SIEB & MEYER SD4B Guide

Drive Amplifier SD4B
D-00000374.1
2023-10-04
Drive Amplifier SD4B
Hardware Description
SIEB & MEYER

Copyright
Original instructions, Copyright © 2023 SIEB & MEYER AG
All rights reserved.
This manual or extracts thereof may only be copied with the explicit authorization by
SIEB & MEYER AG.
Trademarks
All product, font and company names mentioned in this manual may be trademarks or
registered trademarks of their respective companies.
SIEB & MEYER Worldwide
For questions regarding our products and technical problems please contact us.
SIEB & MEYER AG
Auf dem Schmaarkamp 21
21339 Lueneburg
Germany
Phone: [phone]
Fax: [phone]
[e-mail]
http://www.sieb-meyer.com
SIEB & MEYER Shenzhen Trading Co. Ltd.
Room A208 2/F,
Internet Innovation and Creation Services Base Building (2),
No.126, Wanxia road, Shekou, Nanshan district,
Shenzhen City, 518067
P.R. China
Phone: [phone]
Fax: [phone]
[e-mail]
http://www.sieb-meyer.cn
SIEB & MEYER Asia Co. Ltd.
5 Fl, No. 578, Sec. 1
Min-Sheng N. Road
Kwei-Shan Hsiang
Guishan Dist., Taoyuan City 33393
Taiwan
Phone: [phone]
Fax: [phone]
[e-mail]
Drive Amplifier SD4B - Hardware Description

Table of Contents
Table of Contents
1 About this Manual.................................................................5
1.1 Illustration of Warnings................................................................................................5
1.2 Technical Symbols....................................................................................................... 5
1.3 Abbreviations................................................................................................................6
2 General Information..............................................................7
3 Safety Instructions................................................................8
3.1 Standards and Regulations......................................................................................... 8
3.2 Working on the Device.................................................................................................9
3.3 Appropriate Use............................................................................................................9
3.4 Reasonably Foreseeable Misuse.............................................................................. 10
3.5 Electrical Connection.................................................................................................11
3.6 Operation.....................................................................................................................12
3.7 Maintenance................................................................................................................13
3.8 Disposal.......................................................................................................................13
3.9 Legal Warranty............................................................................................................14
4 Unit Assembly Complying EMC........................................ 15
5 Drive Amplifier SD4B..........................................................16
5.1 Connection Examples................................................................................................ 16
5.2 Type Plate....................................................................................................................17
5.3 SD4B Type Designation............................................................................................. 18
5.4 General Technical Data.............................................................................................. 18
5.4.1 Storage and Transport..................................................................................................19
5.4.2 Installation and Operation.............................................................................................19
5.4.3 Current Derating Due to Site Altitude and Temperature...............................................20
5.4.4 Current Derating Due to Low Speed............................................................................ 20
5.4.5 S6 Duty Type................................................................................................................ 21
5.4.6 Technical Data of Interfaces......................................................................................... 21
5.4.7 Motor Control................................................................................................................22
5.4.8 Specification of Real Time Clock..................................................................................23
6 0SD4BB1D1Pxxxx...............................................................24
6.1 Dimensions and Mounting.........................................................................................24
6.2 Technical Data............................................................................................................ 26
6.2.1 Electrical Specification..................................................................................................26
6.2.2 Overload Times............................................................................................................ 27
6.3 Connectors, Displays and Buttons...........................................................................28
7 Connectors.......................................................................... 29
7.1 Operation of the Terminal Connectors..................................................................... 29
7.1.1 Spring-cage Connection...............................................................................................29
7.1.2 Push-in Spring Connection...........................................................................................29
7.2 Cable Requirements...................................................................................................30
7.2.1 Motor Cable..................................................................................................................32
7.2.2 Communication Cables................................................................................................ 33
7.2.3 Cables for the Rotor Position Detection....................................................................... 33
7.3 P2P Button.................................................................................................................. 34
7.4 X6 – encoder............................................................................................................... 34
7.4.1 Encoder Signals........................................................................................................... 35
7.4.2 Hall Sensor RS422.......................................................................................................36
7.4.3 Pulse Encoder 5 V........................................................................................................36
7.4.4 Incremental Encoder with TTL Signals.........................................................................37
7.5 X10 – Communication RS232/RS485/CAN............................................................... 37
7.5.1 RS232 Diagnosis..........................................................................................................38
7.5.2 RS485 Bus................................................................................................................... 38
Drive Amplifier SD4B - Hardware Description 3

Table of Contents
7.5.3 CAN interface............................................................................................................... 39
7.6 X11 – Ethernet 10/100 Mbit........................................................................................ 40
7.6.1 Ethernet communication...............................................................................................40
7.7 X13/X14 – Fieldbus IN/OUT........................................................................................41
7.8 X15 – Inputs/Outputs / Safety Circuit (STO).............................................................42
7.8.1 Digital Inputs.................................................................................................................43
7.8.2 Digital Outputs..............................................................................................................43
7.8.3 Analog Input................................................................................................................. 44
7.8.4 Connecting the Motor Protection..................................................................................45
7.8.5 Connecting the Safety Circuit.......................................................................................45
7.8.5.1 Wiring with OSSD........................................................................................................................ 45
7.8.5.2 Wiring without OSSD................................................................................................................... 46
7.9 X36 – DC Power Supply............................................................................................. 46
7.9.1 Connecting the Voltage Supply.................................................................................... 47
7.10 X53 – Motor Connection............................................................................................ 47
7.10.1 Connecting the Motor Phases...................................................................................... 48
8 Functional Safety................................................................ 49
8.1 Safety Circuit / Restart Lock (STO)...........................................................................49
8.1.1 Functional Description of the Restart Lock...................................................................50
8.1.2 Wiring Example............................................................................................................ 51
8.1.3 Requirements and Standards.......................................................................................53
8.1.4 Restart Lock Procedure................................................................................................54
9 LED Status Displays........................................................... 56
10 SD4x Drive Messages.........................................................58
10.1 Error Messages...........................................................................................................58
10.2 Messages.................................................................................................................... 62
11 Appendix..............................................................................64
A CPU Exception............................................................................................................64
B Manufacturers.............................................................................................................65
B.1 SIEB & MEYER Accessories........................................................................................65
B.1.1 Connector Kit............................................................................................................................... 65
B.2 Phoenix Contact........................................................................................................... 67
12 Index.....................................................................................68
4 Drive Amplifier SD4B - Hardware Description

1 About this Manual
This chapter describes symbols, signal words and abbreviations possibly used in this
manual.
Note
You can download more documentation from the SIEB & MEYER website under http://
www.sieb-meyer.de/downloads.html.
1.1 Illustration of Warnings
In this manual, the warnings listed below are used. Depending on their degree of risk,
the risk levels listed below exist:
DANGER
Imminent risk of injury
Indicates an imminently hazardous situation which, if not avoided, will re-
sult in death or serious injury.
→ Follow the instructions in this manual to avoid danger.
WARNING
Risk of injury
Indicates an imminently hazardous situation which, if not avoided, will re-
sult in death or serious injury.
→ Follow the instructions in this manual to avoid danger.
CAUTION
Slight risk of injury
Indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury or property damage.
→ Follow the instructions in this manual to avoid danger.
NOTICE
Notice
Indicates a hazardous situation which, if not avoided, may result in property damage.
→ Follow the instructions in this manual to avoid danger.
1.2 Technical Symbols
Symbol Description
LED indicator: LED on
LED indicator: LED off
LED indicator: LED flashes
5Drive Amplifier SD4B - Hardware Description
About this Manual

About this Manual
1.3 Abbreviations
BDM basic drive module
CCW counterclockwise
CW clockwise
DC diagnostic coverage of safety function
DHCP Dynamic Host Configuration Protocol: communication protocol for assigning the net-
work configuration to clients using a server
HFT hardware fault tolerance
HSPAM high-speed pulse amplitude modulation
HSPWM high-speed pulse width modulation
HW hardware
mF multifuse
MTTFd mean time to failure, dangerous
n.c. not connected
OSSD output signal switching device
P2P point to point (direct connection between two network nodes)
PAM pulse amplitude modulation
PELV protective extra-low voltage
PFH probability of dangerous failure per hour
PoE Power over Ethernet: power supply via Ethernet
PWM pulse width modulation
SELV safety extra-low voltage
SERVO servo control
SFF safe failure fraction
STO safety function: Safe Torque Off
SVC sensorless vector control
UVLO undervoltage-lockout
VCC voltage at the common collector
VECTOR vector control
VF V/f characteristic curve
6 Drive Amplifier SD4B - Hardware Description

2 General Information
This manual describes the drive amplifiers of the series SD4B. Drive amplifiers of the
generation SD4x are BDM (basic drive modules) that can be used either as frequency
converter or as servo amplifier.
The drive amplifiers of the series SD4B allow operation of high-dynamic servo motors
as well as asynchronous high-frequency spindles in the low-voltage range.
The devices provide interfaces for different digital encoder systems. In addition, motor
systems without any sensors are supported, whereas different customized control meth-
ods are available. The devices can drive rotary and linear motors so that the number of
device variants is reduced for the machine manufacturer.
For real-time requirements, the devices provide an optional fieldbus interface.
The devices are designed according to the standard DIN EN 61800-5-1.
This manual provides information on:
▶Safety instructions and application advice
▶Notes about the electromagnetic compatibility
▶Description of the device (block diagram, type plate, module designation)
▶Technical data, dimensions
▶Connector pin assignment
▶Wiring examples
▶Status and error messages
▶General information regarding the wiring (cables and line cross-sections)
This manual has the following demands on the trained staff of machine manufacturers:
Transport: only by skilled employees familiar with handling electrostatically sensitive compo-
nents.
Installation: only by experts with electromechanical experience
Initial operation: only by experts with experience in the fields of electrical engineering / drive technol-
ogy
Note
Information concerning the initial operation and parameterization of the digital drive am-
plifier can be found in the manual of the software drivemaster4.
Note
You can download more documentation from the SIEB & MEYER website under http://
www.sieb-meyer.de/downloads.html.
7Drive Amplifier SD4B - Hardware Description
General Information

Safety Instructions
3 Safety Instructions
These safety instructions include important information regarding your safety and must
be observed during installation and operation of SIEB & MEYER devices. Read them
carefully and keep them for later use.
Also adhere to safety instructions in the product documentation and on the device.
3.1 Standards and Regulations
SIEB & MEYER devices comply with the regulations of the following standards and di-
rectives:
▶Low-Voltage Directive 2014/35/EU:
EU declaration of conformity, DIN EN 61800-5-1
▶EMC Directive 2014/30/EU:
EU manufacturer's certificate, DIN EN 61800-3
▶Machinery Directive 2006/42/EC:
EU manufacturer's certificate, DIN EN 61800-5-2(safety functions)
Note
SIEB & MEYER frequency converters and servo amplifiers do not fall within the scope of
the Ecodesign Regulation (EU) 2019/1781 for motors and frequency converters as well
as the accompanying amendment (EU) 2021/341 because the devices are not designed
for the operation of the 50/60 Hz standard motors defined in the regulation.
Note
SIEB & MEYER products are no products according to the EU Machinery Directive. The
appropriate use of SIEB & MEYER devices in machines and installations is prohibited
until the manufacturer of the machine or installation confirms the CE conformity of the
complete machine or installation.
Note
If the mechanics or the electronics of the device are modified, the conformity with the
EC/EEC directives and thus the label will expire.
8 Drive Amplifier SD4B - Hardware Description

3.2 Working on the Device
WARNING
Trained staff
→ To avoid risks of serious injuries and material damage any works re-
garding installation, initial operation and maintenance must be carried
out by trained staff only! Furthermore, electricians who connect feed-
in systems must be approved by the local DSO (distribution system
operator).
→ Trained staff, according to this fundamental safety instruction, are
persons familiar with the installation, mounting, initial and permanent
operation of the product and they are qualified appropriately for the
work. The standards DIN VDE 0100 and DIN VDE 0110 as well as the
national accident prevention regulations shall be considered!
→ When installing feed-in systems adhere to all applicable regulations,
special safety instructions and technical connection conditions of the
local DSO.
DANGER
Risk of serious damage to property and personal injury may occur:
- when covers are removed illegally
- due to improper use
- when either the installation or the operation is incorrect
→ Observe the corresponding notes and information in the product doc-
umentation of your device.
WARNING
Risk of injuries and material damage due to illegal modifications
→ Only change the settings of the device after having contacted
SIEB & MEYER.
All Information and advice attached to the device, such as safety instructions or danger
warnings and technical data (type plate) are:
▶not to be removed
▶not to be damaged
▶to be kept readably (no covers, no paint over or the like)
3.3 Appropriate Use
Use the device according to its appropriate use only. Consider the corresponding infor-
mation regarding the application fields of the device in the product documentation.
The device is intended for use within an enclosed cabinet by the OEM or end user to
comply with pollution degree 2 or equivalent environmental conditions. That means: En-
sure to avoid conductive impurities and humidity during the operation.
SIEB & MEYER products are not suitable for use in areas exposed to explosion hazards
(ATEX zones) without approriate housing.
9Drive Amplifier SD4B - Hardware Description
Safety Instructions

Safety Instructions
Terms according to DIN EN 61800
Before initial operation, make sure that the machine will not expose danger (e.g. run-
away moves). The conformity with the safety standards DIN EN 60204-1 and DIN EN
61800-5-1 must be ensured.
The manufacturer of the system or the machine has to meet the requirements of the
legal values regarding the Electromagnetic Compatibility (EMC). SIEB & MEYER units
can be operated in industrial areas, provided that the attached EMC information has
been taken into consideration.
SIEB & MEYER tests all products in its own EMC laboratory to ensure that the products
meet the respective standards, when they are installed properly.
Installation of the device differing from the product documentation and the manual "EMC
Guidelines" means that the machine manufacturer has to carry out new measurements
to comply with the regulations.
SIEB & MEYER devices meet the requirements of the Low-Voltage Directive 2014/35/
EU. The harmonized standards of DIN EN 50178 and DIN EN 60204-1 in combination
with the standards DIN EN 60947 and DIN EN 61800-5-1 are applied consequently.
Technical data and the connection specification can be found in the respective product
documents.
Line filters
If adequate interference suppression measures are applied and the appropriate use in
industrial applications of the device is ensured SIEB & MEYER devices comply with the
Directive EMC Directive 2014/30/EU in terms of the EMC Product Standard (PDS) DIN
EN 61800-3.
The use of line filters helps reaching the following:
▶Resistance to interference. The electronic system is protected against high-fre-
quency disturbances, possibly infiltrated via the mains cable.
▶Protection against radiation. High-frequency disturbances are reduced to legally
authorized measure. This prevents effects of the transients to adjacent components
or devices.
▶Products, not equipped with an integrated AC supply line filter must be operated
with an upstream line filter.
▶Using SIEB & MEYER devices in residential or business areas as well in small busi-
nesses requires additional interference suppression.
For detailed information refer to the manual "EMC Guidelines", chapter "EMC Prod-
uct Standard DIN EN 61800-3 for PDS".
Note
Refer to the product documentation of your device to find out whether or not your device
is equipped with a line filter. For detailed information on line filters refer to the manual
"EMC Guidelines".
3.4 Reasonably Foreseeable Misuse
The Machinery Directive defines a "reasonably foreseeable misuse" as "use of machin-
ery in a way not intended in the instructions but which may result from predictable hu-
man behavior".
SIEB & MEYER products are no products according to the EU Machinery Directive.
During design and construction of the machine as well as in the operation manual the
machine manufacturer is obliged to give consideration to the intended (appropriate) use
of the machine and risks arising from reasonably foreseeable misuse of the machine.
10 Drive Amplifier SD4B - Hardware Description

To avoid injuries and material damage any use, installation and setup of SIEB & MEYER
products by non-experts which exceed the technical data specified in the product docu-
mentation (high voltages, temperatures etc.) is considered to be not intended use and
forbidden.
Adhere to the safety instructions on the device and in the product documentation.
3.5 Electrical Connection
DANGER
Risk of serious injuries due to touch voltages
After electric devices have been switched off touch voltages may occur de-
pending on the device up to 4 minutes. Longer construction-related dis-
charge times are possible. Refer to the product documentation of your de-
vice.
→ All work at and within the units must only be carried out, when the
units are turned off, the mains supply is cut and the DC bus is com-
pletely discharged.
→ Never touch energized parts after a device has been switched. off.
→ Consider the VDE regulations and the applicable accident prevention
regulations (e.g. VBG 1 and VBG 4).
DANGER
Risk of serious injuries due to improper connection to earth
Incorrect or insufficient connection of the system to earth may cause dan-
gerous currents.
→ Connection to earth must be realized according to the instructions in
the product documentation of your device.
The electrical installation must be carried out according to the relevant electrical codes
(e.g. appropriate wire gauges, fuse protection and connections of ground conductors
must be considered).
Note
SIEB & MEYERdevices are conceived for connection to symmetrically grounded TN
networks. For detailed information regading the connection to TN networks or other net-
works refer to the manual "EMC Guidelines", chapter "Connection to Different Supply
System Types".
Recommendations for the installation complying EMC (e.g. shields, connection to earth
and line installations) can be found in the technical manuals of your device (only for ma-
chine manufacturers). The manufacturer of the system or machine has to meet the re-
quirements of the legislation regarding the EMC.
11Drive Amplifier SD4B - Hardware Description
Safety Instructions

Safety Instructions
1. Consider that the mains supply must be protected via an overload release with re-
stricted guidance for each mains phase. The mains line should not be switched on,
before the work is completed.
2. Before turning on the unit the first time, make sure that the connected machine will
not have runaway axes.
3. Never connect capacitive loads to the output phases of the servo amplifiers and fre-
quency converters.
4. Prevent cable loops. Therefore, the units must only be connected to earth at the
provided PE connection for the mains supply line and the racks only at the provided
earth screw.
DANGER
Hazardous voltage
The use of filters causes leakage currents on the protective earth conduc-
tor (PE) which in the event of an error may be considerably higher than the
rated values. To protect persons against dangerous voltages filters must be
connected to earth before they are taken into operation. Possibly a resid-
ual current device cannot be used. According to DIN EN 61800-5-1/ DIN
EN 60204-1 the following measures are required when leakage currents
≥3.5 mA occur:
→ Install a connection without connector on the device and attach a cor-
responding warning note on the device. which also must appear in the
documentation of the device.
→ Use a protective conductor with min. conductor cross-section of
10 mm² or
→ install a second protective conductor: connect it in parallel to the first
protective conductor by using separate terminals.
Operation with residual current device (RCD)
Note
For detailed information regarding the operation with residual current device (RCD) re-
fer to the manual "EMC Guidelines", chapter "Safety-relevant Aspects, Residual Current
Device (RCD)". Also consider the standard DIN EN 60204-1, section 8: additional re-
quirements for electrical equipment with earth leakage currents greater than 10 mA.
3.6 Operation
WARNING
Risk of serious personal injury due to moving machine parts
During the operation of an installation with open doors or removed covers,
persons may seriously be injured by moving machine parts.
→ Keep the doors closed during the operation and do not remove cov-
ers.
12 Drive Amplifier SD4B - Hardware Description

WARNING
Risk of injuries and material damage due to flying parts
Persons may be injured or material be damaged, if screws of the front pan-
els and housing parts are not fastened.
→ Before the initial operation of the installation ensure that all screws are
tightened.
WARNING
Risk of burn due to hot surfaces
During operation the units can have hot surfaces according to their protec-
tion system. In particular this applies to ventilation inlets and outlets.
Never touch device parts during operation apart from operating units.
When using ferrite rings temperatures may exceed 80 °C in some cases.
→ Only use cables that are provided for temperatures over 90 °C. This
corresponds to the flammability rating UL 94V-0, RTI 105 °C. Dies
entspricht der Entflammbarkeitsklasse UL 94V-0, RTI 105 °C.
→ Consider the relevant notes in the manual.
Systems, into which servo amplifiers and frequency converters are mounted, possibly
must be equipped with additional protective devices according to the valid safety instruc-
tions (e.g. law about technical material, rules for prevention of accidents, etc.)
3.7 Maintenance
The unit must be checked regularly for cleanness and functionality depending on the
ambient pollution. This applies in particular for installed fans.
3.8 Disposal
Note
Make sure to consider country-specific waste and disposal laws and statutes for the dis-
posal of packing material, used batteries and irreparable devices.
SIEB & MEYERproducts meet the requirements of the following directive:
▶2011/65/EU (EU-directive RoHS 2 on the restriction of the use of hazardous sub-
stances in electrical and electronic equipment)
SIEB & MEYERproducts do not exceed the limits of the directive 2011/65/EU for haz-
ardous substances.
SIEB & MEYERproducts labeled with the adjacent symbol also meet
the regulations of the following directive:
▶SJ/T 11364-2014 (China RoHS 2 on the restriction of the use of
hazardous substances in electrical and electronic equipment)
SIEB & MEYER products labeled with the symbol above do not exceed the limits of the
directive SJ/T 11364-2014 for hazardous substances.
13Drive Amplifier SD4B - Hardware Description
Safety Instructions

Safety Instructions
3.9 Legal Warranty
SIEB & MEYER products are liable to a legal warranty of at least one year. Any claims
for the products beyond this warranty shall be declared in an additional contractual
agreement between SIEB & MEYER and the customer.
Claims for damages are excluded:
▶due to improper use of the device
▶when the device has been installed nonstandard or improperly, especially by elec-
tricians without license
▶when the device has been employed although the protection equipment was defec-
tive
▶when the maximum permissible input voltage has been exceeded
▶due to improper operation
▶when the device or its equipment have been modified
▶due to repairs that were not carried out by SIEB & MEYER or a repair shop ap-
proved by SIEB & MEYER
▶when the device was affected by foreign material or force majeure
NOTICE
Due diligence of the machine manufacturer
→ A first programming carried out by SIEB & MEYER does not release the machine
manufacturer from his duty to check the programmed values for correctness.
14 Drive Amplifier SD4B - Hardware Description

4 Unit Assembly Complying EMC
Note
The EU guidelines for electromagnetic compatibility (EMC) must be considered for the
initial operation of all SIEB & MEYER devices.
The manual "EMC Guidelines" is available in German and English and includes:
▶EMC rules
▶information regarding the professional grounding and wiring
▶safety-relevant aspects
▶extracts from the EMC product standard
▶possibilities for the connection to different supply system types
Availability:
▶PDF file under www.sieb-meyer.de/downloads.html
15Drive Amplifier SD4B - Hardware Description
Unit Assembly Complying EMC

Drive Amplifier SD4B
5 Drive Amplifier SD4B
5.1 Connection Examples
Fig. 1: SD4B connection examples
Fig. 1: SD4B connection examples
16 Drive Amplifier SD4B - Hardware Description

5.2 Type Plate
Fig. 2: Example of type plate SD4B
Fig. 2: Example of type plate SD4B
No. Meaning Explanation
Type designation indicates the exact device type (see page 18)
IP code Indicates the level of protection of the device against touching or
intrusion of solid objects (1st digit) and water ingress (2nd digit)
Device version Indicates the version of the hardware; if no version is existent,
0.000 is indicated here
Technical data Specifies technical data such as the input and output power, the
output frequency, etc.
Serial number Indicates the individual number of the device
QA label Test steps for quality assurance:
▶V = pretest or partial test
▶H = high-voltage test
▶W = thermal test
▶E = final tests
During testing, the QA test steps are marked, see below.
Markings of QA test steps
The QA test steps can have the following markings:
two diagonal lines: Test step is completed.
one diagonal line: Test step is not required.
No marking: Test step was not yet carried out.
Note
Which test steps are required is specified in the corresponding test instruction.
17Drive Amplifier SD4B - Hardware Description
Drive Amplifier SD4B

Drive Amplifier SD4B
Example:
W
V H
E
Pretest (V) and high-voltage test (H) were successfully completed;
thermal test (W) is not required; final tests (E) still need to be carried
out.
5.3 SD4B Type Designation
Type: e.g. 0SD4BB1D1P000U
Version: e.g. 1.000
0SD4 B b k X Y Z f p s z a b c d
Generation
0SD4
Product series [A-Z]
B = basic/board
b: size [width × height × depth]
B = 25 × 165 × 120 mm
k: type of cooling [0-9]
1 = passive air cooling
X: current class [A-Z] [Arms]
D = 14
Y: number of output stages or current class of dou-
ble-axis device [1-4, A-Z]
1 = single output stage
Z: voltage class (input voltage [Vac=A-M, Vdc=N-Z] /
output voltage [Vac])
A = input 80 Vac / output 50 Vac
f: variant fieldbus [0-9]
0 = no fieldbus
1 = EtherCAT / POWERLINK / PROFINET RT
p: extension module (no retrofit) [0-9]
0 = no extension module
s: safety option (STO is always available) [0-9]
0 = no additional safety functions
1 = SFM/SLOF
z: export license [A-Z]
U = unlimited output frequency
L = max. output frequency limited to 599 Hz
abcd: administrative options [0-9, A-Z]
Device version X.XXX
Continuous counter: If there is no device version, 0.000 is indicated here. If a device
is exchanged by a device of another version, please contact SIEB & MEYER to check
whether the devices are compatible or not.
In addition, the device version indicates the update capability of the internal device soft-
ware, e.g. BIOS, FPGA or Firmware.
5.4 General Technical Data
The following data apply to all devices of the series SD4B.
18 Drive Amplifier SD4B - Hardware Description

5.4.1 Storage and Transport
Avoid improper mechanical load of the device. The following points must especially be
taken into consideration:
▶Never touch electronic components.
▶Avoid stacking of unpacked devices during transport and storage.
▶Sudden changes of the temperature must not exceed 0.5 °C/min.
The following climatic conditions apply to transport and storage. If required, appro-
priate measures must be taken to ensure these climatic conditions (installation of
heating/air conditioning systems etc.):
Environmental conditions Storage acc. to DIN EN
IEC 60721-3-1 in product
package (up to 6 months)(1)
Transport acc. to DIN EN
IEC 60721-3-2 in shipping
package (over 6 months)
Climatic conditions Class 1K4 Class 2K3
Min. −25 °C −25 °C
Ambient temperature(2)
Max. 55 °C 70 °C
Vibrations Class 1M2 Class 2M1
Chemically active substances Class 1C1 Class 2C1
Relative/absolute humidity Class 1K3 (5 %
RH to 85 % RH)
Class 2K3 (5 %
RH to 85 % RH)
Rain Not permissible Not permissible
Water (not rain) Not permissible Not permissible
Condensation, water spray and ice Not permissible
Salt spray Not permissible
Tab. 1: Environmental Conditions for Storage and Transport
(1) The product package used by SIEB & MEYER does not comply with the standard of a shipping package.
In addition, it does not provide protection against water spray, ice and salt spray.
(2) The limit values apply with the coolant removed.
Tab. 1: Environmental Conditions for Storage and Transport
Note
The maximum storage period is 2 years. Electrolytic capacitors produce high leakage
currents when a voltage is applied after a long storage period without applied voltage
and must be reformed. For this purpose, the operating voltage is applied via a 1 kΩ se-
ries resistor for one hour. Please contact the SIEB & MEYER service department for de-
tails.
5.4.2 Installation and Operation
NOTICE
Damage of electrostatically sensitive components due to improper handling
→ Never touch electronic components.
The following requirements are to be considered for the installation and the operation
of the device. Noncompliance with theses requirements is regarded as abnormal op-
erating condition:
Environmental conditions Operation acc. to DIN EN IEC 60721-3-3
Place of installation Switch cabinet installation, indoor, weath-
erprotected, without air conditioning
Climatic conditions Class 3K3
Temperature range 5 °C to 60 °C (100 % rated current up to max.
40 °C; at higher temperatures the rated cur-
rent must be reduced by 1.5 % per 1 C°.)
Humidity range 5 % RH to 85 % RH (non-condensing)
Tab. 2: Environmental Conditions during Operation
19Drive Amplifier SD4B - Hardware Description
Drive Amplifier SD4B

Drive Amplifier SD4B
Environmental conditions Operation acc. to DIN EN IEC 60721-3-3
Degree of pollution acc. to DIN EN
61800-2
2
Max. site altitude 2000 m above MSL (Units with air cooling only: 100 % rat-
ed current up to 1000 m above MSL; at higher altitudes
the rated current must be reduced by 1.5 % per 100 m.)
Moisture level of human skin Dry
Chemically active substances Class 3C1 (no salt spray)
Mechanically active substances Class 3S1 (no requirement)
Class Class 3M2
2 to 8 Hz: Amplitude excursion = 1.5 mmVibrations
9 to 200 Hz: Amplitude of acceleration = 5 m/s²
Mechanical stability
Shock Peak acceleration = 40 m/s²
Biological influences Class 3B1 (no requirement)
UV resistance No requirement
Tab. 2: Environmental Conditions during Operation
Tab. 2: Environmental Conditions during Operation
Important
Make sure that the aeration elements are free and open, so that the air circulation is not
restricted.
5.4.3 Current Derating Due to Site Altitude and
Temperature
The following table indicates the rated current in percent depending on the site altitude
and the ambient temperature:
Site altitude above MSL
Temperature ≤1000 m ≤2000 m
≤40 °C 100 % 85 %
≤50 °C 85 % 70 %
≤60 °C 70 % 55 %
Linear interpolation is allowed.
Tab. 3: Current Derating Due to Site Altitude and Temperature
Tab. 3: Current Derating Due to Site Altitude and Temperature
5.4.4 Current Derating Due to Low Speed
During phases of a static rotating field or low rotating field frequencies (f ≤ 5 Hz) the
power semiconductors of the output stage are subject to higher loads.
20 Drive Amplifier SD4B - Hardware Description
