Show Tec 41370 Micro Spot User manual

Micro Spot
ORDERCODE 41370

Congratulations!
You have bought a great, innovative product from Showtec.
The Showtec Micro Spot brings excitement to any venue. Whether you want simple plug-&-play action or a
sophisticated DMX show, this product provides the effect you need.
You can rely on Showtec, for more excellent lighting products.
We design and manufacture professional light equipment for the entertainment industry.
New products are being launched regularly. We work hard to keep you, our customer, satisfied.
For more information: [e-mail]
You can get some of the best quality, best priced products on the market from Showtec.
So next time, turn to Showtec for more great lighting equipment.
Always get the best -- with Showtec !
Thank you!

1
2
2
3
4
6
6
7
8
8
8
9
9
10
12
12
12
13
15
15
15
16
16
17
17
17
17
19
Showtec
Showtec Micro Spot™Product Guide
Warning..…...................................................................................……………………………………….………………..
Safety-instructions………………………………………………………………………………………………………….
Operating Determinations……………………………………………………………………………………………….
Rigging……………………………………………………………………………………………………………………….
Description..…..............................................................................……….………………………………………….…….
Features and Overview ………………………………...….……………….………….………………….……………..
Backside…………………………………………………...…...….……………….…………………...….……………….
Set Up and Operation.....................................................................……..……………………………….………………
One Micro Spot.................................................................………………………………………………………….….
Multiple Micro Spots..................................................................………………………………………………………
DMX-Protocol…...................................................………………………………………………………………...............
5 Channel Mode…………………………………………………………………………………………………………..
13 Channel Mode…………………………………………………………………………………………………………
Control Panel….............……....................................…………………………………………………………………...
Control Mode........................................…………………………………………………………………………………
DMX addressing...................................………………………………………………………………………………….
Functions control panel...................................…………………………………………………………………………
Stand –alone mode...................................…………………………………………………………………………….
Master/Slave mode...................................……………………………………………………………………………..
Channel settings…………………………………………………………………………………………………………..
Static Gobowheel.……………………………………………………………..……………..……………………………….
Maintenance...................................................................................………..………….…….…………………………..
Replacing the Fuse........................................................................…………………….…………………………….
Troubleshooting............................................................................………………….………………….…………………
No Light, No Movement - All Products............................................………………….…………………………….
No Response to DMX ....................................................................………………….……………………………….
Product Specifications.................................................................……………….…….………………………………...

2
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!
SAFETY INSTRUCTIONS
Every person involved with the installation, operation and maintenance of this device has to:
-be qualified
-follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should there
be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to follow
the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-
observance of this manual or any unauthorized modification to the device.
Never let the power-cord come into contact with other cables! Handle the power-cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never run the device without lamp!
Never ignite the lamp if the objective-lens or any housing-cover is open, as discharge lamps may
expose and emit a high ultraviolet radiation, which may cause burns.
Never lift the fixture by holding it at the projector-head, as the mechanics may be damaged. Always
hold the fixture at the transport handles.
Never look directly into the light source.
Never leave any cables lying around.
Never unscrew the screws of the rotating gobo, as the ball bearing will otherwise be opened.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the lamp’s life.
Do not touch the device’s housing bare-handed during its operation (housing becomes very hot).
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
CAUTION! Be careful with your operations.
With a dangerous voltage you can suffer
a dangerous electric shock when touching the wires!

3
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always replace the lamp, when it is damaged or deformed due to the heat.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used, before cleaning or when
replacing lamp! Only handle the power-cord by the plug. Never pull out the plug by tugging the
power-cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power-cord is never crimped or damaged. Check the device and the power-
cord from time to time.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Movinghead must be installed out of the reach of children. Never leave the unit
running unattended.
For replacement use lamps and fuses of same type and rating only.
Allow time to cool down, before replacing lamp.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.
OPERATING DETERMINATIONS
This device is not designed for permanent operation. Consistent operation breaks will ensure that the device
will serve you for a long time without defects.
The minimum distance between light-output and the illuminated surface must be more than 1.3 meter.
The maximum ambient temperature tamust never be exceeded.
If this device is operated in any other way, than the one described in this manual, the product may suffer
damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, lamp explosion, crash etc.
You endanger your own safety and the safety of others!
CAUTION ! EYEDAMAGES !.
Avoid looking directly into the light source.
(meant especially for epileptics) !

4
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all other
safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
Use a clamp to mount the projector, with the mounting-bracket, to the trussing system.
The projector must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
The Micro Spot can be placed on a flat stage floor or mounted to any kind of truss by a clamp.

5
Mounting a clamp to the underside of the Micro Spot
Improper installation can cause serious damage to people and property !
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!

6
Description of the device
Features
The Showtec Micro Spot is a moving-head with high output and great effects.
• Gobo wheel with 9 gobo’s and rainbow function
• 15X 1 watt LED (5x Red, 5x Green, 5x Blue)
• RGB Colour mixing system
•16 bit pan/tilt resolution
• DMX-control via standard DMX-controller
• 13/5 DMX-control channels required
• Strobe-effect with adjustable speed (1 - 10 flashes/sec.)
• Sound-controlled via built-in microphone
• Auto mode, music controlled, master-slave function
• Dimmer: mechanical 0-100%
• Pan 0º -- 540º
• Tilt 0º -- 270º
• Fuse T1A / 250V
Overview
1
Fig. 1
1) Lens

7
Backside
Fig. 2
2 3 4 5
2) IEC Connector + Fuse 1A/250V
3) DMX signal connector (IN)
4) Remote control
5) DMX signal connector (OUT)

8
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
One Micro Spot
1. Fasten the moving/head onto firm trussing (Use a 30-kg rated or stronger C-clamp fastened onto the
Micro Spot). Leave at least 1 meter on all sides for air circulation.
2. Plug one end of the electric mains power cord into the IEC socket on the unit.
Then plug the other end of the cord into a proper electric power supply socket.
Multiple Micro Spots
1. Fasten the effect light onto firm trussing (Use a 30-kg rated or stronger C-clamp fastened onto the
Micro Spot). Leave at least 1 meter on all sides for air circulation.
2. Use a 3-p XLR cable to connect the Micro Spots and other devices.
The pins:
1. Earth
2. Signal -
3. Signal +
3. Link the units as shown in (figure 4), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
4. Supply electric power: Plug electric mains power cords into each unit's IEC socket, then plug the other
end of the mains power cord into proper electric power supply sockets, starting with the first unit. Do not
supply power before the whole system is set up and connected properly.
Multiple Micro Spots Set Up
DMX-Set up
Master/Slave Set up
Fig. 3
Note : Link all cables before connecting electric power

9
DMX Protocol
5 Channel Mode
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 3 –Shutter, strobe
0-7
Shutter close
8-134
Shutter open 100 –0%
135-239
Strobe effect from slow to fast
240-255
Shutter open
Channel 4–Colours
0-7
Closed
8-21
Open / white
22-35
Red
36-49
Green
50-63
UV
64-77
Light Blue
78-91
Pink
92-105
Yellow
106-119
Magenta
120-133
Color correction 1
134-147
Light Green
148-161
Color correction 2
162-189
Color correction 3
190-203
Light Pink
204-217
Color correction 4
218-231
Color correction 5
232-255
Rainbow effect
Channel 5 –Static Gobos
128-191
Positive rainbow effect with increasing speed
192-255
Negative rainbow effect with increasing speed

10
13 Channel Mode
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540° and stopped at any position you wish.
Channel 2 - Pan fine 16 bit
Channel 3 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 270° and stopped at any position you wish.
Channel 4 - Tilt fine 16 bit
Channel 5 –Pan / Tilt Speed
0-255
Pan/Tilt controllable speed with decreasing
Channel 6 –Shutter, strobe
0-7
Shutter close
8-134
Shutter open 100 –0%
135-239
Strobe effect from slow to fast
240-255
Shutter open
Channel 7 –Red
Channel 8 –Green
Channel 9 –Blue
Channel 10 –Colours
0-7
Closed
8-21
Open / white
22-35
Red
36-49
Green
50-63
UV
64-77
Light Blue
78-91
Pink
92-105
Yellow
106-119
Magenta
120-133
Color correction 1
134-147
Light Green
148-161
Color correction 2
162-189
Color correction 3
190-203
Light Pink
204-217
Color correction 4
218-231
Color correction 5
232-255
Rainbow effect
0-255
Red from 0 –100%
0-255
Green from 0 –100%
0-255
Blue from 0 –100%

11
Channel 11 –LED Speed
Channel 12 –Auto Program
0-7
No Function
8-22
Auto Program 1
23-37
Auto Program 2
38-52
Auto Program 3
53-67
Auto Program 4
68-82
Auto Program 5
83-97
Auto Program 6
98-112
Auto Program 7
113-127
Auto Program 8
128-142
Sound Control 1
143-157
Sound Control 2
158-172
Sound Control 3
173-187
Sound Control 4
188-202
Sound Control 5
203-217
Sound Control 6
218-232
Sound Control 7
233-255
Sound Control 8
Channel 13 –Static Gobos
0-255
Color change with from fast to slow
128-191
Positive rainbow effect with increasing speed
192-255
Negative rainbow effect with increasing speed

12
The Micro Spot can be operated with a controller in control mode or without the controller in stand-alone
mode.
Control Panel
When the indicator light is on, means the Micro Spot is working.
Fig. 4
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it, the
controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the first
channel from which the Micro Spot will respond to the controller.
Please note when you use the controller, the unit has 13 channels.
When using multiple Micro Spots, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Micro Spot should be 1(001); the DMX address of the second Micro
Spot should be 1+13=14 (014); the DMX address of the third Micro Spot should be 14+13=27 (027), etc.
Please, be sure that you don’t have any overlapping channels in order to control each Micro Spot correctly.
If two or more Micro Spots are addressed similarly, they will work similarly.
For address settings, please refer to the instructions under ”Addressing’ (menu )
Controlling:
After having addressed all Micro Spot fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the Micro Spot will automatically detect whether DMX 512 data is received or not.
If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
The problem may be:
- The XLR cable from the controller is not connected with the input of the Micro Spot.
- The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure proper
transmission on the DMX data link.

13
MODE 1: as default mode. Receive DMX512 signal, set the desired address via the UP/DOWN
buttons.
DMX mode: select channel 1 - channel 512
MODE 2: press the MODE/ESC button until the display shows / / / and set the
desired function via UP/DOWN buttons, as master auto mode. As master sound control
mode, as easy controller mode and as slave mode. Press the ENTER button confirm the
function and then will change to , will change to , will change to
and will change to .
Master mode: master auto mode
Master mode: master sound control mode
Master mode: Easy controller mode
Slave mode: slave
MODE 3: Press the MODE/ESC button until the display shows / and set the desired function via
UP/DOWN buttons, as pan positive mode and as pan negative mode. Press the ENTER button
confirm the function and the display will shows “DMX” or “master/slave” mode that you selected before.
Pan mode: Positive
Pan mode: Negative
MODE 4: Press the MODE/ESC button until the display shows / and set the desired function via
UP/DOWN buttons, as tilt positive mode and as tilt Negative mode. Press the ENTER button
confirm the function and the display will shows “DMX” or “MASTER/SLAVE” mode that you selected before.
Tilt mode: Positive
Tilt mode: Negative
MODE 5: Press the MODE/ESC button until the display shows / and set desired
function via UP/DOWN buttons. as LED positive mode and as LED Negative
mode. Press the ENTER button confirm the function and the display will shows “DMX”
or “MASTER/SLAVE” mode that you selected before.
LED mode: Positive
LED mode: Negative
MODE 6: Press the MODE/ESC button until the display shows / . Select the desired function
using the UP/DOWN buttons. Press the ENTER button confirm the function and the display will shows “DMX” or
“MASTER/SLAVE” mode that you selected before.
13 Channels
5 Channels

14
MODE 7: Select the scan angle for PAN. (just for Master/Slave and sound control) Press the MODE/ESC button
until the display shows / / . Select the desired function using the UP/DOWN buttons.
Press the ENTER button confirm the function and the display will shows “DMX” or “MASTER/SLAVE” mode that
you selected before.
PAN 540°
PAN 360°
PAN 180°
MODE 8: Select the scan angle for TILT. (just for Master/Slave and sound control) Press the MODE/ESC button
until the display shows / / . Select the desired function using the UP/DOWN buttons.
Press the ENTER button confirm the function and the display will shows “DMX” or “MASTER/SLAVE” mode that
you selected before.
TILT 270°
TILT 18°
TILT 90°
MODE 9: Press the MODE/ESC button until the display shows , Press the ENTER button will system reset.
System reset
MODE 10: Press the MODE/ESC button until the display shows , Press the ENTER button will go back to
the default mode.
Load default

15
Static gobo-wheel
This static gobo-wheel has 9 gobos and open.
Shutter/Dimmer/Strobe
The dimming (0-100%) is provided by a simple mechanical shutter unit. This unit may also be used for strobe
effect (1-10 flashes per second).
Stand-alone Mode
The fixtures on a data-link are not connected to the controller, but can execute pre-set programs, which
can be different for every fixture.
To set the program to be played, see the page 13. Stand-alone operation” can be applied to a single
fixture (the fixture may be set to the master/slave mode or controller mode) or to multiple fixture operating
synchronously.
For synchronous operation of multiple fixtures the fixtures must all be connected on a data-link and one of
them is set as a master (master mode) and the rest as slaves (slave mode). The DMX address of all the
slaves are assigned to and on that particular slave address only one fixture can be connected. To the
fixture as the master or slave, see “Addressing” (menu ).
If the master fixture resets or runs a test (program), all slaves will execute these acts too.
You can’t play or edit any program on a slave, if the master is switched on and connected to the
master/slave chain.
Note: Disconnect the fixtures from the DMX controller before master/slave operating, otherwise data
collisions can occur and the fixtures will not work properly!
It’s necessary to insert the XLR termination plug (with 120 Ohm ) into the input of the master fixture and into
the output of the last slave fixture in the data-link, in order to ensure proper transmission on the data link.
From the master’s control panel it is possible to control any slave in a master/slave chain.
Channels settings
Mode 13 Channels Mode 5 Channels
1. Pan 1. Pan
2. Pan Fine 16 bit 2. Pan Fine 16 bit
3. Tilt 3. Shutter
4. Tilt fine 16 bit 4. Colours
5. Pan/Tilt Speed 5. Static Gobos
6. Shutter
7. Red
8. Green
9. Blue
10. Colours
11. LED Speed
12. Auto Program
13. Static Gobos

16
Gobowheel Static
Fig. 5
Maintenance
The operator has to make sure that safety-relating and machine-technical installations are to be inspected
by an expert after every four years in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are to be inspected
by a skilled person once a year.
The following points have to be considered during the inspection:
1. All screws used for installing the device or parts of the device have to be tightly connected and must
not be corroded.
2. There may not be any deformations on housings, fixations and installation spots.
3. Mechanically moving parts like axles, eyes and others may not show any traces of wearing.
4. The electric power supply cables must not show any damages or material fatigue.
The Showtec Micro Spot requires almost no maintenance. However, you should keep the unit clean.
Otherwise, the fixture’s light-output will be significantly reduced. Disconnect the mains power supply, and
then wipe the cover with a damp cloth. Do not immerse in liquid. Wipe lens clean with glass cleaner and a
soft cloth. Do not use alcohol or solvents.
The front PC lens will require weekly cleaning, as smoke-fluid tends to build up residues, reducing the light-
output very quickly.
The cooling-fans, the gobo-wheel, the gobos and the internal lenses should be cleaned monthly with a soft
brush.
Please clean internal components once a year with a light brush and vacuum cleaner.
Keep connections clean. Disconnect electric power, and then wipe the DMX and audio connections with a
damp cloth. Make sure connections are thoroughly dry before linking equipment or supplying electric
power.

17
Replacing a Fuse
Power surges, short-circuit or inappropriate electrical power supply may cause a fuse to burn out. If the fuse
burns out, the product will not function whatsoever. If this happens, follow the directions below to do so.
1. Unplug the unit from electric power source.
2. Insert a flat-head screwdriver into a slot in the fuse cover. Gently pry up the fuse cover. The fuse will
come out.
3. Remove the used fuse. If brown or unclear, it is burned out.
4. Insert the replacement fuse into the holder where the old fuse was. Reinsert the fuse cover. Be sure to
use a fuse of the same type and specification. See the product specification label for details.
Troubleshooting
No Light, No Movement - All Products
This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps
below in sequence until a solution is found. Once the unit operates properly, do not carry out following steps.
If the light effect does not operate properly, refer servicing to a technician.
Response: Suspect three potential problem areas: the power supply, the lamp, the fuse.
1. Power supply. Check that the unit is plugged into an appropriate power supply.
2. The LEDs. Return the device to your Showtec dealers.
3. The fuse. Replace the fuse. See page 17 for replacing the fuse.
No Response to DMX
Response: Suspect the DMX cable or connectors, a controller malfunction, a light effect DMX card
malfunction.
1. Check the DMX cable: Unplug the unit; change the DMX cable; then reconnect to electrical power. Try
your DMX control again.
2. Determine whether the controller or light effect is at fault. Does the controller operate properly with other
DMX products ? If not, take the controller in for repair. If so, take the DMX cable and the light effect to a
qualified technician.
See next page for more problem solving.

18
Problem
Probable cause(s)
Remedy
One or more
fixtures are
completely dead.
No power to the fixture
· Check that power is switched on
And cables are plugged in.
Primary fuse blown.
· Replace fuse.
Fixtures reset
correctly, but all
respond
erratically or not
at all to the
controller.
The controller is not connected.
· Connect controller.
3-pin XLR Out of the controller
does not match XLR Out of the first
fixture on the link (i.e. signal is
reversed).
· Install a phase reversing cable
between the controller and the first
fixture on the link.
Fixtures reset
correctly, but
some respond
erratically or not
at all to the
controller.
Poor data quality
· Check data quality. If much lower
than 100 percent, the problem may
be a bad data link connection, poor
quality or broken cables, missing
termination plug, or a defective
fixture disturbing the link.
Bad data link connection
· Inspect connections and cables.
Correct poor connections. Repair or
replace damaged cables.
Data link not terminated with 120
Ohm termination plug.
· Insert termination plug in output jack
of the last fixture on the link.
Incorrect addressing of the fixtures.
· Check address setting.
One of the fixtures is defective and
disturbs data transmission on the
link.
· Bypass one fixture at a time until
normal operation is regained: unplug
both connectors and connect them
directly together.
· Have the defective fixture serviced
by a qualified technician.
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed).
· Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture, that behaves
erratically.
Shutter closes
suddenly
The gobo wheel has lost its index
position and the fixture is resetting
the effect.
· Contact a technician for servicing if
the problem persists.
No light
The power supply settings do not
match local AC voltage and
frequency.
· Disconnect fixture. Check settings
and correct if necessary.
LEDs broken
· Disconnect fixture and return to your
dealer.
Lamp cuts out
intermittently.
Fixture is too hot.
· Allow fixture to cool.
· Clean fan.
· Make sure air vents at control panel
and front lens are not blocked.
· Turn up the air conditioning.
The power supply settings do not
match local AC voltage and
frequency.
· Disconnect fixture. Check settings
and correct if necessary.
