Siemens DOME COLOUR CFMC1315-LP Quick guide

Building Technologies
Fire Safety & Security Products
CFMC1315-LP
1/3” 1.3 MP Indoor IP Dome
Colour Camera
Configuration

Technical specifications and availability subject to change without notice.
© 2009 Copyright Siemens Switzerland Ltd
We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights
and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our
prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.

3
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
1Safety..............................................................................................................5
1.1 General safety precautions.............................................................................5
1.1.1 Transport..........................................................................................5
1.1.2 Installation........................................................................................5
1.2 Meaning of symbols........................................................................................6
2EU-directives .................................................................................................6
3Technical data ...............................................................................................7
4Ordering data...............................................................................................10
5Package contents........................................................................................10
6Camera parts ...............................................................................................11
7Installing the camera ..................................................................................13
7.1 SD Memory Card...........................................................................................13
7.2 Concept of the Network Camera...................................................................13
7.3 Setting Network Camera Environment..........................................................14
7.4 Connecting the Camera and PC by Network................................................14
7.5 Using the Web-Cam IP manager..................................................................16
7.6 Browser settings............................................................................................17
8Getting started.............................................................................................19
8.1 Login..............................................................................................................19
8.2 Using the Live Player - Web..........................................................................20
8.3 Using a RTSP player.....................................................................................21
8.4 Function support............................................................................................23
9Configuration...............................................................................................24
9.1 Compression.................................................................................................24
9.1.1 Bandwidth requirements................................................................26
9.2 Network settings............................................................................................27
9.2.1 Basic..............................................................................................27
9.2.2 DDNS.............................................................................................29
9.2.3 FTP Server.....................................................................................30
9.3 Image parameters.........................................................................................30
9.3.1 Basic..............................................................................................30
9.3.2 Auto Patrol.....................................................................................33
9.3.3 Mask Zone.....................................................................................34
9.3.4 Cropping ........................................................................................35
9.3.5 OSD...............................................................................................36
9.4 Alarm.............................................................................................................36
9.4.1 Alarm..............................................................................................37
9.4.2 Audio Upload .................................................................................39
9.4.3 Alarm Server..................................................................................39
9.5 Record...........................................................................................................40
9.5.1 FTP Recording...............................................................................40
9.5.2 SD Recording.................................................................................43
9.5.3 E-Mail Recording ...........................................................................45
Table of contents

4
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
9.5.4 NAS Recording ..............................................................................48
9.6 Audio .............................................................................................................50
9.7 Date/Time......................................................................................................51
9.8 Access protection..........................................................................................52
9.8.1 Administrator..................................................................................52
9.8.2 User list..........................................................................................53
9.9 Firewall..........................................................................................................53
9.9.1 IP Address Filter ............................................................................53
9.9.2 Forbidden Ports .............................................................................54
9.9.3 Forbidden Protocol.........................................................................55
9.10 System...........................................................................................................55
9.10.1 Setting............................................................................................55
9.10.2 Firmware Update ...........................................................................55
9.10.3 Configuration..................................................................................56
9.10.4 Temperature...................................................................................57
9.11 Logbook.........................................................................................................57
9.12 Licence information.......................................................................................57
10 Utility program application.........................................................................58
10.1 NAS player setup ..........................................................................................58
10.2 Audio record setup........................................................................................58
10.3 Firmware update setup..................................................................................59
11 Maintenance.................................................................................................60
12 Disposal........................................................................................................61
13 Index.............................................................................................................62

Safety
5
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
1Safety
1.1 General safety precautions
zRead the general safety precautions before installing, configuring and
operating the device.
zKeep this document for reference.
zPlease also take into account any additional country-specific, local safety
standards or regulations concerning project planning, operation and disposal of
the product.
zFollow all warnings and instructions marked on the device.
Liability claim
zDo not make any changes or modifications to the device unless they have been
approved by the manufacturer.
zUse only spare parts and accessories that have been approved by the
manufacturer.
1.1.1 Transport
Damage during transport
zKeep the packaging material for future transportation.
zDo not expose the device to mechanical vibrations or shocks.
1.1.2 Installation
zIt is recommended that all preparatory work (e.g. fitting of accessories) be
carried out in a workshop prior to final installation.
Radio interference with other devices in the environment
zWhen handling modules that are susceptible to electrostatic discharge, please
observe the ESD guidelines.
Damage due to unsuitable mounting location
zThe environmental conditions recommended by the manufacturer must be
observed. See section “Technical data”.
zDo not operate the device in dusty places.
zDo not expose the device to mechanical vibrations or shocks.

EU-directives
6
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
zProtect the device against moisture.
zPlace the unit on a stable surface that will hold its weight.
zThe mounting surface must be solid and non-combustible.
zDo not operate the device close to sources of powerful electromagnetic
radiation.
Danger of electrical shock due to incorrect connection
zConnect the device only to power sources with the specified voltage. Voltage
supply requirements can be found on the mains adapter.
zMake sure the device is permanently connected to the electricity supply; a
readily accessible disconnect device must be provided.
zThis device is designed to work with DC 12 V / AC 24 V-systems or PoE. Do
not connect the device to any other power systems.
1.2 Meaning of symbols
NOTICE
Malfunctioning may result.
Tips and information.
2EU-directives
This product complies with the requirements of the following European directives.
The EU declaration of conformity is available to the responsible agencies at:
Siemens Building Technologies
Fire & Security Products GmbH & Co. oHG
76181 Karlsruhe
Germany
European Directive 2004/108/EC „Electromagnetic Compatibility”
Compliance with the European Directive 2004/108/EC has been proven by testing
according to the following standards:
Emitted interference: EN 61000-6-3
EN 55022 Class B
Interference resistance: EN 50130-4

Technical data
7
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
3Technical data
Image system
Image sensor 1/3” progressive CCD (EXview HAD), 1.3 megapixels
Pixels Full scanning mode:1280 (H) x 960 (V)
Compression MJPEG / MPEG4
Image frame rate SXGA (1280 x 960) at 12.5 ips max. (MJPEG only)
VGA (640 x 480), QVGA (320 x 240) at 25 ips max.
Cropping window Simultaneous video transmission of up to 5 independent
cropping windows max., freely configurable in size and
position at 5 ips max. (MJPEG mode only)
Video outputs 1 Vpp 75 Ω BNC composite video
(CVBS or IP video alternatively selectable by switch)
Electronic
Synchronisation Internal
Signal/noise ratio > 50 dB
Lens High-quality megapixel lens: f= 3.0 – 9 mm, F1.2
Angle of view Horizontal: 31.8 – 90.0º
Vertical: 23.9 – 66.2º
Lens Mount CS mount
Gamma correction 0.45 / 1
Minimum illumination 0.4 lux (F1.2, AGC On)
White balance control Automatic: 2500 – 10000 K
Manual 1500 – 15000 K
Preset
Shutter speed 1/25 – 1/10,000 s; support of long shutter up to 4 s max.
Back light compensation
(BLC)
On/Off, BLC1 – BLC6
Audio Two-way audio; full-duplex, G.726 (integrated
microphone)
Alarm inputs 1
Alarm outputs 1
Telemetry protocol RS485
SD card slot 2 GB SD-RAM included in scope of delivery

Technical data
8
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
Microphone Internal
Motion detection 1 MD window (selectable size & position) with 3 sensitivity
levels
Network
Network connections 10 BASE – T/100 BASE-TX
Compression MJPEG / MPEG4 (dual-streaming)
Resolution MJPEG: VGA (640 x 480 pixels) / QVGA (320 x 240
pixels) at 25 ips max.
MJPEG: SXGA (1280 x 960 pixels) at 12 ips max.
MPEG4: VGA (640 x 480 pixels) / QVGA (320 X 240
pixels) at 25 ips max.
Image quality setting
(compression level)
5 levels
Audio function Two-way mono audio; full-duplex
Protocols TCP/IP, UDP, HTTP, SMTP, DNS, DHCP, NTP, ARP,
ICMP, FTPc, FTPs, DDNS, RTP (RTCP, RTSP), IGMP
v3, UPnP, NFS, CIFS
Web browser IE browser 6.0 or above
I/O connector
Network port RJ45 with control LEDs
Video outputs 2-pin jack (for video setup only)
Audio in & out connector 3.5 mm phone jack
Alarm connector 1 x alarm in / 1 x alarm out
Power connector 2-pin spring terminal
LED Status, network link
Power supply
Power requirements 12 V DC / 24 V AC, 50 Hz or PoE
Power consumption < 7 W
Power connector 2-pin spring terminal
Environment
Ambient temperature,
operating
-10 to +50 ºC
Relative humidity 80 % (operating) or less
Ambient temperature, storage -20 to +60 ºC

Technical data
9
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
Mechanism
Angle control (3-axis) Yes
Pan travel 350º
Tilt travel 146º
Dimensions (H x D) 128 x 140 mm
Weight 0.65 kg

Ordering data
10
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
4Ordering data
Type Art. No. Description Weight
CFMC1315-LP S54561-C81-A1 1/3” 1.3 MP Indoor IP Dome Colour Camera,
12 V DC / 24 V AC, 50 Hz or PoE
0.65 kg
5Package contents
zCCD IP dome
zDocumentation CD
zUtilities CD
zInstallation instruction (English, German, French, Spanish, Italian)
zSD card (2 GB)
zWall plugs (4x)
zMounting screws (4x)
zMounting template for installation
zMonitor out cable

Camera parts
11
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
6Camera parts
White
Orange
Black
Red+
Black-
Red
Brown
Black
1
2
3
4
5
6
7
8
10
11
22
P
12
13
14
15
16
17
18
20
21
19
9
SD CARD
DEFAULT
23
AB
C
Camera parts
1 Alarm out terminal 13 Tilt adjust screws
2 Alarm in terminal 14 Horizontal adjustment ring
3 Power IN connector 15 Zoom lever
4 Audio out (φ 3.5mm) 16 Focus lever
5 Audio in (φ 3.5mm) 17 Reset button
6 Body casing 18 Bottom casing
7 SD Card slot 19 MON (Monitor out connector)
8 Default button 20 IP/TV selection
9 Microphone 21 Loosen the locking screw
10 Front cover screw 22 Open/close dome indication
11 Dome cover 23 Fixed point for ceiling mount
12 Pan adjustment bracket

Camera parts
12
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
YELLOW: ALARM OUT
Alarm out terminal
BLACK: COM
Alarm output port
RED: ALARM IN
Alarm in terminal
ORANGE: GND
External alarm input
WHITE: Power -
Power IN
connector BLACK: Power +
POWER DC12V / AC24V
Audio in WHITE AUDIO JACK: In Audio in (φ3.5mm)
Audio out BLACK AUDIO JACK: Out Audio out (φ3.5mm)
IP Video out through Ethernet
TV BNC composite video out for installation
purpose
IP TV
IP/TV switch
NOTE: After switching between IP and TV the camera has to be restarted
Default button DEFAULT Return to factory default by pressing
button for 5 seconds

Installing the camera
13
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
7Installing the camera
7.1 SD Memory Card
Please install the SD memory card before switching on the camera as the system
can not detect the insertion of an SD card during operation.
zThere is a limit to the number of rewrites that are possible with the SD memory
card. Replacing the SD memory card when performing periodic maintenance of
the camera is recommended.
zThe camera supports the following SD memory cards. Do not use memory
cards with other specifications. SD memory card: 64, 128, 256, and 512 MB, 1
or 2 GB SD memory cards (3.3 V) supported.
zImages may not be recorded or read correctly if an unsupported SD memory
card is used with the camera.
zCarefully read the manual, precautions on use, and any other information
supplied with a purchased memory card.
zDo not use a memory card containing the data recorded by another device with
the camera as this may result in the camera not functioning correctly.
zDo not modify, overwrite the data, or change the folder name of an SD memory
card as this may result in the camera not functioning correctly.
zData recorded with the camera do not comply with the image file format Exit
and the DCF standard. If the SD memory card is to be removed to play images,
use a personal computer to play the images. Other devices may not be capable
of doing so.
7.2 Concept of the Network Camera
The camera can be used in various indoor environments.
It can deliver video images and audio in real time using the Internet or an intranet.
The camera is equipped with Ethernet (RJ-45) 10BASE-T/100BASE-TX network
interfaces.
Hub PC
E
t
h
ernet

Installing the camera
14
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
7.3 Setting Network Camera Environment
Equipment required for a network camera monitoring system:
zAdministrator's personal computer
The personal computer that is given all authorities for setting, operating,
monitoring and other functions with the network camera is called the
"administrator's personal computer" in this manual.
zRecommended personal computer operating conditions
‒ Operating system: Windows Vista or XP
‒ Internet Explorer Version 6.0 or later
‒ CPU: Intel Pentium 4.2 GHz or higher
‒ Memory: 512 MB or more
zNetwork camera
Please purchase the required and appropriate number of cameras
corresponding to the desired camera installation locations.
zConnection equipment such as a hub and router suiting the network system
environment and LAN cable, a Cat 5e LAN cable is recommended.
zCamera search application Web-Cam IP Manager (See also page [J 16] .)
Install this application from the Utilities CD supplied as an accessory.
‒ Install the Web-Cam IP Manager Version 2.0 (Web IP Manager.exe) if all
the units are located in the same network segment.
‒ Install the Web-Cam IP Manager Version 3.0 (IPFinder.exe) if the units are
not located in the same network segment.
7.4 Connecting the Camera and PC by Network
IP address
To connect to the network, the administrator needs to set the network camera IP
address. There are two options for setting the IP address:
zEntering the IP address manually (factory default)
Your camera is set to this mode at the factory with the IP address:
192.168.0.10, so you need to enter this IP number manually to access the
camera for the first time.
zObtaining an IP address automatically from the DHCP server
If your network uses a DHCP server, you do not need to change the IP address
of the camera. But be sure to set DHCP ON/OFF to ON in "Network
settings/Basic".

Installing the camera
15
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
The IP address of the network camera may change when using the DHCP server. In that
case it will not be possible to connect the network camera if it is accessed using the
previously set IP address.
In order to enable permanent access to the network camera, a fixed IP address must be
manually assigned to the camera.
Please read the instruction manuals for the network system equipment as well as those for
the router, hub and modem.
When entering the IP address manually, set DHCP ON/OFF to OFF in "Network/Basic
Settings" and enter the IP address, subnet mask, default gateway, primary DNS and
secondary DNS.
Connection Configuration
Two configurations are available for connection of network cameras.
zCrossover connection
zConnection via a hub, switch, or router
You do not need to assign an IP address to a hub.
The IP address of your camera is set to 192.168.0.10 by default. Set the IP address of
your personal computer in the same subnet. (The network segment must be the same
segment when directly connecting using a cross cable or connecting through the hub).
When connecting more than one camera, connect each camera using the default IP
address and change the IP addresses of the second and subsequent cameras to other IP
addresses, such as 192.168.0.11.
You can also use the LAN port of your broadband router. However, when using the
broadband router, if the DHCP server function is set to "ON", turn on the power after
connecting the camera with the router. The camera gets the IP address from the router's
DHCP server and it may not be 192.168.0.10.
For more information, read your computer's user's guide and the user's guide for
the broadband router.
It is also recommended to set the computer's IP address from the router's DHCP
server.
Connecting Camera and Personal Computer
1. Connect the LAN cable (straight cable) connected to the camera to the hub.
- OR -
Connect the camera to a personal computer with the power turned on using the
LAN cable (cross cable). Connect DC 12 V / AC 24 V to the power terminal.
2. Set the IP address of your personal computer
−Set the IP address of your PC to other than 192.168.0.10 (Camera's default
IP address).
E.g. set the IP address to 192.168.0.20 (and subnet mask to
255.255.255.0).

Installing the camera
16
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
−For details about the procedure, refer to the user's guide of the personal
computer.
3. Test the camera connection using ping.
−Start a command prompt. Type ”ping 192.168.0.10”.
−If the ”Reply from...” message appears, the connection is correctly
established.
4. Enter the camera’s IP address in the address bar of the IE browser.
- OR –
Search the camera with the ”Web-Cam IP Manager” application. See page
[J 16] .
5. Log-in with the administrator ID. See page [J 19] .
7.5 Using the Web-Cam IP manager
The Web-Cam IP Manager is an application for searching for network cameras that
can currently be viewed from the administrator's personal computer or a user's
personal computer, and connecting to those cameras.
Use the Web-Cam IP Manager Version 2.0 (Web IP Manager.exe) if all the units
are located in the same network segment.
Use the Web-Cam IP Manager Version 3.0 (IPFinder.exe) if the units are NOT
located in the same network segment. In that case, you must ensure that
associated gateway (router) passes the SSDP (Simple Service Discovery Protocol)
multicast messages sent by the Web-Cam IP Manager to the network segment
where the device is located.
To search a camera in the network:
1. Start the Web-Cam IP Manager (The file is included on the utilities CD).
ÖThe Web-Cam IP Manager program window will open:

Installing the camera
17
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
2. Click the Start button.
ÖThe Web-Cam IP Manager program window will now display a list of all the
devices available for communication along with their IP and MAC
addresses. Each device's IP address or MAC address is unique.
3. Select the device whose homepage you want to access.
4. Click the Homepage of selected device button.
ÖThe homepage of the selected camera will appear.
Set the personal computer to "Administrator authorization" when using the Web IP
Manager.
To connect with a camera without using the Web IP Manager, launch the Internet browser,
enter the camera’s IP address in the browser bar an press Enter.
If a port number other than "80" is set, designate the port number by suffixing it after ":"
(e.g. http://192.168.0.10:88).
7.6 Browser settings
1. Launch the Internet Explorer.
2. Select Internet option on the tools menu and click the Security tab.
3. Click the Local intranet icon if the camera is inside the Intranet.
- OR -
Click the Internet icon if the camera is on the Internet.

Installing the camera
18
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
4. Click Level Customize and enable the following options in the displayed list:
−"ActiveX control and plug in execute"
−"Execution of script of ActiveX control marked safe even when script is
executed"
−"Download of signed ActiveX control"
5. Enable cookies
Browser settings when proxy server is used
In case a proxy server is used, setting of the browser to bypass the proxy server
during communication with the network camera is recommended.
1. Launch the Internet Explorer.
2. Select Internet option on the tools menu.
3. Click Connections tab and then click the button LAN Settings.
ÖIf the checkbox is not marked: The browser is not set to use a proxy server.
Click Cancel and quit setting.
ÖIf the checkbox is marked, follow the steps:
4. Click Advanced.
5. Enter the IP addresses of the network cameras in the field marked “Do not use
proxy server for addresses beginning with…”.
6. Click OK.
zA proxy server protected by a firewall sometimes cannot be connected to the network
camera. Consult the network administrator so as to avoid impacts on network camera
operations.
zCommunication with the network cameras via a proxy server may cause some
problem. Install the network cameras after consulting the network administrator.
zWhen using the network cameras via a proxy server it may take a long time for the
images to be displayed after log-in, or the frame rate of the images may be reduced.

Getting started
19
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
8Getting started
8.1 Login
1. Open the Internet Explorer and enter the camera’s default IP address in the
browser address bar: 192.168.0.10.
2. If the IP address is unknown use the Web IP Manager to search for the
camera. See page [J 16] .
3. The login dialog will appear.
4. Enter the administrator User name and Password.
The default settings for the administrator login are "admin" and "admin".
NOTICE
Important
The administrator login allows rewriting of all settings. Change the default administrator
user name and password to ensure camera security. See page [J 52] .
5. Click OK.
6. The homepage of the camera will appear.

Getting started
20
Building Technologies CFMC1315-LP Configuration Manual EN
Fire Safety & Security Products 05/05/2009
8.2 Using the Live Player - Web
If the Camera Image screen is not displayed, check your browser settings. See page
[J 17] .
1. Click the desired image stream (Stream 1 or 2).
2. Control the live stream as described in the table below.
Play Shows live image
Pause Pauses live image
Speaker Stops audio input
Microphone Stops audio output
E E-zoom control
See table below.
R * Remote control (see table below).
You can control PTZ functions, move the camera to preset positions
and also make lens adjustments such as focus adjustment and zoom
in/out. Before using this function, please set the baud rate and address
of the telemetry device for control via the RS485 port.
*
NOTE: Not available for this camera type.
Other manuals for DOME COLOUR CFMC1315-LP
2
Table of contents
Other Siemens IP Camera manuals
