Shuttle DS437T User manual

Pin Assignments (TPM1):
1=TPM_33M
2=GND
3=FRAME
5=SIORST
6=NC
7=LAD3
8=LAD2
9=+3.3V
10=LAD1
11=LAD0
12=GND
13=NC
14=NC_ID
15=+3.3VS
16=SERIRQ
17=GND
18=CLKRUN_NC
19=PD#_NC
20=NC_SUSCLK_R
DS437T Quick Guide【 English 】
53R-DS4373-2401
LThe product’s color and specification will depend on the actual shipping product.
C. Component Installation
D. Complete
3. Put the HDD in the chassis and push toward right untill it inserts into the
SATA&SATA Power Connector.
2. Place the HDD in the rack and secure with the two screws from the side.
1. Replace the covers and refasten the screws.
2 . Complete.
A. Begin Installation
1. Unscrew the two screws of the chassis cover.
For safety reasons, please ensure that the power cord is discon-
nected before opening the case.
2. Slide the cover forwards and upwards.
4. Refasten the screw.
Back Panel
B1. CMOS and External Power On Header
B2. DVI-I Port
B3. HDMI Port
B4. Mic-In
B5. Headphone
B6. USB3.0 Ports x2
B7. LAN Port
B8. USB2.0 Ports x2
B9. DC IN
Front Panel
F1. SD Card Reader
F2. Power Button
F3. HDD LED
F4. Power LED
F5. USB2.0 Ports x2
F6. USB3.0 Ports x2
B. Memory Module Installation
notch
SODIMM slot
45-degree
angle
3
1
2
Latch Latch
1. Locate the SODIMM slot on the mainboard.
2. Align the notch of the memory module with the one of the memory slot.
3. Gently insert the module into the slot in a 45-degree angle.
4. Carefully push down the memory module until it snaps into the locking
mechanism.
5. Repeat the above steps to install additional memory modules, if required.
1. Unscrew the rack from the chassis.
Battery Connector
1
Pin Assignments (CN1):
1=V_BAT
2=GND
Pin Assignments (Audio2):
1=PULL AGND 2=LINE-R
3=N/C 4=LINE-L
5=PULL AGND 6=FRONT_L
7=N/C 8=FRONT_SENSE
9=PULL AGND 10=FRONT_R
11=BK_AUDIO-JD 12=MIC1_R
13=AGND 14=MIC1_L
Audio Connector
13 11 9 7 5 3 1
14 12 10 8 6 4 2
Power Button
Pin Assignments (SW3)
Jumper Settings Pin Assignments (SW1):
1=+HD_LED
2=PWR_LED
3=-HD_LED
4=GND
5=RST_SW
6=PWR_SW
7=GND
8=GND
9=NUUL
Power On Header
Safety Information
Read the following precautions before setting up a Shuttle XPC.
CAUTION
Incorrectly replacing the battery may damage this computer. Replace only with the same or equivalent
as recommended by Shuttle. Dispose of used batteries according to the manufacturer's instructions.
Left / Right Panel
Kensington® Lock Port
Kensington® Lock Port
1 2
3
5
7
9
4
6
8
External Power On Header
Pin Assignments (SW2):
1=PWRSW-
2=+5V
3=GND
4=Clear Cmos 2 1
4 3
SMBUS
Pin Assignments (CN6):
1=SMBCLK_SB
2=SMBDATA_SB
3=+5V
4=GND
Please load the optimized BIOS settings.
Operation Position:
1) Device must only be used in vertical position with the DVI
port facing up.
2) Please make sure to use either the supplied feet or the VESA
mount.
Motherboard Illustration
USB 3.0 Ports x2
C1
C3
LAN Port
USB 2.0 Ports x2
Headphone Mic In
HDMI Port
DVI-I Port
Power On Header - SW1
Power Button - SW3
Half size Mini-PCIE slot - CN3
External Power On Header - SW2
Battery Connector - CN1
Audio Connector - AUDIO2
DDR3 SODIMM slots
HDD LED
Power LED
DC IN
C2
2.5 inch HDD slot
USB 2.0 Ports x2
USB 3.0 Ports x2
SMBUS
LPC Header C4
C5
C6
C7
Intel®Celeron®
Processor 1037U
Intel®NM70 Chipset
Super I/O
F1
F3
F5
F6
F2
F4
B1
B3
B4
B6
B8
B2
B5
B7
B9
C1
C2
C3 C5
C7
C6
LPC
1
C4
1
3
5
7
9
11
13
15
17
19
2
4
6
8
10
12
14
16
18
20
1
2
