Floor To Top of Table) - 41 Inches (1041 mm)
Maximum at 250 lbs (1112 Newton) Load Minimum Height (Floor To Top of Table) - 20 Inches (508 mm)
Maximum Shaft Travel - 6 Inches (152 mm) Max. Dimensions - Standard Table - 80 Inches (2032 mm) High
x 54.5 Inches (1384 mm) Long x 27.43 Inches (697 mm) Wide
Min. Dimensions - Standard Table - 42.25 Inches (1073 mm) High
x 46.5 Inches (1184 mm) Long x 27.43 Inches (697 mm) Wide

{15}
Section 8: Dimensions
{Elite Grooming Tables, Electric & Hydraulic Lift}*
*Classic Tables do not come with Grooming Arm.

{16} Shor-Line | 800.444.1579 | www.shor-line.com
{Big Top Grooming Tables, Electric & Hydraulic Lift}*
48"
26"
52"
TABLE FULL UP
54 1/2"
TABLE FULL DOWN
D
C
A
B
C
D
8
8
7
6
5
4
3
2
1
E
F
E
F
12/11/2003
38" MAX 14 1/4"
22" MIN
41"
80"
TABLE FULL UP
ARM FULL UP
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
__________
THE FOLLOWING DOCUMENT CONTAINS INFORMATION PROPRIETARY TO SCHROER MANUFACTURING COMPANY.
ANY REPRODUCTION, DISCLOSURE, OR USE OF THE DOCUMENT IS EXPRESSLY PROHIBITED WITHOUT WRITTEN
CONSENT OF SCHROER MANUFACTURING. SCHROER MANUFACTURING MAKES NO WARRANTIES, EITHER EXPRESSED
OR IMPLIED WITH REGARD TO CUSTOMER REQUESTED MODIFICATIONS AND TO THE EXTENT SUCH MODIFICATIONS
ADVERSELY AFFECT THE PRODUCTS, SUCH MODIFICATIONS VOID ANY WARRANTIES OF THE PRODUCTS. CUSTOMER
FURTHER RELEASES AND AGREES TO INDEMNIFY, DEFEND AND HOLD HARMLESS SCHROER MANUFACTURING FOR,
FROM AND AGAINST ANY AND ALL CLAIMS,DAMAGES,LOSSES,LIABILITIES, COSTS OR EXPENSES
(INCLUDING ATTORNEYS' AND EXPERTS FEES) ARISING OUT OF OR RELATED TO SUCH MODIFICATIONS TO THE PRODUCTS.
12/11/2003
INITIAL
20"
58 1/2"
TABLE FULL DOWN
ARM FULL UP
D
C
B
A
A
B
C
D
1
2
3
4
5
6
7
8
8
7
6
5
4
3
2
1
E
F
E
F
__________
THE FOLLOWING DOCUMENT CONTAINS INFORMATION PROPRIETARY TO SCHROER MANUFACTURING COMPANY.
ANY REPRODUCTION, DISCLOSURE, OR USE OF THE DOCUMENT IS EXPRESSLY PROHIBITED WITHOUT WRITTEN
CONSENT OF SCHROER MANUFACTURING. SCHROER MANUFACTURING MAKES NO WARRANTIES, EITHER EXPRESSED
OR IMPLIED WITH REGARD TO CUSTOMER REQUESTED MODIFICATIONS AND TO THE EXTENT SUCH MODIFICATIONS
ADVERSELY AFFECT THE PRODUCTS, SUCH MODIFICATIONS VOID ANY WARRANTIES OF THE PRODUCTS. CUSTOMER
FURTHER RELEASES AND AGREES TO INDEMNIFY, DEFEND AND HOLD HARMLESS SCHROER MANUFACTURING FOR,
FROM AND AGAINST ANY AND ALL CLAIMS,DAMAGES,LOSSES,LIABILITIES, COSTS OR EXPENSES
(INCLUDING ATTORNEYS' AND EXPERTS FEES) ARISING OUT OF OR RELATED TO SUCH MODIFICATIONS TO THE PRODUCTS.
12/11/2003
INITIAL

{17}
Section 9: Stainless Steel Care & Cleaning
{Quality & Life of Your Product}
IMPORTANT: Routine maintenance will ensure quality and life of your long-term investment and protect animals from
transmittable disease and infection
IMPORTANT: To safeguard your investment and rights to the Shor-Line’s Warranty, it is important that you know
factors that degrade stainless steel. Corrosion, pitting, and discoloration can occur if:
• Bleach, deodorizing agents, disinfectants, and sanitizers (chlorides, bromides, iodides and thiocyanates) stand
wet on your product for a prolonged period (over two minutes).
• Bleach, deodorizing agents, disinfectants, and sanitizers are used frequently without being neutralized with clean
water after each application.
• Acidic urine is not removed rapidly and surfaces are not washed thoroughly.
• Animal hair, holding urine and uids, is allowed to collect around legs, hinges, casters, and welded wire
intersections.
• Solutions like liquid bleach and antibacterials are allowed to evaporate and dry on surfaces.
• Particles from steel wool, metal ber brushes, or metal scrapers (which are never recommended for cleaning
stainless) get embedded in your product’s surface, rust, and give the false impression that the stainless steel is
defective.
• Your water source (local or well) is heavy in iron content and water is allowed to dry on your product.
• High levels of pollution (automotive exhaust, aggressive gases, soot, iron oxides, chemicals, etc.) or chloride (from
sea or de-icing salts) exist in the environment and frequent, thorough cleaning (manual or rain-washing) does not
occur.
{Care & Cleaning Best Practices}
IMPORTANT: You play an essential role in safeguarding your investment and rights to Shor-Line’s Warranty. We
strongly recommend:
• Daily or weekly cleaning of stainless steel to prolong its longevity and value and to help you maintain its nish.
• Using the mildest cleaning procedure that will do the job effectively.
- Ordinary waste deposits and uids can usually be removed with soap and water. Rinse thoroughly with clear
water and dry completely with a soft cloth to discourage water spotting.
- Minor scale build up and some hard water spotting can be removed by washing with vinegar followed by a
clearwater rinse and thorough drying.
- If rubbing, brushing, or scraping is required, use only stainless steel wool, brushes with plastic, nylon or
stainless steel bers, and scrubbers made of plastic or nylon. Ordinary steel wool or steel brushes should
never be used.
- Stubborn deposits or tightly adhering debris may require a commercial cleaning product. Scouring powders
will scratch stainless and should not be used. Always review label statements on cleaning products regarding
use on metals.
- Cleaning is not completed until fresh water has been used to thoroughly rinse all residue of salt, bleach,
deodorizing agents, disinfectants, and sanitizers.
• Rubbing, drying, and polishing should always be in the direction of the product’s grain so scratches will blend into
the surface. Efforts opposite the grain may produce a scratched surface appearance.
• Rubbing a soft cloth moistened with olive oil, undiluted white or cider vinegar, or club soda may brighten stainless
steel and help remove surface streaks and heat stains.
• Never use paint, lacquer, or varnish as a substitute or shortcut for properly caring and cleaning stainless steel.
• Never intentionally stamp or etch stainless surfaces.
{Protecting Against Disease & Infection}
IMPORTANT: Shor-Line shares your commitment to health and safety. This information is intended help protect your
animals, as well as, safeguard your investment.
• Bleaches can be harmful to animals. Bleaches can react with acids and release chlorine gas that is highly toxic.
• Because of its strong corrosive and toxic properties, bleach is diluted with water. The solution’s potency (shelf-life)
quickly degrades as the active chlorine dissipates with water. Animal care professionals, therefore, cannot know
with certainty how effective the bleach solution is over time without implementing a formal monitoring system.
• If chemical deodorizers, disinfectants, or sanitizers are used, protect your animals from respiratory problems and

{18} Shor-Line | 800.444.1579 | www.shor-line.com
infections by using clean water to wash residue from all surfaces and dry thoroughly.
• Clorox®Company warns: “We cannot recommend Clorox®to clean metal surfaces, including stainless steel.
Prolonged or repeated exposure of metal to strong solutions of our product eventually can cause discoloration or
corrosion. To reduce the possibility of metal discoloration, we suggest that exposure time to Clorox®be less than
ve minutes and that surfaces be rinsed well after application of the solution.”
Section 10: Services, Terms & Conditions, & Warranty
{Terms & Conditions}
ORDER & ACCEPTANCE By submitting an order for the products described herein, Buyer shall have agreed to
purchase the products subject to all Seller’s terms including these TERMS and CONDITIONS. Buyer’s order is
subject to and effective only upon acceptance and approval at Seller’s ofces in Kansas City, Kansas as evidenced
by Seller’s issuance of an Order Acknowledgement or Invoice. Processing of an order shall not commence until
receipt of any applicable deposit and all required paperwork and customer sign-offs. The resulting contract shall be
deemed made in Kansas and shall in all respects be governed and interpreted according to the laws of the State of
Kansas. Buyer also consents to the jurisdiction of Kansas courts over any dispute involving this order.
ENTIRE AGREEMENT This order as accepted and approved by Seller constitutes the entire nal agreement between
the parties. Except as otherwise provided in writing by Seller, the terms set forth herein constitute the sole TERMS
AND CONDITIONS for Buyer’s order. Seller’s acceptance of Buyer’s order is expressly conditioned on Buyer’s
assent to these TERMS AND CONDITIONS which may not be supplemented, modied, superseded or otherwise
altered except as authorized in writing by Seller. Any different, conicting or additional terms in Buyer’s purchase
order or any other document of Buyer are rejected and Seller’s TERMS AND CONDITIONS shall prevail.
TERMS OF PAYMENT Unless otherwise expressly specied by Seller in writing, payment shall be due 30 days from
the date of invoice, payable in U.S. Funds. Seller reserves the right to negotiate terms or orders of any unique or
special nature and may require full or partial payment in advance in its sole discretion. Acceptance of all orders and
the payment terms for such orders are subject to approval by Seller’s Credit Department. Seller may decline to make
any shipment or perform any work except upon terms satisfactory to said Department. A charge of 1½% per month
(or the highest monthly interest rate that may be imposed under applicable law) will be imposed on overdue accounts.
Buyer will be liable for all expenses (including reasonable attorneys’ fees) incurred in collecting any overdue
accounts.
PRICES & QUOTES Prices on products specied herein are F.O.B. Seller’s factory unless otherwise specied in
writing and are exclusive of any city, state, local or federal tax. Prices are subject to adjustment without notice and
Seller reserves the right to correct errors in prices or specications. Any quotation (whether written or oral) is not an
offer to contract or acceptance of an order. Similarly, neither a price list nor a catalog constitutes an offer to sell or
contract, but are provided solely for customers’ convenience.
TAXES Any sales, use, property, or other taxes or duties which Seller may be required to pay or collect (under any
existing or future law) in connection with the sale, purchase, delivery, storage, processing, consumption or use of the
products purchased herewith shall be for the account of Buyer and Buyer shall promptly reimburse Seller therefore.
DELIVERIES Delivery dates are estimates only and time shall not be of the essence unless specically provided by
Seller in writing. Seller will not have any liability for loss or damage resulting from a delay in a scheduled delivery or
for non-delivery resulting from labor trouble, part or material shortages, accident, re, war, strike, natural disaster,
carrier delays or any contingency whatsoever (whether of the same class of those enumerated or otherwise) beyond
its reasonable control. Buyer assumes all freight, handling and installation costs and the risk of loss or delay in transit.
Seller will assist Buyer with transit arrangements, but Seller shall be free of any liability in connection therewith. Title
to all materials and products sold by Seller shall pass to Buyer upon delivery to the carrier and Seller’s responsibility
ceases at that time. Risk of loss, injury, or destruction of the products shall be borne by the Buyer and any such loss,
injury or destruction shall not release Buyer from payment of the purchase price.
INSPECTION Buyer must inspect all materials for shortages, damages, conformity with order and defects before
signing any documentation requested by the carrier. Buyer must immediately complete such inspection and shall
not accept delivery of goods that are damaged or not in accordance with the bill of lading or packing slip without
proper notication to the carrier and Seller. If goods are damaged, defective, shorted or appear not to conform to
the order, Buyer shall discontinue their use and immediately notify the carrier and Seller of such condition and afford
a reasonable opportunity to inspect the same. Buyer shall make, or provide Seller in writing with all information

{19}
necessary to make, a claim against such carrier for any shortage, damage, or discrepancy of the shipment within
fteen (15) days after receipt of the goods. Claims or written information thereon not so presented within fteen
(15) days after receipt of the goods will not be allowed. No products will be taken back and credited or replaced
unless arrangements for their return have been made in compliance with Seller’s Return Policy stated below. SEE
SELLER’S CATALOG FOR INFORMATION ON HOW TO FILE A FREIGHT CLAIM.
PRODUCT SATISFACTION In the event Buyer is not fully satised with the quality or workmanship of a product
purchased hereunder, Seller in its sole discretion may arrange either to credit Seller’s account (excluding shipping
and handling costs) or replace the product. However, Buyer must notify Seller in writing of its dissatisfaction within
fteen (15) days of receipt of the product from Seller and immediately discontinue its use. Buyer also must return the
rejected product to Seller freight paid within thirty (30) days of its receipt in compliance with Seller’s Return Policy
stated below. Seller’s obligation is limited to providing the applicable credit or product replacement, which will be
processed only after receipt of the retuned product. In addition, this Product Satisfaction policy does not apply to
specially designed, discontinued, used, factory second or repaired products.
LIMITED WARRANTY Seller warrants to the initial purchaser only of products manufactured by it that such products
are free from defects in materials or labor for varying periods depending on the particular product and subject to
the limitations and conditions set forth herein. Seller’s stainless steel products are warranted to be free from such
defects for their normal useful life. Seller’s mechanical and electrical products, parts, devices and components
(including such parts, devices and components of stainless steel products), and other-non-stainless steel products
are warranted to be free from such defects for only one year. Seller disclaims any express or implied warranty for
products not manufactured by Seller and the only warranty available therefore to Buyer is that offered by the products’
manufacturers.
The warranty period shall run from the date of delivery to Buyer. If within the applicable warranty period a product
proves to be defective as described herein, Seller will repair or replace the product, at Seller’s sole discretion,
conditional upon Buyer’s written notice of the defect within fteen (15) days after its discovery. Upon receipt of
Buyer’s notice including substantiation of Buyer’s status as the initial purchaser and details of the defect, Seller
shall advise Buyer whether it plans to repair or replace the product. Seller’s obligation is solely limited to repair or
replacement of a defective product and in no event shall Seller be liable for transportation from or to Seller’s ofces
or any other expense which may arise in connection with this Limited Warranty or the aforementioned Product
Satisfaction policy.
SELLER MAKES NO OTHER WARRANTY OR GUARANTEE OF ANY KIND WHATSOVER, WHETHER EXPRESS
OR IMPLIED, STATUTORY OR OTHERWISE INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF
FITNESS, AND/OR MERCHANTABILITY. THE ABOVE LIMITED WARRANTY CONSTITUTES SELLER’S ONLY
WARRANTY AND NO PERSON OR ENTITY IS AUTHORIZED, ON BEHALF OF THE SELLER, TO MODIFY OR
EXPAND UPON THE PROVISION EXPRESSED IN THIS PARAGRAPH NUMBER NINE. THE SELLER’S LIABILITY
UNDER THIS LIMITED WARRANTY SHALL BE LIMITED AS PROVIDED FOR ABOVE AND THE FOREGOING
SHALL BE THE BUYER’S SOLE REMEDY AND RECOURSE UNDER THIS CONTRACT. There are no warranties
which extend beyond the description on the face hereof and goods are sold as is. Seller’s Limited Warranty is only
available to the initial purchaser of its products and is effective only upon compliance with the terms set forth herein.
Buyer agrees that the products subject to this Limited Warranty will be properly maintained in the ordinary course
of business. Buyer agrees to comply with all instructions and specications furnished by Seller relating to the
installation, care, use and application of products purchased. Buyer agrees that it will not modify, misapply, or misuse
such products in any manner which would deviate from Seller’s instructions. Any repairs, alterations or service
provided by parties other than Seller, or its authorized representative, may void this Limited Warranty. This Limited
Warranty shall not apply to normal wear and tear, improper or insufcient maintenance, routine maintenance, or
damage caused by accident, negligence, improper operation or the use of corrosive materials (including without
limitation bleach or sodium hypochlorite used on stainless steel surfaces). THE SELLER’S LIMITED WARRANTY
MADE IN CONNECTION WITH THIS SALE SHALL NOT BE EFFECTIVE AND SHALL BE VOID UNLESS SUCH
GOODS ARE APPLIED AND USED IN ACCORDANCE WITH SELLER’S INSTRUCTIONS.
LIMITATION OF LIABILITY UNDER NO CIRCUMSTANCES SHALL SELLER BE LIABLE TO BUYER OR
ANY OTHER PERSON FOR ANY SPECIAL, LIQUIDATED, INCIDENTAL OR CONSEQUENTIAL DAMAGES,
INCLUDING, WITHOUT LIMITATION, DAMAGES BASED UPON LOST GOODWILL, LOST SALES OR PROFITS,
WORK STOPPAGE, DELAY, PRODUCT FAILURE, IMPAIRMENT OF GOODS OR OTHERWISE AND WHETHER
ARISING OUT OF BREACH OF WARRANTY, BREACH OF CONTRACT, NEGLIGENCE OR OTHERWISE, and
in any case, Seller’s liability for any and all losses and damages sustained by Buyer and others, rising out of or by
reason of this contract, shall not exceed the original purchase price of the products upon which liability is founded.

{20} Shor-Line | 800.444.1579 | www.shor-line.com
IN NO EVENT SHALL ANY ACTION BE COMMENCED AGAINST THE SELLER MORE THAN ONE YEAR AFTER
THE CAUSE OF ACTION WITH RESPECT TO WHICH THE CLAIM IS MADE HAS ACCRUED. SELLER SHALL
NOT BE RESPONSIBLE FOR EXPENSES FOR REPAIRS NOT MADE BY SELLER WITHOUT THE PRIOR
WRITTEN CONSENT OF SELLER.
RETURN POLICY All products being returned for any reason or delivered for repair service (whether or not pursuant
to our Limited Warranty) must receive advance authorization from Seller. Buyer must contact Seller’s Technical
Service Department at 1.800.444.1579 to receive a Return Authorization Number. All products returned, except for
warranty service or pursuant to the Product Satisfaction policy, are subject to a minimum 15% restocking charge.
Buyer will be responsible for all freight charges on returns.
INDEMNITY Buyer agrees to protect, defend, indemnify and hold harmless the Seller from and against any and all
direct loss suffered and any liability to third parties due to bodily injury (including death) to any person or animal, or
damage to any property as a result of Buyer’s misuse, misapplication or failure to inspect or maintain the Seller’s
products, or such loss or liability caused by the act or omission of the Buyer in the performance of any services
using said products. Buyer also agrees to indemnify and hold harmless the Seller for any taxes paid as discussed
in paragraph ve above. This indemnity provision expressly includes attorney’s fees and settlements of claims in a
reasonable manner under the circumstances.
UNLAWFUL USE Buyer agrees that no goods covered by this contract shall be used in any manner violative of any
laws of the United States, whether state or federal, or local ordinance, and no such goods shall be distributed to any
foreign country in any manner prohibited by United States law.
REGULATIONS AND CODES Seller makes no representation or promise, express or implied, that goods delivered
hereunder will conform to any state or local laws, regulations, codes, ordinances, or standards, except as particularly
and expressly specied and agreed upon for compliance in writing as a part of the contract between Buyer and Seller.
SELLER’S REMEDIES Seller hereby expressly reserves all remedies provided for by the Uniform Commercial Code
and such remedies are expressly cumulative in nature and include all of the available remedies for breach and Seller
need not make any election of remedy.
MISCELLANEOUS Buyer may not assign its rights or duties relative to this order without Seller’s written consent,
but Seller may assign its interest in such order to any afliate or successor in interest. The waiver of any breach of
these TERMS AND CONDITIONS shall not constitute a waiver as to any further breach. Any of these TERMS AND
CONDITIONS found to be invalid, illegal or unenforceable, shall be considered inoperative and the remaining TERMS
AND CONDITIONS shall be valid and enforceable as though such provisions are not included herein. Contact our
Credit Department toll-free for questions: 800.444.1579
