Anolis ArcSource Outdoor 24 MC Integral SmartWhite User manual

1
Version1.5

2
ArcSource 24 MC Submersible
Table of contents
1. Introduction ...............................................................................................3
2. Safety information ....................................................................................3
3. Mounting.....................................................................................................3
4. ArcSource 24 MC Submersible connection with a control unit.............4
5. Technical specications............................................................................5
6. Mounting the ArcSource 24 MC Submersible into installation sleeve..7
7. Cleaning and maintenance .......................................................................7

3
1. Introduction
The ArcSource 24MC Submersible has a housing crafted from the highest quality marine grade bronze meaning
its is capable to withstand the very harshest environmental conditions.
2. Safety information
The unit must be installed by a qualied electrician in accordance with all national
and local electrical and construction codes and regulations.
Do not install the module near high inammable liquids or materials
Do not allow anything to rest on the module
Do not install the module near the naked ames
Do not install the module in dirty, dusty or badly ventilated location
Avoid using the unit in locations subject to possible impacts.
The unit is suitable for underwater installation up to depth of 10 m.
Do not let the unit in frozen water
Avoid looking directly into the LED light beam at close range.
3. Mounting
The ArcSource 24 MC Submersible can be arranged in any position orientation. The LED module body is
mounted on a bronze bracket for “tilt” adjustment . Use a spanner no.13 (pos.1) and Allen key no.6 (pos. 2)
to adjust desired tilt position of the LED module. For fastening the ArcSource 24 MC Submersible to the at
surface use either three holes or two semicircle slots which allows ne adjusting the xture in a "pan" direction.

4
Wiring of the ArcSource 24 MC Submersible:
Wire Red wire Blue wire Orange wire
Meaning +24V Ground Communication
4. ArcSource 24 MC Submersible connection with a control unit
Maximum distance between the ArcPower 24 MC (24V) and the ArcSource 24 MC
Submersible should must not exceed 50 metres.
Connect the ArcSource 24 MC Submersible to the control unit ArcPower 24 MC (24V) according the picture
below. For more information see the ArcPower 24 MC (24V) user manual.

5
5. Technical specications
Light source: 6 x 10W multichip LEDs
Input voltage : 24 V DC
Maximum power consumption: 35W (Standard Mode, 350mA), 75W (High Power Mode, 700mA)
Max. current (per colour): 700 mA
Compatible control unit: ArcPower 24 MC (24V)
Typical Lumen maintenance: 60 000 hours
Cooling system: Convection
Available beam angles: 7°, 24°, 34°, 60°
Colour variants: RGBCW, CW, SW
Protection factor: for CE: IP68 10m rating
for cETLus: maximum deptht of 10 m.
Impact rating: IK10
Construction: Marine bronze, transparent cover-tempered glass
Weight: 10.5 kg (23.1 lbs)
LED module tilt adjustment range: 125°
Mounting options: Stirrup
Connecting cable: Paige P7342-SP cable, custom length
Operating ambient temperature: -20°C +40°C (-4°F +104°F)
Optional accessories: Installation sleeve (P/N 10980285)
Floor Stand ArcSource 24 MC Submersible 5mm (P/N10980315)
Dmensions (mm)
ArcSource 24 MC Submersible

6
Installation sleeve
Weight: 10 kg

7
6. Mounting the ArcSource 24 MC Submersible into the installation
sleeve
1. Unscrew a bracket from the ArcSource 24 MC Submersible.
2. Insert the ArcSource 24 MC (4) Submersible into chassis (5) and fasten it on both sides it by means of two
bolts (7) with rubber washers (6), 6 mm long spacers ( 10) and nuts M8 (9). These parts (6,7,9,10) are
components of the installation sleeve (8).
3. Insert Allen bolts M5x45 (1) with spring washers (2) to the 30mm spacers (3) and used them to screw
the chassis (5) to the installation sleeve (8) (before inserting chassis, pull the ArcSource 24 MC
Submersible´s cable through the aperture in the installation sleeve.
4. Screw the metal collar (13) to the chassis (5) with two Allen keys M4x12 (11) and washers (12).
5. Insert the at rubber gasket (14) into metal collar (13).
6. Put the glass (15) on the rubber gasket (14).
7. Put the shaped rubber gasket (16) on the glass (15).
8. Screw the top metal ange (17) by means of the six at head screws M6x30 (18) to the installing sleeve.
9. Connect the ArcSource 24 MC Submersible to the ArcPower 24 MC (24V).
7. Cleaning and maintenance
Disconnect from the mains before starting any maintenance work
Rinse o󰀨 loose dirt with low pressure water spray. Wash the housing with a soft brush or sponge and a mild,
non-abrasive washing detergent. Rinse it.
There are no serviceable parts inside the device.
Maintenance and service operations are only to be carried out by a qualied person.
Should you need any spare parts, please use genuine parts.
October 16, 2017
Specications are subject to change without notice.
Made in CZECH REPUBLIC by ROBE LIGHTING s.r.o. Palackeho 416/20 CZ 75701 Valasske Mezirici
