ShoX Supernova User manual
(Pg 2) Getting to know the buttons & controls
(Pg 3/4) Pairing with different devices
(Pg 5) FM Radio
(Pg 5) USB Port
(Pg 6) Micro SD Port
(Pg 6) Mode
(Pg 7) Mic Input
(Pg 7) AUX Port
(Pg 7) Volume Control
(Pg 8) Charging
Switch your shoX supernova on (2).
The sub woofer LED’s will light up... party time!
The LED display (11) will tell you which mode you are in.
If it says “blue”, then you can go ahead with pairing with
your device. If the LED displays a different mode, then
press the Mode button (3) until the display shows “blue”.
Make sure your shoX supernova and the device are within
1 metre of each other.
iPhones & iPads
• Go to General menu, then Bluetooth and swipe to the
“ON” position
• shoX supernova will become discoverable
• Tap on “shoX supernova” to connect
Other cellphones & tablets
• Turn your Bluetooth on and search for “shoX supernova”
• If you’re prompted for a password, enter “0000”
• Check your Bluetooth device list & connect with
“shoX supernova”
• If you’re prompted for a password, enter “0000”
• Check your Bluetooth device list & connect with your
shoX supernova
PC or notebooks
• Activate your Bluetooth connectivity and “search new
device”
• Once “shoX supernova” has become discoverable, click
on it to connect
• If a password is required, enter “0000”
Apple Macs
• Turn your Bluetooth on and scroll down to “Set Up
Bluetooth Device”
• Click on “shoX supernova” and continue
• If you’re asked for a password, enter “0000”
• Now open system preferences and click “Sound”
• Click the output tab and select “shoX supernova”
• Click the input tab and select “shoX supernova”
1. DC 5V Charging Port
2. Off/On
3. Mode
4. Previous Track
5. Play/Pause
6. Next Track
7. Mic Volume
8. TF/Micro SD Port
9. USb Port
10. Mic Port
11. LED Display
12. Aux Port
1. Getting to know the buttons & controls 2. Pairing with different devices
Contents
8
10 9
11
12
2 3 4 5 6 71
SPECS:
Output power: 5W THD=10%
Frequency response: 150-18KHz
Signal to Noise:>80dB
Horn Size:3 inch
Sub woofer Size:4 inch
Battery: Rechargeable lithium-ion
1 2 3 4
Brought to you by:
0861 77 88 88
Press and hold the “Mode” (3) button until the LED
Display shows a radio frequency number. Press the
“Play/Pause” button (6) to search FM channel
automatically. This will scan all FM stations and save
them to memory. The scan will take several minutes to
complete and should not be interrupted. Once
complete, you can press “Previous Track” (4) or “Next
Track” (5) to move forward or backward or press and
hold or to turn down or turn up the Volume.
• FM Radio
Press and hold the Mode button (3) to switch between
Bluetooth, Aux-in or FM Radio.
Press the Mode button to switch between 4 different
light settings:
· Normal
· Fade
· Sync to your beats (not available in Aux mode)
· Off
• Mode
If you notice your shoX supernova is running low
on power, then it’s time to recharge the built-in battery.
Your shoX supernova will take 3 hours to charge if
it is fully flat. Plug the small end of the mini USB cable
(included) into the “DC 5V Charging port”(1) and the
other end into a powered-up computer USB port or
a USB adapter (not included).
• Charging
To connect a device (phone, laptop etc) with a 3,5mm
jack connection to your shoX supernova, connect one
end of the 3,5mm jack cord (included) to the AUX Port
(12) and the other end to your device.
• AUX Port
OK, you know this already...
Press and hold the “Previous Track” (4) to turn down
the volume.
Press and hold the “Next Track” (6) to turn up the
volume.
• Volume Control
Play music directly from a USB device by plugging it
into the USB port (1). Your shoX supernova will
automatically switch to USB mode. Then use the
“Previous Track” (4), “Next Track” (5) and “Play/Pause”
(6) buttons to control your tracks and volume. Supports
MP3 and WAV music formats.
• USB Port
Play music directly from a Micro SD card by plugging it
into the Micro SD Port port (2). Your shoX supernova
will automatically switch to Micro SD mode. Then use
the “Previous Track” (4), “Next Track” (5) and
“Play/Pause” (6) buttons to control your tracks and
volume. Supports MP3 and WAV music formats.
• TF/Micro SD Port
5 6 7 8 series
user manual
SUPERNOVA
Plug in your microphone and brace yourself for karaoke
all day, all night. To turn up the volume of the mic,
simply press the “Mic-Vol” (7) button.
• Mic input
