Show Tec 42512 User manual

Medium Studiobeam RGBW 3° Tour V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 42512
MANUAL
ENGLISH

1
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Table of contents
Warning ...............................................................................................................................................................................2
Safety Instructions .........................................................................................................................................................2
Operating Determinations ..........................................................................................................................................4
Rigging ............................................................................................................................................................................4
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Frontside..........................................................................................................................................................................7
Backside .........................................................................................................................................................................8
Installation...........................................................................................................................................................................8
Set Up and Operation .......................................................................................................................................................8
Color frame retaining clip ...........................................................................................................................................9
Control Modes.............................................................................................................................................................10
One Studiobeam (Built-in programs, Manual Mode and Static Colors).......................................................10
One Studiobeam (Sound-controlled)..................................................................................................................10
Multiple Studiobeams (Master/Slave control)....................................................................................................10
Multiple Studiobeams (DMX Control) ..................................................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel ...............................................................................................................................................................13
Control Mode ..............................................................................................................................................................13
DMX Addressing ..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................15
1. Display ON/OFF....................................................................................................................................................15
2. 4-channel Mode..................................................................................................................................................15
3. 8-channel Mode..................................................................................................................................................15
4. Static Color Presets..............................................................................................................................................15
5. Built-in programs ..................................................................................................................................................16
6. Program speed settings / Sound-controlled ..................................................................................................16
7. Manual Mode ......................................................................................................................................................17
DMX Channels .............................................................................................................................................................17
4 channels .................................................................................................................................................................17
8 channels .................................................................................................................................................................17
Lux Chart ...........................................................................................................................................................................18
Maintenance....................................................................................................................................................................19
Troubleshooting ...............................................................................................................................................................19
No Light.........................................................................................................................................................................19
No Response to DMX..................................................................................................................................................20
Product Specifications....................................................................................................................................................21
Dimensions........................................................................................................................................................................22

2
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec Medium Studiobeam RGBW 3° Tour
1 x color frame
Pro Power connector to Schucko cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

3
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the rotating gobo otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The fixture must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

4
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
•The user is responsible for correct positioning and operating of the Studiobeam. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

5
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
The Studiobeam can be placed on a flat stage floor or mounted to any kind of truss with a clamp.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

6
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Description of the device
Features
The Medium Studiobeam RGBW 3° Tour is an ultra-compact light effect with high output and great
effects. It is equipped with very high quality optics which have a razor sharp beam of only 3 degrees. This
will result in an extremely narrow and powerful beam of light which can be used in countless ways on
your stage from a retro pin-spot effect to powerful truss.
Input voltage: 100-240V AC, 60/50Hz
Power consumption: 25W max @FO
DMX channels: 4 or 8 channels
4-digit LED display for easy setup
Light source: 2x Red, 2x Green, 2x Blue 1W LEDS
Control modes: Built-in programs, Static Color Presets, Manual, Sound-controlled, Master/Slave, DMX
Very narrow Beam angle
Road Proof Design
Control protocol: DMX-512
On Board: Display for easy Set Up
Driver current: 700mA
Output (lux@2m): 11000
Refreshrate: 400 Hz
Dimmer: 0-100%
Strobe: 0-20Hz
Beam Angle: 3°
Compact size
Housing Die cast Aluminium
Connections: Pro Power connectors IN/OUT & 3-pin XLR IN & OUT
IP Rating: IP-20
Dimensions: 240 x 182 x 230 mm (LxWxH)
Weight: 1,8 kg
Frontside
Fig. 01
01) Adjustment screw
02) Mounting bracket with inclination screw
03) 3-pin DMX signal connector OUT
04) 3-pin DMX signal connector IN
05) 2x Red, 2x Green, 2x Blue 1W LEDS

8
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Backside
Fig. 02
06) Ground/earth connection
07) Pro Power connector 100-240V IN
08) Pro Power connector 100-240V OUT
09) 4-digit LED display + menu buttons
Installation
Remove all packing materials from the Medium Studiobeam RGBW 3° Tour. Check if all foam and plastic
padding is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

9
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Color frame retaining clip
The color frame holder is equipped with a spring-loaded retaining clip. This prevents color frames and
accessories from falling out.
Make sure that all color frame accessories are locked in position with the retaining clip
before hanging the Studiobeam.
01) Press the retaining clip down, in order to unlock the color frame slot.
02) Insert the color frame(s).
03) Lock the retaining clip by releasing the retaining clip.
Fig. 03

10
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Control Modes
There are 6 modes:
•Built-in programs
•Static Color Presets
•Manual Mode
•Sound-controlled
•Master/Slave
•DMX-512 (4CH, 6CH)
One Studiobeam (Built-in programs, Manual Mode and Static Colors)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Studiobeam is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 15-17 for more information about the Built-in programs, Static Color Presets and
Manual mode.
One Studiobeam (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Studiobeam will react to the beat of
the music. Please see page 16 for more information about the sound-control options.
Multiple Studiobeams (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin XLR cable to connect the Studiobeam.
03) Set the Slave devices to 1001-1512 or 2001-2512.
The pins:
01) Earth
02) Signal -
03) Signal +
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on pages 15-16 (Built-in
programs, Auto Mode, Manual Mode or Sound-controlled Mode). This means that you can set your
desired operation mode on the master device and all slave devices will react the same as the
master device.
Multiple Studiobeams (Master/Slave control)
Fig. 04
Each Slave device must be set to or .

11
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Multiple Studiobeams (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the Studiobeams and other devices.
04) Link the units as shown in fig. 05. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple Studiobeams DMX Set Up
Fig. 05
Note : Link all cables before connecting electric power

12
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

13
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
The Medium Studiobeam RGBW 3° Tour can be operated with a controller in control mode or without the
controller in stand-alone mode.
Control Panel
A) LED display
B) MODE button
C) UP button
D) DOWN button
Fig. 06
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Studiobeam will respond to the controller.
Please note, when you use the controller, the unit has 8channels.
When using multiple Studiobeams, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Studiobeam should be 1(001); the DMX address of the second
Studiobeam should be 1+8=9 (009); the DMX address of the third Studiobeam should be 9+8=17 (017),
etc. Please, be sure that you do not have any overlapping channels in order to control each
Studiobeam correctly.
If two or more Studiobeams are addressed similarly, they will work similarly.
Controlling:
After having addressed all Studiobeam fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Studiobeam will automatically detect whether DMX 512 data is received or
not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Studiobeam.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

14
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Menu Overview

15
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Main Menu Options
Display ON/OFF
4-channel Mode
8-channel Mode
Static Color Mode
Built-in programs
Program speed settings / Sound-controlled
Red LED intensity (Manual Mode)
Green LED intensity (Manual Mode)
Blue LED intensity (Manual Mode)
White LED intensity (Manual Mode)
1. Display ON/OFF
With this menu, you can set the LED display.
01) Press the MODE button until the display shows .
02) The display will now remain continuously ON.
03) Press the MODE button until the display shows .
04) The display will switch OFF after 10 seconds, if no button is pressed.
05) In order to switch the display ON, press and hold down for 5 seconds one of the menu buttons:
MODE, UP or DOWN.
2. 4-channel Mode
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the DMX address. The adjustment range is between 001-512.
3. 8-channel Mode
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the DMX address. The adjustment range is between 001-512.
4. Static Color Presets
With this menu, you can set the desired color preset.
01) Press the MODE button until the display shows .
02) = blackout
03) Press the UP/DOWN buttons to toggle between the 64 static color presets.

16
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Static Color Diagram
R
G
B
W
R
G
B
W
Black
0
0
0
0
Macro 1
80
255
234
80
Macro 33
255
206
143
0
Macro 2
80
255
164
80
Macro 34
254
177
153
0
Macro 3
77
255
112
77
Macro 35
254
192
138
0
Macro 4
117
255
83
83
Macro 36
254
165
98
0
Macro 5
160
255
77
77
Macro 37
254
121
0
0
Macro 6
223
255
83
83
Macro 38
176
17
0
0
Macro 7
255
243
77
77
Macro 39
96
0
11
0
Macro 8
255
200
74
74
Macro 40
234
139
171
0
Macro 9
255
166
77
77
Macro 41
224
5
97
0
Macro 10
255
125
74
74
Macro 42
175
77
173
0
Macro 11
255
97
77
74
Macro 43
119
130
199
0
Macro 12
255
71
77
71
Macro 44
147
164
212
0
Macro 13
255
83
134
83
Macro 45
88
2
163
0
Macro 14
255
93
182
93
Macro 46
0
38
86
0
Macro 15
255
96
236
96
Macro 47
0
142
208
0
Macro 16
238
93
255
93
Macro 48
52
148
209
0
Macro 17
196
87
255
87
Macro 49
1
134
201
0
Macro 18
150
90
255
90
Macro 50
0
145
212
0
Macro 19
100
77
255
77
Macro 51
0
121
192
0
Macro 20
77
100
255
77
Macro 52
0
129
184
0
Macro 21
67
148
255
67
Macro 53
0
83
115
0
Macro 22
77
195
255
87
Macro 54
0
97
166
0
Macro 23
77
234
255
77
Macro 55
1
100
167
0
Macro 24
158
255
144
144
Macro 56
0
40
86
0
Macro 25
255
251
153
153
Macro 57
209
219
182
0
Macro 26
255
175
147
147
Macro 58
42
165
85
0
Macro 27
255
138
186
138
Macro 59
0
46
35
0
Macro 28
255
147
251
147
Macro 60
8
107
222
0
Macro 29
151
138
255
138
Macro 61
107
156
231
0
Macro 30
151
147
255
147
Macro 62
165
198
247
0
Macro 31
138
169
255
138
Macro 63
0
0
189
0
Macro 32
255
255
255
255
Macro 64
255
255
255
0
5. Built-in programs
With this menu, you can set the built-in programs.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to toggle between the 9 built-in programs.
03) Press the MODE button until the display shows .
04) The device will playback all the 9 built-in programs after each other.
6. Program speed settings / Sound-controlled
With this menu, you can set the speed of the built-in programs.
01) Press the MODE button until the display shows .
02) Press the UP/DOWN buttons to set the program speed. The adjustment range is between 01-16, from
slow to fast.
03) Press the MODE button until the display shows .
04) The device is now operating in the Sound-controlled mode and will react to the beat of the
background music.

17
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
7. Manual Mode
With this menu, you can see the intensity of the LEDs.
01) Press the MODE button until the display shows one of the following 4 options:
Red LED intensity
Green LED intensity
Blue LED intensity
White LED intensity
02) Press the MODE button to toggle between the LEDs listed above.
03) Press the UP/DOWN buttons to increase/decrease the intensity of the desired LED.
04) You can combine Red, Green, Blue and White to create an infinite range of colors (000-255).
DMX Channels
4 channels
Channel 1 –Red
0-255
Gradual adjustment Red, from 0-100%
Channel 2 –Green
0-255
Gradual adjustment Green, from 0-100%
Channel 3 –Blue
0-255
Gradual adjustment Blue, from 0-100%
Channel 4 –White
0-255
Gradual adjustment White, from 0-100%
8 channels
Channel 1 –Red Dimmer must be open
0-255
Gradual adjustment Red, from 0-100%
Channel 2 –Green Dimmer must be open
0-255
Gradual adjustment Green, from 0-100%
Channel 3 –Blue Dimmer must be open
0-255
Gradual adjustment Blue, from 0-100%
Channel 4 –White Dimmer must be open
0-255
Gradual adjustment White, from 0-100%
Channel 5 –Color Macros
0
Not functional
1-255
Macro Mode (64 static colors)

18
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Channel 6 –Strobe Ch 7 must be set between 0-127
0-15
Closed
16-255
Strobe flash frequency, from slow to fast
Channel 6 –Speed Ch 7 must be set between 128-223
0-255
Speed, from slow to fast
Channel 7 –Mode
0-127
Color Adjustment (also use CH1-5)
128-159
Automatic color mixing
160-191
3-color switch
192-223
7-color switch
224-255
Sound-controlled
Note:
When CH6 is set between 0-127, use CH1-CH5 to select your color.
When CH6 is set between 128-223, use CH6 to set the speed.
Channel 8 –Dimmer intensity
0-255
Gradual adjustment, from dark to brightest 0-100%
Lux Chart
1m
2m
3m
6m
Distance
11800
3945
1799
629
Red (Lux)
22020
6362
2807
1006
Green (Lux)
3772
1030
460
163
Blue (Lux)
12870
3218
1446
524
Total (Lux)
50310
14430
6460
2314

19
Ordercode: 42512
Medium Studiobeam RGBW 3° Tour
Maintenance
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by an expert after every year in the course of an acceptance test.
The operator has to make sure that safety-related and machine-technical installations are to be
inspected by a skilled person once a year.
The following points have to be considered during the inspection:
01) All screws used for installing the device or parts of the device have to be tightly connected and
must not be corroded.
02) There may not be any deformations on housings, fixations and installation spots.
03) Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
04) The electric power supply cables must not show any damages or material fatigue.
The Medium Studiobeam RGBW 3° Tour requires almost no maintenance. However, you should keep the
unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and
a soft cloth. Do not use alcohol or solvents.
The front lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections
with a damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying
electric power.
Troubleshooting
This troubleshooting guide is meant to help solve simple problems.
If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit
operates properly, do not carry out following steps.
No Light
If the light effect does not operate properly, refer servicing to a technician.
Suspect two potential problem areas as: the power supply and the LEDs.
01) Power supply. Check that the unit is plugged into an appropriate power supply.
02) The LEDs. Return the Studiobeam to your Showtec dealer.
03) If both of the above appear to be O.K., plug the unit in again.
04) If you are unable to determine the cause of the problem, do not open the Studiobeam, as this may
damage the unit and the warranty will become void.
05) Return the device to your Showtec dealer.
