Show Tec Compact Par 60 COB RGBW V1 User manual

Compact Par 60 COB RGBW V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42583
MANUAL
ENGLISH

1
Ordercode: 42583
Compact Par 60 COB RGBW
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Beam angle adjustment..............................................................................................................................................9
Control Modes.............................................................................................................................................................10
One Compact Par 60 COB RGBW (Auto Run Mode, Built-in programs and Static Color Mode) ...........10
One Compact Par 60 COB RGBW (Sound-controlled)....................................................................................10
Multiple Compact Pars 60 COB RGBW (Master/Slave control)......................................................................10
Multiple Compact Pars 60 COB RGBW (DMX Control) ....................................................................................11
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
Control Mode ..............................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Menu Overview...........................................................................................................................................................15
Main Menu Options....................................................................................................................................................15
Auto Run Mode........................................................................................................................................................16
Built-in Programs .......................................................................................................................................................16
Slave Mode...............................................................................................................................................................16
DMX Addressing / DMX configuration .................................................................................................................16
Sound control mode ...............................................................................................................................................17
Static Color control..................................................................................................................................................17
Settings.......................................................................................................................................................................17
Info..............................................................................................................................................................................18
DMX Channels .............................................................................................................................................................19
4 channels .................................................................................................................................................................19
6 channels .................................................................................................................................................................19
11 channels...............................................................................................................................................................19
Maintenance....................................................................................................................................................................22
Replacing the Fuse.....................................................................................................................................................22
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................23
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25
Notes ..................................................................................................................................................................................26

2
Ordercode: 42583
Compact Par 60 COB RGBW
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Compact Par 60 COB RGBW
IEC power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 42583
Compact Par 60 COB RGBW
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the rotating gobo otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 42583
Compact Par 60 COB RGBW
•The user is responsible for correct positioning and operating of the Compact Par 60 COB RGBW. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the Compact Par is lowered from the ceiling or high joists, professional trussing systems have to be
used.
•Use a clamp to mount the Compact Par, with the mounting bracket, to the trussing system.
•The Compact Par must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the Compact Par, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 42583
Compact Par 60 COB RGBW
The Compact Par 60 COB RGBW can be placed on a flat stage floor or mounted to any kind of truss with
a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 42583
Compact Par 60 COB RGBW
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 42583
Compact Par 60 COB RGBW
Description of the device
Features
The Showtec Compact par 60 COB is a COB LED parcan in a compact housing. It offers RGBW colors
powered by 1 single 60 watt COB LED. The COB technology ensures a high definition perfect color mix. It
has a big reflector with a large soft 120° edge beam angle and with the included Fresnel lens it can be
transformed into a hard edge narrow 20° beam angle. With the 4, 6,or 11 channel DMX personality and
the built-in programs it is an ideal and easy to use LED fixture for mobile dj’s.
Included Fresnel lens
Double bracket
Rubber feet
Input voltage: 100-240V, 50/60Hz
Drive Current: 450mA
Refresh rate: 12 kHz
Power consumption: 64W
DMX channels: 4, 6 or 11 channels
4-digit LED display for easy setup
Light source: 1 x 60W RGBW COB LED
Lux @2m: 1833
Control modes: Built-in Programs, Auto, Sound-controlled, Static color, Master/Slave, DMX
Control protocol: DMX-512
Dimmer: 0-100%
Strobe: 0-15Hz
Beam Angle: 20° and 120°
Protection rate: IP-20
Black housing: Aluminum and Iron
Cooling: Cooling fan
Connections: IEC IN & OUT, 3-pin XLR IN & OUT
Fuse: T1L/250V
Dimensions: 270 x 155 x 285 mm (LxWxH)
Weight: 2,4 kg
Frontside
Fig. 01
01) Mounting bracket
02) Adjustment screw
03) 60W RGBW COB LED

8
Ordercode: 42583
Compact Par 60 COB RGBW
Backside
Fig. 02
04) IEC power connector OUT
05) 3-pin DMX signal connector OUT
06) Cooling fan
07) 4-digit LED display + menu buttons
08) IEC power connector IN
09) 3-pin DMX signal connector IN
Installation
Remove all packing materials from the Compact Par 60 COB RGBW. Check if all foam and plastic
padding is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 42583
Compact Par 60 COB RGBW
Beam angle adjustment
The Compact Par 60 COB RGBW can be used with a 20° beam angle or a 120° beam angle.
Please follow the instructions below to change the beam angle.
01) Loosen the screws in the indicated direction.
02) Take the Fresnel lens from the fixture.
03) Now the fixture has a 120° beam angle.
01) Take the Fresnel lens and put it back on the fixture.
02) Tighten the screws in the indicated direction.
03) Now the fixture has a 20° beam angle.

10
Ordercode: 42583
Compact Par 60 COB RGBW
Control Modes
There are 6 modes:
•Auto run
•Built-in programs
•Static Color
•Sound-controlled
•Master/slave
•DMX-512 (4CH, 6CH or 11CH)
One Compact Par 60 COB RGBW (Auto Run Mode, Built-in programs and Static Color Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Compact Par is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 16 and 17 for more information about Auto Run Mode, the Built-in programs and
Static Color Mode.
One Compact Par 60 COB RGBW (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Compact Par will react to the beat
of the music. Please see page 17 for more information about the sound-control options.
Multiple Compact Pars 60 COB RGBW (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-p XLR cable to connect the Compact Par and other devices.
The pins:
1. Earth
2. Signal (-)
3. Signal (+)
04) Link the units as shown in Fig. 03, connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on pages 16 and 17 (Auto run, Built-in
Programs, Static color). This means you can set your desired operation mode on the master device
and all slave devices will react the same as the master device.

11
Ordercode: 42583
Compact Par 60 COB RGBW
Multiple Compact Pars 60 COB RGBW (Master/Slave control)
Fig. 03
Multiple Compact Pars 60 COB RGBW (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Compact Pars and other devices.
04) Link the units as shown in Fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.

12
Ordercode: 42583
Compact Par 60 COB RGBW
Multiple Compact Pars 60 COB RGBW DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

13
Ordercode: 42583
Compact Par 60 COB RGBW
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin. Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.
The Compact Par 60 COB RGBW can be operated with a controller in DMX mode or without the
controller in stand-alone mode.

14
Ordercode: 42583
Compact Par 60 COB RGBW
Control Panel
A) LED display
B) Mode button
C) Setup button
D) Up button
E) Down button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the side of the device allows you to assign DMX fixture addresses, which is the first
channel with which the Compact Par will respond to the controller.
Please note, when you use the controller, the unit has 11 channels.
When using multiple Compact Pars, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Compact Par should be 1(001); the DMX address of the second
Compact Par should be 1+11=12 (012); the DMX address of the third Compact Par should be 12+11=23
(023), etc. Please, be sure that you do not have any overlapping channels in order to control each
Compact Par correctly. If two or more Compact Pars are addressed similarly, they will work similarly.
Controlling:
After having addressed all Compact Par fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Compact Par will automatically detect whether DMX 512 data is received
or not. If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Compact Par.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 20 seconds
When no button is pressed for 20 seconds, the display will turn off.
To light up the display, you have to press the Mode, Setup, Up or Down button.
Once you have pressed the button, the display will light up.

15
Ordercode: 42583
Compact Par 60 COB RGBW
Menu Overview
Main Menu Options
Auto run
Built in programs
Master-Slave
DMX address / DMX configuration
Sound-controlled Mode
Static Color Mode
Settings
Info

16
Ordercode: 42583
Compact Par 60 COB RGBW
Auto Run Mode
With this menu you can start the Auto Run program of the Compact Par 60 COB RGBW.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) The Compact Par will start immediately the Auto Run program.
Built-in Programs
With this menu you can set the built-in programs.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu.
03) You can use the Up/Downbuttons to scroll through the 16 built-in programs.
04) When you select program , you can use a wide variety (33) of manual color settings. Press
Setup to enter and choose one with the Up/Down buttons.
05) Press the Setup button to open menu . You can set the Flash frequency with
the Up/Down buttons.
06) Press the Setup button again, until the display shows .
07) Use the Up/Down buttons until the display shows .
08) Use the Up/Down buttons to scroll between In menu ,
you can switch between the Flash frequency and the Program Running Speed by pressing the Setup
button.
09) Use the Up/Down buttons to change the values.
Speed from 00-99 and FL.
Flash Frequency from 00-99
Slave Mode
With this menu you can set the device as a Master or Slave.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the master movement. If the device has been set to slave, it will react the same as
its master device.
DMX Addressing / DMX configuration
With this menu you can set the DMX address and choose a DMX configuration.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu. You can choose 512 different DMX addresses.
03) Use the Up/Down buttons to select the required address from .
Once you have set the desired DMX address, you can also choose the desired DMX Mode.
04) Press the Setup button to choose one of the 3 different DMX Modes. Use the Up/Down buttons to
select 4, 6 or 11 channels DMX mode.

17
Ordercode: 42583
Compact Par 60 COB RGBW
Sound control mode
With this menu you can set the sensitivity of the sound mode.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to change the values.
04) Set the sensitivity of the sound control mode between .
Static Color control
With this menu you can manually set a desired color.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu.
03) You can use the Setup button to scroll through the 4 color options.
04) Use the Up/Down buttons to change the values.
Gradual adjustment red (0-255)
Gradual adjustment green (0-255)
Gradual adjustment blue (0-255)
Gradual adjustment white (0-255)
You can combine Red, Green, Blue and White to create an infinite range of colors (0-255).
Settings
With this menu you can set various options.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to choose between the 5 options.
04) Press the Setup button to open one of the 5 options.
05) With the Up/Down buttons you can set the desired option.
06) With option you can set the dimming curve of the fixture. There are four curves which can be
selected.

18
Ordercode: 42583
Compact Par 60 COB RGBW
07) With option you can set the Dimmer Speed, smooth or fast.
08) With option you can reset the device to the factory settings. If you choose “Yes” the fixture
will reset and start up in the Auto Run mode.
09) With option you can set the fixture to “HOLD” or “OFF”. If you choose “OFF”, the fixture will go
out if there is no DMX signal. If you choose “HOLD”, the fixture will remember the last settings and will
not go out if there is no DMX signal.
10) The option is a tool which helps to keep multiple fixtures synchronized when using them in
master slave mode.
Info
With this menu you can see various info of the fixture.
01) Press the Mode button and then the Up/Down buttons, until the display shows .
02) Press the Setup button to open this menu.
03) Use the Up/Down buttons to choose between the 2 options, and .
04) Press the Setup button to see one of the 2 options.
05) With the option you can see if the fixture is too hot or not. If the fixture has a normal
temperature, the display will show “t-on”. If the fixture is too hot, the display will show “t-nn”. You’ll
have to switch off the fixture.
06) The option is for showing the software version of the fixture.

19
Ordercode: 42583
Compact Par 60 COB RGBW
DMX Channels
4 channels
Channel 1 –Red Dimmer intensity
0-255
Red from 0-100%
Channel 2 –Green Dimmer intensity
0-255
Green from 0-100%
Channel 3 –Blue Dimmer intensity
0-255
Blue from 0-100%
Channel 4 –White Dimmer intensity
0-255
White from 0-100%
6 channels
Channel 1 –Master Dimmer intensity
0-255
From dark to brightest 0-100%
Channel 2 –Linear strobe ( CH1, CH3, CH4, CH5 or CH6 must be set between 001-255 )
0-10
Closed
11-255
Strobe flash frequency, from slow to fast (0-15 Hz)
Channel 3 –Red Dimmer intensity ( CH1 must be set between 001-255 )
0-255
Red from 0-100%
Channel 4 –Green Dimmer intensity ( CH1 must be set between 001-255 )
0-255
Green from 0-100%
Channel 5 –Blue Dimmer intensity ( CH1 must be set between 001-255 )
0-255
Blue from 0-100%
Channel 6 –White Dimmer intensity ( CH1 must be set between 001-255 )
0-255
White from 0-100%
11 channels
Channel 1 –Master Dimmer intensity
0-255
From dark to brightest 0-100%
Channel 2 –Linear strobe ( CH1, CH4, CH5, CH8, CH9, CH10 or CH11 must be set between 001-255 )
0-10
Closed
11-255
Strobe flash frequency, from slow to fast (0-20 Hz)
Channel 3 –Random strobe (CH1, CH4, CH5, CH8, CH9, CH10 or CH11 must be set between 001-255 )
0-10
Closed
11-255
Random strobe flash
