ShowTex EASYDRAPE User manual

EASYDRAPE
SUPPORT BRACE

Create unlimited EasyDrape congurations using these dierent parts.
COMPONENTS
2X
3X
8X4X
1X
1X
4X3X 4X
02
EasyDrape Installation Manual

[1] Place 2 base plates at the desired distance apart
[2] Attach the base plate connectors to the base plates (page 7)
[3] Attach an Upright to one of the plates (page 8)
ASSEMBLY
03
EasyDrape Installation Manual

[1] Attach the base plate connectors to the base plates
and position the EasyDrape base plates at the desired distance apart.
When positioning the base plate connectors in the base plates, make sure the two holes
in the sides of the connector are lined up in the same direction as the small markings in
the base plate.
ASSEMBLY
[tooltip]
use the EasyDrape Tool to
screw the base connectors
into the base plates
04
EasyDrape Installation Manual

[2] Attach the Uprights to the plates and the four way adaptor piece to the Uprights
Hammer the pin into the larger of the two holes in the upright.
ASSEMBLY
[tooltip]
use the EasyDrape Tool
to hammer in the pins
05
EasyDrape Installation Manual

[4] Attach an extension to the Upright with one conical coupler.
Hammer the pins into the larger of the two holes. Use safety R-springs to secure the two curved
supports to each other.
ASSEMBLY
[tooltip]
use the EasyDrape Tool
to hammer in the pins
06
EasyDrape Installation Manual

ASSEMBLY
[5] Attach a hinge to the other Upright using a half conical coupler.
Use the EasyDrape Tool to hammer the pin into the larger of the two holes in the coupler.
Use a safety R-spring to secure the coupler to the Upright and screw the hinge to the coupler.
[tooltip]
use the EasyDrape Tool
to hammer in the pins
07
EasyDrape Installation Manual

[6] Attach the Upright to the Base Plate.
Use the EasyDrape Tool to hammer the pin into the larger of the two holes of the hinge.
Use a safety R-spring to secure the hinge to the Base Plate.
ASSEMBLY
[tooltip]
use the EasyDrape Tool
to hammer in the pin
08
EasyDrape Installation Manual

[tooltip]
use the EasyDrape Tool
to hammer in the pin
ASSEMBLY
[7] Attach a clamp to the top of the Upright using two hinges and a half conical coupler.
First screw the half conical coupler to the hinge using a nut, and attach the hinge to the Upright.
Use the EasyDrape Tool to hammer the pin into the larger of the two holes in the coupler.
Use a safety R-spring to secure the coupler to the Upright and.
09
EasyDrape Installation Manual

[6] Then screw a hinge to the clamp using a nut.
Hammer the pin into the larger of the two holes of the hinges. Use safety R-springs to secure
the two hinges together. Next attach the two hinges together using a pin and R-spring.
ASSEMBLY
[tooltip]
use the EasyDrape Tool
to hammer in the pin
10
EasyDrape Installation Manual

ASSEMBLY
[7] Attach the clamp to the larger upright and you’re ready to roll!
11
EasyDrape Installation Manual

•For more technical assistance please contact your local ShowTex office.
TROUBLE SHOOTING
