ShowPro LED PixPar 3 IP65 RGBW Zoom User manual

LED PixPar 3 IP65 RGBW Zoom
USER MANUAL
LEDPAR210

1 PRODUCT SPECIFICATIONS
1.1 Product Specicaons
•Voltage: AC100~240V 50/60Hz
•Max Power: 130W
•Operaon Temperature: -20℃ ~45℃
•Size: 376 x 274 x 210mm
•Weight: 7.3kg

1.2 Safety Warning
IMPORTANT
•This product must be installed by a qualied professional.
•All maintenance must be carried out by a qualied electrician.
•A minimum distance of 0.5m must be maintained between the equipment and a
combusble surface.
•The product must always be operated in a well-venlated area.
•DO NOT stare directly into the LED light source.
•Always disconnect the power before carrying out any maintenance.
•The earth must always be connected to the ground.
•Ensure that all parts of the equipment are kept clean and free of dust.
2 INSTALLATION
2.1 Mounng
HANGING
The xture can be mounted in a hanging posion using the
supporng bracket. The bracket should be secured to the mounng
truss or structure using a standard mounng clamp. Please note
that when hanging the unit, a safety cable should also be used.
UPRIGHT
The xture can be mounted in an upright or sing posion using
the supporng brackets.
The LED MODULE can be mounted at any angle and in any posion. It is possible to further
adjust the angle of the LED MODULE using the two adjustment knobs located on the side of
the xture.

2.2Power Connecons
@ 220V: 15 units may be connected in series
@110V: 7 units may be connected in series
Note: If the signal cable is over 60m between the DMX512 controller and xture or between
two xtures, then a DMX signal amplier is needed as well.
3 DISPLAY PANEL OPERATION
3.1 Display Operaon
•Menu: Open menu or back
•Enter: Enter or save
•UP: Increase value
•Down: Decrease value
3.2 Menu Map

3.3 Edit Stac Colour
•Combine RED, GREEN, BLUE, and WHITE to create an innite range of colours (0-255)
•Set the value of the STROBE (0-25Hz)
3.4 DMX512 Sengs
•Enter the ADDRESS mode to set the DMX ADDRESS.
3.5 Acvang Auto Programs
•Select the target under AUTO PROGRAM and press ENTER.
•Programs AUTO.01 to AUTO.10 are fully pre-programmed and will not be altered by
changes in EDIT mode.
•Programs PR.01 to PR.10 are fully pre-programmed and can be edited in EDIT mode.
3.6 Run Mode
•Enter the RUN MODE to set working mode.
•DMX mode is for using the DMX512 controller to control the xtures. SLAVE mode is
for Master-Slave operaon.

3.7 Zoom Mode
•ZOOM MODE 1 is the default fast zoom speed, work in Ambient Temp. > 0℃
•ZOOM MODE 2 is slow zoom speed, works in Ambient Temp. < 0℃
3.8 Personality
•Enter the PERSONALITY mode to select DMX mode: HSIC \ SSP \ TOUR \ TR16
Introducon for HSIC
•HUE: colour selecon
•HUE FINE: ne dimming when choose a colour.
•SATURATION adjust saturaon when choose a colour.
•INTENSITY: adjust intensity for chosen colour.
•CCT: choose needed colour temperature (2700k, 3000k, 3200k, 3500k, 4000k, 4200k,
4500k, 5600k, 6000k, 6500k, 7200k, 8000k).
3.9 Eding Custom Programs
•Enter the EDIT mode to edit the custom programs PROGRAM01 to PROGRAM10.
•Each custom program has 30 scenes that can be edited.
•Each step allows the creaon of a scene using RED, GREEN, BLUE, WHITE, ZOOM,
STROBE, TIME & FADE.

3.10 Special Sengs
•SETTING menu allows the user to adjust key operaon sengs for this xture. Select
UPLOAD to upload the custom programs from the current MASTER unit to the SLAVE
units.
•To reset custom modes to default values, select RESET.
•Note: UC/RGBW/CALIB.C can’t be reset
•COLOR acvates/deacvates the colour calibraon funcons. When RGBW is
selected, on RGB = 255,255,255, the colour is displayed as calibrated in CALIB.C -
RGBW. When COLOR is set to OFF, on RGB = 255,255,255, the RGB values are not
adjusted, and the output is the most powerful. When UC is selected, the RGB
outputs are adjusted to a standard preset universal colour which balances xtures
from dierent generaons. Note: COLOR works only when choose NORMAL at FULL
POWER CCT
•Select DIM1, DIM2, DIM3 or DIM4 for dierent dimming speeds. (DIM4 is the
slowest dimming speed)
•DMX ERROR Choose SAVE in order to save the last DMX data in case of DMX signal
error. Choose BLACK in order to blackout in case of DMX signal error.
•PWM RATE sets the PWM refresh rate. Press UP/DOWN to choose 600Hz, 1200Hz,
4000Hz and 25000Hz.
Note: with refresh rate increased, grey rate of dimmer will be reduced, (that means
high refresh rate, low grey rate). When 4000Hz is selected, CV3 is invalid, when
25000Hz is selected, CV1, CV2, and CV3 are invalid, so please lower PWM rate to
increase grey rate if necessary.
•FULL POWER CCT is the colour temperature choose boom, press UP/DOWN to
choose. Under full power, 3200k, 4200k, 5600k can be chosen, but when COLOR is
chosen, 3200k, 4200k, 5600k will not work, only NORMAL will work.

3.11 Acvate the Password
•Enter the KEY mode to select whether the access password is on or o.
•When the xture is set as PASS ON, aer 30 seconds, the xture will need an access
password to enter the display menu control.
Note: The factory access password is UP + DOWN + UP + DOWN, then press ENTER
to conrm the access.
3.12 Parameter Correcon
Press MENU buon to enter the password conrmaon, to enter the correct password UP +
DOWN + UP + DOWN, press the MENU in, the correct password will show the submenu.
•Enter the CALIB.C to select white colour of dierent colour temperatures.
•There are 12 pre-programmed white colours can be edited by using RED, GREEN,
BLUE, and WHITE
•When DMX mode is HSIC, CH5 will have access to 12 white colours.
•When DMX mode is TOUR, CH6 will have access to 12 white colours.
•When DMX mode is TR16, CH11 will have access to 12 white colours.
Note: if CCT data is changed in WHITE from WT.01 to WT.12, the CCT of the
corresponding channel will be changed also.
•Enter the RGBW to adjust the RGB parameter to make dierent whites.
•When the new seng is acvated, the DMX controller choose RGB = 255,255,255
the white colour will be made by the actual RGB values on the RGBW.
3.13 Info
•Press ENTER and go to INFO. You can check VERSION, or use DOWN/UP to check
RDM, LABEL, press MENU and back.

4 USING A DMX CONTROLLER
4.1 Channel Assignment
Note: This product has four DMX512 channel conguraons: HSIC, SSP, TOUR, TR16.
HSIC
CHANNEL
VALUE
FUNCTION
1
000 – 255
Intensity
2
000 – 255
Hue
3
000 – 255
Hue Fine
4
000 – 255
Saturaon
5
CCT
000 – 010
No funcon
011 – 030
2700K
031 – 050
3000K
051 – 070
3200K
071 – 090
3500K
091 – 110
4000K
111 – 130
4200K
131 – 150
4500K
151 – 170
5600K
171 – 190
6000K
191 – 210
6500K
211 – 230
7200K
231 – 255
8000K
6
Strobe
000 – 009
No funcon
010 – 099
Strobe from slow to fast (0-25Hz)
100 – 109
No funcon
110 – 179
Lightning strobe
180 – 189
No funcon
190 – 255
Random strobe
7
000 – 255
Zoom
8
Control
000 – 200
No funcon
201 – 220
Zoom reset
221 – 255
No funcon
9
Dimmer Speed
000 – 009
No funcon
010 – 029
O
030 – 069
Dim 1
070 – 129
Dim 2
130 – 189
Dim 3
190 – 255
Dim 4

SSP
CHANNEL
VALUE
FUNCTION
1
000 – 255
Dimmer
2
000 – 255
Red
3
000 – 255
Green
4
000 – 255
Blue
5
000 – 255
White
6
Strobe
000 – 009
No funcon
010 – 099
Strobe from slow to fast (0-25Hz)
100 – 109
No funcon
110 – 179
Lightning strobe
180 – 189
No funcon
190 – 255
Random strobe
7
000 – 255
Zoom
8
Control
000 – 200
No funcon
201 – 220
Zoom reset
221 – 255
No funcon
9
Dimmer Speed
000 – 009
No funcon
010 – 029
O
030 – 069
Dim 1
070 – 129
Dim 2
130 – 189
Dim 3
190 – 255
Dim 4
TOUR
CHANNEL
VALUE
FUNCTION
1
000 – 255
Dimmer
2
000 – 255
Red
3
000 – 255
Green
4
000 – 255
Blue
5
000 – 255
White
6
Colour Macros
000 – 010
No funcon
011 – 170
RGB Macros
171 – 195
All LEDs at full
196 – 200
2700K
201 – 205
3000K
206 – 210
3200K
211 – 215
3500K
216 – 220
4000K
221 – 225
4200K
226 – 230
4500K
231 – 235
5600K

236 – 240
6000K
241 – 245
6500K
246 – 250
7200K
251 – 255
8000K
7
Strobe
000 – 009
No funcon
010 – 099
Strobe from slow to fast (0-25Hz)
100 – 109
No funcon
110 – 179
Lightning strobe
180 – 189
No funcon
190 – 255
Random strobe
8
Auto
000 – 040
No Funcon
041 – 050
Auto 1
051 – 060
Auto 2
061 – 070
Auto 3
071 – 080
Auto 4
081 – 090
Auto 5
091 – 100
Auto 6
101 – 110
Auto 7
111 – 120
Auto 8
121 – 130
Auto 9
131 – 140
Auto 10
141 – 150
Program 1
151 – 160
Program 2
161 – 170
Program 3
171 – 180
Program 4
181 – 190
Program 5
191 – 200
Program 6
201 – 210
Program 7
211 – 220
Program 8
221 – 230
Program 9
231 – 255
Program 10
9
000 – 255
Auto Speed Adjustment
10
000 – 255
Zoom
11
Control
000 – 200
No funcon
201 – 220
Zoom reset
221 – 255
No funcon
12
Dimmer Speed
000 – 009
No funcon
010 – 029
O
030 – 069
Dim 1
070 – 129
Dim 2
130 – 189
Dim 3
190 – 255
Dim 4

TR16
CHANNEL
VALUE
FUNCTION
1
000 – 255
Dimmer
2
000 – 255
Dimmer Fine
3
000 – 255
Red
4
000 – 255
Red Fine
5
000 – 255
Green
6
000 – 255
Green Fine
7
000 – 255
Blue
8
000 – 255
Blue Fine
9
000 – 255
White
10
000 – 255
White Fine
11
Colour Macros
000 – 010
No funcon
011 – 170
RGB Macros
171 – 195
All LEDs at full
196 – 200
2700K
201 – 205
3000K
206 – 210
3200K
211 – 215
3500K
216 – 220
4000K
221 – 225
4200K
226 – 230
4500K
231 – 235
5600K
236 – 240
6000K
241 – 245
6500K
246 – 250
7200K
251 – 255
8000K
12
Strobe
000 – 009
No funcon
010 – 099
Strobe from slow to fast (0-25Hz)
100 – 109
No funcon
110 – 179
Lightning strobe
180 – 189
No funcon
190 – 255
Random strobe
13
Auto
000 – 040
No Funcon
041 – 050
Auto 1
051 – 060
Auto 2
061 – 070
Auto 3
071 – 080
Auto 4
081 – 090
Auto 5
091 – 100
Auto 6
101 – 110
Auto 7
111 – 120
Auto 8
121 – 130
Auto 9
131 – 140
Auto 10
141 – 150
Program 1
151 – 160
Program 2

161 – 170
Program 3
171 – 180
Program 4
181 – 190
Program 5
191 – 200
Program 6
201 – 210
Program 7
211 – 220
Program 8
221 – 230
Program 9
231 – 255
Program 10
14
000 – 255
Auto Speed Adjustment
15
000 – 255
Zoom
16
Control
000 – 200
No funcon
201 – 220
Zoom reset
221 – 255
No funcon
17
Dimmer Speed
000 – 009
No funcon
010 – 029
O
030 – 069
Dim 1
070 – 129
Dim 2
130 – 189
Dim 3
190 – 255
Dim 4
