Show Tec Helios 200 COB Q4 User manual

Helios 200 COB Q4 V3
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 43715
MANUAL
ENGLISH

Ordercode: 43715
Helios 200 COB Q4
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions.........................................................................................................................................................2
Operating Determinations..........................................................................................................................................4
Rigging............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................9
Backside .......................................................................................................................................................................10
Installation.........................................................................................................................................................................10
Set Up and Operation.....................................................................................................................................................11
Control Modes.............................................................................................................................................................11
One Helios (Manual Mode, Auto Mode, Built-in programs and Sound-controlled)...................................11
Multiple Helioses (Master/Slave control).............................................................................................................11
Multiple Helioses (DMX Control)............................................................................................................................12
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel...............................................................................................................................................................14
Control Mode ..............................................................................................................................................................14
DMX Addressing..........................................................................................................................................................14
Menu Overview...........................................................................................................................................................15
Main Menu Options....................................................................................................................................................16
1. DMX-512 Mode ....................................................................................................................................................16
2. Sound-controlled.................................................................................................................................................16
3. Manual Mode (Static Color Mode) .................................................................................................................16
4. Settings...................................................................................................................................................................17
4.1. Dimming curves................................................................................................................................................17
4.2. Dimmer speed ..................................................................................................................................................17
4.3. LCD Backlight....................................................................................................................................................17
4.4. Factory Reset.....................................................................................................................................................17
4.5. DMX Fail..............................................................................................................................................................17
4.6. Synchronous DMX.............................................................................................................................................18
5. Info..........................................................................................................................................................................18
6. Auto Mode............................................................................................................................................................18
7. Built-in Programs...................................................................................................................................................18
8. Slave Mode...........................................................................................................................................................19
DMX Channels.............................................................................................................................................................19
4 channels.................................................................................................................................................................19
6 channels.................................................................................................................................................................19
7 channels.................................................................................................................................................................20
8 channels.................................................................................................................................................................20
11 channels...............................................................................................................................................................21
Maintenance....................................................................................................................................................................23
Troubleshooting ...............................................................................................................................................................23
No Light.........................................................................................................................................................................23
No Response to DMX..................................................................................................................................................24
Product Specifications....................................................................................................................................................25
Dimensions........................................................................................................................................................................26
1

Ordercode: 43715
Helios 200 COB Q4
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
•Showtec Helios 200 COB Q4
•Pro power cable (1,5 m)
•User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
2

Ordercode: 43715
Helios 200 COB Q4
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the Helios. The manufacturer will not
accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
3

Ordercode: 43715
Helios 200 COB Q4
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
4

Ordercode: 43715
Helios 200 COB Q4
The Helios can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!
5

Ordercode: 43715
Helios 200 COB Q4
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.
6

Ordercode: 43715
Helios 200 COB Q4
Description of the device
Features
The Showtec Helios 200 COB is a die-cast spot effect with RGBW color mixing. The COB technology with
RGBW colors offers an excellent color mix, which can be used for making both, high saturated and pastel
colors. The 16-character LCD display with a user-friendly menu structure makes it convenient to apply
your desired settings.
•Input voltage: 100-240V AC, 60/50Hz
•Power consumption: 210W
•Light source: 1 x 200W COB RGBW
•Lux @2m: 2036
•Refresh rate:12kHz
•Control protocol: DMX-512
•DMX channels: 4, 6, 7, 8, 11 channels
•Control modes: Built-in programs, Auto, DMX, Master/Slave, Sound-controlled, Manual
•Dimmer: 0-100%
•Strobe: 0-20Hz
•Beam angle: 15°-60°
•Housing: Die-cast aluminum
•Connections: 3-pin/5-pin XLR connectors IN/OUT & Pro Power IN/OUT
•Cooling: Cooling fan
•Color: Black
•Dimensions: 400 x 270 x 370 mm (LxWxH)
•Weight: 4,54 kg
15°
Lux @ 1 - 5m
1 m
2 m
3 m
4 m
5 m
Red
6190
1650
765
428
257
Green
10600
2908
1331
753
401
Blue
2260
610
280
160
104
White
12120
3239
1458
764
539
FULL ON
27340
7560
3412
1910
1159
7

Ordercode: 43715
Helios 200 COB Q4
30°
Lux @ 1 - 5m
1 m
2 m
3 m
4 m
5 m
Red
3624
929
451
245
160
Green
6540
1717
795
461
300
Blue
1370
366
167
97
64
White
7340
1940
895
525
340
FULL ON
16240
4400
2000
1180
760
60°
Lux @ 1 - 5m
1 m
2 m
3 m
4 m
5 m
Red
1441
410
200
119
79
Green
2627
746
360
216
143
Blue
550
161
75
45
30
White
2761
803
386
235
153
FULL ON
6400
2036
960
577
378
8

Ordercode: 43715
Helios 200 COB Q4
Frontside
Fig. 01
01) Adjustment screw
02) Double mounting bracket
03) 1 x 200W COB RGBW
9

Ordercode: 43715
Helios 200 COB Q4
Backside
Fig. 02
04) LCD display + control buttons
05) 5-pin DMX signal connector IN
06) 3-pin DMX signal connector IN
07) Pro power connector 100-240V IN
08) Pro power connector 100-240V OUT
09) 3-pin DMX signal connector OUT
10) 5-pin DMX signal connector OUT
Installation
Remove all packing materials from the Helios 200 COB Q4. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
10

Ordercode: 43715
Helios 200 COB Q4
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
Control Modes
There are 6 modes:
•Manual Mode (Static Color)
•Auto Mode
•Built-in programs
•Sound-controlled
•Master/Slave
•DMX-512 (4CH, 6CH, 7CH, 8CH, 11CH)
One Helios (Manual Mode, Auto Mode, Built-in programs and Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Helios is not connected with a DMX cable, it functions as a stand-alone device.
04) Turn on the music. If the device is set to sound-control, then the Helios will react to the beat of the
music.
05) Please see page 16-18 for more information about the Built-in programs, Auto mode, Sound-
controlled and Manual mode.
Multiple Helioses (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin/5-pin XLR cable to connect the Helios.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 16-18 (Built-in
programs, Auto mode, Manual mode or Sound-controlled mode). This means that you can set your
desired operation mode on the master device and all slave devices will react the same as the
master device.
Multiple Helioses (Master/Slave control)
Fig. 03
11

Ordercode: 43715
Helios 200 COB Q4
Multiple Helioses (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Helioses and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's Pro power socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Helioses DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power
12

Ordercode: 43715
Helios 200 COB Q4
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
13

Ordercode: 43715
Helios 200 COB Q4
The Helios 200 COB Q4 can be operated with a DMX controller in control mode or without the DMX
controller in stand-alone mode.
Control Panel
A) LCD display
B) MODE button
C) SETUP button
D) UP button
E) DOWN button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Helios will respond to the controller.
Please note, when you use the controller, the unit has 11 channels.
When using multiple Helioses, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Helios should be 1(001); the DMX address of the second Helios
should be 1+11=12 (012); the DMX address of the third Helios should be 12+11=23 (023), etc. Please, be
sure that you do not have any overlapping channels in order to control each Helios correctly. If two or
more Helioses are addressed similarly, they will work similarly.
Controlling:
After having addressed all Helios fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Helios will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Helios 200 COB Q4.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 60 seconds
When no button is pressed for 60 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.
14

Ordercode: 43715
Helios 200 COB Q4
Menu Overview
15

Ordercode: 43715
Helios 200 COB Q4
Main Menu Options
1. DMX-512 mode
2. Sound-controlled mode
3. Manual mode (Static Color mode)
4. Settings
5. Info
6. Auto Mode
7. Built-in programs
8. Master/Slave mode
The Helios 200 COB Q4 will show its version number at start-up!
1. DMX-512 Mode
With this menu you can set the DMX address.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu. You can choose 512 different DMX addresses.
03) Press the UP/DOWN buttons to select the required address from .
04) Once you have set the desired DMX address, you can also choose one of the 3 DMX channel
modes.
05) Press the SETUP button to proceed to channel mode selection.
06) Press the UP/DOWN buttons to choose between 4, 6, 7, 8 or 11 channel modes:
2. Sound-controlled
With this menu you can you can set the sound sensitivity.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to select the required sensitivity from , from OFF to
high sound sensitivity.
04) Turn on the music and the Helios will react to the beat of the music.
3. Manual Mode (Static Color Mode)
With this menu you can manually set the desired color.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Repeatedly press the SETUP button to toggle between the following color settings: RED, GREEN, BLUE
and WHITE.
04) Press the UP/DOWN buttons to adjust the intensity of each of the color LEDs. The adjustment range is
between 0-255, from low to high intensity. You can combine RED, GREEN, BLUE and WHITE to create
an infinite range of colors.
16

Ordercode: 43715
Helios 200 COB Q4
4. Settings
With this menu you can manually adjust the device’s settings.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to toggle through the following menus:
Dimming curves
Dimmer speed
LCD Backlight
Factory Reset
DMX Clear
Synchronous DMX
4.1. Dimming curves
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose one of the 4 dimming curves: linear, square, inverted square
and S-type.
4.2. Dimmer speed
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose between Fast or Smooth.
4.3. LCD Backlight
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to select the desired LCD backlight time. The adjustment range is from
ON (display remains continuously ON) and 10/20/30/60s (the amount of time after which the display
will turn OFF, if no button is pressed).
4.4. Factory Reset
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose between Yes and No.
04) Press the SETUP button to confirm your choice.
05) If you have chosen Yes, the device will restore the factory settings.
4.5. DMX Fail
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose OFF or HOLD.
04) If you have chosen OFF, the device perform a blackout (when a DMX signal error occurs).
05) If you have chosen HOLD, the device will use the last working DMX signal from before the DMX error,
which ensures undisrupted performance.
17

Ordercode: 43715
Helios 200 COB Q4
4.6. Synchronous DMX
01) Press the UP/DOWN buttons until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to choose ON or OFF.
04) If you have chosen ON and you are operating the device(s) in Master/Slave mode, the devices will
keep moving synchronously, even after a certain amount of time.
05) It is highly advisable to keep this option set to ON position, all the time.
5. Info
With this menu you can view the software version and the device’s current temperature.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu.
03) Press the UP/DOWN buttons to toggle between temperature and software version.
04) Once you have chosen one of these options, press the SETUP button to view the information.
6. Auto Mode
With this menu you can activate Auto mode.
01) Press the MODE button on the device, until the display shows .
02) The device will now run all the available built-in programs in a sequence. It is not possible to adjust
any settings in Auto mode.
7. Built-in Programs
With this menu you can you can set the built-in programs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to open the menu.
03) Press the UP/DOWN buttons to toggle through the 16 built-in programs.
04) Press the UP/DOWN buttons to choose .
05) Press the SETUP button to open the menu. Press the UP/DOWN buttons to choose one of the 33 color
macros and black.
06) Press the SETUP button again to proceed to strobe settings. Press the UP/DOWN buttons to
increase/decrease the strobe frequency. The adjustment range is between ,
from OFF to high strobe frequency.
07) Return to step 4 and choose one of the built-in programs: .
08) Press the SETUP button to open the menu.
09) Press the UP/DOWN buttons to increase/decrease the program speed. The adjustment range is
between , from slow to fast.
10) Press the SETUP button again to proceed to strobe settings. Press the UP/DOWN buttons to
increase/decrease the strobe frequency. The adjustment range is between ,
from OFF to high strobe frequency.
18

Ordercode: 43715
Helios 200 COB Q4
8. Slave Mode
With this menu you can set the slave mode.
01) Press the MODE button until the display shows .
If the device has not been set to slave, it is automatically classified as a master device. All slave
devices will follow the movement of the master. If the device has been set to slave, it will react the
same as its master device.
DMX Channels
4 channels
Channel 1 – Red
0-255
Gradual adjustment Red, from 0-100%
Channel 2 – Green
0-255
Gradual adjustment Green, from 0-100%
Channel 3 – Blue
0-255
Gradual adjustment Blue, from 0-100%
Channel 4 – White
0-255
Gradual adjustment White, from 0-100%
6 channels
Channel 1 – Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Channel 2 – Strobe Dimmer and CH3-6 must be open
0-10
No function
11-255
Strobe flash frequency, from low to high
Channel 3 – Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 4 – Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 5 – Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 6 – White Dimmer must be open
0-255
Gradual adjustment White, from 0-100%
19
