Show Tec Dancefloor Sparkle RGB V1 User manual

Dancefloor Sparkle RGB V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42330
MANUAL
ENGLISH

1
Ordercode: 42330
Dancefloor Sparkle RGB
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Connection with the mains.........................................................................................................................................4
Return Procedure..........................................................................................................................................................5
Claims..............................................................................................................................................................................5
Description of the device.................................................................................................................................................6
Optional accessories....................................................................................................................................................6
Overview ........................................................................................................................................................................7
Backside .........................................................................................................................................................................7
Installation...........................................................................................................................................................................7
Set Up and Operation .......................................................................................................................................................7
Connecting multiple floor tiles....................................................................................................................................8
Connect the powersupply with the dancefloor.....................................................................................................9
Installation example ...................................................................................................................................................11
Control Modes.............................................................................................................................................................12
Controlled by the remote control ........................................................................................................................12
Controlled by the Dancefloor Sparkle DMX Box ...............................................................................................13
Data Cabling...............................................................................................................................................................13
Remote control ................................................................................................................................................................14
Overview ......................................................................................................................................................................14
Intensity of the LEDS....................................................................................................................................................14
Speed selection ..........................................................................................................................................................14
Color selection ............................................................................................................................................................15
Program selection.......................................................................................................................................................15
Dancefloor Sparkle DMX Box........................................................................................................................................16
Overview ......................................................................................................................................................................16
Backside .......................................................................................................................................................................16
Control Panel ...............................................................................................................................................................17
Control Mode ..............................................................................................................................................................17
DMX Addressing ..........................................................................................................................................................17
Menu Overview...........................................................................................................................................................18
Main Menu Options ....................................................................................................................................................18
DMX Addressing .......................................................................................................................................................18
Built-in programs.......................................................................................................................................................18
Color selection .........................................................................................................................................................19
Interval time/speed .................................................................................................................................................19
Intensity ......................................................................................................................................................................19
DMX Channels .................................................................................................................................................................20
5 Channels ...................................................................................................................................................................20
Maintenance....................................................................................................................................................................22
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25
Notes ..................................................................................................................................................................................26

2
Ordercode: 42330
Dancefloor Sparkle RGB
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear to be damaged from shipping or the carton
itself shows signs of mishandling. Save the carton and all packing materials. In the event that the fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box and
packing.
Your shipment includes:
●1 Tile Dancefloor Sparkle RGB
●1 Dancefloor Connection Plate
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

3
Ordercode: 42330
Dancefloor Sparkle RGB
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s lifespan.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the surface is obviously damaged, it has to be replaced to prevent its functions from being
impaired, due to cracks or deep scratches.
If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement, use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Showtec Dancefloor Sparkle RGB.
The manufacturer will not accept liability for damages caused by the misuse or incorrect installation
of this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electrical connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

4
Ordercode: 42330
Dancefloor Sparkle RGB
Operating Determinations
●This device is not designed for permanent operation. Regular operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be bigger than 0,5
meter.
●The minimum ambient temperature must never be under ta = 0°C.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

5
Ordercode: 42330
Dancefloor Sparkle RGB
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause of the
return. Be sure to properly pack fixture as any shipping damage resulting from inadequate packaging is
the customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that the fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period, complaints will not be handled anymore.
Complaints will only be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

6
Ordercode: 42330
Dancefloor Sparkle RGB
Description of the device
Features
The Showtec Dancefloor Sparkle RGB is a stylish yet user friendly dancefloor which is ideal for wedding,
corporate events, dance parties etc. The dancefloor has a safe low voltage DC connection which
makes it very easy to connect.
●Easy to assemble
●Compact size
●Lightweight
●Audio controlled for each tile
●LED Quantity: 16x RGB LEDs
●LED Type: 5050SMD
●Control protocol: RF
●Control: Programs, Colors, Speed, Brightness, DMX
●DMX channels: 5
●Power consumption: 8W
●IP rating: IP20 back, IP44 top.
●Max load: 150 Kg per panel
●Dimensions: 607 x 607 x 30 mm (LxWxH)
●Weight: 8,5 Kg
Note: Knowledge of DMX is required to fully utilize this unit.
Optional accessories
42331 Dancefloor Sparkle PSU (included remote control)
42332 Dancefloor Sparkle DMX Box
42333 Seperate RF remote control
42335 Ramp 61 cm for Dancefloor Sparkle
42336 Ramp + corner 61 cm for Dancefloor Sparkle
42337 Ramp 122 cm for Dancefloor Sparkle
42338 Dancefloor Connection Plate
42339 Ramp + corner 61 cm (feed-in hole)

7
Ordercode: 42330
Dancefloor Sparkle RGB
Overview
Fig. 01
01) 16x RGB (5050SMD) LEDs
Backside
Fig. 02
02) 2,5 mm DC connection cable male
03) 2,5 mm DC connection cable female
Installation
Remove all packing materials from the Dancefloor Sparkle RGB. Check that all foam and plastic padding
is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

8
Ordercode: 42330
Dancefloor Sparkle RGB
Connecting multiple floor tiles
With the included Dancefloor Connection Plate you can connect multiple tiles and ramps.
You can connect a maximum of four tiles to one Connection Plate.
Take the first tile and place it on the Connection Plate, see figure 03 and 04.
Fig. 03
Fig. 04
(connection plate on each corner)

9
Ordercode: 42330
Dancefloor Sparkle RGB
Then take the second tile and place it on the first and second Connection Plate, see figure 05.
Fig. 05
Proceed this till you have made your desired dancefloor size (figure 05).
To protect the edge of the floor and make a visible boundary, you can use a ramp (42335, 42337), see
figure 06, or a ramp including a corner (42336, 42339), see figure 07.
You can use the special ramp 42339 with the feed-in hole to connect the powersupply to the dancefloor.
Fig. 06
Fig. 07
Connect the powersupply with the dancefloor
To operate the Dancefloor you’ll have to connect the dancefloor with the optional powersupply (42331).
You have to purchase the powersupply in order to provide power to the Dancefloor Sparkle RGB. Please
connect the tiles to the powersupply according to the following steps.
First install the desired number of tiles and connect them with the connector cables. Connect the male
connection cable with the female connection cable, see figure 08.

10
Ordercode: 42330
Dancefloor Sparkle RGB
Fig. 08
If all tiles are properly connected you have to connect the powersupply to the dancefloor. Always
connect the outer tile to the powersupply. Connect one of the five female connectors from the
powersupply to the male connector from the outer tile, see figure 09.
Fig. 09
The powersupply has 5 female connector cables to connect with the dancefloor. Each cable (output)
can link a maximum of 10 tiles at the same time. We recommend to use a maximum of 9 tiles per output.
The powersupply has a total capacity of 400W. After you have linked the first output to the first tile range,
link the second output to the next outer tile. Proceed this till you have used the 5 outputs.
Plug electric mains power cords into the IEC socket from the powersupply, then plug the other end of
the mains power cord into a proper electric power supply socket. Do not supply power before the
whole system is set up and connected properly.
Max. 45 tiles on 1 powersupply

11
Ordercode: 42330
Dancefloor Sparkle RGB
Installation example
9,2 m2Dancefloor Sparkle RGB
The list of needed items:
(A) 25 x Dancefloor Sparkle RGB 0,607 m x 0,607 m (42330)
(B) 36 x Dancefloor Connection Plates (42338)
(C) 16 x Ramp 61 cm for Dancefloor Sparkle (42335)
(D) 3 x Ramp + corner 61 cm for Dancefloor Sparkle (42336)
(E) 1 x Ramp + corner 61 cm (feed-in hole) (42339)
1 x Dancefloor Sparkle PSU (included remote control) (42331)
Optional 1 x Dancefloor Sparkle DMX Box (42332)
Fig.10

12
Ordercode: 42330
Dancefloor Sparkle RGB
Control Modes
There are 2 control modes:
Controlled by the remote control (included with the power supply 42331
or separate available ordercode 42333)
Controlled by the Dancefloor Sparkle DMX Box (42332)
Controlled by the remote control
01) Setup and link the tiles as shown in the previous paragraphs (page 8-11).
02) Use the remote control to operate the dancefloor, see figure 11.
03) For more information about the remote control, see page 14 (Remote control).
Fig. 11

13
Ordercode: 42330
Dancefloor Sparkle RGB
Controlled by the Dancefloor Sparkle DMX Box
01) Setup and link the tiles as shown in the previous paragraphs (page 8-11).
02) Link the DMX lightcontroller with the Dancefloor Sparkle DMX Box by using a DMX-cable.
03) Use the Dancefloor Sparkle DMX Box or DMX lightcontroller to operate the dancefloor, see figure 12.
04) For more information about Dancefloor Sparkle DMX Box, see the chapter Dancefloor Sparkle DMX
Box.
Fig. 12
Data Cabling
To link the Dancefloor Sparkle DMX Box with a suitable lightcontroller you must obtain a data cable. You
can purchase DAP Audio certified DMX cables directly from a dealer/distributor or construct your own
cable. If you choose to create your own cable please use data-grade cables that can carry a high
quality signal and are less prone to electromagnetic interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.Ordercode
FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
•DAP Audio DMX adapter: 3-pin/5-pin. Ordercode FLA30.

14
Ordercode: 42330
Dancefloor Sparkle RGB
Remote control
With the remote control you can control your dancefloor (max distance 20 m). The remote control is not
included with the tile. If you purchase the powersupply (42331), the remote control is included or
separate available ordercode 42333.
When no button is pressed for 10 seconds, the remote control will turn off. To activate the remote control,
you have to press the B- button. Once you have pressed this button, the remote control will be activated
and one of the LED indicators will light up.
Overview
01) LED Indicator Intensity
02) LED Indicator Speed
03) LED Indicator Color
04) A-button: Up / Increase button
05) B-button: Program change / Turn on the remote control
06) C-button: Down / Decrease button
07) : intensity of the LEDs
08) : speed selection
09) : preset colors
Fig. 13
Intensity of the LEDS
With this function you can set the intensity of the LEDs. Press the button and the first LED indicator will
light up. To increase the intensity of the LEDs you have to press the A-button. Press the C-button to
decrease the intensity of the LEDs. The LEDs will light up from dark till brightest in 15 steps.
Note: If you choose color white there are only 11 steps.
Speed selection
With this function you can set the speed of the LEDs during a program. Press the button, the second
LED indicator will light up. To increase the speed you have to press the A-button. Press the C-button to
decrease the speed. The program speed will go from slow to fast in 16 steps.

15
Ordercode: 42330
Dancefloor Sparkle RGB
Color selection
With this function you can select a preset color. Press the button, the third LED indicator will light up. To
select the next color you have to press the A-button. Press the C-button to return to the previous color.
You can choose 16 preset colors.
Color table:
Program selection
With this function you can select a built-in program.
Press the B-button to activate the remote control. Now you can select a program by using the B-button
again, to activate the next program press the B-button. To go back to the previous built-in program press
the B and C-button simultaneously. You can choose 32 built-in programs. To switch faster between these
programs you can use some key combinations, these are (Note: press them simultaneously):
Button A+B:
program 1
Button A+ :
program 3
Button A+ :
program 5
Button A+ :
program 9
Button B+ :
program 13
Button B+ :
program 15
Button B+ :
program 18
Button C+ :
program 20
Button C+ :
program 23
Button C+ :
program 25
Button + :
program 27
Button + :
program 29 (Sound mode, pr.29-31)
Button + :
program 32
Button A+C:
off, stand-by mode

16
Ordercode: 42330
Dancefloor Sparkle RGB
Dancefloor Sparkle DMX Box
With the optional Dancefloor Sparkle DMX Box (42332)you can choose between two options to control
your dancefloor. The first option is to use the menu options 2-5 inside the Dancefloor Sparkle DMX Box.
These will be explained in this chapter. The second option is to control the dancefloor with a DMX
controller. The Dancefloor Sparkle DMX Box has 5 DMX channels to control your dancefloor.
Overview
Fig. 14
01) LED Display + menu buttons
Backside
Fig. 15
02) Input 9V adapter
03) 3-pin DMX signal connector IN
04) 3-pin DMX signal connector OUT
05) Antenna for wireless connection with the dancefloor

17
Ordercode: 42330
Dancefloor Sparkle RGB
Control Panel
A) LED display
B) MENU + button
C) MENU - button
D) UP button
E) DOWN button
Fig. 16
Control Mode
The devices are individually addressed on a data-link and connected to the controller.
The devices respond to the DMX signal from the controller. (When you select the DMX address and save
it, the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the device allows you to assign DMX fixture addresses, which is the
first channel with which the Dancefloor Sparkle DMX Box will respond to the controller.
Please note, when you use the controller, the unit has 5channels.
When using multiple Dancefloor Sparkle DMX Boxes, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Dancefloor Sparkle DMX Box should be 1(d001); the DMX address
of the second Dancefloor Sparkle DMX Box should be 1+5=6 (d006); the DMX address of the third
Dancefloor Sparkle DMX Box should be 6+5=11 (d011), etc. Please, be sure that you do not have any
overlapping channels in order to control each Dancefloor Sparkle DMX Box correctly. If two or more
Dancefloor Sparkle DMX Boxes are addressed similarly, they will work similarly.
Controlling:
After having addressed all Dancefloor Sparkle DMX Boxes, you may now start operating these via your
lighting controller.
Note: After switching on, the Dancefloor Sparkle DMX Box will automatically detect whether DMX 512
data is received or not. If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Dancefloor Sparkle DMX
Box.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last device in order to ensure
proper transmission on the DMX data link.
Display Off after 60 seconds
When no button is pressed for 60 seconds, the display will turn off.
To light up the display, you have to press the MENU +, MENU - , UP or DOWN button.
Once you have pressed the button, the display will light up.

18
Ordercode: 42330
Dancefloor Sparkle RGB
Menu Overview
Main Menu Options
DMX address
Built in programs
Color selection
Interval time/speed
Intensity
DMX Addressing
With this menu you can set the DMX address.
01) Press the MENU+ button until the display shows .
02) You can choose 512 different DMX addresses.
03) Use the UP/DOWN buttons to select the required address from .
04) Press the MENU+ and MENU- buttons simultaneously to save the desired DMX address.
05) The device will remember the last saved address when starting up.
Built-in programs
With this menu you can choose a built-in program.
01) Press the MENU+ button until the display shows .
02) You can choose 32 different built-in programs.
03) Use the UP/DOWN buttons to select the desired program from .
04) is the stand-by mode.
05) Press the MENU+ and MENU- buttons simultaneously to save the desired built-in program.
06) The device will remember the last saved built-in program when starting up.

19
Ordercode: 42330
Dancefloor Sparkle RGB
Color selection
With this menu you can choose a desired color.
01) Press the MENU+ button until the display shows .
02) You can choose 16 preset colors.
03) Use the UP/DOWN buttons to select the desired color from .
04) Press the MENU+ and MENU- buttons simultaneously to save the desired color.
05) The device will remember the last saved preset color when starting up.
Interval time/speed
With this menu you can set the interval time of the steps from the built-in programs.
01) Press the MENU+ button until the display shows .
02) You can choose 16 interval times.
03) Use the UP/DOWN buttons to select the desired interval time/speed from .
04) Press the MENU+ and MENU- buttons simultaneously to save the desired interval time/speed.
05) The device will remember the last saved interval time/speed when starting up.
Intensity
With this menu you can set the intensity of the LEDs.
01) Press the MENU+ button until the display shows .
02) You can choose 16 intensity steps.
03) Use the UP/DOWN buttons to select the desired intensity from .
04) Press the MENU+ and MENU- buttons simultaneously to save the desired intensity.
05) The device will remember the last saved intensity when starting up.
Note: If you choose color white there are only 11 steps.
