Sigma MC 1812 User manual

MC 18
MOTOR CYCLE COMPUTER
MEASUREMENT
ACCELERATION
MAX. SPEED
399.8 KM/H
1/4 MILE RACE
MEASUREMENT
BREAKING
DISTANCE
MEASUREMENT
ACCELERATION
HIGHWAY
EN

MC 1812
www.sigmasport.com MC 1812 Page 2

MC 1812
www.sigmasport.com MC 1812 Page 3
Contents
Contents
1 Functions and packaging contents............................................................................................5
1.1 Foreword ............................................................................................................................................................ 5
1.2 Packaging contents........................................................................................................................................ 6
1.3 MC 1812 functions........................................................................................................................................ 6
2 Attaching the MC 1812 and initial use...................................................................................7
2.1 Attaching the bracket.................................................................................................................................... 7
2.2 Attaching the sensor ..................................................................................................................................... 7
2.3 Connecting the sensor to the bracket ................................................................................................... 7
2.4 Attaching the Sigma MC 1812 to the bracket.................................................................................. 8
2.5 Initial use.............................................................................................................................................................. 8
2.6 Initial use of the sensor................................................................................................................................. 8
2.6.1 Auto wake up................................................................................................................................... 8
3 Operating concept............................................................................................................................9
3.1 Button functions............................................................................................................................................... 9
3.1.1 Standard button functions......................................................................................................... 9
3.1.2 Button functions for basic settings........................................................................................ 10
3.2 Display structure ............................................................................................................................................. 10
3.2.1 Top display segment..................................................................................................................... 10
3.2.2 Bottom display segment............................................................................................................. 10
4 Basic settings .....................................................................................................................................11
4.1 Acceleration measurement ........................................................................................................................ 11
4.2 Highway acceleration measurement ...................................................................................................... 12
4.3 Braking measurement .................................................................................................................................. 12
4.4 Total distance.................................................................................................................................................... 13
4.5 Total time ............................................................................................................................................................ 13
4.6 Contrast .............................................................................................................................................................. 14
4.7 Language............................................................................................................................................................. 14
4.8 Setting/changing the unit........................................................................................................................... 14
4.9 Wheel size.......................................................................................................................................................... 15
4.9.1 Determining the wheel size....................................................................................................... 15
4.10 Time....................................................................................................................................................................... 16
4.11 Exiting the basic settings.............................................................................................................................. 16
5 General MC 1812 functions........................................................................................................17
5.1 Display backlight............................................................................................................................................... 17
5.2 Trip distance...................................................................................................................................................... 17
5.3 Trip time .............................................................................................................................................................. 17
5.4 Average speed.................................................................................................................................................. 18
5.5 Maximum speed............................................................................................................................................... 18

MC 1812
www.sigmasport.com MC 1812 Page 4
Contents
5.6 Acceleration measurement ........................................................................................................................ 18
5.7 Highway acceleration measurement ...................................................................................................... 19
5.8 Braking measurement .................................................................................................................................. 19
5.9 Drag race/quarter-mile race..................................................................................................................... 19
6 Reset functions..................................................................................................................................20
6.1 General functions ............................................................................................................................................ 20
6.2 Mode 2 functions ............................................................................................................................................ 20
7 Important information, troubleshooting, and FAQ ..............................................................21
7.1 Important information ................................................................................................................................... 21
7.2 Troubleshooting ............................................................................................................................................... 21
7.3 Frequently asked questions (FAQ)............................................................................................................ 21
8 Technical data ....................................................................................................................................23
8.1 Max, min, and default values....................................................................................................................... 23
8.2 Changing the batteries.................................................................................................................................. 24
8.3 Temperature, batteries ................................................................................................................................ 24
9 Warranty and guarantee...............................................................................................................25

Foreword
Functions and packaging contents
www.sigmasport.com MC 1812 Page 5
MC 1812
Foreword
Functions and packaging contents
1 Functions and packaging contents
1.1 Foreword
Thank you for choosing a SIGMA SPORT®motorcycle computer. Your new
MC 1812 will be a loyal companion for your motorbike trips for years to come.
To familiarize yourself with and learn how to use the many functions of your new
motorbike computer, please read these operating instructions carefully.
SIGMA SPORT®wishes you hours of fun and enjoyment with your MC 1812.
The MC 1812 is a multi-functional motorbike computer that provides you with a
broad range of information both during and after your trips:
Note
Use the MC 1812’s functions to improve your safety when riding your motorbike.
For example, you can optimize your braking technique during motorcycling safety
training. Use the highway acceleration measurement values to see how long it
actually takes to overtake on a country road or motorway. Implement the values
obtained to make your riding style even safer.
− Speed measurement up to 399 km/h.
− Large display (32mm x 34mm)
− Speed, time, distance, acceleration, highway acceleration measurement,
braking measurement
− Ability to customize the MC 1812’s settings.
WARNING
Do not operate the device while riding. A lack of attention to the other traffic on
the road can lead to accidents with serious material damage, personal injury or
even death. You bear full responsibility for the use of this device.

Packaging contents
Functions and packaging contents
www.sigmasport.com MC 1812 Page 6
MC 1812
1.2 Packaging contents
MC 1812 motorcycle computer Universal bracket (CR2450)
Battery compartment key and battery Magnets
Attachment materials
MC 1812 quick start guide
1.3 MC 1812 functions
The MC 1812 is a versatile motorcycle computer. In addition to the classic
functions, the MC 1812 can also measure the average speed, maximum speed,
acceleration, highway acceleration, braking coefficient, and braking distance.
All current values can be simply and permanently read from the large display.

Attaching the bracket
Attaching the MC 1812 and initial use
www.sigmasport.com MC 1812 Page 7
MC 1812
2 Attaching the MC 1812 and initial use
Detailed attachment information can be found in the quick start guide provided.
2.1 Attaching the bracket
− Attachment to the handlebars or cockpit
− Remove the adhesive tape from the bracket (permanent attachment)
− The bracket can be attached using either cable ties (permanent attachment)
or the O-rings.
2.2 Attaching the sensor
− Use the cable ties to attach the sensor to the front wheel fork.
− Ensure that the sensor cable cannot rub anywhere.
− The sensor cable must have enough play when turning the handlebars.
2.3 Connecting the sensor to the bracket
− Guide a sensor cable contact head from below into the left, lower section of
the bracket.
− Insert the cable with the contact head into the opening from the top.
− Press the contact head into the bracket.
− Now guide the other end of the sensor cable into the right, lower section of
the bracket from below.
− Insert the cable with the contact head into the lower of the two openings
from above.
− Press the contact head into the bracket.
− The sensor is now connected to the bracket.

o
p
e
n
-
c
l
o
s
e
Attaching the Sigma MC 1812 to the bracket
Attaching the MC 1812 and initial use
www.sigmasport.com MC 1812 Page 8
MC 1812
2.4 Attaching the Sigma MC 1812 to the bracket
− Hold the MC 1812 motorcycle computer in your hand with the display facing
upward so you can read it.
− Rotate the MC 1812 approx. 45° to the right and insert it into the bracket.
− Turn the MC 1812 to the left.
− The MC 1812 audibly clicks into place.
2.5 Initial use
To save power, the MC 1812 comes without the battery inserted.
Please insert the battery by opening the battery compartment using the tool
provided. Once you have inserted the battery, use the tool to close the battery
compartment.
The MC 1812 jumps to setting mode.
2.6 Initial use of the sensor
To use the sensor, the MC 1812 must be clicked into the bracket. As soon as at
the wheel has rotated at least twice, the speed, for example, will appear on the
display.
2.6.1 Auto wake up
To reduce the power consumption, the device will switch to sleep mode after a
five-minute break. A wheel rotation automatically exits this mode.

Button functions
Operating concept
www.sigmasport.com MC 1812 Page 9
MC 1812
3 Operating concept
3.1 Button functions
Reset button
Press this button to scroll
backward through the Mode 2
functions.
Press and hold this button to
zero the values for the general
functions.
Basic settings menu:
(-) button, backward.
Mode 2 button
Press this button to scroll forward
through the Mode 2 functions.
Basic settings menu:
(+) button, forward.
Mode 1 button
Press this button to scroll forward
through the Mode 1 functions.
Basic settings menu: Select menu
item.
Set button
Press this button to scroll
backward through the Mode 1
functions.
Press and hold the button to
open/close the basic settings
menu.
Basic settings menu:
press the button to save the
change.
3.1.1 Standard button functions
Mode 1 functions Mode 2 functions
Trip distance Time
Trip time Total distance
Avg. speed Total time
Max. speed
Acceleration measurement
Highway acceleration measurement
Braking coefficient measurement
Braking distance
Drag racing

Display structure
Operating concept
www.sigmasport.com MC 1812 Page 10
MC 1812
3.1.2 Button functions for basic settings
Reset Mode 2
Minus (-) Plus (+)
Backward Forward
Set Mode 1
Open Mode 1 functions Acceleration
Save Mode 1 functions Highway acceleration
Set (press and hold) Braking
Settings OPEN Total distance
Settings CLOSE Total time
Contrast
Language
Unit
Wheel size
Time
3.2 Display structure
The MC 1812’s display is divided into two main areas:
3.2.1 Top display segment
This always displays your current speed in either KMP or MPH. The unit can be
set in the basic settings menu.
3.2.2 Bottom display segment
This displays the currently selected function (first line) and the current value
(second line).
Press the Mode 1 and Mode 2 buttons (see 3.1.1) to select the individual
functions.

Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Acceleration measurement
Basic settings
www.sigmasport.com MC 1812 Page 11
MC 1812
4 Basic settings
Accessing the basic settings menu:
-Press and hold the Set button for three seconds.
-‘Setting OPEN’ appears in the bottom display segment.
-‘Setting OPEN’ flashes.
-The first menu item appears on the display: ‘Accel.’ and
‘0 - 100’ (default value).
Now press the Mode 1 button to go to the menu item that you want to set or
change.
To exit the basic settings:
-Press and hold the Set button for three seconds.
-‘Setting CLOSE’ appears on the display
-‘Setting CLOSE’ flashes
-The display menu reappears.
WARNING
Do not operate the device while riding. A lack of attention to the other traffic on
the road can lead to accidents with serious material damage, personal injury or
even death. You bear full responsibility for the use of this device.
4.1 Acceleration measurement
1 Press the Set button.
2 ‘Target speed’ appears and the indicator ‘100’ (default value) flashes.
3 Press Mode 2 (+) or Reset (-) to set the value you desire (e.g. ‘80’).
4 Press the Set button to save your setting.
‘Setting OK’ appears on the display.
Further explanations can be found in section „5.6 Acceleration measurement“.

Highway acceleration measurement
Basic settings
www.sigmasport.com MC 1812 Page 12
MC 1812
4.2 Highway acceleration measurement
1 Press the Mode 1 button to switch to the ‘highway acceleration’ menu.
2 Press the Set button.
3 ‘Start speed’ and ‘60’ (default value) appear.
4 Press Mode 2 (+) or Reset (-) to set the value you desire.
5 Press the Set button.
6 ‘End speed’ and ‘100’ (default value) appear.
7 Press Mode 2 (+) or Reset (-) to set the value you desire.
8 Press the Set button.
9 ‘High. accel. time’ appears on the display and flashes.
Press the Mode 2 or Reset button to change the display to ‘High. accel. dst.’
(distance, indicator in m for meters). Set the function you desire.
10 Press the Set button to save your setting.
‘Setting OK’ appears on the display.
Explanations about this function can be found in section
„5.7 Highway acceleration measurement“.
4.3 Braking measurement
1 Press the Mode 1 button to switch to the ‘braking’ menu.
2 Press the Set button.
3 ‘Braking’ (m/s²) and the factory default value appears on the display for the
minimum deceleration.
4 Press Mode 2 (+) or Reset (-) to set the value.
5 Press the Set button to save your setting.
‘Setting OK’ appears on the display.
Explanations about this function can be found in section
„5.8 Braking measurement“.
Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set

Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Total distance
Basic settings
www.sigmasport.com MC 1812 Page 13
MC 1812
4.4 Total distance
Use this area to enter existing values (e.g. transferred from your old device). New
values are then added to these (see also section „5.2 Trip distance“).
1 Press the Mode 1 button to switch to the ‘Total dist.’ display.
The total distance is displayed.
2 Press the Set button.
3 The first digit for entry flashes (displayed with thousands separator).
4 Press Mode 2 (+) or Reset (-) to set the value.
5 Press the Mode 1 button to switch to the next digit.
6 Repeat the process.
7 Press the Set button to save your setting.
‘Set OK’ appears on the display.
4.5 Total time
Use this area to enter existing values (e.g. transferred from your old device). New
values are then added to these (see also section „5.3 Trip time“).
1 Press the Mode 1 button to switch to the ‘Total time’ display.
2 Press the Set button. The first digit for entering the hours (h) flashes
(attention: a dot appears on the display as a thousands separator!).
3 Press the Mode 2 (+) or Reset (-) button to set the value and the Mode 1 button to
move to the next digit.
4 Repeat the process.
5 Once you have changed all four digits for the hours indicator, press the Set
button to move to the minutes input.
6 The first digit for entering the minutes (min) flashes.
7 Press the Mode 2 (+) or Reset (-) button to set the value and the Mode 1 button to
move to the next digit.
8 Press the Set button to save your setting.
‘Set OK’ appears on the display.

Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Contrast
Basic settings
www.sigmasport.com MC 1812 Page 14
MC 1812
4.6 Contrast
1 Press the Mode 1 button to switch to the default menu item ‘Contrast’.
2 Press the Set button. The digit displayed flashes.
3 Press Mode 2 (+) or Reset (-) to set the value. (1=weak/3=strong)
4 Press the Set button to save your setting.
‘Set OK’ appears on the display.
4.7 Language
1 Press the Mode 1 button to switch to the default language.
2 Press the Set button. The display flashes.
3 Press Mode 2 or Reset to select the desired language.
4 Press the Set button to save your setting.
‘Set OK’ appears on the display.
4.8 Setting/changing the unit
1 Press the Mode 1 button to switch to the default unit.
2 Press the Set button. The display flashes.
3 Press Mode 2 or Reset to switch between KMH and MPH.
4 Press the Set button to save your setting.
‘Set OK’ appears on the display.

1x
= WS (mm)
mm x 3,14
Mode 2
Mode 1
Reset
Set
Wheel size
Basic settings
www.sigmasport.com MC 1812 Page 15
MC 1812
4.9 Wheel size
1 Press the Mode 1 button to switch to the ‘Wheel size’ menu.
2 Press the Set button. The first two digits for entry flash.
3 Press Mode 2 (+) or Reset (-) to set the value.
4 Press Mode 1 to move to the next digit and Mode 2 (+) or Reset (-) to set the value.
Repeat the process for the final digit.
5 Press the Set button to save your setting.
‘Set OK’ appears on the display.
4.9.1 Determining the wheel size
You can determine the wheel size in several ways.
− Calculation on the basis of Figure A or B
Figure A Figure B

Mode 2
Mode 1
Reset
Set
Mode 2
Mode 1
Reset
Set
Time
Basic settings
www.sigmasport.com MC 1812 Page 16
MC 1812
4.10 Time
1 Press the Mode 1 button to switch to the ‘Time’ menu.
2 Press the Set button. The hours digit flashes.
3 Press Mode 2 (+) or Reset (-) to set the value.
4 Press the Mode 1 button to move to the minutes.
5 Press Mode 2 (+) or Reset (-) to set the value.
6 Press the Set button to save your setting.
‘Set OK’ appears on the display.
4.11 Exiting the basic settings
Press and hold the Set button for at least three seconds to exit the basic
settings. ‘Setting CLOSE’ appears on the display, which then switches to the
normal menu.

Reset
Set
Reset
Reset
Display backlight
General MC 1812 functions
www.sigmasport.com MC 1812 Page 17
MC 1812
5 General MC 1812 functions
WARNING
Do not operate the device while riding. A lack of attention to the other traffic on
the road can lead to accidents with serious material damage, personal injury or
even death. You bear full responsibility for the use of this device.
Press any button on the MC 1812 to exit standby mode. The speed indicator
appears in the top display segment and ‘Trip distance’, for example, appears in
the bottom display segment.
To activate the functions described below, simply scroll to the relevant function by
pressing Mode 1 (forward) or Set (backward).
5.1 Display backlight
The backlight function is switched on/off by simultaneously pressing the Set
and Reset buttons. ‘Light On’ or ‘Light Off’ briefly appears on the display.
The display lights up for three seconds when any button is pressed; it switches to
the respective function when the button is pressed a second time.
5.2 Trip distance
The trip distance is automatically recorded each time the computer is started.
Press the Reset button to reset the distance traveled.
The function is used, for example, to record the length of a specific trip.
5.3 Trip time
The trip time is automatically recorded each time the computer is started. Press
the Reset to reset the recorded time.
The function is used, for example, to record the duration of a specific trip.

Reset
Reset
Reset
Average speed
General MC 1812 functions
www.sigmasport.com MC 1812 Page 18
MC 1812
5.4 Average speed
The average speed is automatically recorded each time the computer is started.
Press the Reset button to reset the recorded average speed.
The function is used, for example, to record the average speed of a specific trip.
5.5 Maximum speed
The maximum speed reached is saved here. Press the Reset button to reset the
recorded maximum speed.
Note
Do not use this function when riding on standard roads, only on special sites (e.g.
motorcyclist training centers).
5.6 Acceleration measurement
The MC 1812 has an acceleration measurement function.
The function ‘0...100/sec’ (default value) starts from standstill. During the
measurement, ‘calc.’ appears on the display. On reaching the target speed, the
measurement stops and the result is displayed in the format xx.x sec.
This function is used to record the motorcycle’s ‘real’ acceleration values.
The results can be deleted by pressing the Reset button.
Note
Do not use this function when riding on standard roads, only on special sites (e.g.
motorcyclist training centers).

Highway acceleration measurement
General MC 1812 functions
www.sigmasport.com MC 1812 Page 19
MC 1812
5.7 Highway acceleration measurement
The MC 1812 has a highway acceleration measurement function.
This function ‘60...100/sec’ (default value) measures the time (or optionally
the distance – selectable in the basic settings) that the motorcycle needs to
accelerate from a lower to a higher speed.
The measurement starts as soon as the lower speed is exceeded. The
measurement ends as soon as the higher speed is reached. During the
measurement, ‘calc.’ appears on the display. The measurement result is
displayed in the format xx.x sec or optionally in m.
Note
Do not use this function when riding on standard roads, only on special sites (e.g.
motorcyclist training centers).
5.8 Braking measurement
The MC 1812’s braking measurement measures the braking coefficient ‘brake
(m/s²)’ and the braking distance ‘brake dist.’. The measurement is triggered
via a freely configurable minimum deceleration value (see basic settings). The
minimum deceleration is needed to prevent the braking measurement from being
triggered when the rider simply releases the throttle.
During the measurement, ‘calc.’ appears on the display. The measurement result
is displayed in the format xx m/s² for the braking coefficient and in xx m for the
braking distance. The speed range in which the measurement took place is also
displayed.
This provides you with information about your braking behavior so that you can
optimize it.
Note
Do not use this function when riding on standard roads, only on special sites (e.g.
motorcyclist training centers).
5.9 Drag race/quarter-mile race
The MC 1812 has a drag race function. The measurement begins from a
standing start. During the measurement, ‘calc.’ appears on the display. On
reaching a distance of quarter of a mile, the measurement stops and the result is
displayed in the format xx.x sec.
Note
Do not use this function when riding on standard roads, only on special sites (e.g.
motorcyclist training centers).

General functions
Reset functions
www.sigmasport.com MC 1812 Page 20
MC 1812
6 Reset functions
6.1 General functions
The general functions such as:
-Trip distance
-Trip time
-Avg. speed
-Max. speed
-Acceleration measurement
-Highway acceleration measurement
-Braking coefficient measurement
-Braking distance
-Drag racing
are reset (zeroed) by pressing the Reset button. Each function must be reset
individually.
6.2 Mode 2 functions
The Mode 2 functions
-Total time
-Total distance
can only be reset in setting mode.
