1Ryle Pressure Balance Shower Valve Installation Instructions
RYLE PRESSURE BALANCE SHOWER VALVE
INSTALLATION INSTRUCTIONS
Before you begin, read the installation instructions below. Observe all local building and safety codes.
Unpack and inspect the product for any shipping damages. If you nd damages, do not install. Contact Customer
Service at 1.866.855.2284. If you need assistance or have questions while installing your shower valve, contact
Customer Service.
We recommend consulting a professional if you are unfamiliar with installing bathroom xtures, and plumbing.
Signature Hardware accepts no liability for any damage to the plumbing or wall, or for personal injury during
installation.
TOOLS AND MATERIALS:
INSTALLATION
Screwdriver
1. Install the valve body. Wrap the threaded portion
of the joints in Teon tape and connect the water
inlet and outlet.
2. Put the protective cover on the valve body and
nish the shower wall.
3. When the nished wall is complete, remove
the protective cover.
4. Install the escutcheon, and handle. Tighten the set
screw with an Allen wrench to secure.

2Ryle Pressure Balance Shower Valve Installation Instructions
1 SD10101000200
2 M0105004
3 SD15617000100
4 SD10117000400
5 SD10117000500
6 SD15619000300
7 OXQ50030
8 FX0402
9 SD10117000600
10 SD10119000800-1
11 SD10119000700-1
12 M0305022
13 SD10119000900
14 M0805032
15 SD10119001000
16 SD10119001100
17 M110405
PARTS LIST:
