Show Tec XS-1 RGBW User manual

XS-1 RGBW V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40159
MANUAL
ENGLISH

1
Ordercode: 40158
XS-1 RGBW
Table of contents
Warning...................................................................................................................................................................................................2
Unpacking Instructions ....................................................................................................................................................................2
LED Expected Lifespan....................................................................................................................................................................2
Safety Instructions ............................................................................................................................................................................2
Operating Determinations..............................................................................................................................................................4
Rigging ...............................................................................................................................................................................................4
Connection with the mains ............................................................................................................................................................5
Return Procedure .............................................................................................................................................................................6
Claims.................................................................................................................................................................................................6
Description of the device ....................................................................................................................................................................7
Overview ...........................................................................................................................................................................................7
Backside.............................................................................................................................................................................................8
Installation ..............................................................................................................................................................................................8
Set Up and Operation...........................................................................................................................................................................8
Control Modes ..................................................................................................................................................................................9
One XS-1 RGBW (Built-in Programs and Manual) ...................................................................................................................9
One XS-1 RGBW (Sound-controlled) .........................................................................................................................................9
Multiple XS-1 moving heads (Master/Slave control)..............................................................................................................9
Multiple XS-1 moving heads (DMX Control) ......................................................................................................................... 10
Fixture Linking ................................................................................................................................................................................. 11
Data Cabling ................................................................................................................................................................................. 11
Control Panel ................................................................................................................................................................................. 12
Control Mode ................................................................................................................................................................................ 12
DMX Addressing ............................................................................................................................................................................ 12
Menu Overview ............................................................................................................................................................................. 13
Main Menu Options .................................................................................................................................................................. 14
1. DMX Addressing .................................................................................................................................................................... 15
2. Channel Mode ...................................................................................................................................................................... 15
3. Slave Mode ............................................................................................................................................................................ 15
4. Auto programs....................................................................................................................................................................... 15
5. Sound control Mode............................................................................................................................................................. 15
6. Sensitivity Mode..................................................................................................................................................................... 16
7. Blackout Mode ...................................................................................................................................................................... 16
8. Display Mode......................................................................................................................................................................... 16
9. Display settings ...................................................................................................................................................................... 16
10. Pan Invert ............................................................................................................................................................................. 16
11. Tilt Invert ................................................................................................................................................................................ 16
12. Manual control.................................................................................................................................................................... 17
13. Test......................................................................................................................................................................................... 17
14. Lifetime.................................................................................................................................................................................. 17
15. Firmware Version ................................................................................................................................................................. 17
16. Reset...................................................................................................................................................................................... 17
DMX Channels .................................................................................................................................................................................... 18
9 Channels...................................................................................................................................................................................... 18
16 Channels ................................................................................................................................................................................... 19
Maintenance ...................................................................................................................................................................................... 20
Replacing a Fuse........................................................................................................................................................................... 21
Troubleshooting .................................................................................................................................................................................. 21
No Light........................................................................................................................................................................................... 21
No Response to DMX.................................................................................................................................................................... 21
Product Specifications ...................................................................................................................................................................... 23
Dimensions .......................................................................................................................................................................................... 24
Notes .................................................................................................................................................................................................... 25

2
Ordercode: 40158
XS-1 RGBW
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
• Showtec XS-1 RGBW
• 1 mounting bracket
• IEC power cable 0,85 m
• 2 mounting M10 screws
• User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
•be qualified
•follow the instructions of this manual
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.

3
Ordercode: 40158
XS-1 RGBW
This device contains no user-serviceable parts. Refer to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged.
Always hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Never loosen the screws of the gobo, otherwise you risk opening of the ball bearing.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Allow the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device.
Leave the device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. The moving head must be installed beyond the reach of children. Never leave the
unit running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.
•The user is responsible for correct positioning and operating of the XS-1 RGBW. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.

4
Ordercode: 40158
XS-1 RGBW
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.
The XS-1 can be placed on a flat stage floor or mounted to any kind of truss with a clamp.

5
Ordercode: 40158
XS-1 RGBW
Mounting a clamp to the underside of the XS-1 moving head
Improper installation can cause serious injuries to people and/or damage of property !
Connection with the mains
Connect the device to the mains with the power plug.
Always check if the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious damage to people and property!

6
Ordercode: 40158
XS-1 RGBW
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

7
Ordercode: 40158
XS-1 RGBW
Description of the device
Features
The XS-1 is an extreme compact beam moving head, available in white and RGBW. The special optical
lens system creates strong and solid beam.
Mounting of your XS-1 is easy with only one bracket
Strong narrow RGBW beam
Compact housing
Input Voltage: 100-240VAC, 60/50Hz
Power consumption: 25W max. at full output
Beam Angle: 3°
Light Source: 1x10W RGBW
On-Board: Auto, Sound control & Master/Slave
Control Protocol: DMX512
9 or 16 DMX Channels
Display: 4 digits LED
Optical system
Dimmer: 0-100%
Strobe: 0-15Hz
Pan: 540°
Tilt: 270°
Pan/Tilt resolution: 8/16 bit
Special: Pan/Tilt reverse
Color: Black, Rubber paint
Metal & Flame-retardant plastic housing
Data Connection: 3-pin DMX signal connector IN/OUT
Power Connection: IEC input
Fuse F1AL/250V
Dimensions: 125 x 125 x 236 mm (LxWxH)
Weight: 2 kg
Overview
Fig. 01
01) LCD display
02) Lens

8
Ordercode: 40158
XS-1 RGBW
Backside
Fig. 02
03) IEC Power connector 100-240V (IN) + Fuse F1AL/250V
04) ON/OFF
05) 3-pin DMX signal connector IN
06) 3-pin DMX signal connector OUT
Installation
Remove all packing materials from the XS-1 RGBW. Check that all foam and plastic padding is removed.
Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

9
Ordercode: 40158
XS-1 RGBW
Control Modes
There are 5 modes:
•Stand-alone (Built-in programs)
•Stand-alone (Manual)
•Sound-controlled mode
•Master/Slave mode
•DMX512 (9 or 16 channels)
One XS-1 RGBW (Built-in Programs and Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the XS-1 RGBW is not connected with a DMX-cable, it functions as a stand-alone device.
Please, see page 15 and 17 for more information about the built-in programs and Manual Mode..
One XS-1 RGBW (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the XS-1 RGBW will react to the music
beats. Please, see page 15 for more information about the sound control options.
Multiple XS-1 moving heads (Master/Slave control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the XS-1 moving heads.
04) Plug the end of the electric mains power cord into a proper electric power supply socket.
The pins:
01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in (Fig.03). Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on page 15 and 17 (Auto, manual or
Sound). This means on the master device you can set your desired operation Mode and all slave
devices will react the same as the master device.
Multiple XS-1 moving heads (Master/Slave control)
Fig. 03

10
Ordercode: 40158
XS-1 RGBW
Multiple XS-1 moving heads (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the XS-1 moving heads and other devices.
05) Link the units as shown in (Fig.04), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the
other end of the mains power cord into proper electric power supply sockets, starting with the first
unit. Do not supply power before the whole system is set up and connected properly.
Multiple XS-1 moving heads DMX Set Up
Note : Link all cables before connecting electric power
Fig. 04

11
Ordercode: 40158
XS-1 RGBW
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

12
Ordercode: 40158
XS-1 RGBW
Control Panel
A)
B)
C)
D)
E)
LCD Display
MENU button
Up Button
Down Button
Enter Button
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the XS-1 moving head will respond to the controller.
Please note when you use the controller, the unit has 16 channels.
When using multiple XS-1 moving heads, make sure you set the DMX addresses right.
Therefore, the DMX address of the first XS-1 moving head should be 1(A001); the DMX address of the
second XS-1 moving head should be 1+16=17 (A017); the DMX address of the third XS-1 moving head
should be 17+16=33 (A033), etc.
Please, be sure that you don’t have any overlapping channels in order to control each XS-1 moving
head correctly.
If two or more XS-1 moving heads are addressed similarly, they will work similarly.
Controlling:
After having addressed all XS-1 fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the XS-1 moving head will automatically detect whether DMX 512 data is
received or not. If there is no data received at the DMX-input, the “LED“ on the control panel will not
flash.
The problem may be:
•The XLR cable from the controller is not connected with the input of the XS-1 moving head.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.

13
Ordercode: 40158
XS-1 RGBW
Menu Overview

14
Ordercode: 40158
XS-1 RGBW
Main Menu Options
DMX address
Channel Mode
Master/Slave
Auto
Sound-controlled
Sound Sensitivity
Blackout
LED Display
Display Invert
Pan Invert
Tilt Invert
Manual Mode
Test
Hours Used
Firmware Version
Reset

15
Ordercode: 40158
XS-1 RGBW
1. DMX Addressing
With this menu you can set the DMX address.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu. You can choose 512 different DMX addresses.
03) Use the Up / Down buttons to select the required address from .
04) Once you have set the desired DMX address, press the ENTER button to store your DMX address.
2. Channel Mode
With this menu you can set the Channel Mode.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
Use the UP/DOWN buttons to change the setting from 9CH to 16CH .
03) Once you have set the desired Mode, press the ENTER button to store your setting.
3. Slave Mode
With this menu you can set the Master or Slave Mode.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) Use the UP/DOWN buttons to toggle between the following Auto modes:
Master mode
Normal slave mode
Mirror slave mode
04) Press the SETUP button to store your setting.
4. Auto programs
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) Use the UP/DOWN buttons to toggle between the auto programs:
-
Auto Program 0 - 12
Sound-controlled auto program
04) Press the SETUP button to confirm your choice.
5. Sound control Mode
With this menu you can set the Sound control.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) Use the UP/DOWN buttons to change the setting from On to Off .
04) Once you have set the desired Mode, press the ENTER button to store your setting.
05) If the device has been set to Off, the device will not react to the beat of the music.
06) If the device has been set to On, the device will react to the beat of the music.

16
Ordercode: 40158
XS-1 RGBW
6. Sensitivity Mode
With this menu you can set the Sensitivity control.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) You can choose 100 different Audio Sensitivity levels .
04) Press the SETUP button to confirm your choice.
7. Blackout Mode
With this menu you can set the Blackout control.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) If the device has been set to No, the device will not blackout.
04) If the device has been set to Yes, the device will blackout.
05) Press the SETUP button to confirm your choice.
8. Display Mode
With this menu you can set the Display control.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) If the device has been set to ON, the display is always ON.
04) If the device has been set to OFF, the display is OFF after 10 seconds.
05) Press the SETUP button to confirm your choice.
9. Display settings
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the SETUP button to enter the menu.
03) Press the UP and DOWN buttons to toggle between:
Normal Display
Display Invert
04) Press the SETUP button to confirm your choice.
10. Pan Invert
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the SETUP button to enter the menu.
03) Press the UP and DOWN buttons to toggle between:
Normal Pan
Pan Invert
04) Press the SETUP button to confirm your choice.
11. Tilt Invert
05) Press the MENU button and then the Up / Down buttons, until the display shows .
06) Press the SETUP button to enter the menu.
07) Press the UP and DOWN buttons to toggle between:
Normal Tilt
Tilt Invert
08) Press the SETUP button to confirm your choice.

17
Ordercode: 40158
XS-1 RGBW
12. Manual control
With this menu you can set the manually set 8 options.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) Press the UP and DOWN buttons to toggle between:
Pan 000-255
Tilt 000-255
Red 000-255
Green 000-255
Blue 000-255
White 000-255
Dimmer 000-255
Strobe 000-255
04) Press the SETUP button to confirm your choice.
13. Test
With this menu you can test your XS-1.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) The XS-1 will now run the automatic test of all the available features.
14. Lifetime
With this menu you can view how long your XS-1 has been used.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) The XS-1 will now show its operating time.
15. Firmware Version
With this menu you can view which version your XS-1 has.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) The XS-1 will now show its currently installed software version .
16. Reset
With this menu you can reset your XS-1 has.
01) Press the MENU button and then the Up / Down buttons, until the display shows .
02) Press the ENTER button to open this menu.
03) Use the UP/DOWN buttons to change the setting from No to Yes .
04) If the device has been set to No, the device will not reset.
05) If the device has been set to Yes, the device will reset.
06) Press the SETUP button to confirm your choice.

18
Ordercode: 40158
XS-1 RGBW
DMX Channels
9 Channels
Channel 1 –Horizontal movement (Pan)
Move the slider up and down, in order to move head horizontally (PAN).
Gradual head adjustment by moving the slider from one end to the other (0-255).
The head can be turned by 540° and stopped in any position.
Channel 2 –Vertical movement (Tilt)
Move the slider up in order to move head vertically (TILT).
Gradual head adjustment by moving the slider from one end to the other (0-255).
The head can be turned by 270° and stopped in any position.
Channel 3 –Shutter/Strobe
0-7
Shutter closed
8-15
Shutter open
16-131
Strobe effect, from slow to fast
132-139
Shutter open
140-181
Fast Close to slow Open, from slow to fast
182-189
Shutter open
190-231
Slow Close to Fast Open, slow Open, from slow to fast
232-239
Shutter open
240-247
Random shutters are on or off, from long to short intervals
248-255
Shutter open
Channel 4 –Red
0-255
Red color intensity, from OFF to full ON
Channel 5 –Green
0-255
Green color intensity, from OFF to full ON
Channel 6 –Blue
0-255
Blue color intensity, from OFF to full ON
Channel 7 –White
0-255
White color intensity, from OFF to full ON
Channel 8 –Dimmer
0-255
0-100% dimmer
Channel 9 –Channel Functions
0-69
Not used
70-79
Enable Pan/tilt blackout (after 5 seconds)
80-89
Disable Pan/tilt blackout (after 5 seconds)
90-199
No Function
200-209
Reset All (after 5 seconds)
210-249
No Function
250-255
Sound-controlled

19
Ordercode: 40158
XS-1 RGBW
16 Channels
Channel 1 –Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 –Pan fine 16 bit
Channel 3 –Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 180° and stopped at any position you wish.
Channel 4 –Tilt fine 16 bit
Channel 5 –Pan / Tilt speed
0-255
From Max Speed (0) to Min. Speed (255)
Channel 6 –Pan/Tilt Macro
0-15
Not used
16-35
Color Macro 1
36-55
Color Macro 2
56-75
Color Macro 3
76-95
Color Macro 4
96-115
Color Macro 5
116-135
Color Macro 6
136-155
Color Macro 7
156-175
Color Macro 8
176-195
Color Macro 9
196-215
Color Macro 10
216-235
Color Macro 11
236-255
Color Macro 12
Channel 7 –Pan/Tilt Macro Speed
0-255
From fast to slow
Channel 8 –Channel Functions
0-69
Not used
70-79
Enable Pan/tilt blackout (after 5 seconds)
80-89
Disable Pan/tilt blackout (after 5 seconds)
90-199
No Function
200-209
Reset All (after 5 seconds)
210-249
No Function
250-255
Sound-controlled
Channel 9 –Dimmer
0-255
0-100% dimmer
Channel 10 –Shutter/Strobe
0-7
Shutter closed
8-15
Shutter open
16-131
Strobe effect, from slow to fast
132-139
Shutter open
140-181
Fast Close to slow Open, from slow to fast
182-189
Shutter open
190-231
Slow Close to Fast Open, slow Open, from slow to fast
