Siemens RUGGEDCOM RM1224 User manual

RUGGEDCOM
Industrial Remote Communication
Remote Networks
RUGGEDCOM RM1224
Operating Instructions
10/2016
RC1260-EN-02
Preface
Description of the device
1
Installation
2
Connecting up
3
Dimension drawing
4
Technical specifications
5
Approvals
A

Siemens Canada Ltd.
Division Process Industries and Drives
300 Applewood Drive
Concord, ON, L4K 5C7
CANADA
Document order number: RC1260-EN-02
© 10/2016 Subject to change Copyright © Siemens Canada Ltd. 2016.
All rights reserved
Legal information
Warning notice system
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert
symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are
graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger will
be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to
property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the specific
task in accordance with the relevant documentation, in particular its warning notices and safety instructions.
Qualified personnel are those who, based on their training and experience, are capable of identifying risks and
avoiding potential hazards when working with these products/systems.
Proper use of Siemens products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommended
or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permissible
ambient conditions must be complied with. The information in the relevant documentation must be observed.
Trademarks All names identified by ® are registered trademarks of Siemens Canada Ltd.. The remaining trademarks in this
publication may be trademarks whose use by third parties for their own purposes could violate the rights of the
owner.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software
described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the
information in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.

RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 3
Preface
Purpose of the Operating Instructions
These compact operating instructions contain information with which you will be able to
install and connect up the RUGGEDCOM RM1224. The configuration and the integration of
the device in a network are not described in these instructions.
RUGGEDCOM manuals
You will find RUGGEDCOM manuals on the Internet pages of Siemens Industry Online
Support:
Link to Siemens Industry Online Support (http://support.automation.siemens.com/)
Trademarks
The following and possibly other names not identified by the registered trademark sign ®are
registered trademarks of Siemens Canada Ltd.:
RUGGEDCOM, ROS
Security information
Siemens provides products and solutions with industrial security functions that support the
secure operation of plants, solutions, machines, equipment and/or networks. They are
important components in a holistic industrial security concept. With this in mind, Siemens’
products and solutions undergo continuous development. Siemens recommends strongly
that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable
preventive action (e.g. cell protection concept) and integrate each component into a holistic,
state-of-the-art industrial security concept. Third-party products that may be in use should
also be considered. For more information about industrial security, visit
http://www.siemens.com/industrialsecurity.
To stay informed about product updates as they occur, sign up for a product-specific
newsletter. For more information, visit http://support.automation.siemens.com.
License conditions
Note
Open source software
Read the license conditions for open source software carefully before using the product.
You will find license conditions in the following documents on the supplied data medium:

Preface
RUGGEDCOM RM1224
4Operating Instructions, 10/2016, RC1260-EN-02
●DOC_OSS-RUGGEDCOM-RM1224_74.pdf
●DC_LicenseSummaryRUGGEDCOMRM1224_76.htm
●DC_LicenseSummaryRUGGEDCOMRM1224_76.htm
SIMATIC NET glossary
Explanations of many of the specialist terms used in this documentation can be found in the
SIMATIC NET glossary.
You will find the SIMATIC NET glossary here:
●SIMATIC NET Manual Collection or product DVD
The DVD ships with certain SIMATIC NET products.
●On the Internet under the following entry ID:
50305045 (http://support.automation.siemens.com/WW/view/en/50305045)

RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 5
Table of contents
Preface............................................................................................................................................................. 3
1 Description of the device......................................................................................................................... 7
1.1 Product characteristics..............................................................................................................7
1.2 Accessories...............................................................................................................................8
1.3 LED display...............................................................................................................................9
1.4 SET button..............................................................................................................................12
1.5 C-PLUG and KEY-PLUG........................................................................................................14
2 Installation ............................................................................................................................................ 17
2.1 Securing the housing..............................................................................................................18
2.2 Wall mounting .........................................................................................................................18
2.3 Installation on the DIN rail.......................................................................................................19
2.4 Installing on the S7-300 standard rail.....................................................................................21
2.5 Installing on the S7-1500 standard rail...................................................................................22
3 Connecting up....................................................................................................................................... 25
3.1 Safety when connecting up.....................................................................................................25
3.2 SIM card..................................................................................................................................27
3.3 Power supply ..........................................................................................................................28
3.4 Grounding ...............................................................................................................................29
3.5 Digital input/output..................................................................................................................30
3.6 Antennas.................................................................................................................................32
3.7 Ethernet port...........................................................................................................................35
3.8 Inserting and removing the PLUG ..........................................................................................36
4 Dimension drawing ............................................................................................................................... 39
4.1 RUGGEDCOM RM1224.........................................................................................................39
5 Technical specifications ........................................................................................................................ 41
A Approvals.............................................................................................................................................. 45
A.1 EU declaration of conformity...................................................................................................47
A.1.1 R&TTE ....................................................................................................................................47
A.1.1.1 Protection of health and safety...............................................................................................47
A.1.1.2 EMC........................................................................................................................................48
A.1.1.3 Efficient use of the radio spectrum .........................................................................................49
A.1.2 RoHS.......................................................................................................................................49

Table of contents
RUGGEDCOM RM1224
6Operating Instructions, 10/2016, RC1260-EN-02
A.1.3 Products................................................................................................................................. 50
A.2 RCM / C-TICK........................................................................................................................ 50
A.3 IECEx..................................................................................................................................... 51
A.4 FM certification....................................................................................................................... 51
A.5 UL certification (product safety)............................................................................................. 51
A.6 EAC........................................................................................................................................ 52
Index 53

RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 7
Description of the device
1
1.1 Product characteristics
Interfaces
Functionality RM1224
Connectors for external antennas 2 x SMA antenna connectors
Ethernet interface 4 x RJ-45 10 / 100 Mbps
Digital input/output 1/1
Scope of delivery
The following components ship with the product:
●One device
●A 5-pin terminal block for the power supply
●A 2-pin terminal block for the digital output
●A 2-pin terminal block for the digital input
●Product CD
Note
Not included with the product
The following components do not ship with the product:
KEY-PLUG / C-PLUG
You will find more detailed information in "C-PLUG and KEY-PLUG (Page 14)".
Antennas
You will find more detailed information in "Accessories (Page 8)".
SIM card
Use the SIM card from the chosen mobile wireless provider
Article numbers
Type Article number Description
RUGGEDCOM
RM1224 6GK6 108-4AM00-2BA2 Mobile wireless router for 4G (LTE) with antenna diversity

Description of the device
1.2 Accessories
RUGGEDCOM RM1224
8Operating Instructions, 10/2016, RC1260-EN-02
Unpacking and checking
WARNING
Do not use any parts that show evidence of damage
If you use damaged parts, there is no guarantee that the device will function according to
the specification.
If you use damaged parts, this can lead to the following problems:
Injury to persons
Loss of the approvals
Violation of the EMC regulations
Use only undamaged parts.
1. Make sure that the package is complete.
2. Check all the parts for transport damage.
1.2 Accessories
You will find further information on the accessories program for the M-800 in the Industry
Mall
(https://eb.automation.siemens.com/goos/WelcomePage.aspx?regionUrl=/en&language=en)
.
Antennas
Type Properties Article number
ANT794-3M Flat antenna for GSM networks, for tri-band
with 900 / 1800 / 1900 MHz; weatherproof for
indoor and outdoor areas; 1.2 m connecting
cable connected permanently to the antenna;
SMA connector, including adhesive mounting
tape
6NH9870-1AA00
ANT794-4MR Omnidirectional antenna for GSM (2G), UMTS
(3G) and LTE(4G); weatherproof for indoor and
outdoor areas; 5 m connecting cable connected
permanently to the antenna; SMA connector,
including installation bracket, screws, wall plugs
6NH9860-1AA00

Description of the device
1.3 LED display
RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 9
1.3 LED display

Description of the device
1.3 LED display
RUGGEDCOM RM1224
10 Operating Instructions, 10/2016, RC1260-EN-02
LED Status Meaning
F OFF No fault/error.
ON The device is starting up or an error has occurred.
Possible errors/faults:
Wrong PIN number
Flashing The bootloader waits in this state for a new firmware file that you can
download using TFTP.
L OFF Device turned off, no power supply.
ON Device turned on, power supply present.
SC OFF SIM card OK, no connection.
ON Wrong PIN number / SIM card error
ON Connection established
Q OFF No reception
Signal strength: < -109 dBm
Flashing Signal strength bad: -89 dBm to -109 dBm
On Signal strength medium: -73 dBm to -89 dBm
ON Signal strength good: > -73 dBm
OFF No VPN connection is established.
ON All configured VPN connections are established.
Flashing Only some of the configured VPN connections are established.
P1
P2
P3
P4
OFF Ethernet connection to local computer or LAN not established
ON Ethernet connection to local computer or LAN established

Description of the device
1.4 SET button
RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 11
LED Status Meaning
ON Device receiving / sending data
DI OFF Digital input inactive
ON Digital input active.
DO OFF Digital output inactive
ON Digital output active.

Description of the device
1.4 SET button
RUGGEDCOM RM1224
12 Operating Instructions, 10/2016, RC1260-EN-02
1.4 SET button
With a M-800RUGGEDCOM RM1224, the SET button is on the front of the housing beside
the LED display.

Description of the device
1.4 SET button
RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 13
The SET button has the following functions:
●Restart
Hold down the button for longer than 3 seconds to run a restart.
●Loading new firmware
If the normal procedure with the "Load & Save" menu of Web Based Management does
not work, the reset button can be used to load new firmware. This situation can occur if
there is a power outage during the normal firmware update.
– Hold down the button until the red fault LED (F) starts to flash after approximately 3
seconds.
– Now release the button. The bootloader waits in this state for a new firmware file that
you can download using TFTP.
You will find more information in the section "Service and Maintenance" in the
RUGGEDCOM RM1224 Web Based Management configuration manual.
●Reset to factory defaults
– Hold down the button until the red fault LED (F) stops flashing after approximately 10
seconds and is permanently lit.
– Now release the button and wait until the fault LED (F) goes off again. The device then
starts automatically with the factory settings and can be reached via the IP address
192.168.1.1.
You will find more information in the section "Service and Maintenance" in the
RUGGEDCOM RM1224 Web Based Management configuration manual.
WARNING
EXPLOSION HAZARD
Do not press the SET button when there is an explosive atmosphere.

Description of the device
1.5 C-PLUG and KEY-PLUG
RUGGEDCOM RM1224
14 Operating Instructions, 10/2016, RC1260-EN-02
1.5 C-PLUG and KEY-PLUG
How it works
The C-PLUG or KEY-PLUG is used to transfer the configuration of the old device to the new
device when a device is replaced.
NOTICE
Do not remove or insert a C-PLUG / KEY-PLUG during operation!
A PLUG may only be removed or inserted when the device is turned off.
The device checks whether or not a PLUG is present at one second intervals. If it is
detected that the PLUG was removed, there is a restart.
If a valid KEY-PLUG was inserted in the device, the device changes to a defined error state
following the restart.
When the new device starts up with the PLUG, it then continues automatically with exactly
the same configuration as the old device. One exception to this can be the IP configuration if
it is set over DHCP and the DHCP server has not been reconfigured accordingly.
A reconfiguration is necessary if you use functions based on MAC addresses.
If an incorrect PLUG, for example from another product or a damaged PLUG is inserted, the
device signals an error with the "F" LED.
You can either remove the PLUG again or select the option to reformat the PLUG.
In terms of the PLUG, devices work in two modes:
●Without PLUG
The device stores the configuration in internal memory. This mode is active when no
PLUG is inserted.
●With PLUG
The configuration stored on the PLUG is displayed in WBM in "Information > PLUG". If
changes are made to the configuration, the device stores the configuration directly on the
PLUG and in the internal memory. This mode is active as soon as a PLUG is inserted. As
soon as the device is started with a PLUG inserted, the device starts up with the
configuration data on the PLUG.
License information on the KEY-PLUG
In addition to the configuration, the KEY-PLUG also contains a license that allows the use of
Siemens Remote Services.

Description of the device
1.5 C-PLUG and KEY-PLUG
RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 15
Article numbers
Type Article number Description
C-PLUG 6GK1900-0AB00 Exchangeable storage medium (32 MB) for
the configuration data
KEY-PLUG SINEMA
RC 6GK5908-0PB00 Exchangeable storage medium (256 MB) to enable the connection functionality to
SINEMA Remote Connect and for accepting
configuration data.
See also
Inserting and removing the PLUG (Page 36)

RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 17
Installation
2
Safety notices
When installing the device, keep to the safety notices listed below.
WARNING
If a device is operated in an ambient temperature of more than 50 °C, the temperature of
the device housing may be higher than 75 °C. The device must therefore be installed so
that it is only accessible to service personnel or users that are aware of the reason for
restricted access and the required safety measures at an ambient temperature higher than
50 °C.
Safety notices on use in hazardous areas
General safety notices relating to protection against explosion
WARNING
The device may only be operated in an environment with pollution degree 1 or 2 (see IEC
60664-1).
WARNING
When used in hazardous environments corresponding to Class I, Division 2 or Class I,
Zone 2, the device must be installed in a cabinet or a suitable enclosure.
General notes on use according to ATEX and IECEx
WARNING
To comply with EC Directive 94/9 (ATEX95) or the conditions of IECEx, this enclosure or
cabinet must meet the requirements of at least IP54 in compliance with EN 60529.

Installation
2.1 Securing the housing
RUGGEDCOM RM1224
18 Operating Instructions, 10/2016, RC1260-EN-02
2.1 Securing the housing
Types of installation
For the device, you have the following options:
●Wall mounting (no ceiling mounting)
●Installation on a DIN rail
●Installing on the S7-300 standard rail
●Installing on the S7-1500 standard rail
Strain relief for the cables
Regardless of the type of installation, make sure that there is suitable strain relief for the
connecting cable.
Shielding of cables
If cables are installed permanently, it is advisable to remove the insulation of the shielded
cable and to establish contact on the shield/PE conductor bar.
Permitted installation direction
●Vertical installation (ventilation openings at the top and bottom)
Clearances
Keep to the minimum clearances to other components or to walls of a housing so that the
convection ventilation of the device is not blocked.
●Below at least 10 cm
●Above at least 10 cm
●With an RM1224, a clearance of 5 cm must be maintained between the sides and
adjacent devices.
2.2 Wall mounting
Note
The wall mounting must be capable of supporting four times the weight of the device, but at
least 50 N. For information on the weight, refer to the section "Technical specifications
(Page 41)".
Requirement
There is a SIM card for the device.

Installation
2.3 Installation on the DIN rail
RUGGEDCOM RM1224
Operating Instructions, 10/2016, RC1260-EN-02 19
Installation
1. Insert the SIM card, see section "SIM card (Page 27)".
2. Prepare the drill holes for wall mounting. For the precise dimensions, refer to the section "
Dimension drawing (Page 39)".
3. Secure the device to the wall with two screws. When mounting on a wall, use mounting
fittings suitable for the type of wall.
4. Connect the power supply, refer to the section "Power supply (Page 28)".
5. Fit the connectors for the digital input and digital output, refer to the section "Digital
input/output (Page 30)".
6. Connect the antenna, refer to the section "Antennas (Page 32)".
7. Connect the device to the local network, refer to the section "Ethernet port (Page 35)".
8. Connect the terminal with as short a cable as possible ≤ 150 mm and a large cross-
sectional area ≥ 2.5 mm² to the ground of the system, see section "Grounding (Page 29)"
2.3 Installation on the DIN rail
Requirement
There is a SIM card for the device.

Installation
2.3 Installation on the DIN rail
RUGGEDCOM RM1224
20 Operating Instructions, 10/2016, RC1260-EN-02
Installation
1. Insert the SIM card, see section "SIM card (Page 27)".
2. Place the third housing guide of the device on the top edge of the DIN rail ①.
3. Press the device down against the DIN rail until the spring catch locks in place ②.
4. Connect the power supply, refer to the section "Power supply (Page 28)".
5. Fit the connectors for the digital input and digital output, refer to the section "Digital
input/output (Page 30)".
6. Connect the antenna, refer to the section "Antennas (Page 32)".
7. Connect the device to the local network, refer to the section "Ethernet port (Page 35)".
8. Connect the terminal with as short a cable as possible ≤ 150 mm and a large cross-
sectional area ≥ 2.5 mm² to the ground of the system, see section "Grounding (Page 29)"
Dismantling
1. Disconnect all connected cables.
2. Using a screwdriver, pull down the catch on the rear of the device.
3. Pull lower part of the device away from the DIN rail.
