Side-Power RC-20U Instruction Manual

Installation & User Manual
Radio Remote
Made in Norway
©Sleipner Motor AS 2018
SLEIPNER MOTOR AS
P.O. Box 519
N-1612 Fredrikstad
Norway
www.side-power.com
RC-20U RC-21U RC-22U RC-23U
EN
Document id: 5488
Revision: 2

Installation & User Manual, Radio Remote 5488-2-2018 Page 2
We Sleipner Motor AS declare that this
device complies with health and safety
requirements according to the Directives
EN301 489-3 V1.4.1:2002
EN301 489-1 V1.4.1:2008
IEC 60533:1999
EN300 220-1 V2.3.1:2010
EN300 220-2 V2.3.1:2010
The radio remote control can control a single bow thruster/windlass or a bow and stern thruster/
windlass combined. The receiver can receive the signals of up to four transmitters/remote con-
trols.
Remote control kit RC-20U consists of:
- Receiver: Part no. RCR-2U
- Transmitter (incl. battery): Part no. RCT-20U
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-21U consists of:
- Receiver: Part no. RCR-2U
- Transmitter (incl. battery): Part no. RCT-21U
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-22U consists of:
- Receiver: Part no. RCR-2U
- Transmitter (incl. battery): Part no. RCT-22U
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Remote control kit RC-23U consists of:
- Receiver: Part no. RCR-2U
- Transmitter (incl. battery): Part no. RCT-23U
- Holding bracket for transmitter unit: Part no. RC-HOLDER
Additional transmitters/remote controls can be ordered separately;
The transmitter and the receiver have the same factory preset code so no programming is neces-
sary. The battery is already inserted in the transmitter.
When additional transmitters/remote controls are to be used, the new transmitter(s) must be
paired with the receiver (please see programming section).
Model range................................................................................................................................ 2
Technical specications .............................................................................................................. 3
Important precautions................................................................................................................. 3
Receiver installation ................................................................................................................... 4
User precautions ........................................................................................................................ 6
How to use RC-20U..................................................................................................................... 7
How to use RC-21U..................................................................................................................... 8
How to use RC-22U..................................................................................................................... 9
How to use RC-23U................................................................................................................... 10
Transmitter LED operation and alarm indication ....................................................................... 12
Electric diagram......................................................................................................................... 13
Output signals diagram.............................................................................................................. 14
Programming additional transmitters/remote controls............................................................... 15
Replacing transmitter battery.................................................................................................... 16
Dimensions .............................................................................................................................. 17
Safety Information ................................................................................................................... 18
Model range
Contents

Installation & User Manual, Radio Remote 5488-2-2018 Page 3
•With the boat on land, only run the thruster for a fraction of a second, as without resistance it
will accelerate very fast to a damaging rpm.
• This manual is intended to support educated / experienced sta󰀨.
• When installed in boats approved or classied according to international or special national
rules, the installer is responsible for following the demands in accordance with these regula-
tions / classication rules. The instructions in this guide can not be guaranteed to comply with
all di󰀨erent regulations / classication rules.
•The transmitter and the receiver have the same factory preset code so no programming is
necessary. When additional transmitters/remote controls are to be used, follow the instructions
in the programming section on page 15.
Compass safe distance:
- RCT-2xxU: 0,3m
- RCR-2U: 0,2m
Technical specications
Important precautions
Transmitter Receiver
Power feed 1x3V battery (type: CR2032) 12V or 24V power source
Frequency (MHz) 914-917 MHz 914-917 MHz
RF-power <10mW <10mW
Operation temp. -10°C / +55°C -15°C / +55°C
HxWxD (mm) 107x47x21 83x136x36
Weight (g) 60 275
Voltage 8-30V
Standby power <300mW
Load, max 4A
Operating range 30m under normal operating conditions

Installation & User Manual, Radio Remote 5488-2-2018 Page 4
Prior to installation, it is important that the responsible installer reads this guide to ensure
necessary acquaintance with this product.
WARNING!
• Install the receiver minimum 1 meter (3ft) from high power cables and data communication
cables or other sources of electrical interference, i.e. navigation instruments, radio communica-
tion devices, electric motors and generators.
• Install the receiver minimum 1 meter (3ft) above sea level.
• Install the receiver outside of shielded areas for radio signals, i.e. boxes made of metals or
other material with shielding properties.
• Install the receiver in a dry environment, where no condensation can enter the unit. (The
receiver assembly is not waterproof.).
• Mount the receiver using the four holes (please see picture on page 5).
• The receiver must have a separate power supply tted with a 5 Amp fuse in the positive lead
that has either a separate power switch or is shut of by the thrusters system main power
switch. The receiver can not be powered by the thrusters/windlass control looms even if you
nd positive and negative lead there.
• Connect the supplied wiring harnesses to the receiver unit according to the wiring diagram
on page 13. Connect thrusters and windalsses to the appropirate connectors according to
diagram.
• For use with other windlass brands, connections must be determined by the installer according
to output signals diagram on page 14.
NB: Max. load on the windlass signal output is 4A!
If the windlass requires more than 4A, use extra control relay.
Note! Faulty installation will render all warranty given by Sleipner Motor AS void.
Receiver installation
WARNING!
Remote receiver power supply negative lead must be connected to the thrusters`s
negative lead. Bow and stern thruster must have common negative. Power to the
thruster’s must be switched o󰀨 during installation!

Installation & User Manual, Radio Remote 5488-2-2018 Page 5
Mount the receiver by using
the 4 holes.
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
olekr 18.08.2015
Designed by Checked by Approved by Date
1 / 1
Edition Sheet
Date

Installation & User Manual, Radio Remote 5488-2-2018 Page 6
• Ensure that you know the location of the main battery switch that disonnects the thruster from
all power sources (batteries) so that the thruster/windlass can be turned o󰀨 in case of a mal-
function.
• The maximum continues usage time of the electrical thruster is approx. 3 minutes. The electro
motor has a built in thermal cut-o󰀨 switch that will shut it o󰀨 when overheating and re-engage it
when it has cooled down some. This should be considered when planning your manouvering.
• Never use a thruster close to somebody in the water, as the thruster will draw objects close by
into the tunnel and contact with the rotating propellers will cause serious injuries.
• Never use a windlass close to somebody in the water, an unexpectedly drop of the anchor can
cuse serious injuries.
• If the thruster stops giving thrust while the electric motor is running, chances are that there is a
problem in the drive-system. You must then immediately stop trying to run it, and turn it o󰀨, as
running the electricmotor for more than a few seconds without resistance from the propeller,
can cause serious damage to the electricmotor.
• When leaving the boat always turn o󰀨 the main power switch for the thruster/windlass and turn
o󰀨 the power to the receiver.
• We advice to always keep the main engine(s) running while using a thruster/windlass. This
will keep the batteries in a good charge condition. This will also give better performance to the
thruster.
• It is the owner/captain/other responsible party full responsibility to assess the risk of any
unexpected incidents on the vessel. If the thruster stops giving thrust for some reason while
maneuvering you must have considered a plan on how to avoid damage to persons or other
objects.
User precautions

Installation & User Manual, Radio Remote 5488-2-2018 Page 7
How to use a bow/stern thruster
1. Turn the main power switch for the bow/stern thruster on. Turn on main switch so the receiver
has power.
2. Turn on the transmitter by pushing the transmitter’s two “ON” buttons. The remote system is
now activated and then turns o󰀨 automatically appr. 4 min. after the last usage.
3. Please take some time to exercise thruster usage in open water to avoid damages to your boat.
4. Turn the bow/stern in the desired directiony by pushing the red button for port movement or the
green button for starboard movement.
How to use a bow & stern thruster combined
The combination of a bow and stern thruster o󰀨ers total manouverability to the boat and the
opportunity to move the bow and the stern separately of each other. The remote middle buttons
gives you the opportunity to operate both thrusters in the same direction with one keypress,
making sidewards movement easier.
Remote Control Deactivation
Push the transmitter’s “OFF” button for 2 seconds (the remote control deactivates automati-
cally after approx. 4 minutes after the last usage).
• If in doubt, try in open water rst!
Remote control “ON” Turn boat to Port Bow + Stern thruster
Remote control “OFF” Turn boat to Starboard
Auto-OFF
appr. 4 min.
Hold for
2 seconds
RC-20U

Installation & User Manual, Radio Remote 5488-2-2018 Page 8
How to use a bow thruster
1. Turn the main power switch for the bow thruster on. Turn on main switch so the receiver has
power.
2. Turn on the transmitter by pushing the transmitter’s two “ON” buttons. The remote system is
now activated and then turns o󰀨 automatically appr. 4 min. after the last usage.
3. Please take some time to exercise thruster usage in open water to avoid damages to your boat.
4. Turn the bow in the desired direction. By pushing the red button for port movement or the
green button for starboard movement.
How to use the windlass
1. Turn the main power switch for the windlass on. Turn on the power to the receiver.
2. Turn on the transmitter by pushing the transmitter’s two “ON” buttons. The remote system is
now activated and then turns o󰀨 automatically appr. 4 min. after the last usage.
3. Please consult your windlass manual for use and precautions.
Remote Control Deactivation
Push the transmitter’s “OFF” button for two seconds (the remote control deactivates automati-
cally after approx. 4 minutes after the last usage).
• If in doubt, try in open water rst!
Remote control “ON” Turn boat to Port Windlass
Remote control “OFF” Turn boat to Starboard
Auto-OFF
appr. 4 min.
Down
Up
Hold for
2 seconds
RC-21U

Installation & User Manual, Radio Remote 5488-2-2018 Page 9
How to use a bow/stern windlass
1. Turn the main power switch for the windlass on. Turn on main switch so the receiver has
power.
2. Turn on the transmitter by pushing the transmitter’s two “ON” buttons. The remote system is
now activated and then turns o󰀨 automatically appr. 4 min. after the last usage.
3. Please consult your windlass manual for use and precautions.
Remote Control Deactivation
Push the transmitter’s “OFF” button for two seconds (the remote control deactivates automati-
cally after approx. 4 minutes after the last usage).
Remote control “ON” Windlass 2
Remote control “OFF”
Auto-OFF
appr. 4 min.
Down
Up
Hold for
2 seconds
Windlass 1
Down
Up
RC-22U

Installation & User Manual, Radio Remote 5488-2-2018 Page 10
Remote control “ON” Turn boat to Port Bow + Stern thruster
Remote control “OFF” Turn boat to Starboard
Auto-OFF
appr. 4 min.
Hold for
2 seconds
RC-23U
Windlass 2
Down
Up
Windlass 1
Down
Up
