Siemens RUGGEDCOM RX1400 User manual

RUGGEDCOM NETCONF
Reference Guide
For RX1400, RX1500, RX1501, RX1510, RX1511,
RX1512, RX5000, MX5000, MX5000RE
06/2017
RC1065-EN-03
Preface
Introduction 1
NETCONF Capabilities and
Namespaces 2
NETCONF Sessions 3
Getting Data 4
Changing Configuration
Data 5
RUGGEDCOM ROX II Actions 6
Examples 7
NETCONF XML Elements 8

RUGGEDCOM NETCONF
Reference Guide
ii
Copyright © 2017 Siemens Canada Ltd
All rights reserved. Dissemination or reproduction of this document, or evaluation and communication of its contents, is not authorized
except where expressly permitted. Violations are liable for damages. All rights reserved, particularly for the purposes of patent application or
trademark registration.
This document contains proprietary information, which is protected by copyright. All rights are reserved. No part of this document may be
photocopied, reproduced or translated to another language without the prior written consent of Siemens Canada Ltd.
Disclaimer Of Liability
Siemens has verified the contents of this document against the hardware and/or software described. However, deviations between the product
and the documentation may exist.
Siemens shall not be liable for any errors or omissions contained herein or for consequential damages in connection with the furnishing,
performance, or use of this material.
The information given in this document is reviewed regularly and any necessary corrections will be included in subsequent editions. We
appreciate any suggested improvements. We reserve the right to make technical improvements without notice.
Registered Trademarks
RUGGEDCOM™ and ROS™ are trademarks of Siemens Canada Ltd.
Linux® is the registered trademark of Linus Torvalds in the United States and other countries.
The registered trademark Linux® is used pursuant to a sublicense from LMI, the exclusive licensee of Linus Torvalds, owner of the mark on a
world-wide basis.
Other designations in this manual might be trademarks whose use by third parties for their own purposes would infringe the rights of the
owner.
Open Source
RUGGEDCOM ROX II is based on Linux®. Linux® is made available under the terms of the GNU General Public License Version 2.0 [http://
www.gnu.org/licenses/gpl-2.0.html].
RUGGEDCOM NETCONF contains additional Open Source Software. For license conditions, refer to the associated License Conditions
document.
Security Information
Siemens provides products and solutions with industrial security functions that support the secure operation of plants, machines, equipment
and/or networks. They are important components in a holistic industrial security concept. With this in mind, Siemens' products and solutions
undergo continuous development. Siemens recommends strongly that you regularly check for product updates.
For the secure operation of Siemens products and solutions, it is necessary to take suitable preventive action (e.g. cell protection concept) and
integrate each component into a holistic, state-of-the-art industrial security concept. Third-party products that may be in use should also be
considered. For more information about industrial security, visit http://www.siemens.com/industrialsecurity.
To stay informed about product updates as they occur, sign up for a product-specific newsletter. For more information, visit http://
support.automation.siemens.com.
Contacting Siemens
Address
Siemens Canada Ltd
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone
Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-mail
[email protected]
Web
www.siemens.com/ruggedcom

RUGGEDCOM NETCONF
Reference Guide

Table of Contents
iii
Table of Contents
Preface ............................................................................................................ ix
How This Guide Is Organized ............................................................................................................... ix
Alerts .................................................................................................................................................. x
Related Documents .............................................................................................................................. x
Accessing Documentation ..................................................................................................................... x
Training .............................................................................................................................................. xi
Customer Support ............................................................................................................................... xi
Chapter 1
Introduction ..................................................................................................... 1
1.1What is NETCONF? ........................................................................................................................ 1
1.2What Can NETCONF Do? ............................................................................................................... 3
1.3Who Should Use This Guide ........................................................................................................... 3
1.4Supported IETF RFCs ..................................................................................................................... 3
1.5Sample NETCONF sessions ............................................................................................................ 3
1.5.1Sample Session: Getting Data ............................................................................................. 4
1.5.2Sample Session: Performing an Action ................................................................................. 6
1.5.3Sample Session: Editing Data .............................................................................................. 9
Chapter 2
NETCONF Capabilities and Namespaces ........................................................... 15
2.1IETF Capabilities .......................................................................................................................... 15
2.2Vendor-Defined Capabilities ......................................................................................................... 17
2.3IETF Namespaces ........................................................................................................................ 17
2.4Vendor-Defined Namespaces ....................................................................................................... 18
2.5RUGGEDCOM Namespaces ........................................................................................................... 18
2.6Viewing the Capabilities on a Device ............................................................................................ 20
Chapter 3
NETCONF Sessions .......................................................................................... 23
3.1Configuring/Monitoring NETCONF in RUGGEDCOM NETCONF ......................................................... 23
3.2Connecting to the NETCONF Service ............................................................................................ 23
3.3Saying Hello ............................................................................................................................... 24
3.3.1RUGGEDCOM ROX II NETCONF <hello> Message ................................................................. 25
3.4Closing the Session ..................................................................................................................... 26


Table of Contents
RUGGEDCOM NETCONF
Reference Guide
iv
3.5Killing a Session .......................................................................................................................... 26
Chapter 4
Getting Data ................................................................................................... 29
4.1Using the <get> Command .......................................................................................................... 29
4.2Using the <get-config> Command ................................................................................................ 30
4.3Using XPaths with <get> and <get-config> ................................................................................... 31
4.4Getting Information for a Specific Object ...................................................................................... 33
4.4.1Specifying Objects with Hierarchical XML Elements ............................................................. 33
4.4.2Specifying Objects with XPaths ......................................................................................... 34
4.5Getting Default Values ................................................................................................................ 34
4.6Getting Data Models from the Device ........................................................................................... 35
4.6.1Getting Schemas from the Device ..................................................................................... 36
4.6.2Getting YIN and YANG Files from the Device ...................................................................... 37
4.6.3Using pyang .................................................................................................................... 38
4.6.3.1Using the Text-Based Tree ...................................................................................... 39
Chapter 5
Changing Configuration Data .......................................................................... 41
5.1Changing Data in the Running Configuration ................................................................................ 41
5.2Changing Data in the Candidate Configuration .............................................................................. 42
5.2.1Locking Data Stores ......................................................................................................... 43
5.2.2Copying Data ................................................................................................................... 44
5.2.3Replacing Data ................................................................................................................. 46
5.2.4Deleting Data ................................................................................................................... 48
5.2.5Validating Changes .......................................................................................................... 50
5.2.6Committing Changes ........................................................................................................ 51
Chapter 6
RUGGEDCOM ROX II Actions ............................................................................ 53
6.1Admin Namespace Actions .......................................................................................................... 54
6.1.1snmp-discover .................................................................................................................. 55
6.1.2launch-upgrade ................................................................................................................ 55
6.1.3decline-upgrade ............................................................................................................... 56
6.1.4rollback-reboot ................................................................................................................. 56
6.1.5roxflash ........................................................................................................................... 57
6.1.6clear-all-alarms ................................................................................................................. 57
6.1.7acknowledge-all-alarms .................................................................................................... 57
6.1.8shutdown ........................................................................................................................ 58
6.1.9reboot ............................................................................................................................. 58
6.1.10set-system-clock ............................................................................................................. 58

RUGGEDCOM NETCONF
Reference Guide

Table of Contents
v
6.1.11restore-factory-defaults ................................................................................................... 59
6.1.12delete-logs ..................................................................................................................... 59
6.1.13install-files ..................................................................................................................... 59
6.1.14backup-files (Backup Files) .............................................................................................. 60
6.1.15full-configuration-save .................................................................................................... 60
6.1.16full-configuration-load .................................................................................................... 61
6.2Interfaces Namespace Actions ...................................................................................................... 61
6.2.1reset (Modem) ................................................................................................................. 62
6.2.2at (Modem) ..................................................................................................................... 62
6.2.3reset (Cellular Modem) ..................................................................................................... 63
6.2.4at (Cellular Modem) ......................................................................................................... 63
6.2.5reset (Serial Port) ............................................................................................................. 64
6.2.6clear-serial-port-stats ........................................................................................................ 64
6.2.7restart-serserver ............................................................................................................... 65
6.2.8reset-port (Switch Port) .................................................................................................... 65
6.2.9clear-port-stats (Switch Port) ............................................................................................. 66
6.2.10start-cable-test (Switch Port) ........................................................................................... 66
6.2.11clear-cable-stats-port (Switch Port) .................................................................................. 67
6.3Services Namespace Actions ........................................................................................................ 67
6.3.1ntp-status ........................................................................................................................ 67
6.3.2log (Link-Failover) ............................................................................................................ 68
6.3.3start-test (Link Failover) .................................................................................................... 68
6.3.4cancel-test (Link Failover) ................................................................................................. 69
6.3.5show-active-leases (DHCP Server) ...................................................................................... 69
6.4Switch Namespace Actions .......................................................................................................... 69
6.4.1clear-stp-stats (Switch) ..................................................................................................... 70
6.4.2flush-dynamic-rules (Switch) ............................................................................................. 70
6.4.3reset-all-switch-ports (Switch) ........................................................................................... 70
6.4.4clear-all-switch-stats (Switch) ............................................................................................ 71
6.4.5clear-cable-stats-all (Switch) .............................................................................................. 71
6.5Tunnel Namespace Actions .......................................................................................................... 71
6.5.1display-public-key (IPSEC) ................................................................................................. 72
6.5.2status (IPSEC) .................................................................................................................. 72
6.5.3install-certificate (IPSEC) ................................................................................................... 72
6.5.4install-ca-certificate (IPSEC) ............................................................................................... 73
6.5.5install-crl-file (IPSEC) ........................................................................................................ 74
6.5.6remove-ca-certificate (IPSEC) ............................................................................................. 75
6.5.7remove-certificate (IPSEC) ................................................................................................. 75
6.5.8remove-crl (IPSEC) ............................................................................................................ 76


Table of Contents
RUGGEDCOM NETCONF
Reference Guide
vi
Chapter 7
Examples ........................................................................................................ 77
7.1Getting the System Name ........................................................................................................... 80
7.2Getting the ROX Release ............................................................................................................. 80
7.3Getting the Chassis Status ........................................................................................................... 81
7.4Setting the System Clock ............................................................................................................. 81
7.5Acknowledging Alarms ................................................................................................................ 81
7.6Clearing All Alarms ..................................................................................................................... 82
7.7Viewing Alarms ........................................................................................................................... 82
7.8Restoring Factory Defaults ........................................................................................................... 82
7.9Changing the System Name by Locking and Committing ............................................................... 83
7.10Changing the System Name Directly ........................................................................................... 84
7.11Creating a Static VLAN .............................................................................................................. 85
7.12Assigning a PVID on a Port ........................................................................................................ 86
7.13Disabling Spanning Tree on a Specific Port .................................................................................. 87
7.14Configuring an IP Address on a Specific Port ............................................................................... 88
7.15Deleting an IP Address .............................................................................................................. 90
7.16Setting a Static Route ................................................................................................................ 91
7.17Disabling Spanning Tree Globally ............................................................................................... 92
7.18Retrieving all IP Addresses from the Running Configuration .......................................................... 94
7.19Retrieving the Active Routes on a Device .................................................................................... 94
7.20Configuring Static Multicast Routing on a Layer 3 Device ............................................................. 95
7.21Enabling Static Multicast Routing on a Layer 3 Device .................................................................. 96
7.22Retrieving Static Multicast Status on a Layer 3 Device .................................................................. 97
7.23Replacing an IP Address ............................................................................................................. 98
7.24Configuring a Port to Dynamically Obtain an IP Address ............................................................... 99
7.25Configuring OSPF Area and Network on a Layer 3 Device ........................................................... 100
7.26Enabling the OSPF Passive-Default Option ................................................................................. 102
7.27Configure an OSPF Non-Passive Port ......................................................................................... 103
7.28Configuring OSPF Parameters ................................................................................................... 104
7.29Enabling the OSPF redistribute-connected Option ...................................................................... 106
7.30Enabling OSPF on a Layer 3 Device .......................................................................................... 107
7.31Retrieving OSPF Status ............................................................................................................ 108
7.32Retrieving All Data from the Routing Namespace ....................................................................... 109
7.33Configuring DHCP Server ......................................................................................................... 109
7.34Configure the DHCP Server Port Listening for DHCP Client Requests ............................................. 110
7.35Enabling the DHCP Server Service ............................................................................................. 112
7.36Disabling an Ethernet Port ....................................................................................................... 113
7.37Enabling an Ethernet Port ........................................................................................................ 114
7.38Checking an IP Address on a Specific Port using the Interfaces Namespace ................................... 115

RUGGEDCOM NETCONF
Reference Guide

Table of Contents
vii
7.39Retreiving All Data From Running Database Including Default Values ........................................... 116
7.40Retreiving All Data From Running Database Including Default Tags and Values ............................. 116
7.41Changing a User's Password ..................................................................................................... 117
7.42Displaying the Status of the IPsec Service ................................................................................. 118
7.43Selecting a Certificate for an IPSec Tunnel ................................................................................ 118
7.44Installing a CA Certificate ......................................................................................................... 120
7.45Configuring a Signed CA Certificate .......................................................................................... 121
7.46Installing a Private Key to a Signed CA Certificate ...................................................................... 121
7.47Installing a CRL File ................................................................................................................. 122
7.48Removing a Certificate ............................................................................................................ 123
7.49Removing a CA certificate ........................................................................................................ 123
7.50Removing a CRL File ................................................................................................................ 124
Chapter 8
NETCONF XML Elements ................................................................................ 125
8.1]]>]]> ....................................................................................................................................... 125
8.2<close-session/> ........................................................................................................................ 126
8.3<commit> ................................................................................................................................. 126
8.4<copy-config> ........................................................................................................................... 127
8.5<data> ..................................................................................................................................... 127
8.6<discard-changes> .................................................................................................................... 128
8.7<edit-config> ............................................................................................................................ 128
8.8<error-info> .............................................................................................................................. 128
8.9<get-config> ............................................................................................................................. 129
8.10<hello> ................................................................................................................................... 129
8.11<kill-session> .......................................................................................................................... 131
8.12<lock> .................................................................................................................................... 131
8.13<ok/> ..................................................................................................................................... 132
8.14<rpc> ..................................................................................................................................... 132
8.15<rpc-error> ............................................................................................................................. 132
8.16<rpc-reply> ............................................................................................................................. 133
8.17<target> ................................................................................................................................. 134
8.18<unlock> ................................................................................................................................ 134
8.19<validate> .............................................................................................................................. 135


Table of Contents
RUGGEDCOM NETCONF
Reference Guide
viii

RUGGEDCOM NETCONF
Reference Guide

Preface
How This Guide Is Organized ix
Preface
This guide describes how to use RUGGEDCOM NETCONF – the Network Configuration Protocol – to manipulate
configuration data on RUGGEDCOM devices running RUGGEDCOM NETCONF v.
CONTENTS
•“How This Guide Is Organized”
•“Alerts”
•“Related Documents”
•“Accessing Documentation”
•“Training”
•“Customer Support”
How This Guide Is Organized
•Chapter1, Introduction introduces RUGGEDCOM NETCONF and demonstrates what a typical NETCONF session
with RUGGEDCOM NETCONF looks like. Read this section for a quick introduction to RUGGEDCOM NETCONF on
RUGGEDCOM NETCONF.
•Chapter2, NETCONF Capabilities and Namespaces describes the RUGGEDCOM NETCONF functions and data
models supported by RUGGEDCOM NETCONF. Read this section to learn about the RUGGEDCOM NETCONF
functions supported by RUGGEDCOM NETCONF.
•Chapter3, NETCONF Sessions describes how to connect to and communicate with a device with RUGGEDCOM
NETCONF. Read this section to learn about connecting to your device, responding to the device's initial
NETCONF message, locking and unlocking datastores, and signing off from the device.
•Chapter4, Getting Data describes how to retrieve configuration data from RUGGEDCOM NETCONF. Read this
section to learn how to retrieve individual configuration elements, subsections of configuration data, or the
entire configuration from the device.
•Chapter5, Changing Configuration Data describes how to change RUGGEDCOM NETCONF configuration data.
Read this section to learn how to set configuration data and perform actions.
•Chapter6, RUGGEDCOM ROX II Actions describes how to activate NETCONF actions on a device. Read this
section to learn how to activate NETCONF commands, such as rebooting and clearing statistics, on the device.
•Chapter7, Examples describes many examples of how to configure RUGGEDCOM NETCONF data. Read this
section to learn how to perform common network configuration tasks through RUGGEDCOM NETCONF.
•Chapter8, NETCONF XML Elements describes the XML elements unique to NETCONF commands. Read this
section to learn about the XML elements used to build NETCONF commands and for information on what the
elements mean when they are returned in a message from the server.


Preface
RUGGEDCOM NETCONF
Reference Guide
x Alerts
Alerts
The following types of alerts are used when necessary to highlight important information.
DANGER!
DANGER alerts describe imminently hazardous situations that, if not avoided, will result in death or
serious injury.
WARNING!
WARNING alerts describe hazardous situations that, if not avoided, may result in serious injury and/or
equipment damage.
CAUTION!
CAUTION alerts describe hazardous situations that, if not avoided, may result in equipment damage.
IMPORTANT!
IMPORTANT alerts provide important information that should be known before performing a procedure
or step, or using a feature.
NOTE
NOTE alerts provide additional information, such as facts, tips and details.
Related Documents
Other documents that may be of interest include:
•RUGGEDCOM NETCONF Web Interface User Guide for the RUGGEDCOM RX1400
•RUGGEDCOM NETCONF Web Interface User Guide for the RUGGEDCOM RX1500/RX1501/RX1510/RX1511/
RX1512
•RUGGEDCOM NETCONF Web Interface User Guide for the RUGGEDCOM RX5000
•RUGGEDCOM NETCONF CLI User Guide for the RUGGEDCOM RX1400
•RUGGEDCOM NETCONF CLI User Guide for the RUGGEDCOM RX1500/RX1501/RX1510/RX1511/RX1512
•RUGGEDCOM NETCONF CLI User Guide for the RUGGEDCOM RX5000
Most documents are available on Siemens' Industry Online Support portal [https://support.industry.siemens.com]
or mobile application. For all others, contact a Siemens Sales representative or Siemens Customer Support.
Accessing Documentation
The latest user documentation for RUGGEDCOM NETCONF v is available online at www.siemens.com/ruggedcom.
To request or inquire about a user document, contact Siemens Customer Support.

RUGGEDCOM NETCONF
Reference Guide

Preface
Training xi
Training
Siemens offers a wide range of educational services ranging from in-house training of standard courses on
networking, Ethernet switches and routers, to on-site customized courses tailored to the customer's needs,
experience and application.
Siemens' Educational Services team thrives on providing our customers with the essential practical skills to make
sure users have the right knowledge and expertise to understand the various technologies associated with critical
communications network infrastructure technologies.
Siemens' unique mix of IT/Telecommunications expertise combined with domain knowledge in the utility,
transportation and industrial markets, allows Siemens to provide training specific to the customer's application.
For more information about training services and course availability, visit www.siemens.com/ruggedcom or
contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general
information, contact Siemens Customer Support through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a Support Request (SR) or check on the status of an
existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a local hotline center, visit http://
www.automation.siemens.com/mcms/aspa-db/en/automation-technology/Pages/default.aspx.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android, Apple iOS or Windows mobile device and be able to:
• Access Siemens' extensive library of support documentation, including FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support, Training, etc.
• Ask questions or share knowledge with fellow Siemens customers and the support community


Preface
RUGGEDCOM NETCONF
Reference Guide
xii Customer Support

RUGGEDCOM NETCONF
Reference Guide
Chapter 1
Introduction
What is NETCONF? 1
Introduction
Welcome to the RUGGEDCOM NETCONF Reference Guide. This document aims to describe the Network
Configuration Protocol (NETCONF) and how it can be used to control the configuration of a device running
RUGGEDCOM ROX II.
All versions of RUGGEDCOM ROX II supports NETCONF sessions.
CONTENTS
•Section1.1, “What is NETCONF?”
•Section1.2, “What Can NETCONF Do?”
•Section1.3, “Who Should Use This Guide”
•Section1.4, “Supported IETF RFCs”
•Section1.5, “Sample NETCONF sessions”
Section1.1
What is NETCONF?
The Network Configuration Protocol (NETCONF) is a network configuration protocol developed by the Internet
Engineering Task Force (IETF). NETCONF provides functions to download, upload, change, and delete the
configuration data on network devices. Devices running the RUGGEDCOM ROX II operating system also support
the ability to collect data and perform direct actions on the device, such as rebooting the device, clearing statistics,
and restarting services.
NETCONF actions and data are described using Extensible Markup Language (XML). NETCONF uses a collection
of XML elements to identify functions and operations. Configuration data is represented as a hierarchy of XML
elements that describe the path to a configurable setting and its data.
The NETCONF protocol can be thought of as having four conceptual layers:

Chapter 1
Introduction
RUGGEDCOM NETCONF
Reference Guide
2 What is NETCONF?
Figure1:NETCONF Concepts and Implementation
• The Transport Protocol layer provides connectivity between the device and the NETCONF client. RUGGEDCOM
ROX II supports the use of Secure Shell (SSH) for the connection.
• The Remote Procedure Call layer represents NETCONF requests and responses. Requests from the client to the
device are wrapped within <rpc> elements in the XML query text. Responses from the device to the client are
wrapped within <rpc-reply> elements in the XML response text.
• The Operations layer represents actions and functions performed on the RUGGEDCOM ROX II server. The
operations available for use are defined by the NETCONF capabilities advertised by the device.
• The Content layer represents the configuration data on the device. NETCONF can query, manipulate,
and monitor the configuration data on the device. The configuration data is defined by the RUGGEDCOM
namespaces. The configuration data is structured in NETCONF in the same way as it is in the RUGGEDCOM ROX
II web interface and command line interface (CLI).
The NETCONF protocol is defined in several Internet Engineering Task Force Request For Comment (RFC)
documents. It is not necessary to read the RFCs to use NETCONF with devices, but this guide provides links to the
RFCs for those interested in the design details of the NETCONF protocol.
For more general background information on NETCONF, refer to the Internet Engineering Task Force RFC 6241
[http://tools.ietf.org/html/rfc6241]. This RFC, published in June 2011, is the current main defining document for
the NETCONF protocol.
For historical interest, refer to Internet Engineering Task Force RFC 4741 [http://tools.ietf.org/html/rfc4741]. This
RFC, published in 2006, contains the initial definition of the NETCONF protocol. Note that RFC 6241 obsoletes RFC
4741.
Several additional RFCs define the NETCONF capabilities and namespaces. Links to these documents appear
throughout Chapter2, NETCONF Capabilities and Namespaces, where this guide discusses the capabilities and
namespaces supported by devices.

RUGGEDCOM NETCONF
Reference Guide
Chapter 1
Introduction
What Can NETCONF Do? 3
Section1.2
What Can NETCONF Do?
NETCONF provides an easy-to-use application programming interface (API) for RUGGEDCOM NETCONF. It provides
the ability to view and manipulate configuration data, monitor device status, and perform device management
commands.
Use NETCONF to develop custom configuration management tools and applications, such as:
• shell scripts for common device management tasks
• custom device management interfaces
• custom configuration management applications and databases
• integrating devices into existing configuration management applications and databases
Section1.3
Who Should Use This Guide
This guide is for network administrators and programmers tasked with the configuration management of network
devices.
Readers should be familiar with the following:
• general use and function of the RUGGEDCOM ROX II software.
• network design and network management concepts and tasks.
• using Secure Shell (SSH) to connect to RUGGEDCOM ROX II.
• how to create well-formed and valid XML documents.
Section1.4
Supported IETF RFCs
RUGGEDCOM ROX II supports the following IETF Request For Comments (RFC):
•Internet Engineering Task Force RFC 5277 [http://tools.ietf.org/html/rfc5277]
•Internet Engineering Task Force RFC 5717 [http://tools.ietf.org/html/rfc5217]
•Internet Engineering Task Force RFC 6021 [http://tools.ietf.org/html/rfc6021]
•Internet Engineering Task Force RFC 6022 [http://tools.ietf.org/html/rfc6022]
•Internet Engineering Task Force RFC 6241 [http://tools.ietf.org/html/rfc6241]
•Internet Engineering Task Force RFC 6243 [http://tools.ietf.org/html/rfc6243]
Section1.5
Sample NETCONF sessions
This section provides a walk-through of three typical types of NETCONF sessions:

Chapter 1
Introduction
RUGGEDCOM NETCONF
Reference Guide
4 Sample Session: Getting Data
•Section1.5.1, “Sample Session: Getting Data” describes a simple session where you connect to a device, get
data from the device, and close the session
•Section1.5.2, “Sample Session: Performing an Action” describes a simple session where you connect to a device,
perform an action on the device, and close the session
•Section1.5.3, “Sample Session: Editing Data” describes a more complex session where you connect to a device,
prepare the device data-stores for editing, edit the data, commit the data, and close the session
Each sample provides an overview of the primary steps in the session, a schematic illustration of the primary steps,
and the actual NETCONF code sent to and received from the device.
Read these sections to become familiar with the general flow of typical NETCONF sessions. Also, review these
sections to become familiar with examples of working NETCONF XML code. The text in these examples can be
copied and tested on an operating RUGGEDCOM NETCONF device.
The XML code in these examples has been formatted for legibility. Line breaks and white space have been added
to the XML text to make the lines easier to read and to show the element hierarchy. When sending XML text to the
device, the line breaks and whitespace are not required. You can send XML text to the device in a single line, as
long as the XML is well-formed.
Text returned from the device has also been formatted for legibility. The text returned from the device typically
appears in a single line, without whitespace between the elements.
In these examples, the <hello> message from the device has been truncated for clarity.
CONTENTS
•Section1.5.1, “Sample Session: Getting Data”
•Section1.5.2, “Sample Session: Performing an Action”
•Section1.5.3, “Sample Session: Editing Data”
Section1.5.1
Sample Session: Getting Data
To retrieve data from a device, do the following:
Figure2:Getting Data

RUGGEDCOM NETCONF
Reference Guide
Chapter 1
Introduction
Sample Session: Getting Data 5
Basic Steps
1. Connect to the device and exchange <hello> messages.
2. Issue <get> or <get-config> commands to retrieve data from the device. You determine the data to
retrieve by stating the RUGGEDCOM namespace from which you want to retrieve the data, and then stating
the path through the data model to the information you want to return.
3. Close the session. Closing the session ensures that the NETCONF session closes gracefully without incomplete
processes or locked datastores.
Detailed Steps
1. Log in to the device via ssh:
$ ssh {user}@{ipAddress} -p 830 -s netconf
•{user} is a user name on the device. Typically, the user should be assigned the administrative user role.
•{ipAddress} is an address on the device listening for NETCONF activity. The -p parameter indicates the
port listening for NETCONF activity. Port 830 is the default NETCONF port. The -s parameter indicates the
subsystem. All NETCONF communication must be identified with -s netconf. You can configure the IP
addresses and ports on which RUGGEDCOM NETCONF listens for NETCONF. For more information, refer to
Section3.1, “Configuring/Monitoring NETCONF in RUGGEDCOM NETCONF”.
The device responds with its <hello> statement:
<?xml version="1.0" encoding="UTF-8"?>
<hello xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<capabilities>
.
.
.
</capabilities>
<session-id>797</session-id>
</hello>]]>]]>
2. Respond to the device with the client's <hello> statement. The client's <hello> statement can describe the
client's capabilities, or it can respond with just the base NETCONF capability. This example shows the minimal
<hello> response:
<hello xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<capabilities>
<capability>urn:ietf:params:netconf:base:1.0</capability>
</capabilities>
</hello>]]>]]>
3. Issue an <rpc> request to retrieve data from the device:
<rpc message-id="1001" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<get-config>
<source>
<running/>
</source>
<filter type="subtree">
<admin xmlns="http://ruggedcom.com/ns/rmf_admin">
<system-name></system-name>
</admin>
</filter>
</get-config>
</rpc>]]>]]>

Chapter 1
Introduction
RUGGEDCOM NETCONF
Reference Guide
6 Sample Session: Performing an Action
• All commands must be enclosed within <rpc> tags. The message-id attribute is not required but is
recommended. The message-id attribute is returned in the device response, allowing you to match
responses with requests.
• The <source> element indicates the datastore from which we are requesting data. In this example we are
requesting data from the running configuration database.
• The <filter> element encloses the data model tags. The type="subtree" attribute is mandatory.
• The <admin> element is the root of the RUGGEDCOM admin namespace. Within the <admin> element,
additional elements navigate down to the desired element. In this example, we are navigating to admin/
system-name in the RUGGEDCOM NETCONF data model.
• The ]]>]]> string indicates the end of the NETCONF message. Each NETCONF message must end with
]]>]]>
The device responds with the requested data:
<?xml version="1.0" encoding="UTF-8"?>
<rpc-reply xmlns="urn:ietf:params:xml:ns:netconf:base:1.0" message-id="1001">
<data>
<admin xmlns="http://ruggedcom.com/ns/rmf_admin">
<system-name>Substation Ethernet Switch 2</system-name>
</admin>
</data>
</rpc-reply>]]>]]>
• The <rpc-reply> element contains the response. Notice the message-id attribute returned with the
<rpc-reply> element; it corresponds to the <message-id> sent in the <rpc> request.
4. After receiving the data, close the session:
<rpc message-id="1002" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<close-session/>
</rpc>]]>]]>
The device responds with the following and closes the session:
<?xml version="1.0" encoding="UTF-8"?>
<rpc-reply xmlns="urn:ietf:params:xml:ns:netconf:base:1.0" message-id="1002">
<ok/>
</rpc-reply>]]>]]
Section1.5.2
Sample Session: Performing an Action
To perform an action on a device, do the following:

RUGGEDCOM NETCONF
Reference Guide
Chapter 1
Introduction
Sample Session: Performing an Action 7
Figure3:Performing an Action
Basic Steps
1. Connect to the device and exchange <hello> messages.
2. Issue an <rpc> command with the action to perform. The <rpc> request must contain the <action>
element referring to the action namespace. You determine the action to perform by stating the RUGGEDCOM
namespace where the command is found, and then stating the path through the data model to the
command.
3. Close the session. Closing the session ensures that the NETCONF session closes gracefully without incomplete
processes or locked datastores.
Detailed Steps
1. Log in to the device via ssh:
$ ssh {user}@{ipAddress} -p 830 -s netconf
•{user} is a user name on the device. Typically, the user should be assigned the administrative user role.
•{ipAddress} is an address on the device listening for NETCONF activity. The -p parameter indicates the
port listening for NETCONF activity. Port 830 is the default NETCONF port. The -s parameter indicates the
subsystem. All NETCONF communication must be identified with -s NETCONF. You can configure the IP
addresses and ports on which RUGGEDCOM NETCONF listens for NETCONF. For more information, refer to
Section3.1, “Configuring/Monitoring NETCONF in RUGGEDCOM NETCONF”.
The device responds with its <hello> statement:
<?xml version="1.0" encoding="UTF-8"?>
<hello xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<capabilities>
.
.
.
</capabilities>
<session-id>797</session-id>
</hello>]]>]]>

Chapter 1
Introduction
RUGGEDCOM NETCONF
Reference Guide
8 Sample Session: Performing an Action
2. Respond to the device with the client's <hello> statement. The client's <hello> statement can describe the
client's capabilities, or it can respond with just the base NETCONF capability. This example shows the minimal
<hello> response:
<hello xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<capabilities>
<capability>urn:ietf:params:netconf:base:1.0</capability>
</capabilities>
</hello>]]>]]>
3. Issue an <rpc> request with the action to perform:
<rpc message-id="1005" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<action xmlns="http://tail-f.com/ns/netconf/actions/1.0">
<data>
<admin xmlns="http://ruggedcom.com/ns/rmf_admin">
<set-system-clock>
<time>2012-03-26 18:00:00</time>
</set-system-clock>
</admin>
</data>
</action>
</rpc>]]>]]>
• All commands must be enclosed within <rpc> tags. The message-id attribute is not required but is
recommended. The message-id attribute is returned in the device response, allowing you to match
responses with requests.
• The <action> element indicates that this request is to perform an action on the device. The <action>
element must refer to the action namespace in the xmlns attribute.
• The <admin> element is the root of the RUGGEDCOM admin namespace. Within the <admin> element,
additional elements navigate down to the desired command. In this example, we are navigating to admin/
set-system-clock in the RUGGEDCOM NETCONF data model.
• The ]]>]]> string indicates the end of the NETCONF message. Each NETCONF message must end with
]]>]]>
The device responds with the results of the command:
<?xml version="1.0" encoding="UTF-8"?>
<rpc-reply xmlns="urn:ietf:params:xml:ns:netconf:base:1.0" message-id="1005">
<data>
<admin xmlns='http://ruggedcom.com/ns/rmf_admin'>
<set-system-clock>
<system-clock>Mon Mar 26 18:00:01 2012</system-clock>
</set-system-clock>
</admin>
</data>
</rpc-reply>]]>]]>
• The <rpc-reply> element contains the response. Notice the message-id attribute returned with the
<rpc-reply> element; it corresponds to the <message-id> sent in the <rpc> request.
4. After receiving the response, close the session:
<rpc message-id="1006" xmlns="urn:ietf:params:xml:ns:netconf:base:1.0">
<close-session/>
</rpc>]]>]]>
The device responds with the following and closes the session:
<?xml version="1.0" encoding="UTF-8"?>
<rpc-reply xmlns="urn:ietf:params:xml:ns:netconf:base:1.0" message-id="1006">
