Show Tec Performer 3000 LED User manual

Performer 3000 LED V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 33043
MANUAL
ENGLISH

1
Ordercode: 33043
Performer 3000 LED
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Features ..........................................................................................................................................................................7
Overview ........................................................................................................................................................................7
Backside .........................................................................................................................................................................9
Installation.........................................................................................................................................................................10
Set Up and Operation .....................................................................................................................................................10
Color frame retaining clip .........................................................................................................................................10
Setting the angle ........................................................................................................................................................10
Control Modes.............................................................................................................................................................11
One Performer (Stand-alone) ...............................................................................................................................11
Multiple Performers (Master/Slave control) ........................................................................................................11
Multiple Performers (DMX Control) .......................................................................................................................12
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
Control Mode ..............................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Menu Overview...........................................................................................................................................................15
Main Menu Options....................................................................................................................................................16
1. DMX-512 Mode ....................................................................................................................................................16
2. Run Mode..............................................................................................................................................................16
3. Zoom/Dimmer settings........................................................................................................................................16
4. White color calibration .......................................................................................................................................17
5. General settings...................................................................................................................................................17
5.1. Dimming curve settings ...................................................................................................................................18
5.2. Dimmer speed ..................................................................................................................................................18
5.3. Safety key...........................................................................................................................................................18
5.4. DMX data transfer ............................................................................................................................................18
5.5. Performance settings.......................................................................................................................................19
5.6. Zoom range settings ........................................................................................................................................19
5.7. Save DMX/Blackout .........................................................................................................................................19
5.8. Settings menu safety lock ...............................................................................................................................19
5.9. DMX channel modes .......................................................................................................................................19
5.10 Reset settings....................................................................................................................................................20
6. Motor reset............................................................................................................................................................20
DMX Channels .............................................................................................................................................................20
1 channel ..................................................................................................................................................................20
2 channels .................................................................................................................................................................20
5 channels .................................................................................................................................................................20
Cleaning............................................................................................................................................................................21
Cleaning the glass lens ..............................................................................................................................................21
Maintenance....................................................................................................................................................................21
Replacing the Fuse.....................................................................................................................................................21
Troubleshooting ...............................................................................................................................................................22
No Light.........................................................................................................................................................................22
No Response to DMX..................................................................................................................................................22
Product Specifications....................................................................................................................................................24
Dimensions........................................................................................................................................................................25
Notes ..................................................................................................................................................................................26

2
Ordercode: 33043
Performer 3000 LED
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Performer 3000 LED
1 color frame
1 safety cable
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 33043
Performer 3000 LED
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Never leave the unit running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 33043
Performer 3000 LED
•The user is responsible for correct positioning and operating of the Performer. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
Improper installation can cause serious injuries and/or damage of property!

5
Ordercode: 33043
Performer 3000 LED
The Performer can be put on a flat stage floor or mounted to any kind of truss with a clamp.
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 33043
Performer 3000 LED
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 33043
Performer 3000 LED
Description of the device
Features
The Showtec Performer 3000 LED is a theater spotlight fixture with high output and great effects.
Light Source: 32 x 10W Cree White LED
Input Voltage: 100-240V AC, 60/50Hz
Power Consumption: 320W
Light output: 8400 Lumen
Lux @ 2 m 15º: 20497
Peak Intensity: 82091 cd
Color Rendering: >85 Ra
Color Temperature: 3200K
Dimmer: 0-100%
Dim Curve: Dimm4 technology, 4 presets
Strobe: 0-20Hz
Motorized zoom: 15-60º
Control modes: Stand-alone, Master/Slave, DMX -512
Connections: 3- and 5-pin XLR signal connectors IN/OUT, PowerCON power connectors IN/OUT
Refresh Rate: 600Hz
Power Linking: 4 units @ 110V; 8 units @ 220V
DMX channels: 1, 2, or 5 channels
Extremely quiet
Housing: Die-cast aluminum & flame retardant plastic
Cooling: Internal fan
IP Rating: IP20
Fuse: T5AL/250V
Dimensions: 425 x 335 x 445 mm (LxWxH)
Weight: 8 kg
Optional accessories
33044 –Barndoor for Performer 3000
Overview
Fig. 01

8
Ordercode: 33043
Performer 3000 LED
Fig. 02
01) Barn door/lens cover
02) Retaining clip
03) Fresnel lens
04) 5º frosted lens
05) Front cover
06) Top cover
07) Mounting bracket with inclination screw
08) Transmission bar
09) Slide block
10) Thermal switch
11) LED board
12) Heat sink
13) Cooling fan
14) Motor
15) Magnetic sensor
16) Tilt belt
17) Rear cover
18) Rear plate
19) Fuse T5AL/250V
20) Control board
21) Driver board
22) PCB adapter
23) PS socket
24) PS socket
25) Adjustment screw
26) Aluminum cover
27) Power supply
28) Cooling fan
29) Dust cover

9
Ordercode: 33043
Performer 3000 LED
Backside
Fig. 03
30) PowerCON power connector 100-240V IN
31) 3-pin DMX signal connector IN
32) 5-pin DMX signal connector IN
33) 3-pin DMX signal connector OUT
34) 5-pin DMX signal connector OUT
35) PowerCON power connector 100-240V OUT
36) Fuse T5AL/250V
37) LED display + control buttons

10
Ordercode: 33043
Performer 3000 LED
Installation
Remove all packing materials from the Performer 3000 LED. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Color frame retaining clip
The color frame holder is equipped with a spring-loaded retaining clip. This prevents color frames and
accessories from falling out.
Make sure that all color frame accessories are locked in position with the retaining clip
before hanging the Performer 3000 LED.
01) Release the retaining clip by pressing the lock towards the lens and pressing the longer side of the
screw. The retaining clip will open.
02) Insert the color frame(s).
03) Lock the retaining clip by pressing the retaining clip towards the lens.
Fig. 04
Setting the angle
01) Loosen the adjustment screw (25).
02) Tilt the fixture to the desired position.
03) Tighten the adjustment screw (25) to secure the fixture in position.

11
Ordercode: 33043
Performer 3000 LED
Control Modes
There are 3 modes:
•Stand-alone
•Master/Slave
•DMX-512 (1CH, 2CH, 5 CH)
One Performer (Stand-alone)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Performer is not connected with a DMX cable, it functions as a stand-alone device.
Please see pages 16-20 for more information.
Multiple Performers (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Performer.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 16-20. This means that
you can set your desired operation mode on the master device and all slave devices will react the
same as the master device.
Multiple Performers (Master/Slave control)
Fig. 05

12
Ordercode: 33043
Performer 3000 LED
Multiple Performers (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Performers and other devices.
04) Link the units as shown in fig. 06. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Performers DMX Set Up
Fig. 06
Note : Link all cables before connecting electric power

13
Ordercode: 33043
Performer 3000 LED
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a Powercon link: 4 units @110V
Maximum recommended number of fixtures on a Powercon link: 8 units @220V
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

14
Ordercode: 33043
Performer 3000 LED
The Performer 3000 LED can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) MENU button
B) ENTER button
C) DOWN button
D) UP button
E) ZOOM control
F) LED display
G) DIMMER control
Fig. 07
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Performer will respond to the controller.
Please note, when you use the controller, the unit has 5channels.
When using multiple Performers, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Performer should be 1(001); the DMX address of the second
Performer should be 1+5=6 (006); the DMX address of the third Performer should be 6+5=11 (011), etc.
Please, be sure that you do not have any overlapping channels in order to control each Performer
correctly. If two or more Performers are addressed similarly, they will work similarly.
Controlling:
After having addressed all Performer fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Performer will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED“ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Performer 3000 LED.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MENU, UP, DOWN, ENTER button or press the DIMMER or
ZOOM control. Once you have pressed the button, the display will light up.

15
Ordercode: 33043
Performer 3000 LED
Menu Overview

16
Ordercode: 33043
Performer 3000 LED
Main Menu Options
DMX-512 Mode
Run Mode
Zoom/Dimmer settings
White color calibration
General settings
Motor reset
1. DMX-512 Mode
In this mode you can set the DMX address.
01) While in the main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to set the desired DMX address. The adjustment range is between
.
2. Run Mode
In this mode you can set the device as a master or slave.
01) While in the main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the 2 options:
Master Mode (DMX-controlled)
Slave mode
04) If the display shows , the Performer will become a master device and will utilize the DMX
protocol to determine its performance.
05) If the display shows , the Performer will become a slave device and will react the same as the
master device.
3. Zoom/Dimmer settings
You can enter the Zoom/Dimmer settings by pressing the ZOOM/DIMMER controls (on the control panel
(37)) twice. You can also gain access by following the instructions below.
01) While in the main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) Press the UP/DOWN buttons to toggle between the 2 options:
Zoom
Dimmer
04) When the display shows , press the ENTER button to open the zoom settings.
05) Press the UP/DOWN buttons (or turn the ZOOM control on the control panel (36)) to
increase/decrease the zoom factor. The adjustment range is between , from
low to high.
06) When the display shows , press the ENTER button to open the dimmer intensity settings.
07) Press the UP/DOWN buttons (or turn the DIMMER control on the control panel (36)) to
increase/decrease the dimmer intensity. The adjustment range is between ,
from dark to brightest.

17
Ordercode: 33043
Performer 3000 LED
4. White color calibration
01) While in the main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) If the display shows , you need to insert a key combination which will unlock the menu.
04) Insert the key combination by pressing the buttons in the following order: UP, DOWN, UP, DOWN,
ENTER. The display will show .
05) Press the ENTER button to proceed to zoom range selection.
06) Press the UP/DOWN buttons to choose one of the 2 options: or .
07) Once you have chosen one of the 2 zoom ranges, press the ENTER button to open its submenu.
08) Press the UP/DOWN buttons to increase/decrease the zoom factor. The adjustment range is between
, from low to high.
5. General settings
01) While in the main menu, press the UP/DOWN buttons until the display shows .
02) Press the ENTER button to open the menu.
03) If the display shows , you need to insert a key combination which will unlock the menu.
04) Insert the key combination by pressing the buttons in the following order: UP, DOWN, UP, DOWN,
ENTER.
05) Press the UP/DOWN buttons to toggle between the following options:
Dimming curve settings
Dimmer speed
Safety key
DMX data transfer
Performance settings
Zoom range settings
Save DMX/Blackout
Settings menu safety lock
DMX channel modes
Reset settings

18
Ordercode: 33043
Performer 3000 LED
5.1. Dimming curve settings
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose the desired dimming curve out of the 4 available options:
5.2. Dimmer speed
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to choose one of the 5 options:
OFF
Dimmer speed, from fast to slow
5.3. Safety key
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between to deactivate/activate the
safety lock.
03) When the option is active, you will need to insert the safety key combination every time the display
turns off.
5.4. DMX data transfer
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
DMX data transfer OFF
DMX data transfer ON
03) If the display shows , the Performer will not send DMX data to the other connected devices.
04) If the display shows , the Performer will send DMX data to the other connected devices.

19
Ordercode: 33043
Performer 3000 LED
5.5. Performance settings
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 3 modes:
Default mode. It provides a compromise between output
quality and noise level.
Output-oriented mode. The device does not offer any
consideration for noise level and operates at full power.
Noise level-oriented mode. It emits little noise and operates at
moderate power level.
5.6. Zoom range settings
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the following 3 options:
Zoom, basic position
Zoom, 1st position
Zoom, 2nd position
5.7. Save DMX/Blackout
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 2 options:
Blackout
DMX data save
03) If the display shows , the Performer will black the output out, in case of a DMX signal error.
04) If the display shows , the Performer will fall back on the last working DMX signal, which will
ensure undisrupted performance.
5.8. Settings menu safety lock
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between to deactivate/activate the
menu lock.
03) When the option is active, you will always need to insert the safety key in attempt to enter the
Settings menu.
04) When the option is inactive, the Settings menu will not get locked, providing that the device remains
in it.
05) If the display shows and turns off after 30 seconds –you will need to re-insert the safety key,
anyway.
5.9. DMX channel modes
01) When the display shows , press the ENTER button to open the menu.
02) Press the UP/DOWN buttons to toggle between the 3 channel modes:
1-channel mode
2-channel mode
5-channel mode
