Show Tec LED Par 64 COB RGBW 200W User manual

LED Par 64 COB RGBW 200W V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 43305
MANUAL
ENGLISH

1
Ordercode: 43305
LED Par 64 COB RGBW 200W
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Control Modes...............................................................................................................................................................9
One LED Par (Built-in programs and Manual Mode) ..........................................................................................9
Multiple LED Pars (DMX Control) .............................................................................................................................9
Fixture Linking...............................................................................................................................................................10
Data Cabling...............................................................................................................................................................10
Control Panel ...............................................................................................................................................................11
Control Mode ..............................................................................................................................................................11
DMX Addressing ..........................................................................................................................................................11
Menu Overview...........................................................................................................................................................12
Main Menu Options....................................................................................................................................................13
1. Built-in Programs...................................................................................................................................................13
2. Program Speed....................................................................................................................................................13
3. Dimmer Red..........................................................................................................................................................13
4. Dimmer Green......................................................................................................................................................14
5. Dimmer Blue..........................................................................................................................................................14
6. Dimmer White.......................................................................................................................................................14
7. Fixture Hours ..........................................................................................................................................................14
8. Lock Key ................................................................................................................................................................14
9. DMX 4-channel mode ........................................................................................................................................14
10. DMX 8-channel mode ......................................................................................................................................14
11. DMX 15-channel mode ....................................................................................................................................14
12. Color Mode (LEE + Kelvin)................................................................................................................................15
DMX Channels .............................................................................................................................................................15
4 channels .................................................................................................................................................................15
8 channels .................................................................................................................................................................16
15 channels...............................................................................................................................................................16
Maintenance....................................................................................................................................................................18
Replacing the Fuse.....................................................................................................................................................18
Troubleshooting ...............................................................................................................................................................18
No Light.........................................................................................................................................................................18
No Response to DMX..................................................................................................................................................19
Product Specifications....................................................................................................................................................20
Dimensions........................................................................................................................................................................21
Notes ..................................................................................................................................................................................22

2
Ordercode: 43305
LED Par 64 COB RGBW 200W
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec LED Par 64 COB RGBW
Pro power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 43305
LED Par 64 COB RGBW 200W
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Always hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the LED Par 64 COB RGBW. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.

4
Ordercode: 43305
LED Par 64 COB RGBW 200W
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 43305
LED Par 64 COB RGBW 200W
The LED Par 64 COB RGBW can be placed on a flat stage floor or mounted to any kind of truss with a
clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 43305
LED Par 64 COB RGBW 200W
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 43305
LED Par 64 COB RGBW 200W
Description of the device
Features
The LED Par 64 COB RGBW is a compact light effect with high output and great effects.
Light source: 1 x 200W RGBW COB LED
Preprogrammed LEE color presets
Compact size
Wash fixture with latest technology LED source
High-power light output with rich hues and smooth color mixing for stage and wall washing
Double bracket for easy and versatile installation
Due to the special design of the mirror it is possible to project a light beam up to 66 degree's without
getting different color shades or high spots on the projected surface
3 menu buttons + LCD Display for easy setup
Input voltage: 100-240V, 60/50Hz
Refresh rate: 400Hz
Power consumption: 210W max @FO
DMX channels: 4, 8 or 15 channels
Lux @2m: 3774 Lux, R: 552, G: 1371, B: 215, W: 1971
Max distance: 20m
Control modes: Built-in programs, DMX, Manual color control
Control protocol: DMX-512
Dimmer: 0-100%
Strobe: 0-20Hz
Beam Angle: 66°
Protection rate: IP-20
Cooling: Forced Cooling (Fan)
Connections: Pro Power connector IN/OUT & 3-pin XLR IN & OUT
Fuse: T3,15AL/250V
Dimensions: 280 x 268 x 382 mm (LxWxH)
Weight: 3,52 kg
Frontside
Fig. 01
01) Mounting bracket with inclination screw
02) Adjustment screw
03) 1 x 200W RGBW COB LED
04) Color frame retaining clip

8
Ordercode: 43305
LED Par 64 COB RGBW 200W
Backside
Fig. 02
05) LCD Display + 3 Menu buttons
06) Fuse T3,15AL/250V
07) Grey Pro Power connector OUT
08) 3-pin DMX signal connector OUT
09) 3-pin DMX signal connector IN
10) Blue Pro Power connector IN
11) Ground/Earth connection
Installation
Remove all packing materials from the LED Par 64 COB RGBW. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 43305
LED Par 64 COB RGBW 200W
Control Modes
There are 3 modes:
•Built-in programs
•Manual Mode
•DMX-512 (4CH, 8CH or 15CH)
One LED Par (Built-in programs and Manual Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the LED Par is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 13+14 for more information about the Built-in programs and Manual Mode.
Multiple LED Pars (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the LED Pars and other devices.
04) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Pro Power socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple LED Pars DMX Set Up
Fig. 03
Note : Link all cables before connecting electric power

10
Ordercode: 43305
LED Par 64 COB RGBW 200W
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller. The
combined number of channels required by all the fixtures on a serial data link determines the number of
fixtures the data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of LED Pars on a power link: 8 fixtures @110V
Maximum recommended number of LED Pars on a power link: 16 fixtures @240V
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

11
Ordercode: 43305
LED Par 64 COB RGBW 200W
The LED Par 64 COB RGBW can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LED display
B) MODE button
C) UP button
D) DOWN button
Fig. 04
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the LED Par will respond to the controller.
Please note, when you use the controller, the unit has 15 channels.
When using multiple LED Pars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first LED Par should be 1(001); the DMX address of the second LED Par
should be 1+15=16 (016); the DMX address of the third LED Par should be 16+15=31 (031), etc. Please, be
sure that you do not have any overlapping channels in order to control each LED Par correctly.
If two or more LED Pars are addressed similarly, they will work similarly.
Controlling:
After having addressed all LED Par fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the LED Par will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the LED Par 64 COB RGBW.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

12
Ordercode: 43305
LED Par 64 COB RGBW 200W
Menu Overview
The LED Par 64 COB RGBW will only show its version number at start-up !

13
Ordercode: 43305
LED Par 64 COB RGBW 200W
Main Menu Options
DMX-512 Mode
Channel Mode
Program Speed
Built-in programs
Sound-controlled Mode
Static Color Mode
Strobe
Red
Green
Blue
White
Color Mode (LEE + Kelvin)
The LED Par 64 will automatically detect the presence of a DMX signal.
In order to receive a DMX signal, the controller must be attached to a DMX controller by a 3-pin DMX
cable and the DMX controller must be turned on.
The LED Par 64 system can operate as a 4, 8 or 15-channel DMX fixture.
1. Built-in Programs
With this menu you can set your desired built-in program mode.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 6 different programs.
2. Program Speed
With this menu you can set your desired speed of the built-in programs.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 16 different speed settings.
1 is slowest, 16 is fastest and sound-controlled.
3. Dimmer Red
With this menu you can set your desired dim value.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 255 different dimmer settings.

14
Ordercode: 43305
LED Par 64 COB RGBW 200W
4. Dimmer Green
With this menu you can set your desired dim value.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 255 different dimmer settings.
5. Dimmer Blue
With this menu you can set your desired dim value.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 255 different dimmer settings.
6. Dimmer White
With this menu you can set your desired dim value.
01) Press the MODE button, until the display shows .
02) Press the Up/Down buttons to choose 255 different dimmer settings.
7. Fixture Hours
With this menu you can keep track of the operating time.
01) Press the MODE button, until the display shows .
02) Now you can keep track of the operating time of your LED Par 64 COB.
8. Lock Key
With this menu, you can activate/deactivate a display lock.
01) Press the MODE button, until the display shows .
02) Press the UP/DOWN buttons to activate/deactivate a display lock.
03) If you choose “Yes” and the display turns OFF after 10 seconds, you will have to press and hold down
one of the menu buttons (MODE, UP/DOWN) for 3 seconds. The display will turn ON.
04) If you choose “No”, the display will remain continuously ON.
9. DMX 4-channel mode
With this menu, you can set the DMX address in 4-channel mode.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between 1-512.
10. DMX 8-channel mode
With this menu, you can set the DMX address in 8-channel mode.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between 1-512.
11. DMX 15-channel mode
With this menu, you can set the DMX address in 15-channel mode.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between 1-512.

15
Ordercode: 43305
LED Par 64 COB RGBW 200W
12. Color Mode (LEE + Kelvin)
With this menu, you can set a specific color.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to choose one of the following 38 color presets:
DMX Channels
4 channels
Channel 1 –Red
0-255
Gradual adjustment Red, from 0-100%
Channel 2 –Green
0-255
Gradual adjustment Green, from 0-100%
Channel 3 –Blue
0-255
Gradual adjustment Blue, from 0-100%
Channel 4 –White
0-255
Gradual adjustment White, from 0-100%

16
Ordercode: 43305
LED Par 64 COB RGBW 200W
8 channels
Channel 1 –Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 3 –Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 4 –Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 5 –White Dimmer must be open
0-255
Gradual adjustment White, from 0-100%
Channel 6 –Color Macros
0-13
Not functional
14-255
Macro Mode
Channel 7 –Strobe
0-15
Closed
16-255
Strobe flash frequency, from slow to fast
Channel 8 –Dim Curve
0-255
Dim Curve Control
15 channels
Channel 1 –Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Dimmer Fine
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 3 –Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 4 –Red Fine Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 5 –Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 6 –Green Fine Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 7 –Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%

17
Ordercode: 43305
LED Par 64 COB RGBW 200W
Channel 8 –Blue Fine Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 9 –White Dimmer must be open
0-255
Gradual adjustment White, from 0-100%
Channel 10 –White Fine Dimmer must be open
0-255
Gradual adjustment White, from 0-100%
Channel 11 –Color Macros
0-13
Not functional
14-255
Macro Mode
Channel 12 –Strobe
0-15
Closed
16-255
Strobe flash frequency, from slow to fast
Channel 13 –Dim Curve
0-255
Dim Curve Control
Channel 14 –Mode
0-35
Color Adjustment
36-71
Slow Fade in to OFF
72-107
ON to slow fade out
108-143
Slow Fade in to slow Fade out
144-179
Automatic color mixing
180-215
3-color switch
216-251
7-color switch
252-255
7-color sound controlled
Note:
When CH14 is set between 0-143: Use in combination with CH1-CH11 to select your color
When CH14 is set between 144-251: Use in combination with CH15 to set the speed
Channel 15 –Speed (when CH14 is set between 36-251)
0-255
Speed, from slow to fast

18
Ordercode: 43305
LED Par 64 COB RGBW 200W
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The LED Par 64 COB RGBW requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Replacing the Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out.
If the fuse burns out, the product will not function whatsoever. If this happens, follow the directions below:
01) Unplug the unit from electric power source.
02) Insert a flat-head screwdriver into a slot in the fuse cover. Turn the screwdriver to the left, at the
same time gently push a bit (Turn and Push). The fuse will come out.
03) Remove the used fuse. If brown or unclear, it is burned out.
04) Insert the replacement fuse into the holder. Reinsert the fuse cover. Be sure to use a fuse of the
same type and specification. See the product specification label for details.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
No Light
If the light effect does not operate properly, refer servicing to a technician.
Suspect three potential problem areas as: the power supply, the LED, the fuse.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LED. Return the LED Par to your Showtec dealer.
03) The fuse. Replace the fuse. See page 18 for replacing the fuse.
04) If all of the above appears to be O.K., plug the unit in again.
05) If you are unable to determine the cause of the problem, do not open the LED Par, as this may
damage the unit and the warranty will become void.
06) Return the device to your Showtec dealer.

19
Ordercode: 43305
LED Par 64 COB RGBW 200W
No Response to DMX
Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card malfunction.
01) Check the DMX setting. Make sure that DMX addresses are correct.
02) Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power.
Try your DMX control again.
03) Determine whether the controller or light effect is at fault. Does the controller operate properly with
other DMX products? If not, take the controller in for repair. If so, take the DMX cable and the light
effect to a qualified technician.
Problem
Probable cause(s)
Solution
One or more
fixtures do not
function at all
No power to the fixture
•Check if power is switched on and
cables are plugged in
Primary fuse blown
•Replace fuse
Fixtures reset
correctly, but all
respond
erratically or not
at all to the
controller
The controller is not connected.
•Connect controller.
3-pin XLR Out of the controller
does not match XLR Out of the first
fixture on the link (i.e. signal is
reversed)
•Install a phase reversing cable
between the controller and the
first fixture on the link
Fixtures reset
correctly, but
some respond
erratically or not
at all to the
controller
Poor data quality
•Check data quality. If much lower
than 100 percent, the problem
may be a bad data link
connection, poor quality or
broken cables, missing termination
plug, or a defective fixture
disturbing the link
Bad data link connection
•Inspect connections and cables.
Correct poor connections. Repair
or replace damaged cables
Data link not terminated with 120
Ohm termination plug
•Insert termination plug in output
jack of the last fixture on the link
Incorrect addressing of the fixtures
•Check address setting
One of the fixtures is defective and
disturbs data transmission on the
link
•Bypass one fixture at a time until
normal operation is restored:
unplug both connectors and
connect them directly together.
•Have the defective fixture
serviced by a qualified technician
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed)
•Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture that behaves
erratically
No light or lamp
cuts out
intermittently
Fixture is too hot
•Allow the fixture to cool down
•Clean the fan
•Make sure air vents in control
panel and the front lens are not
blocked
•Turn up the air conditioning
LEDs damaged
•Disconnect the fixture and return it
to your dealer
The power supply settings do not
match local AC voltage and
frequency
•Disconnect fixture. Check settings
and correct if necessary
