Show Tec ACT Image Spot 50 CW V1 User manual

ACT Image Spot 50 CW
Product name
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: 34060
USER MANUAL
ENGLISH
V1

1
ACT Image Spot 50 CW
Product code: 34060
Preface
Thank you for purchasing this Showtec product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2023 Showtec. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
ACT Image Spot 50 CW
Product code: 34060
Table of contents
1. Introduction..........................................................................................................................................................4
Before Using the Product ..................................................................................................................................4
Intended Use .......................................................................................................................................................4
Product Lifespan.................................................................................................................................................4
LEDs Lifespan .......................................................................................................................................................4
Text Conventions ................................................................................................................................................4
Symbols and Signal Words................................................................................................................................5
Symbols on the Information Label ..................................................................................................................5
2. Safety ....................................................................................................................................................................6
Warnings and Safety Instructions ....................................................................................................................6
Requirements for the User.................................................................................................................................8
3. Description of the Device ...................................................................................................................................9
Front View ............................................................................................................................................................9
Back View ............................................................................................................................................................9
Accessories........................................................................................................................................................10
Optional Accessories.......................................................................................................................................10
Product Specifications ....................................................................................................................................11
Dimensions.........................................................................................................................................................12
4. Installation ..........................................................................................................................................................13
Safety Instructions for Installation ..................................................................................................................13
Installation Site Requirements ........................................................................................................................13
Rigging ...............................................................................................................................................................13
Angle Adjustment ............................................................................................................................................14
Color Frame Installation ..................................................................................................................................14
Connecting to Power Supply.........................................................................................................................15
Power Linking of Multiple Devices.................................................................................................................15
5. Setup ...................................................................................................................................................................16
Warnings and Precautions .............................................................................................................................16
Stand-alone Setup ...........................................................................................................................................16
DMX Connection..............................................................................................................................................16
DMX-512 Protocol...................................................................................................................................16
DMX Cables.............................................................................................................................................17
DMX Linking .............................................................................................................................................17
DMX Addressing......................................................................................................................................18
Beam Angle Adjustment.................................................................................................................................18
Focus Adjustment.............................................................................................................................................19
Changing the Gobo........................................................................................................................................20
6. Operation ...........................................................................................................................................................21
Safety Instructions for Operation...................................................................................................................21
Control Modes ..................................................................................................................................................21
Control panel ....................................................................................................................................................22
Start-up...............................................................................................................................................................23
Menu Overview ................................................................................................................................................24
Main Menu Options .........................................................................................................................................26
DMX Functions.........................................................................................................................................26
DMX Address .......................................................................................................................................27
DMX Channel Mode..........................................................................................................................27
DMX Fail................................................................................................................................................27
View DMX Value.................................................................................................................................28
Fixture Settings.........................................................................................................................................28
Manual Mode .........................................................................................................................................29
Display Settings .......................................................................................................................................29
Fixture Test ................................................................................................................................................29

3
ACT Image Spot 50 CW
Product code: 34060
Fixture Information..................................................................................................................................30
Special Functions....................................................................................................................................30
DMX Channels ..................................................................................................................................................31
Remote Control ................................................................................................................................................32
Blackout ...................................................................................................................................................34
Gobo Rotation ........................................................................................................................................34
Gobo Index .............................................................................................................................................34
Speed .......................................................................................................................................................34
Strobe........................................................................................................................................................35
DMX Mode...............................................................................................................................................35
DMX Address ...........................................................................................................................................35
Dimmer .....................................................................................................................................................35
7. Troubleshooting .................................................................................................................................................36
8. Maintenance .....................................................................................................................................................37
Safety Instructions for Maintenance.............................................................................................................37
Preventive Maintenance................................................................................................................................37
Basic Cleaning Instructions ...................................................................................................................37
Corrective Maintenance................................................................................................................................38
Replacing the Fuse ................................................................................................................................38
9. Deinstallation, Transportation and Storage ....................................................................................................39
Instructions for Transportation ........................................................................................................................39
Instructions for Deinstallation..........................................................................................................................39
Storage...............................................................................................................................................................39
10. Disposal ..............................................................................................................................................................39
11. Approval.............................................................................................................................................................39

4
ACT Image Spot 50 CW
Product code: 34060
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●Showtec ACT Image Spot 50 CW
●Gobo (already installed)
●Color frame
●Schuko to power pro cable (1,5 m)
●User manual
Fig. 01
Intended Use
This device is intended for use as a professional LED gobo projector and is suitable for indoor installation
only. It is not suitable for households or general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when it is not in use. This will reduce wear and improve the device’s lifespan.
LEDs Lifespan
The light output of LEDs gradually decrease over time (lumen depreciation). High operating temperatures
contribute to this process. The lifespan of LEDs can be extended by ensuring adequate ventilation and
operating the LEDs at the lowest possible brightness.
Text Conventions
Throughout the user manual the following text conventions are used:
●Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment handle (11)”
●0–255: Defines a range of values
●Notes: Note: (in bold lettering) is followed by useful information or tips

5
ACT Image Spot 50 CW
Product code: 34060
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
serious injury or death.
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result
in serious injury or death.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket of the device.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.

6
ACT Image Spot 50 CW
Product code: 34060
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage (> 120 V DC) may be present.
●Do not open the device or remove any covers.
●Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
●Disconnect the device from electrical power supply before service and maintenance, and when the
device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection Class I.
●Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
●Do not cover the ground (earth) connection.
●Do not bypass the thermostatic switch or fuses.
●For replacement use fuses of the same type and rating only.
●Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
●Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
●Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
●Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.

7
ACT Image Spot 50 CW
Product code: 34060
WARNING
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at
strobe lights.
Attention
Power supply
●Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
●Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals. This reduces the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Change the lens or the LEDs if they are visibly damaged to such an extent that their effectiveness is
impaired, for example by cracks or deep scratches. Contact your Highlite International dealer for
more information, as servicing can be performed only by instructed or skilled persons.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
●If the device fails to work properly, discontinue the use immediately.
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a professional LED gobo projector. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
●This device is not suitable for households and for general lighting.
●This device is not designed for permanent operation.
●This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.

8
ACT Image Spot 50 CW
Product code: 34060
Attention
Before each use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●The safety devices are not damaged.
●There are no deformations on housings, fixations and installation points.
●The lens is not cracked or damaged.
●The power cables are not damaged and do not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Installation, service and maintenance shall be carried out
only by instructed or skilled persons. Contact your Highlite International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the service of this product, so that they can
identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

9
ACT Image Spot 50 CW
Product code: 34060
3. Description of the Device
The Showtec ACT Image Spot 50 CW is a compact, LED gobo projector suitable for commercial
applications. It is equipped with a gobo holder and has a manually adjustable zoom and focus. A color
frame is also included.
Front View
Mounting bracket
Gobo holder screw
Gobo holder
Focus control
Zoom control
Spring-loaded screw
Color frame clip
Lens
3 x Color frame holder
Infrared sensor
Adjustment handle
Safety eye
Fig. 02
Back View
3-pin DMX signal connector OUT
Fuse T 1 AL / 250 V
Power pro connector OUT 100–
240 V, 7 A, 50/60 Hz (Gray)
Power pro connector IN 100–
240 V, 10 A, 50/60 Hz (Blue)
3-pin DMX signal connector IN
Control panel: OLED display and
control buttons
Fig. 03

10
ACT Image Spot 50 CW
Product code: 34060
Accessories
Safety eye
Fig. 04
Optional Accessories
●Product code: 42704 (Showtec IR Controller)
●Product code: 34050 (Showtec Season Gobo Set)

11
ACT Image Spot 50 CW
Product code: 34060
Product Specifications
Model:
ACT Image Spot 50 CW
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
57W
Fuse:
T 1 AL/250 V
Physical:
Dimensions:
425 x 165 x 145 mm (L x W x H) (without accessories)
Weight:
2,8 kg (without accessories)
Optics:
Light source:
1 x 50 W LED
Dimmer:
0–100 %
Strobe:
0–20 Hz
Beam angle:
15,2°–27,5° (manual adjustment)
Output:
6672 lx @ 2 m, 2965 lx @ 3 m, 1068 lx @ 5 m
CRI:
96
CCT:
6500 K (max.)
Total luminous flux:
1743 lm
Refresh rate:
1100 Hz
Operation and control:
Control:
Stand-alone (manual), DMX-512, IR
DMX channels:
2 and 3-channel mode
Control panel:
OLED display and buttons
Manual operation:
Zoom & Focus
Connections:
Power connections:
Power pro connectors IN/OUT
Data connections:
3-pin DMX connectors IN/OUT
Signal pinouts:
Pin 1 (ground), pin 2 (-), pin 3 (+)
Construction:
Housing:
Aluminum
Color:
Black
IP rating:
IP20
Cooling:
Convection/Axial fan
Thermal:
Maximum ambient temperature ta:
45 °C
Minimum ambient temperature ta:
0 °C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m

12
ACT Image Spot 50 CW
Product code: 34060
Dimensions
Fig. 05

13
ACT Image Spot 50 CW
Product code: 34060
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Installation Site Requirements
●The device can be used indoors only.
●The device can be mounted to a truss or another rigging structure in any orientation.
●The minimum distance to other objects must be bigger than 0,5 m.
●The maximum ambient temperature ta= 45 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.
Rigging
The device can be mounted to a truss or other rigging structure in any orientation. Make sure that all
loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
To mount the device, follow the steps below:
Use a clamp to attach the device to the supporting structure, as shown in Fig. 06. Make sure that the
device cannot move freely.
Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through the safety eye (12), as shown in Fig. 06.
Fig. 06

14
ACT Image Spot 50 CW
Product code: 34060
Angle Adjustment
You can adjust the angle of the device with the adjustment handle (11).
Turn the adjustment handle (11) counterclockwise to loosen it.
Tilt the device to the desired angle (see Fig. 07).
Turn the adjustment handle (11) clockwise to tighten it. Make sure that the device cannot move
freely after the adjustment handle (11) is tightened.
Fig. 07
Color Frame Installation
The ACT Image Spot 50 CW is delivered with a color frame. You can insert a color gel or a diffusion filter
into the color frame. To install the color frame, follow the steps below:
01) Push the spring-loaded screw (06) and at the same time lift the color frame clip (07) and flip it
backwards (see Fig. 08).
02) Insert a color gel or a diffusion filter into the color frame.
03) Insert the color frame into the color frame holders (09) (see Fig. 09).
04) Pull the color frame clip (07) downwards to release the spring-loaded screw (06) (see Fig. 10). The
color frame will be locked in position.
05) Secure the color frame to the overhead structure with an appropriate secondary attachment, for
example a safety cable. Put the safety cable through the safety eye (19) of the color frame. See 4.3.
Rigging on page 13 for more information.
Note:
Make sure that the color frame is locked in position with the color frame clip before using the device.
Fig. 08
Fig. 09
Fig. 10

15
ACT Image Spot 50 CW
Product code: 34060
Connecting to Power Supply
DANGER
Electric shock caused by short-circuit
The device can be powered by 100–240 V 50/60 Hz AC mains power. Do not supply mains power at any
other voltage or frequency to the device.
This device falls under IEC protection class I. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
●Make sure that the power supply matches the input voltage specified on the information label on
the device.
●Make sure that the socket-outlet has ground (earth) connection.
Connect the device to the socket outlet with the power plug. Do not connect the device to a dimmer
circuit, as this may damage the device.
Power Linking of Multiple Devices
This device supports power linking. Power can be relayed to another device via the power OUT
connector. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
●Use cables with sufficient current-carrying capacity. The power cable supplied with the device is not
suitable for power linking of multiple devices.
●Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker.
●Do not link more devices on one power link than the maximum recommended number.
Maximum recommended number of devices:
●at 100–120 V: 16 devices ACT Image Spot 50 CW
●at 200–240 V: 32 devices ACT Image Spot 50 CW

16
ACT Image Spot 50 CW
Product code: 34060
5. Setup
Warnings and Precautions
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.
Stand-alone Setup
When the ACT Image Spot 50 CW is not connected to a controller or to other devices, it functions as a
stand-alone device. It can be operated manually via the control panel and the manual controls or via
an optional remote control.
For more information about the control modes, refer to 6.2. Control Modes on page 21.
DMX Connection
DMX-512 Protocol
You need a DMX serial data link to run light shows of one or more devices using a DMX-512 controller.
The ACT Image Spot 50 CW has 3-pin DMX signal IN and OUT connectors.
The pin assignment is as follows: pin 1 (ground), pin 2 (-), pin 3 (+).
Devices on a serial data link must be daisy-chained in a single line. The number of devices that you can
control on one data link is limited by the combined number of the DMX channels of the connected
devices and the 512 channels available in one DMX universe.
To comply with the TIA-485 standard, no more than 32 devices should be connected on one data link.
In order to connect more than 32 devices on one data link, you must use a DMX optically isolated
splitter/booster, otherwise this may result in deterioration of the DMX signal.
Notes:
●Maximum recommended DMX data link distance: 300 m
●Maximum recommended number of devices on a DMX data link: 32 devices

17
ACT Image Spot 50 CW
Product code: 34060
DMX Cables
Shielded twisted-pair cables with 3-pin XLR connectors must be used for a reliable DMX connection.
You can purchase DMX cables directly from your Highlite International dealer or make your own cables.
If you use XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable
operation of the DMX network.
When you make your own DMX cables, make sure that you connect the pins and wires correctly as
shown in Fig. 11.
Fig. 11
DMX Linking
To connect multiple devices on one DMX data link, follow the steps below:
Connect the DMX OUT connector on the lighting controller to the DMX IN connector on the first
device with a 3-pin DMX cable.
Connect the DMX OUT connector on the first device to the DMX IN connector on the second device
with a 3-pin DMX cable.
Repeat step 2 to connect all devices in a daisy-chain as shown in Fig. 12.
Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device on the data
link.
Fig. 12

18
ACT Image Spot 50 CW
Product code: 34060
DMX Addressing
In a setup with multiple devices, make sure that you set the DMX starting address of each device
correctly. The ACT Image Spot 50 CW has 2 personalities: 2 channels and 3 channels.
If you want to connect multiple devices on one data link and use them in 3-channel mode, for example,
follow the steps below:
Set the starting address of the 1st device on the data link to 1 (001).
Set the starting address of the 2nd device on the data link to 4 (004), as 1 + 3 = 4.
Set the starting address of the 3rd device on the data link to 7 (007) as 4 + 3 = 7.
Continue assigning the starting addresses of the remaining devices by adding 3 to the previous
number each time.
Make sure that you do not have any overlapping channels in order to control each ACT Image Spot 50
CW correctly. If two or more devices are addressed similarly, they will work similarly.
Beam Angle Adjustment
The beam angle of the ACT Image Spot 50 CW can be adjusted manually in the range 15,2°–27,5°. To
adjust the beam angle, follow the steps below (see Fig. 13):
Turn the zoom control (05) counterclockwise to loosen it.
Slide the zoom control (05) forwards or backwards to achieve the desired beam angle.
After adjusting the beam angle, turn the zoom control (05) clockwise to tighten it. Do not
overtighten it.
Fig. 13

19
ACT Image Spot 50 CW
Product code: 34060
Focus Adjustment
The focus of the ACT Image Spot 50 CW can be adjusted manually. To adjust the focus, follow the steps
below (see Fig. 14):
Turn the focus control (04) counterclockwise to loosen it.
Slide the focus control (04) forwards or backwards to achieve the desired focus.
After adjusting the focus, turn the focus control (04) clockwise to tighten it. Do not overtighten it.
Fig. 14
