Siemens CCAW1417-LPI Instruction sheet

Siemens AG
High-Resolution, Day/Night,
Wide-Dynamic, Autofocus
All-In-One Camera with
22x Optical / 16x Digital Zoom
CCAW1417-LPI
Configuration Manual

Liefermöglichkeiten und technische Änderungen vorbehalten.
Data and design subject to change without notice. / Supply subject to availability.
© 2011 Copyright by Siemens AG
Wir behalten uns alle Rechte an diesem Dokument und an dem in ihm dargestellten Gegenstand vor. Der Empfänger erkennt diese Rechte
an und wird dieses Dokument nicht ohne unsere vorgängige schriftliche Ermächtigung ganz oder teilweise Dritten zugänglich machen oder
außerhalb des Zweckes verwenden, zu dem es ihm übergeben worden ist.
We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights
and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our
prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.

3
Siemens AG 04.2011
Contents
1Safety .......................................................................................................5
1.1 Target readers...........................................................................................5
1.2 Work safety information ............................................................................5
1.2.1 Transport...................................................................................................5
1.2.2 Installation .................................................................................................5
1.2.3 Service and maintenance .........................................................................6
1.3 Meaning of the written warning notices ....................................................6
1.4 Meaning of the hazard symbols................................................................6
2Directives and standards .......................................................................7
3Technical data .........................................................................................8
4Details for ordering...............................................................................10
5Package contents..................................................................................10
6Description of the camera....................................................................11
6.1 Camera features .....................................................................................11
6.2 Camera parts ..........................................................................................12
7System installation ...............................................................................13
8Connection ............................................................................................14
8.1 General ...................................................................................................15
8.1.1 Automatic switching between colour and B/W mode..............................15
8.1.2 RS-485 connection .................................................................................15
8.1.3 Twisted-pair video output........................................................................16
8.1.4 Alarm output............................................................................................16
8.2 Remote configuration..............................................................................17
9Camera settings ....................................................................................18
9.1 OSD main screen....................................................................................18
9.2 Main menu ..............................................................................................18
9.2.1 FOCUS....................................................................................................18
9.2.2 WB (White Balance)................................................................................19
9.2.3 AE (Auto Exposure) ................................................................................20
9.2.4 BLC / WDR (Back Light Compensation / Wide Dynamic Range)...........20
9.2.5 ALARM / MD (Motion Detection) / FD (Face Detection) .........................21
9.2.6 PRIVACY ................................................................................................21
9.2.7 SPECIAL .................................................................................................22
9.2.8 EFFECT ..................................................................................................22
9.2.9 CAMSET .................................................................................................23
10 Troubleshooting and maintenance .....................................................24
10.1 Troubleshooting ......................................................................................24
10.2 Maintenance............................................................................................24
11 Disposal .................................................................................................25

Safety
5
Siemens AG 04.2011
1 Safety
1.1 Target readers
The instructions in this document are designed only for the following target
readers:
Target readers Qualification Activity Condition of the
equipment
Start-up personnel Has appropriate
technical training with
regard to the tasks
and the products,
devices or systems to
be put in service.
Puts the device or
system which is readily
assembled and installed
on site into service.
New, readily assembled
and installed device or
modified device.
1.2 Work safety information
zRead the general safety precautions before operating the unit.
zFollow all warnings and instructions marked on the device.
zKeep this document available for reference.
zAlways pass this document on together with the product.
zPlease also take into account any additional country-specific, local safety
standards or regulations concerning project planning, operation and disposal of
the product.
Liability claim
zDo not connect the device if it is damaged or any parts are missing.
zDo not make any changes or modifications to the device that are not mentioned
in this manual and that have not been approved by the manufacturer.
zUse only spare parts and accessories that have been approved by the
manufacturer.
1.2.1 Transport
Damage during transport
zKeep the packaging material for future transportation.
zDo not expose the device to mechanical vibrations or shocks.
1.2.2 Installation
Damage due to unsuitable mounting location
zThe environmental conditions recommended by the manufacturer must be
observed.
zDo not operate the device in excessively dusty places.
zDo not expose the device to mechanical vibrations or shocks.

Safety
6
Siemens AG 04.2011
Danger of electric shock
zConnect the device only to power sources with the specified voltage. Voltage
supply requirements can be found on the type label and on the mains adapter.
zConnect the device only to a power source that complies with the Limited Power
Source requirements to EN 60950-1.
zConnect the device only to a power source that complies with SELV
requirements.
Risk of cable damage due to stress
zDo not apply tensile stress to the cable.
zMake sure that cables are not under stress, kinked or damaged.
1.2.3 Service and maintenance
Damage to the device
zDo not attempt to service this device yourself. Refer this work to qualified service
personnel.
zAlways disconnect the power cable and other cables from the main power
supply before performing maintenance.
zDisconnect the device from the mains supply before cleaning it.
zDo not use liquid cleaners or sprays that contain alcohol, spirit or ammonia.
1.3 Meaning of the written warning notices
The severity of a hazard is indicated by the following written warning notices.
Warning notice Type of risk
WARNING Death or severe bodily injury may result
CAUTION There is a risk of minor injuries or damage to property
IMPORTANT Malfunctioning may result
1.4 Meaning of the hazard symbols
The nature of the hazard is indicated by icons.
CAUTION Dangerous area!
CAUTION Dangerous electrical voltage!
Important information

Directives and standards
7
Siemens AG 04.2011
2 Directives and standards
The product complies with the requirements of the following EU directives. The EU
declaration of conformity is available from:
Siemens AG
Siemensallee 84
76181 Karlsruhe
European Directive 2004/108/EC "Electromagnetic Compatibility"
Compliance with the European Directive 2004/108/EC has been proven by testing
according to the following standard:
Emitted interference: EN 55022 Class A
Resistance to interference: EN 50130-4
CAUTION
This is a Class A device. This equipment may cause radio interference in a
residential installation. In this case the user is encouraged to perform
appropriate measures to correct the interference.

Technical data
8
Siemens AG 04.2011
3 Technical data
AB
C
121.4
72.0
66.0
23.031.0
20.0
1
Abb. 1 Dimensions
1 ¼-inch 20 UNC female thread
A Front view
B Side view
C Bottom view
Power supply
Power requirement 12 V DC / 24 V AC, 0.6 A, 50 Hz
General
Image sensor ¼-inch SONY 760H EXview HAD CCD
Pixels 795 (H) x 596 (V)
Scanning system 2:1 interlace
Scanning frequency 15,625 kHz (H), 50 Hz (V)
Synchronization Internal/external: line lock
Horizontal resolution Colour: 560 TV lines
B/W: 600 TV lines
Min. illumination Colour: 0.5 lux
B/W: 0.05 lux
Slow shutter: 0.001 lux
0.5 lux at F=1.6 (AGC on, 50 IRE video output)
Video output 1.0 Vpp (75 Ω, composite)
Signal/noise ratio 50 dB (AGC off)
Functions
Wide dynamic range (WDR) On/Off/Level (x512, 48 dB)
Back-light compensation (BLC) Auto/Manual (Area, Level)/Off
Day/night Colour/BW/Auto/EXT

Technical data
9
Siemens AG 04.2011
Motion detection (MD) On/Off (Area/Sensitivity)
Slow-speed shutter 2x – 128x
Digital noise reduction (DNR) 2D/3D
Face detection (FD) On/Off
Privacy masking (PM) Max. 16 zones, mosaic function
White balance (WB) AWB/WAWB/Indoor/Outdoor/Manual/CRS
(Colour Rolling Suppression)
Auto exposure (AE) Auto1/Auto2/Shutter Priority/Manual
Iris control Automatic
Automatic gain control (AGC) MIN/LOW/MID/HIGH (max. 30 dB)
Shutter speed Normal: 1/100000 s
Title A – Z / 0 – 9
Display On/Off/Push On (DISP1/DISP2)
Brightness Adjustable in steps from 10 – 50
Sharpness Adjustable in steps from 0 – 15
Zoom presets 10
Zoom tour 1 tour / 10 presets
Alarm mode On/Off/Dwell Time
Remote configuration RS-232: Siemens B (parameter setting)
RS-485: Siemens B, S; Molynx; Pelco D/-P
Bit rate 2400/4800/9600/19200
Camera ID 1 – 255
Effect Sharpness, Nega/Posi, D-FLIP, Freeze,
HI-RES, 2-3 DNR
Home preset Off/Home Preset Select/Dwell Time
Lens
Focus mode Auto/Manual/Push AF
Distance 0.1 m/1.0 m/1.5 m/2.5 m/6.0 m
Total zoom 22x optical zoom, 16x digital zoom (video AF)
Focal length 3.9 – 85.8 mm
Aperture F1.6 (wide-angle) – F3.7 (tele)
Angle of view Horizontal: 49.5° (wide-angle) – 2.6° (tele)
Connections and environmental conditions
Power input 2-pin connection terminal
Video output BNC connector / TP output
Environmental operating
temperature -10 to +50 °C
Relative humidity 0 – 96% (non-condensing)
Storage temperature -20 to +60 °C
Dimensions (W x H x D) 72 x 66 x 121.4 mm
Weight 0.40 kg
TP output
Video output Adjustable: 2.0 Vpp, 2.6 Vpp, 3.2 Vpp
Frequency accentuation Adjustable: 0 dB, 6 dB, 12 dB

Details for ordering
10
Siemens AG 04.2011
4 Details for ordering
Type Part no. Designation Weight
CCAW1417-LPI S54561-C34-A1 ¼-inch Camera D/N WD AF 0.4 kg
5 Package contents
zCamera
zInstallation Instruction
z12-pin interface cable
zSoftware and documentation on CD

Description of the camera
11
Siemens AG 04.2011
6 Description of the camera
6.1 Camera features
The high-resolution, day/night, autofocus all-in-one camera is particularly suited for
closed circuit television (CCTV) and security surveillance applications.
zHigh-performance SONY ¼-inch 760H EXview HAD CCD
z352x zooming capability (optical: 22x / digital: 16x)
zUltra-sensitivity minimum illumination of 0.5 lux at F1.6
(AGC on, 50 IRE video output)
zExcellent picture quality
zVarious picture effects
zFlexible configuration
zCamera control via RS-485
zTwisted-pair video output
zDual-power operation 12 V DC / 24 V AC
CAUTION Use only certified class 2 power supply units.
Functions:
zDay/Night (D/N)
zWide dynamic range (WDR)
zDigital noise reduction (DNR)
zAuto exposure (AE)
zBack-light compensation (BLC)
zDigital zoom (D-Zoom)
zDay/Night switching (D/N)
zFreeze
zDigital slow shutter (DSS)
zAutomatic white balance (AWB)
zAutomatic gain control (AGC)
zOn-screen menu (OSD)
zNegative/Positive switching (NEGA/POSI)
zE function (H/V flip, rotation)
zHigh resolution
zMotion detection and face detection
zPrivacy masking
zZoom preset and tour function
zHome preset

Description of the camera
12
Siemens AG 04.2011
CAUTION
The user of this camera is responsible for checking and complying with local,
state, and federal laws and statutes concerning the recording and monitoring of
audio and video signals.
6.2 Camera parts
8
9
7
3
5
6
4
13
15 10
11
12
14
1
2
Abb. 2 Camera parts definition
1 Zoom lens Integrated lens with 22x optical zoom
2 Filter mount For standard filters with diameter 37 mm
3 Front part of the
housing
4 Mounting adapter For mounting the camera, ¼-inch 20 UNC thread
5 Housing body
6 Rear part of the housing
7 Camera module
8 Connector Connection of control signals
9 TELE, WIDE keys Press "WIDE" for wide-angle view and "TELE" to zoom in
10 MENU key Press to activate the OSD menu
11 NEAR, FAR keys Press the "NEAR" button to focus on near objects and the "FAR"
button to focus on distant objects. The focus keys are activated when
AF mode is Off.
12 BNC connector Monitor connection port
13 Power input terminal 24 V AC / 12 V DC
14 Power indicator LED
15 DIP switch Twisted-pair video output parameters
A Front view
B Side view
C Rear view

System installation
13
Siemens AG 04.2011
7 System installation
Installation of the camera must be performed by qualified service personnel in
accordance with all local national electrical and mechanical codes.
Typical system configuration with DVR Typical system configuration with SIMATRIX
111
C1 C2 C10
A
B
B
234
C
111
.....
C1 C2 C10
A
B
2
4
3
C
1 Camera C1..C10 A RS485
2 Keyboard B Video
3 DVR C RS232/485
4 Monitor
1 Camera C1..C10 A RS485
2 Keyboard B Video
3 SIMATRIX C TTY
4 Monitor
When using the camera in conjunction with a video matrix switcher (SIMATRIX SYS, 648, 164) or
other telemetry equipment (different protocol), an interface converter CAC0103 is required.
Typical system configuration with directly controlled cameras
11
.....
C1 C2 C10
2
3
33
BBB
A
1 Camera C1..C10 A RS485
2 Keyboard B Video
3 Monitor

Connection
14
Siemens AG 04.2011
8 Connection
CAUTION Do not connect the power cable until all other connections have been
completed. Any unused wires should be trimmed and insulated.
Abb. 3 Connection
1 Monitor BNC
2 Video BNC
3 DVR/VCR BNC
A Pink RS-485(-)4 RS-485 connection
B Black RS-485(+)
C Blue TP-A(+)5 Twisted-pair video output
D Green TP-B (-)
E Grey Ext. input6 Aut. switching between
colour and B/W /
Alarm input F Red GND
G Yellow GND7 Remote control
H Orange Control
Light blue TxDRS-232 connection,
PC configuration Brown RxD
MD output Violet MD/FD off: 0 V, on: 3.3 V
Red +12 V DC / 24 V ACPower supply
White - 12 V DC / 24 V AC

Connection
15
Siemens AG 04.2011
8.1 General
8.1.1 Automatic switching between colour and B/W mode
The camera must be connected to an external sensor to receive day/night
detection signals.
2
3
4
1
1 External sensor switch
2 External input (EXT-In) Grey
3 External output (EXT-Out) White
4 GND Red
Positions of the external sensor switch (1)
Activate alarm: closed
EXT-IN Deactivate alarm: open
Alarm activated: 5 V
EXT-OUT Alarm deactivated: 0 V
To activate the sensor inputs, select the mode EXT in the function menu B/W.
8.1.2 RS-485 connection
The camera can be controlled remotely by an external device or control system,
such as a control keyboard, using RS-485 half-duplex. Connect marked Rx+, Rx-
to Tx+ and Tx- of the RS-485 control system.
1 RS-485(+) Black
2 RS-485(-) Pink

Connection
16
Siemens AG 04.2011
8.1.3 Twisted-pair video output
1 TP-A(+) Blue
2 TP-B (-) Green
Switch description S1 S2 S3 S4 Note
Off Off 2.0 Vpp
On Off 2.6 Vpp
Output voltage without
accentuation
On On 3.2 Vpp
Off Off 0 dB
Off On 6 dB
On Off 6 dB
Frequency-dependent
accentuation at 5 MHz
On On 12 dB
ON
1234
Condition on delivery On Off Off Off
8.1.4 Alarm output
The alarm output (motion detection result or face detection result or external signal
fed in) is active high.
1 Alarm output Violet
2 GND Red

Connection
17
Siemens AG 04.2011
8.2 Remote configuration
3
1
122
1
122
1
122
1
122
1
122
R22 150
R20 12K
R21 5.6K
Sw10 TELE
R19 22K
Sw11 WIDE
Sw13
FAR
Sw12
NEAR
R18 33K
Sw9 MENU
1
2
A
3
MENU
TELE
NEAR
FAR
WIDE
43
1M95mm
42mm
4
Abb. 4 Remote configuration – circuit diagram
Camera
1 GND Yellow
2 Remote control Orange
Remote control unit
3 Remote control White
4 GND Black
A Remote control unit
The remote control cable must not be extended.

Camera settings
18
Siemens AG 04.2011
9 Camera settings
9.1 OSD main screen
CAMERA TEXT
001x CAM 001
1
23
1 Camera title
2 Status of the zoom position
3 Camera ID
9.2 Main menu
<MAIN MENU>
FOCUS
WB
AE
BLC/WDR
ALARM/MD/FD
PRIVACY
SPECIAL
EFFECT
CAM SET
END <EXIT>
Navigate the camera menu using the remote control (see Section 8.2 Remote configuration).
9.2.1 FOCUS
<FOCUS MENU>
MODE
DISTANCE
D-ZOOM
D-ZOOM END
ZOOM PRESET
SET PRESET
TOUR CONFIG
HOME PRESET
HOME DWELL
END
MODE Focus mode: Auto, Manual, PushAF
DISTANCE Min. distance in focus between camera and object
D-ZOOM 0.1 / 1.0 / 1.5 / 2.5 / 6.0 m
D-ZOOM END Digital zoom function On/Off
ZOOM PRESET Max. digital zoom factor: x2 – x16
SET PRESET Zoom preset number: 1 – 10

Camera settings
19
Siemens AG 04.2011
TOUR CONFIG Zoom position of zoom preset
HOME PRESET Press ENTER to save the tour configuration (preset combination)
HOME WAIT Home preset On/Off
END Waiting time after which the camera returns to start position (HOME PRESET)
Move the cursor using the "Far/Near", "Tele/Wide" keys.
Press MENU to enter the next level for configuration.
12
<TOUR CONFIG MENU>
01* 02* 03 04 05
06 07 08 09 10
< S E
DWELL TIME 010
CMD description
* : User-saved preset
< : Deletes the character at the cursor position and
moves one position to the left
S : Save the present tour setting
E : Exit
DWELL TIME
Zoom preset dwell time (10 – 180 s)
When ZOOM PRESET is selected, you can adjust the preset zoom position using the “Tele” and
“Wide” buttons.
When a ZOOM PRESET has been selected press the MENU button to save the preset.
9.2.2 WB (White Balance)
<WB MENU>
MODE
R GAIN
B GAIN
FRAME ADJ
END
MODE WB modes:
zAWB: Auto White Balance: 2500K – 9500K
zWAWB: Wide Auto White Balance: 1800K – 10500K
zINDOOR: Indoor white balance mode
zOUTDOOR: Outdoor white balance mode
zMANUAL: You can change R and B gain manually
zCRS (Colour Rolling Suppression): Decrease colour rolling effect; useful in
SHUTTER mode in AE menu
R GAIN Red gain: 0 – 255
B GAIN Blue gain: 0 – 255
FRAME ADJ Since the colour rolling path differs depending on the fluorescent lamp used, it has to
be adjusted individually. To do so, select the WB menu.
After about 10 s, the adjust mode will be finished automatically.
END Back to the next higher menu level

Camera settings
20
Siemens AG 04.2011
9.2.3 AE (Auto Exposure)
<AE MENU>
MODE
SHUTTER
GAIN
DSS
MAX DSS
FLICKERLESS
BRIGHTNESS
END
MODE AE modes:
zAuto1: For use in normal environments: Indoor (shutter speed 1/50 s)
zAuto2: For use in high-brightness environments: Outdoors
zShutter Pri.: Shutter priority exposure mode
zManual: Manual exposure mode
SHUTTER Shutter speed: 1/50 – 1/100 000 s
Can be changed while in "Shutter Pri" and "Manual" mode
GAIN Maximum Auto Gain Control (AGC) value
DSS Digital slow shutter On/Off (enable in low light)
MAX DSS Digital slow shutter range: x2 – x128
FLICKERLESS Flicker-less function On/Off
BRIGHTNESS Brightness level: 10 – 50
END Back to the next higher menu level
9.2.4 BLC / WDR (Back Light Compensation / Wide Dynamic Range)
<BLC/WDR MENU>
BLC MODE
AREA
LEVEL
WDR MODE
LEVEL
END
1 2 3
4 5 6
7 8 9
<BLC area number>
BLC MODE BLC mode: OFF, AUTO, MANUAL:
AUTO: Automatic back-light compensation (area & level)
MANUAL: Back-light compensation (area & level reserved)
BLC AREA Select BLC area: 1-9, activated only in manual BLC mode
BLC LEVEL Back-light compensation level: LOW, MID, HIGH
WDR MODE WDR (Wide Dynamic Range) function On/Off
WDR LEVEL WDR level: 10 – 50
END Back to the next higher menu level
