OPERATING INSTRUCTIONS
SICHARGE UC
Dispenser UL
May 
usa.siemens.com/sichargeuc

SICHARGE UC Dispenser UL | Operating Instructions
. Introduction
. Safety instructions
. Description
. Application planning
. Installation
. Connecting
. Commissioning
. Operation
. Handling alarms and errors
. Maintenance and service
. Disposal
. Service and support
. Technical specifications
. Declaration of Conformity
A. Abbreviations
Sections


Operating Instructions | SICHARGE UC Dispenser UL
Legal information
Warning notice system
This manual contains notices you must observe in order to ensure your personal safety as well as prevent damage to property. The
notices referring to your personal safety are highlighted in the manual by a safety alert symbol, while notices referring only to
property damage have no safety alert symbol. The notices shown below are graded according to the degree of danger.
DANGER
This indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
This indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
This indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
This indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will be used. A notice
warning of injury to persons with a safety alert symbol may also include a warning relating to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific task in accordance
with the relevant documentation; in particular, its warning notices and safety instructions. Qualified personnel are those who, based
on their training and experience, can identify risks and avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation, and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication may be
trademarks whose use by third parties for their own purposes could violate the rights of the owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software described. Since variance
cannot be precluded entirely, we cannot guarantee full consistency. However, the information in this publication is reviewed
regularly and any necessary corrections are included in subsequent editions.


SICHARGE UC Dispenser UL | Operating Instructions
 Introduction 
. FCC compliance 
. About the operating instructions 
. Open-source software 
. Security Information 
. Note regarding general data protection regulation 
 Safety instructions 
. Basic safety instructions 
. The five safety rules for electrical work 
. Safety sign 
. Industrial Security 
. Identification of the device 
 Description 
. Product overview 
. Overview of variants 
. Structure of a SICHARGE UC dispenser 
.. External structure 
.. Internal structure 
. Charging cable type  
. Electrical protection devices 
 Application planning 
. Incoming inspection of the devices 
.. Checking the delivery for completeness and correctness 
.. Checking the transport packaging 
.. Unpackaging the charging station 
.. Reporting missing delivery components or transport damage 
. Location planning 
. Preparing the mounting surface 
.. Preparing for floor mounting 
.. Preparing for wall mounting 
. Storing the dispenser 
Table of Contents


Operating Instructions | SICHARGE UC Dispenser UL
. Transporting the dispenser 
 Installation 
. Safety instructions 
. Floor mounting 
.. Mounting the dispenser on the floor 
. Wall mounting 
.. Mounting the dispenser to the wall 
 Connecting 
. Safety instructions 
. Connecting the power supply cable 
. Connecting the DC cable 
. Connecting the communication cable 
 Commissioning 
. Switching on the dispenser 
 Operation 
. Safety instructions 
. Plugging in the charging cable 
. Monitoring the charging process 
. Stopping charging 
. Unplugging the charging cable 
. Displaying alarms 
. Operating the Service menu 
.. Selecting options 
.. Checking recorded alarms 
.. Restarting the charging process after an alarm 
.. Displaying information about the charging station 
.. Displaying energy delivered during the last charging session 
.. Displaying the current and voltage trend of the charging process 
.. Selecting advanced options 
 Handling alarms and errors 
. Overview 
. "Emergency Stop" alarm message 
. "Cabinet Door Opened" alarm message 
. "Ground Fault Detection" alarm message 


SICHARGE UC Dispenser UL | Operating Instructions
. Alarm messages in the alarm history 
 Maintenance and service 
. Safety instructions 
. Maintenance plan 
. Checking the outside of the charging station 
. Testing the inside of the charging station 
. Servicing the charging station 
.. Cleaning the touch screen 
.. Cleaning the cabinet and the charging cable 
.. Cleaning the ventilation grille 
 Disposal 
. Disposing of the packaging 
. Disposing of the charging station 
 Service and support 
 Technical specifications 
. Technical specifications 
. Charging the current/power curve 
 Declaration of Conformity 
. Declaration of Conformity 
A List of abbreviations 
A. Abbreviations 
Index 


Operating Instructions | SICHARGE UC Dispenser UL
SECTION 1
Introduction
. FCC Compliance
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant
to part  of the FCC Rules. These limits are designed to provide reasonable protections against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, this is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance may void
the user’s authority to operate the equipment and the warranty on the product.
Contact information
Siemens Industry, Inc.
Smart Infrastructure
 Parkway Ln. Peachtree Corners, GA 
---
usa.siemens.com/sichargeuc
More information
Product information is subject to change without notice.
All trademarks are recognized as the property of their respective owners.
For Siemens SICHARGE UC™ Warranty Terms and Conditions, see the Warranty section of this manual.
©  Siemens Industry, Inc. All rights reserved.


SICHARGE UC Dispenser UL | Operating Instructions
. About the operating instructions
These operating instructions contain the information necessary for the safe operation and intended
use of the SICHARGE UC dispenser.
Safekeeping the operating instructions
The operating instructions are an integral part of the product and an indispensable part of the product safety concept.
The following requirements therefore apply for safekeeping the operating instructions:
• Keep the operating instructions for the entire service life of the SICHARGE UC dispenser.
• Make the operating instructions easily accessible for all persons involved at all times.
• When you transfer the SICHARGE UC dispenser to a third party, also transfer the operating instructions.
Using the operating instructions
How to use the operating instructions correctly:
• Make the operating instructions available to all persons involved before they start working and while
they are working on the SICHARGE UC dispenser.
• Read the operating instructions carefully before starting work.
• Follow the safety instructions and handling instructions.
Definition
• SICHARGE UC charging station
The SICHARGE UC charging station converts the connected main voltage into direct voltage for
charging electric vehicles. To provide multiple charge points for electric vehicles at a SICHARGE UC
charging station, you can connect multiple SICHARGE UC dispensers in series to the SICHARGE UC
charging station.
• SICHARGE UC dispenser
The SICHARGE UC dispenser switches and controls the charging of connected electric vehicles.
. Open-source software
Open-source software is used in the firmware of the product described. Open-source software is provided
free of charge. We are liable for the product described, including the open-source software contained in it,
pursuant to the conditions applicable to the product. Siemens accepts no liability for the use of the open-source
software over and above the intended program sequence or for any faults caused by modifications to the software.
For legal reasons, we are obliged to publish the original text of the license conditions and copyright notices.
Please also read the information that is supplied with the product or made available here (assets.new.siemens.com/
siemens/assets/api/uuid:bedade-ea-- -dcdda/sicharge-uc-open-source-software.pdf).


Operating Instructions | SICHARGE UC Dispenser UL
. Security Information
Siemens provides products and solutions with industrial security functions that support the secure
operation of plants, systems, machines and networks.
In order to protect plants, systems, machines, and networks against cyber threats, it is necessary to
implement – and continuously maintain – a holistic, state-of-the-art industrial security concept.
Siemens’ products and solutions constitute one element of such a concept.
Customers are responsible for preventing unauthorized access to their plants, systems, machines, and
networks. Such systems, machines, and components should only be connected to an enterprise
network or the internet if and to the extent such a connection is necessary and only when appropriate
security measures (such as firewalls and/or network segmentation) are in place.
For additional information on industrial security measures that may be implemented, please visit
(https://www.siemens.com/industrialsecurity).
Siemens’ products and solutions undergo continuous development to make them more secure.
Siemens strongly recommends that product updates are applied as soon as they are available and that
the latest product versions are used. Use of product versions that are no longer supported and failure
to apply the latest updates may increase customers’ exposure to cyber threats.
To stay informed about product updates, subscribe to the Siemens Industrial Security RSS Feed visit
(https://www.siemens.com/industrialsecurity).
. Note regarding the general data protection regulation
Siemens observes the principles of data protection; in particular, the principle of data minimization
(privacy by design). For this product this means:
The product does not process / store any personal data, only technical functional data (such as the
time stamp). If the user links this data with other data (such as shift plans) or stores personal data on
the same medium (such as a hard disk) and thus establishes a personal reference, the user must
ensure compliance with data protection regulations.


SICHARGE UC Dispenser UL | Operating Instructions
. Basic safety instructions
The SICHARGE UC dispenser meets all required technical standards and therefore provides the greatest
possible product safety. To ensure the safety of all persons, systems, and equipment at all times, adhere
to the following basic safety instructions.
Important safety instructions
SAVE THESE INSTRUCTIONS - This manual contains important instructions for SICHARGE UC that must be
followed during the installation, operation, and maintenance of the unit. Please note the ambient temperature
ratings in Section ..
Guidelines and regulations
In order to ensure comprehensive safety, adhere to the following guidelines and regulations:
• Guidelines for occupational safety
• Regulations for the prevention of accidents
• Trade regulations
• Technical connection conditions of the power supply unit
• Building regulations
• Generally accepted rules of technology
Target group
These operating instructions are intended for the following persons:
• Planners
– Planning the location of the charging station
• Carriers
– Transporting the charging station to the place of use
• Installers
– Mounting the charging station
• Qualified electricians
– Connecting electrical cables to the charging station
– Performance of the electrical work on the charging station
• Users
– Charging electric vehicles
• Service personnel
– Performing maintenance and servicing
SECTION 2
Safety instructions


Operating Instructions | SICHARGE UC Dispenser UL
Intended use
Intended use of the SICHARGE UC dispenser is limited exclusively to the charging of batteries of electric
vehicles. The electric vehicle must be equipped with a CCS type  charging socket for this. The SICHARGE UC
dispenser charges electric vehicles in accordance with the SAE J and SAE J standards. Any other or
additional use is not in accordance with the intended use and constitutes misuse of the device. The SICHARGE
UC dispenser can be used indoors and outdoors. Observe the permissible ambient conditions when used for
the intended purpose.
Qualified personnel
All work on the SICHARGE UC dispenser may only be performed after having received the proper instructions.
Non-electrical work, such as transport and assembly, may only be performed by qualified personnel. Qualified
personnel are qualified by training and experience to recognize risks arising during the respective work and to avoid
possible hazards.
Electrical engineering work may only be performed by qualified electricians themselves or under their direction and
supervision. A qualified electrician is someone who is able to assess the work assigned to them and recognize potential
dangers due to their professional training, knowledge, and experience as well as knowledge of the relevant standards.
Personal protective equipment (PPE)
PPE protects you against hazards to your health and safety. Use your PPE in accordance with occupational
safety guidelines and accident prevention regulations.
Fall arrester
When you are working at a height above  m, use a fall arrester.
Use work platforms/lifting platforms to provide qualified personnel with a stable surface.
Take necessary precautions to prevent tools and components from falling.
Fire and explosion protection
Do not store or use highly flammable liquids that produce flammable vapors, such as gasoline or ethanol, in the
proximity of the SICHARGE UC dispenser. Electrostatic charge or heat generated during charging can ignite
explosive and flammable liquids.
WARNING
In case of a fire, leave the danger zone.
Do not use the SICHARGE UC dispenser in case of a fire.


SICHARGE UC Dispenser UL | Operating Instructions
Protection against electromagnetic fields
The electromagnetic emission in the charging station meets the requirements of the UL  standard:
Note
Radio interferences
The operation of this device can cause radio interferences in residential areas.
Protection against ingress of liquid
The protection standard of the cabinet protects the SICHARGE UC dispenser from ingress of water
splashing against it from all directions. In particular, the NEMA R enclosure prevents the ingress of
precipitation and any liquid not under pressure that comes into contact with the cabinet surface.
In addition, protect the SICHARGE UC dispenser from liquids hitting the cabinet surface under pressure:
• Never use a pressure washer or steam cleaner to clean the SICHARGE UC dispenser.
• Set up the SICHARGE UC dispenser at a flood-proof location.
Protection against unauthorized opening
A lock system protects the SICHARGE UC dispenser from unauthorized opening of the device door.
• Only make the key available to authorized personnel for work performed inside the SICHARGE UC dispenser.
• Do not leave the SICHARGE UC dispenser unattended when the device door is open.
WARNING
Electric shock due to ingress of liquid.
Powerful water jets or flooding can cause the liquid to enter the SICHARGE UC dispenser. Moisture
or liquid inside the SICHARGE UC dispenser can lead to electric shock.
Conduct the following safety measures when there is a chance that liquid may have entered the
SICHARGE UC dispenser:
• Shut down the SICHARGE UC dispenser by disconnecting the power supply to the SICHARGE UC
charging station.
• Qualified personnel must dry the SICHARGE UC dispenser and check it for damages.


Operating Instructions | SICHARGE UC Dispenser UL
Alterations to the device
The operating instructions describe all permissible alterations to the SICHARGE UC dispenser.
Any other or additional changes are not permitted. Unauthorized modifications void the manufacturer’s
warranty and the approvals of the device become invalid.
Only use undamaged equipment or parts
WARNING
Danger due to missing or unrecognizable safety signs and warnings
Missing or unrecognizable safety signs or warnings do not indicate that danger is no longer present.
Undetected dangers can result in accidents regarding serious physical injury or death.
• Use the operating instructions to verify that all safety signs and warnings are attached.
• Replace missing safety signs and warnings.
• Do not remove safety signs and warnings.
• Replace unrecognizable safety signs and warnings.
NOTICE
Manipulation at the connections
Manipulation of the following connections is prohibited:
• Charging plug
• AC/DC inputs
• AC/DC outputs
WARNING
Electric shock in case of damaged equipment
Improper handling can damage the equipment. Damaged devices may have dangerous voltages on
the cabinet or exposed components, which can cause serious injury or death if touched.
• Comply with the technical specifications for transport, storage, and operation.
• Check the charging cables and the charging plugs for manipulation, damage, and foreign bodies.
• Do not use a device if it is damaged.


SICHARGE UC Dispenser UL | Operating Instructions
. The five safety rules for electrical work
NFPA E “Standard for Electrical Safety in the Workplace” prescribes safety rules for working in and on electrical
systems. To ensure the safety of persons and property in accordance with the standards, always comply with the
following safety rules:
Securing an electrical system before starting work
Before starting work on and in electrical installations, apply the following five safety rules:
. Disconnect the charging station from the voltage source
. Secure against reclosing
. Ensure there is no voltage present
. Install temporary grounding means
. Install temporary shields over any adjacent live parts
Prepare to switch on again after work is finished
After finishing and checking the work, prepare the restart as follows:
• Inform persons no longer required that the work is completed and no further work is permitted.
• Withdraw all persons no longer required.
• Remove all tools, equipment, and aids used.
Switch on the electrical system again
After finishing the work, remove the protective measures and switch the system on again:
. Remove temporary shields over live parts
. Remove temporary grounding means
. Reinstate any reclosing
. Close and latch all doors
. Switch the system back on
. Safety sign
Safety signs are attached to the SICHARGE UC dispenser and on the packaging for safe handling of the
SICHARGE UC dispenser.


Operating Instructions | SICHARGE UC Dispenser UL
Safety signs on the packaging
The following safety signs are attached to the packaging of the SICHARGE UC dispenser:
Safety signs in the cabinet of the SICHARGE UC dispenser
The following safety signs are attached in the cabinet of the SICHARGE UC dispenser:
Safety sign Meaning
Marking of the center of gravity
Warning of tipping hazard
Marking of the places at which forklifts are not
allowed to lift
Tilt indicator
Safety sign Meaning
Warning of dangerous voltage


SICHARGE UC Dispenser UL | Operating Instructions
. Industrial Security
Siemens AG provides products and solutions with industrial security functions that support the secure
operation of plants, systems, machines, and networks.
Implement and maintain the industrial security concept
In order to protect plants, systems, machines, and networks against cyber threats, it is necessary to
implement and continuously maintain a holistic, state-of-the-art industrial security concept. Siemens’
products and solutions constitute one element of such a concept. Customers are responsible for
preventing unauthorized access to their plants, systems, machines, and networks. Systems, machines,
and components should only be connected to the enterprise network or the internet if and to the extent
that it is necessary and with appropriate security measures in place (such as using firewalls and
network segmentation).
In addition, the recommendations of Siemens regarding appropriate protective measures should be
observed. You can find additional information about Industrial Security at:
Industrial Security (siemens.com/cybersecurity#ouraspiration).
Only use current product versions
Siemens’ products and solutions undergo continuous development to make them more secure. Siemens
strongly recommends that product updates are applied as soon as they are available and that the latest
product versions are used. Using versions that are obsolete or are no longer supported can increase the
risk of cyber threats.


Operating Instructions | SICHARGE UC Dispenser UL
. Identification of the device
The nameplate clearly identifies the charging station. To this end, the nameplate contains the identification
data of the device, the manufacturer, and the UL marking.
Information on the nameplate
You can find the following information on the nameplate of the charging station:
Figure - Example of a SICHARGE UC dispenser UL nameplate
Position of the nameplate on the device
The nameplate is positioned at the upper right corner on the front of the cabinet.


SICHARGE UC Dispenser UL | Operating Instructions
SECTION 3
Description
. Product overview
The SICHARGE UC dispenser allows for the high power charging of vehicles powered by electricity.
Thanks to the support of the open, universal charging standard CSS type , the SICHARGE UC dispenser
charges a variety of vehicle models from different manufacturers both quickly and efficiently.
The SICHARGE UC dispenser is used for the decentralized distribution of charging ports of a SICHARGE UC
charging station.
Performance features
The SICHARGE UC dispenser charges your electric vehicle quickly and safely. To start the charging process,
connect the charging cable to your vehicle. The SICHARGE UC dispenser then controls the entire charging
process fully automatically and accurately.
The SICHARGE UC dispenser is characterized by the following performance features:
• Fully automatic control of the charging process
• User-friendly operation thanks to a central touch screen
• Space-saving construction
• High availability
• Easy maintenance and servicing
• Attractive indication LEDs


Operating Instructions | SICHARGE UC Dispenser UL
Different versions
The SICHARGE UC dispenser is available in various versions. Therefore, the graphics are displayed with
many options. The local SICHARGE UC dispenser may not include one of the options described.
The figure below shows the two different mounting variants:
 
 a Floor mounting
 s Wall mounting
Figure - Mounting variants
Application
The SICHARGE UC dispenser is intended for charging of electric vehicles in semi-public commercial
and industrial areas such as:
• Terminals
• Vehicle depots
• Company parking lots


SICHARGE UC Dispenser UL | Operating Instructions
. Overview of variants
Overview of variants for floor mounting
The following table shows a comparison of the basic version and the variant with all options available for floor mounting:
Floor mounting
aLED lighting
s Touch screen (HMI)
d Cable holder
fVentilation slots
gFloor mounting plate

