Show Tec Bar Cameleon Bar 16 Q4 User manual

Cameleon Bar 16 Q4 V3
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42670
MANUAL
ENGLISH

1
Ordercode: 42670
Cameleon Bar 16 Q4
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................8
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One Cameleon Bar (Auto program) .....................................................................................................................9
One Cameleon Bar (Built-in programs, Manual mode).....................................................................................9
Multiple Cameleon Bars (Master/Slave control)..................................................................................................9
Multiple Cameleon Bars (DMX Control) ..............................................................................................................10
Fixture Linking...............................................................................................................................................................11
Data Cabling...............................................................................................................................................................11
Control Panel ...............................................................................................................................................................12
Control Mode ..............................................................................................................................................................12
DMX Addressing ..........................................................................................................................................................12
Menu Overview...........................................................................................................................................................13
Main Menu Options....................................................................................................................................................14
1. Auto program.......................................................................................................................................................14
2. Built-in programs ..................................................................................................................................................14
3. DMX Address/ DMX Configuration...................................................................................................................15
4. Master/slave .........................................................................................................................................................15
5. Manual Color mode ...........................................................................................................................................15
6. Settings...................................................................................................................................................................16
6.1. Curves Select ....................................................................................................................................................16
6.2. Dimmer Speed ..................................................................................................................................................16
6.3. DMX Fail..............................................................................................................................................................17
6.4. DMX Sync ...........................................................................................................................................................17
6.5. Lock.....................................................................................................................................................................17
6.6. Factory................................................................................................................................................................17
7. Information............................................................................................................................................................17
DMX Channels .............................................................................................................................................................18
4 Channels ................................................................................................................................................................18
5 Channels ................................................................................................................................................................18
6 Channels ................................................................................................................................................................19
9 Channels ................................................................................................................................................................20
Maintenance....................................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25

2
Ordercode: 42670
Cameleon Bar 16 Q4
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Cameleon Bar 16 Q4
1 x Schuko to 3-pin (IP-65) power cable (1,5 m)
4 x Endcaps
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 42670
Cameleon Bar 16 Q4
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmer pack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 42670
Cameleon Bar 16 Q4
•The user is responsible for correct positioning and operating of the Cameleon Bar 16 Q4. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•To eliminate wear and improve lifespan, during periods of non-use, completely disconnect from
power via breaker or by unplugging.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Cameleon Bar is lowered from the ceiling or high joists, professional trussing systems have to be
used.
•Use a clamp to mount the Cameleon Bar, with the mounting bracket, to the trussing system.
•The Cameleon Bar must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Cameleon Bar, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 42670
Cameleon Bar 16 Q4
The Cameleon Bar 16 Q4 can be placed on a flat stage floor or mounted to a wall.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE
GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 42670
Cameleon Bar 16 Q4
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause for
the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 42670
Cameleon Bar 16 Q4
Description of the device
Features
The Cameleon Bar 16 Q4 is a LED bar with high output and great effects.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 80W @FO
DMX modes: 4, 5, 6 or 9 channels
Light source: 16 x 5W 4-in-1 RGBW ProLight Opto Hornet Series
Lux @2m: Red: 640 Lumen
Green: 898 Lumen
Blue: 282 Lumen
White: 1287 Lumen
Full Output: 2966 Lumen
Onboard: OLED touch display for easy setup
XLR 3-pin to mini 3-pin cable (42708) to connect the Cameleon to DMX, not included!
Drive current: 350mA
Refresh rate: > 6000Hz
Color range: 16,7 million additive colors
Beam angle: 39°
Max. distance: 20 m
Protection rate: IP-65
Lens plate: Tempered glass
Control: DMX, Auto Program, Built-in programs, Master/Slave, Manual
Dimmer: 0-100%
Strobe: 0-20Hz
Housing: Die-cast aluminum
Cooling: Convection (no fans)
Connections: Dedicated power cable IP-65 IN/OUT & data IP-65 IN/OUT
Dimensions: 1002 x 72 x 142 mm (LxWxH)
Weight: 6 kg
Optional accessories
42698 Power end cap set male/female for Cameleon series
42699 Data end cap set male/female for Cameleon series
42705 Power extension cable for Cameleon series (3 m)
42706 Power connection cable for Cameleon series (3 m)
42707 DMX extension cable for Cameleon series (3 m)
427076 DMX extension cable for Cameleon series (6 m)
42708 DMX input cable for Cameleon series (3 m)
Please make sure to obtain the XLR 3-pin to mini 3-pin cable (42708) to connect the device to
DMX.

8
Ordercode: 42670
Cameleon Bar 16 Q4
Frontside
Fig. 01
01) 16 x 5W 4-in-1 RGBW ProLight Opto Hornet Series
02) Mounting bracket
Backside
Fig. 02
03) Special mini 3-pin power cable IN IP-65
04) Special mini 3-pin DMX cable IN IP-65
05) OLED display + control buttons
06) Special mini 3-pin DMX cable OUT IP-65
07) Special mini 3-pin power cable OUT IP-65
08) Ground/earth connection
Installation
Remove all packing materials from the Cameleon Bar 16 Q4. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

9
Ordercode: 42670
Cameleon Bar 16 Q4
Control Modes
There are 5 modes:
•Auto program
•Built-in programs
•Manual Color mode
•Master/slave
•DMX-512 (4CH, 5CH, 6CH, 9CH)
One Cameleon Bar (Auto program)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Cameleon Bar is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 14 for more information about the Auto program.
One Cameleon Bar (Built-in programs, Manual mode)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Cameleon Bar is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 14-15 for more information about the Built-in programs and the Manual mode.
Multiple Cameleon Bars (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Cameleon Bars and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
04) Link the units as shown in Fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using the 42707/427076 –DMX Extension cable. Link the second and third units using the
42707/427076 –DMX Extension cable.
You can use the same functions on the master device as described on pages 14-15 (Auto program,
Built-in programs, Manual Color mode). This means that you can set your desired operation mode
on the master device and all slave devices will react the same as the master device.
Multiple Cameleon Bars (Master/Slave control)
Fig. 03

10
Ordercode: 42670
Cameleon Bar 16 Q4
Multiple Cameleon Bars (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Cameleon Bars and other devices.
04) Link the units as shown in fig. 04. Connect a light controller to the first unit's DMX "in" socket, using the
42708 –DMX input cable. Connect the first unit’s "out" socket with the second unit's "in" socket, using
the 42707/427076 –DMX Extension cable, Link the second and third units using the 42707/427076 –
DMX Extension cable.
05) Supply electric power: Plug electric mains power cords into each unit's special IP65 power IN socket,
then plug the other end of the mains power cord into proper electric power supply sockets, starting
with the first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Cameleon Bars DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power
Note: You cannot plug a standard DMX cable directly into the connector. Be sure to use
the special cable for DMX connection (42708) and extension cables (42707/427076).

11
Ordercode: 42670
Cameleon Bar 16 Q4
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX
optically isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a Power link @120V: 11 units
Maximum recommended number of fixtures on a Power link @230V: 23 units
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
Note: Use the special DMX cables for DMX connection.
42707 DMX extension cable for Cameleon series (3 m)
427076 DMX extension cable for Cameleon series (6 m)
42708 DMX input cable for Cameleon series (3 m)

12
Ordercode: 42670
Cameleon Bar 16 Q4
Control Panel
A) OLED display
B) MODE button
C) UP button
D) SET button
E) DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Cameleon will respond to the controller.
Please note, when you use the controller, the unit has 9channels.
When using multiple Cameleons, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Cameleon should be 1(001); the DMX address of the second
Cameleon should be 1+9=10 (010); the DMX address of the third Cameleon should be 10+9=19 (019),
etc. Please, be sure that you do not have any overlapping channels in order to control each Cameleon
correctly. If two or more Cameleons are addressed similarly, they will work similarly.
Controlling:
After having addressed all Cameleon fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Cameleon will automatically detect whether DMX 512 data is received or
not. If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Cameleon.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MODE, SET, UP or DOWN button.
Once you have pressed the button, the display will light up.

13
Ordercode: 42670
Cameleon Bar 16 Q4
Menu Overview

14
Ordercode: 42670
Cameleon Bar 16 Q4
Main Menu Options
01) Upon start-up, the display will show:
02) Press the SET or MODE button to open main menu. The display will show:
03) Press the UP/DOWN buttons to toggle through the menus.
04) Press the SET button to open the desired menu.
05) Press the MODE button to return to the previous screen.
1. Auto program
With this menu you can activate the built-in auto program.
01) While in main menu, press the UP/DOWN buttons to choose Auto.
02) The device will now run the built-in auto show.
2. Built-in programs
With this menu you can set one of the built-in programs, preset colors and strobe frequency.
01) While in main menu, press the UP/DOWN buttons to choose Program.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose Mode, Color or Strobe.
04) Once you have chosen Mode, press the SET button to open the submenu. Press the UP/DOWN
buttons to choose 16 different built-in programs.
05) Once you have chosen Color, press the SET button to open the submenu. Press the UP/DOWN
buttons to choose 33 preset colors.
06) Once you have chosen Strobe, press the SET button to open the submenu. Press the UP/DOWN
buttons to increase/decrease the strobe frequency. The adjustment range is between 0-99, from
OFF to high strobe frequency.

15
Ordercode: 42670
Cameleon Bar 16 Q4
3. DMX Address/ DMX Configuration
With this menu you can set the device’s DMX starting address and choose a DMX channel mode.
01) While in main menu, press the UP/DOWN buttons to choose DMX.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose between Address or Channels.
04) Once you have chosen Address, press the SET button to open the submenu. Press the UP/DOWN
buttons to set the desired DMX address. The adjustment range is between 001-512.
05) Once you have chosen Channels, press the SET button to open the submenu. Press the UP/DOWN
buttons to choose one of the following DMX channel modes: 4, 5, 6 or 9 channels.
4. Master/slave
With this menu you can set the device as a slave.
01) While in main menu, press the UP/DOWN buttons to choose Slave.
02) The device is now operating in Slave mode. It means that it will react the same as the master device.
5. Manual Color mode
With this menu you can set the static colors.
01) While in main menu, press the UP/DOWN buttons to choose Manual.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle through the static colors: Red, Green, Blue and White.
04) Once you have chosen the desired color, press the SET button to open the submenu. Press the
UP/DOWN buttons to set the color brightness. The adjustment range is between 0-255, from dark to
brightest.
05) You can combine Red, Green, Blue and White to create an infinite range of colors (0-255).

16
Ordercode: 42670
Cameleon Bar 16 Q4
6. Settings
With this menu you can set the device’s settings.
01) While in main menu, press the UP/DOWN buttons to choose Settings.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following menus: Curves Select, Dimmer Speed,
DMX Fail, DMX Sync, Lock, Factory.
6.1. Curves Select
With this menu you can adjust the dimming of the device by choosing a dimming curve.
01) While in Settings menu, press the UP/DOWN buttons to choose Curves Select.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired dimming curve out of the 4 available options:
6.2. Dimmer Speed
With this menu, you can adjust the dimming speed of the device.
01) While in Settings menu, press the UP/DOWN buttons to choose Dimmer Speed.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired dimming speed.
04) You can choose between Fast and Smooth.

17
Ordercode: 42670
Cameleon Bar 16 Q4
6.3. DMX Fail
With this menu, you can adjust the behaviour of the device in case of a DMX signal error.
01) While in Settings menu, press the UP/DOWN buttons to choose Dmx Fail.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired option. You can choose between Off and Hold.
04) Press the SET button to confirm your choice.
05) If you have chosen Off, the device will blackout its output, when a DMX signal error occurs.
06) If you have chosen Hold, the device will fall back on the last properly working DMX signal, which
ensures undisrupted performance.
6.4. DMX Sync
With this menu, you can set the DMX synchronisation of the device.
01) While in Settings menu, press the UP/DOWN buttons to choose Dmx Sync.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired option. You can choose between On and Off.
04) Press the SET button to confirm your choice.
05) The Sync option is a tool which helps to keep multiple fixtures synchronized, when using them in
master slave mode.
06) When you choose On, the synchronization function will be activated.
6.5. Lock
With this menu you can select whether the safety lock is active.
01) While in Settings menu, press the UP/DOWN buttons to choose Lock.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired option. You can choose between Yes and No.
04) Press the SET button to confirm your choice.
05) If you have chosen Yes, after 30 seconds the device will enter Lock mode. You will need to unlock
the device, to access main menu. Press and hold down the MODE and SET buttons for 3 seconds, to
unlock main menu.
06) If you have chosen No, main menu will remain unlocked.
6.6. Factory
With this menu, you can reset to the default settings.
01) While in Settings menu, press the UP/DOWN buttons to choose Factory.
02) Press the SET button to open the menu.
03) Press the UP/DOWN buttons to choose the desired option. You can choose between Yes and No.
04) Press the SET button to confirm your choice.
05) If you have chosen Yes, the default settings will be restored.
06) The device will return to the built-in Auto program.
7. Information
With this menu you can view the currently installed software version, temperature and the device code.
01) While in main menu, press the UP/DOWN buttons to choose Information.
02) Press the SET button to open the menu.
03) You can now view the currently installed software version, temperature and the device code.

18
Ordercode: 42670
Cameleon Bar 16 Q4
DMX Channels
4 Channels
Channel 1 –Red Dimmer intensity
0-255
Gradual adjustment Red from 0-100%
Channel 2 –Green Dimmer intensity
0-255
Gradual adjustment Green from 0-100%
Channel 3 –Blue Dimmer intensity
0-255
Gradual adjustment Blue from 0-100%
Channel 4 –White Dimmer intensity
0-255
Gradual adjustment White from 0-100%
5 Channels
Channel 1 –Master Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Linear strobe Dimmer and CH3 or CH4 must be open
0-10
Closed
11-255
Strobe flash, from low to high frequency (0-20 Hz)
Channel 3 –Color presets Dimmer must be open
0-7
Not functional
8-13
Color 1 (R255, G000, B000, W000)
14-20
Color 2 (R255, G000, B000, W100)
21-27
Color 3 (R255, G000, B000, W200)
28-34
Color 4 (R255, G050, B000, W000)
35-41
Color 5 (R255, G150, B000, W000)
42-48
Color 6 (R255, G255, B000, W000)
49-55
Color 7 (R255, G255, B000, W075)
56-62
Color 8 (R000, G255, B000, W255)
63-69
Color 9 (R000, G255, B000, W150)
70-76
Color 10 (R000, G255, B000, W050)
77-83
Color 11 (R000, G255, B000, W000)
84-90
Color 12 (R000, G255, B050, W000)
91-97
Color 13 (R000, G255, B150, W000)
98-104
Color 14 (R000, G255, B255, W000)
105-111
Color 15 (R000, G255, B255, W075)
112-118
Color 16 (R000, G255, B255, W150)
119-125
Color 17 (R000, G100, B255, W255)
126-132
Color 18 (R000, G000, B255, W100)
133-139
Color 19 (R000, G000, B255, W050)
140-146
Color 20 (R000, G000, B255, W000)
147-153
Color 21 (R075, G000, B255, W000)
154-160
Color 22 (R160, G000, B255, W000)
161-167
Color 23 (R255, G000, B255, W000)
168-174
Color 24 (R255, G000, B175, W000)
175-181
Color 25 (R255, G000, B100, W000)
182-188
Color 26 (R255, G000, B100, W050)
189-195
Color 27 (R255, G000, B025, W050)
196-202
Color 28 (R255, G000, B025, W025)
203-209
Color 29 (R255, G000, B025, W000)

19
Ordercode: 42670
Cameleon Bar 16 Q4
210-216
Color 30 (R000, G000, B000, W255)
217-223
Color 31 (R075, G075, B000, W255)
224-230
Color 32 (R000, G000, B100, W255)
231-255
Color 33 (R255, G255, B255, W255)
Channel 4 –Built-in programs Dimmer must be open
0-15
Not functional
16-31
Color switch 1
32-47
Color switch 2
48-63
Color switch 3
64-79
Color switch 4
80-95
Color switch 5
96-111
Color switch 6
112-127
Color switch 7
128-143
Color switch 8
144-159
Color flow 1
160-175
Color flow 2
176-191
Color flow 3
192-207
Color flow 4
208-223
Color flow 5
224-239
Color flow 6
240-255
Color flow 7
Channel 5 –Program speed Dimmer and CH4 must be open
0-255
Speed adjustment, from slow to fast
6 Channels
Channel 1 –Master Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Linear strobe Dimmer and CH3-6 must be open
0-10
Closed
11-255
Strobe flash, from low to high frequency (0-20 Hz)
Channel 3 –Red Dimmer intensity Dimmer must be open
0-255
Gradual adjustment Red from 0-100%
Channel 4 –Green Dimmer intensity Dimmer must be open
0-255
Gradual adjustment Green from 0-100%
Channel 5 –Blue Dimmer intensity Dimmer must be open
0-255
Gradual adjustment Blue from 0-100%
Channel 6 –White Dimmer intensity Dimmer must be open
0-255
Gradual adjustment White from 0-100%
