Siemens Tek wireless enhancement User manual

Tek wireless enhancement
User Guide

2

3
Content
Content
Introduction 4
TEK 5
Intended use 7
General notes on safety 8
Getting started 12
Basic functions 15
Display information 18
What is Bluetooth? 20
Using the remote control with a phone 21
Using the Tek Transmitter 27
Using the direct audio input 33
Maintenance and care 35
Technical information 36
Technical Data - power supply 38
Disposal information 39

Introduction
4
Dear Customer,
Your hearing instruments equipped with e2e wirelessTM
2.0 technology can be controlled by your new Tek Con-
nect remote control.
This remote control offers you more hearing comfort in
your daily activities. Via Bluetooth it links your hearing
instruments to the expanding world of electronic media.
It will support you when you watch television, listen to
music or talk on the phone.
These instructions, together with the guidance from your
Hearing Care Professional, will help you to understand
how your remote control works.
If you have further questions, please contact your Hearing
Care Professional.
Introduction

Introduction
5
Included in delivery
Device and accessories:
■ Tek Connect remote control with rechargeable battery
and lanyard
① Display
② Program buttons
③ Volume buttons
④ Telephone buttons;
remote control on/off
⑤ Microphone opening
⑥ Key lock
⑦ Read out button;
hearing instruments
on/off
⑧ SoundBalance buttons
⑨ 2.5 mm stereo socket
⑩ Socket for power plug
■ Tek Transmitter
① On/off switch
② Sound level
③ Socket for power plug
④ 2.5 mm stereo socket
⑤ LED
TEK

Introduction
6
■ 2 Power plugs with country specific adapters (one for
remote control, one for Tek Transmitter)
■ Cables:
□ 1.8 m audio cable with 3.5 stereo
plug on one side and a 2.5 mm
stereo plug on the other side
□ 0.3 m audio cable with 3.5 stereo
plug on one side and a 2.5 stereo
plug on the other side
■ Adapter set:
□ 2.5 stereo plug to 3.5 stereo socket
□ 6.3 stereo plug to 3.5 stereo socket
□ RCA (cinch) to 3.5 stereo socket
□ RCA (cinch) to SCART

Intended use
7
This remote control is intended to operate hearing
instruments.
Read and follow the instructions of this user guide to
avoid injuries or damage to remote control.
Symbols:
Be aware of information marked with the warning symbol
WARNING, CAUTION or NOTICE!
WARNING points out a situation that could
lead to serious injuries, CAUTION indicates a
situation that could lead to minor and moder-
ate injuries.
NOTICE NOTICE indicates possible property damage.
Advice and tips on how to handle your device
better.
Instruction. Indicates that something has to be
done.
Intended use

General notes on safety
8
WARNING
Wireless systems may interfere with devices and
electronic equipment.
Turn the remote control off when in hospitals or
airplanes.
Do not use with life supporting systems.
The remote control may respond when triggered
by an external Bluetooth device.
NOTICE
The remote control is sensitive to extreme heat,
high humidity, strong magnetic fields (> 0.1T),
X-rays and mechanical stress.
Do not expose the remote control to extreme
temperature or high humidity.
Do not leave it in direct sunlight.
Do not immerse it in water.
Do not place your remote control in a micro-
wave oven.
In some countries restrictions for the usage of
wireless equipment exist.
Refer to local authorities for further informa-
tion.
General notes on safety

General notes on safety
9
The performance of the e2e wireless function may
be affected by electromagnetic interference – e.g.
from a computer monitor or fluorescent lamp
system.
Move away from the source of interference if
you experience difficulty.
In the event your hearing instruments can be
controlled by another person's remote control,
return hearing instruments and remote control
to your Hearing Care Professional.
WARNING
Risk of interference with cardiac pacemakers.
Do not use the remote control if you are fitted
with a cardiac pacemaker.
WARNING
Hazard of explosion in gas-filled spaces!
Do not use your hearing instruments and re-
mote control in areas where there is danger of
explosions (e.g. mining).

General notes on safety
10
WARNING
Strangulation hazard when lanyard gets entangled
in moving mechanical parts of machines for ex-
ample.
Use only the delivered breakaway lanyard. It will
automatically detach when entangled.
Do not use lanyard for children under the age of
twelve.
WARNING
Risk of explosion when the rechargeable battery is
handled wrong.
Do not short circuit, pierce, crush or disassem-
ble the rechargeable battery.
Prior to return the battery for recycling, tape the
electrodes to prevent short circuit, which may
cause the battery to explode.
Do not place it in oven or fire.
Do not immerse it in water.
Charge the rechargeable battery between 0ºC
and 45ºC.
Remove the rechargeable battery when the
instrument is not in use for a prolonged period
of time.

General notes on safety
11
Batteries contain harmful substances that pollute
the environment.
Do not throw used batteries into household
trash.
Return them to your Hearing Care Professional
for environmentally correct disposal.
WARNING
Choking hazard posed by small parts.
Keep batteries, small parts and remote control
out of children‘s reach.
If swallowed consult a physician or hospital im-
mediately.
NOTICE
Please make sure that the power plug is easily ac-
cessible to remove it from power supply if neces-
sary.

Getting started
12
Set up the remote control
Insert the rechargeable battery into the remote control:
Insert first the top part of the battery (the part without
contacts) into the top part of the battery compartment.
Press down the bottom part of the battery into the bat-
tery compartment.
The contact areas of battery and battery compartment
match up.
Charge the rechargeable battery before first use.
Charging process
Connect the remote control with
the power plug to a power supply.
The charging process starts. Charg-
ing time is about 5 hours depend-
ing on the status of the recharge-
able battery.
Charging is complete when the bat-
tery symbol shows a full battery.
Running time of the rechargeable battery
The running time of the rechargeable battery depends on
the way the remote control is used.
■ The function with the highest power consumption is
the transmission of an audio signal. This function is
active when telephoning or listening to an external
device. The rechargeable battery will last about 6 hours
in this case.
Getting started

Getting started
13
■ When no transmission of audio signal is active and
a phone is paired, the rechargeable battery will last
several days.
■ When no transmission of audio signal is active and
no telephone is paired, the rechargeable battery lasts
several months.
Display information
① Hearing program
② Program description (only
available if programmed by your
Hearing Care Professional)
③ Battery status of remote control
The remote control goes into a stand-by mode
after a period of inactivity. In stand-by mode no
information is shown on the display.
Press any key to turn the remote control back
into working mode to see the information on
the display.
Wearing the remote control
To operate your hearing instruments wear the remote
control within a distance of 1 m (40 in) to the hear-
ing instruments. You can wear the remote control, for
example, in your pocket.

Getting started
14
For best listening quality when
receiving an audio stream, wear
the remote control with the
lanyard around your neck. This
way remote control and
hearing instruments are in the
proper distance and alignment.
You can also set the remote control on
the table in front of you, for example
when watching TV.
For best listening quality turn the re-
mote control in the same direction you
are facing.
When telephoning with the remote
control, hold the remote control in
your hand and speak directly into the
microphone.

Basic functions
15
Your remote control has a key lock on the left side.
Slide the control to the bot-
tom to enable the key lock.
Pressing the buttons will now
have no effect.
Slide the control to the top to
disable the key lock.
locked / unlocked
Changing the hearing program
Your Hearing Care Professional can activate or
de-activate acoustic signals in your hearing instru-
ments. Acoustic signals confirm changes in the set-
tings such as program, volume or SoundBalance.
The remote control allows you to control
up to 5 programs of your hearing instru-
ments.
Your Hearing Care Professional will
program the settings in the different
programms for your particular listening
needs.
Press the number of the desired hear-
ing program.
The remote control shows the number
of the program you are in now.
You hear the acoustic signal for the chosen program in
your hearing instruments.
Basic functions

Basic functions
16
Changing the volume
Press to increase the volume.
Press to decrease the volume.
Changing the SoundBalance (Treble)
With the rocker switch on the right side of the
remote control you can change the sound of your
hearing instruments.
Press + (up) to get a more shrill sound.
Press – (down) to get more muffled sound.
Reading out the hearing instrument's information
This functions gives you the possibility to view
the current settings like battery status, volume or
hearing program of your hearing instruments.
Hold the remote control close to one of your
hearing instruments (about 10 cm / 4 in).
Press the read out button.
The display of the remote control shows you the follow-
ing information:
① Hearing program with description
② Sound control of hearing instru-
ments
③ Volume of hearing instruments
④ Battery status of hearing instruments left / right

Basic functions
17
Turning the hearing instruments on/off
Press the read out button for more than 5 sec-
onds to turn your hearing instruments off.
Press one of the program buttons on the
remote control to turn the hearing instruments
back on.
Turning the remote control on/off
Press for about 5 seconds to turn the remote
control off.
Press for about 5 seconds to turn the remote
control back on.
WARNING
Wireless systems may interfere with measuring
devices and electronic equipment.
Turn the remote control off when in hospi-
tals or airplanes.
Prior to use in conjunction with an electronic
implant or life supporting system, have the
electromagnetic compatibility verified.

Display information
18
Symbols
program number
bluetooth connection active
or
phone connection active
full
empty
charging
battery status of remote control
/
volume up / volume down
/
treble up / treble down
/ key lock activated / deactivated
incoming call
active call
hearing instruments off
error
Display information

Display information
19
Symbols
/ / searching bluetooth audio stream /
bluetooth audio stream active /
audio stream active
Read-out symbols
Sound balance and volume of hearing
instruments
battery status of left and right hearing
instrument
Display information

What is Bluetooth?
20
Bluetooth is a wireless standard that provides a way to
wirelessly connect devices like cell phones, laptops,
headsets and others.
Over a Bluetooth connection the devices can exchange
information such as data, sound or even control com-
mands. The range of the Bluetooth connection in the Tek
Connect remote control is about 10 m (32 ft). Walls or
objects in between the devices can shorten this distance.
The Bluetooth symbol denotes if a device is
Bluetooth compatible.
The Tek Connect remote control can be connected via
Bluetooth to your cell phone or to the Tek Transmitter.
Follow the instructions in the following chapters to hear
the sound of your cell phone, TV or mp3 player directly in
your hearing instruments.
What is Bluetooth?
