Show Tec White-PIX V1 User manual

White-PIX V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42278
MANUAL
ENGLISH

1
Ordercode: 42278
White-PIX
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................9
Vertical Installation of White-PIX ................................................................................................................................9
Control Modes.............................................................................................................................................................10
One PIX device (Auto Mode)................................................................................................................................10
Multiple PIX device (Master/Slave control) ........................................................................................................10
Multiple PIX devices (DMX Control)......................................................................................................................11
Multiple PIX devices (ArtNet/KlingNet Control)..................................................................................................12
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
Control Mode ..............................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Menu Overview...........................................................................................................................................................15
Main Menu Options....................................................................................................................................................15
1. Auto Mode............................................................................................................................................................16
2. DMX Channels......................................................................................................................................................16
3. DMX Address ........................................................................................................................................................16
4. Software Information ..........................................................................................................................................17
5. Network Settings ..................................................................................................................................................17
6. Master/Slave Mode.............................................................................................................................................17
DMX Channels .............................................................................................................................................................18
6 channels .................................................................................................................................................................18
25 channels...............................................................................................................................................................19
Connecting to a Network ..............................................................................................................................................20
KlingNet settings ..........................................................................................................................................................20
ArtNet settings .............................................................................................................................................................20
How to make a data cable......................................................................................................................................21
Software for controlling .............................................................................................................................................21
Maintenance....................................................................................................................................................................22
Replacing the Fuse.....................................................................................................................................................22
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................23
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25
Notes ..................................................................................................................................................................................26

2
Ordercode: 42278
White-PIX
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec White-PIX
Blue/White power cable (1,5 m)
2 x safety cable
2 x quick-locks
1 x mounting bracket
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.

3
Ordercode: 42278
White-PIX
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•The user is responsible for correct positioning and operating of the White-PIX. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

4
Ordercode: 42278
White-PIX
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
The projector must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
Improper installation can cause serious injuries and/or damage of property!

5
Ordercode: 42278
White-PIX
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 42278
White-PIX
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail aftersal[email protected] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 42278
White-PIX
Description of the device
Features
The White-PIX is a LED panel with pixel control. It supports the most popular control protocols, such as:
DMX, ArtNet and KlingNet.
Power Supply: 100-240 VAC, 60/50Hz
Power Consumption: 80W
Light Source: 25 x 3W Edison White LED
Light output: 160 lumen
Color temperature: 3200K
Control Protocol: DMX-512, ArtNet, KlingNet
Built-in programs: 30 programs
DMX channels: 6 and 25 channels
Onboard: LCD display for easy setup
Connectors: Blue/White power connector and 3-pin XLR, RJ45 IN/OUT
Cooling: Convection
Dimmer: 0-100%
Strobe: 0-30Hz
Field angle: 8º
Pixels: 5H x 5V
Pixel pitch: 60 mm
Housing: Die-cast aluminium and flame retardant plastic
IP rating: IP20
Fuse: F5AL/250V
Dimensions: 300 x 90 x 345 mm (LxWxH)
Weight: 4 kg
Frontside
Fig. 01
01) 25 x 3W Edison White LED

8
Ordercode: 42278
White-PIX
Backside
Fig. 02
02) Mounting bracket with inclination screw
03) Mounting rail with mounting screw
04) Adjustment screw
05) Blue/White power connector 100-240V OUT
06) 3-pin DMX signal connector OUT
07) RJ45 ArtNet/KlingNet signal connectors IN/OUT
08) 3-pin DMX signal connector IN
09) Fuse F5AL/250V
10) Blue/White power connector 100-240V IN
11) LCD display + menu buttons
Installation
Remove all packing materials from the White-PIX. Check if all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

9
Ordercode: 42278
White-PIX
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Vertical Installation of White-PIX
It is possible to install multiple White-PIX devices by attaching them to each other in a vertical position.
Follow the instructions below to carry out the installation process.
Fig. 03
01) Loosen the mounting screws on the White-PIX #1 and release the mounting rail.
02) Insert the mounting rail in the slot on the White-PIX #2.
03) Tighten the mounting screws to secure both White-PIX in position.
04) Secure the installation, using a safety cable and clamps.
The mounting rails enable seamless installation of the fixtures.
You can attach up to 10 devices.

10
Ordercode: 42278
White-PIX
Control Modes
There are 3 modes:
•Auto Mode
•Master/Slave
•DMX-512 (6CH and 25CH)/ArtNet/KlingNet
One PIX device (Auto Mode)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the White-PIX is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 16 for more information about Auto Mode.
Multiple PIX device (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the White-PIX.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on page 16 (Auto Mode). This
means that you can set your desired operation mode on the master device and all slave devices
will react the same as the master device.
Multiple PIX devices (Master/Slave control)
Fig. 04

11
Ordercode: 42278
White-PIX
Multiple PIX devices (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the PIX and other devices.
04) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple PIX devices DMX Set Up
Fig. 05
Note : Link all cables before connecting electric power

12
Ordercode: 42278
White-PIX
Multiple PIX devices (ArtNet/KlingNet Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a CAT-5/CAT-6 cable to connect the White-PIX and other KlingNet devices.
04) Link the units as shown in fig. 06. Connect the first unit's RJ45 "out" socket with the second unit's "in"
socket, using a CAT-5/CAT-6 signal cable. Repeat this process to link the second, third, and fourth
units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple PIX devices ArtNet/KlingNet Set Up
Fig. 06
Note : Link all cables before connecting electric power

13
Ordercode: 42278
White-PIX
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
DAP Audio PC Interface Cables
CAT-5 cable 7,6 mm Matte blue PVC. Ordercode FL55150 (1,5 m), FL553 (3 m), FL556 (6 m),
FL5510 (10 m), FL5515 (15 m), FL5520 (20 m).
CAT-6 cable (recommended for best data transfer). Ordercode FL563 (3 m), FL566 (6 m),
FL5610 (10 m), FL5615 (15 m), FL5640 (40 m).

14
Ordercode: 42278
White-PIX
The White-PIX can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) LCD display
B) MENU button
C) ENTER button
D) UP button
E) DOWN button
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the White-PIX will respond to the controller.
Please note, when you use the controller, the unit has 25 channels.
When using multiple PIX devices, make sure you set the DMX addresses right.
Therefore, the DMX address of the first White-PIX should be 1(001); the DMX address of the second White-
PIX should be 1+25=26 (026); the DMX address of the third White-PIX should be 26+25=51 (051), etc.
Please, be sure that you do not have any overlapping channels in order to control each White-PIX
correctly. If two or more PIX devices are addressed similarly, they will work similarly.
Controlling:
After having addressed all White-PIX fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the White-PIX will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the White-PIX.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 25 seconds
When no button is pressed for 25 seconds, the display will turn off.
To light up the display, you have to press the MENU, ENTER, UP or DOWN button.
Once you have pressed the button, the display will light up.

15
Ordercode: 42278
White-PIX
Menu Overview
Main Menu Options
Auto Mode
DMX channels
DMX address
Software information
Network settings
Master/Slave Mode

16
Ordercode: 42278
White-PIX
1. Auto Mode
With this menu, you can set the built-in programs.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 2 options:
Program speed
Program choice
04) When the display shows , press the ENTER button to open the menu.
05) Press the UP/DOWN buttons to increase/decrease the program speed. The adjustment range is
between , from slow to fast.
06) Press the ENTER button to save changes.
07) When the display shows , press the ENTER button to open the menu.
08) Press the UP/DOWN buttons to toggle between the available programs:
. You can choose between 29
programs and Mix (all the built-in programs will be displayed in a sequence).
09) Press the ENTER button to save changes.
2. DMX Channels
With this menu, you can set the desired channel mode.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between the 2 DMX channel modes:
6-channel mode
25-channel mode
04) Press the ENTER button to confirm your choice.
3. DMX Address
With this menu, you can set the desired DMX address.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose the desired DMX address. The adjustment range is between
(in 25-channel mode) or
(in 6-channel mode).
04) Press the ENTER button to save changes.

17
Ordercode: 42278
White-PIX
4. Software Information
With this menu, you can check the currently installed software version.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) The display shows the current software version: .
5. Network Settings
With this menu, you can adjust the device’s properties, such as the IP address, subnet mask and the
universes.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the following 3 options:
IP address
Subnet mask
Universe
04) Once you have chosen one of the options listed above, press the ENTER button to proceed to
edition mode.
05) Press the UP/DOWN buttons to choose the piece of the IP address/Subnet mask/Universe which
needs to be adjusted and which is indicated by the [bracket.
06) Press the ENTER button to confirm your choice.
07) Press the UP/DOWN buttons to adjust the desired seting.
08) Press the ENTER button to save changes.
6. Master/Slave Mode
With this menu, you can set the device as a slave.
01) Press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to choose between “Yes” or “No”.
04) Press the ENTER button to confirm your choice.

18
Ordercode: 42278
White-PIX
DMX Channels
6 channels
Channel 1 –Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 –Strobe Dimmer must be open
0-255
Strobe frequency, from low to high frequency
Channel 3 –LED intensity Dimmer must be open
0-255
Gradual adjustment LED, from 0-100%
Channel 4 –Built-in programs 1-15 Dimmer must be open and CH3 must be set to 0
0-15
Not functional
16-31
Program 1
32-47
Program 2
48-63
Program 3
64-79
Program 4
80-95
Program 5
96-111
Program 6
112-127
Program 7
128-143
Program 8
144-159
Program 9
160-175
Program 10
176-191
Program 11
192-207
Program 12
208-223
Program 13
224-239
Program 14
240-255
Program 15
Channel 5 –Built-in programs 16-30 Dimmer must be open and CH3 must be set to 0
0-15
Not functional
16-31
Program 1
32-47
Program 2
48-63
Program 3
64-79
Program 4
80-95
Program 5
96-111
Program 6
112-127
Program 7
128-143
Program 8
144-159
Program 9
160-175
Program 10
176-191
Program 11
192-207
Program 12
208-223
Program 13
224-239
Program 14
240-255
Program 15
Channel 6 –Program speed
0-255
Speed adjustment, from slow to fast

19
Ordercode: 42278
White-PIX
25 channels
Channel 1 –LED 1
0-255
Gradual adjustment LED, from 0-100%
Channel 2 –LED 2
0-255
Gradual adjustment LED, from 0-100%
Channel 3 –LED 3
0-255
Gradual adjustment LED, from 0-100%
Channel 4 –LED 4
0-255
Gradual adjustment LED, from 0-100%
Channel 5 –LED 5
0-255
Gradual adjustment LED, from 0-100%
Channel 6 –LED 6
0-255
Gradual adjustment LED, from 0-100%
Channel 7 –LED 7
0-255
Gradual adjustment LED, from 0-100%
Channel 8 –LED 8
0-255
Gradual adjustment LED, from 0-100%
Channel 9 –LED 9
0-255
Gradual adjustment LED, from 0-100%
Channel 23 –LED 23
0-255
Gradual adjustment LED, from 0-100%
Channel 24 –LED 24
0-255
Gradual adjustment LED, from 0-100%
Channel 25 –LED 25
0-255
Gradual adjustment LED, from 0-100%
