Signature UPRM3010 series User manual

MFL07529605
OWNER’S MANUAL
MICROWAVE OVEN
Read this owner’s manual thoroughly before operating the appliance
and keep it handy for reference at all times.
www.thesignaturekitchen.com
UPRM3010**

2TABLE OF CONTENTS
TABLE OF CONTENTS
3IMPORTANT SAFETY
INSTRUCTIONS
6PRODUCT OVERVIEW
6 Parts
6 Accessories
7INSTALLATION
7 Product Specifications
8 Installation Requirements
9OPERATION
9 Control Panel Overview
11 Cookware Guide
12 Microwave Cooking Tips
13 Cleaning
13 Clock
13 Kitchen Timer
14 Child Lock
14 Add 30sec.
14 Using Sensor Touch
14 Sensor Cooking
15 Sensor Touch Table
15 Sensor Touch Reheat
16 Sensor Touch Popcorn
16 Custom Set
17 Auto Cook
18 More / Less
18 Auto Defrost
19 Express Defrost
19 Multi-Stage Cooking
20 Soften
20 Melt
21 Time Cook
21 Microwave Power Levels
22 Cooking Tips
22 Meat
-Meat Cooking Table
22 Poultry
-Poultry Cooking Table
23 Fish
-Fresh Fish Cooking Table
24 TROUBLESHOOTING
24 Questions and Answers
26 Before Calling for Service
27 WARRANTY

3
IMPORTANT SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all instructions when using the range to prevent the risk of fire, electric
shock, personal injury, or damage. This guide does not cover all possible conditions that
may occur. Always contact your service agent or manufacturer about problems that you do
not understand.
Download this owner's manual at: www.thesignaturekitchen.com
This is the safety alert symbol. This symbol alerts you to potential hazards that
can result in property damage and/or serious bodily harm or death.
All safety messages will follow the safety alert symbol and either the word
WARNING or CAUTION. These words mean:
WARNING -Indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION - Indicates a hazardous situation which, if not avoided, could result
in minor or moderate injury.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
•Do not attempt to operate this oven with the door open, since open-door operation
can result in harmful exposure to microwave energy. It is important not to defeat or tamper
with the safety interlocks.
•Do not place any object between the oven front face and the door, or allow soil or
cleaner residue to accumulate on sealing surfaces.
•Do not operate the oven if it is damaged. It is particularly important that the oven door
close properly and that there is no damage to the:
- door (bent),
- hinges and latches (broken or loosened),
- door seals and sealing surfaces.
•The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
GROUNDING INSTRUCTIONS
•This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance
is equipped with a cord having a grounding wire and a grounding
plug. The plug must be plugged into an outlet that is properly
installed and grounded. Ensure proper ground
exists before use
WARNING
•This product contains chemicals known to the
State of California to cause cancer and birth
defects or other reproductive harm. Wash
hands after handling.

4IMPORTANT SAFETY INSTRUCTIONS
WARNING
Improper grounding can result in a risk of electric shock. Consult a qualified electrician
if the grounding instructions are not completely understood, or if doubt exists as to
whether the appliance is properly grounded, and either:
•If it is necessary to use an extension cord,use only a 3-wire extension cord that has
a 3-blade grounding plug, and a 3-slot receptacle that will accept the plug on the
appliance. The marked rating of the extension cord shall be equal to or greater than the
electrical rating of the appliance, or...
•Do not use an extension cord. If the power supply cord is too short, have a qualified
electrician install an outlet near the appliance.
•A short power-supply cord is provided to reduce the risks resulting from becoming
entangled in or tripping over a longer cord.
•Longer cord sets or extension cords are available and may be used if care is exercised in
their use.
•If a long cord or extension cord is used, (1) the marked electrical rating of the cord set or
extension cord should be at least as great as the electrical rating of the appliance, (2) the
extension cord must be a grounding-type 3-wire cord, and (3) the longer cord should be
arranged so that it will not drape over the countertop or tabletop where it can be pulled on
by children or tripped over accidentally.
WARNING
•Read all instructions before using the appliance.
•Read and follow the specific PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY found on page 3 of this manual.
•This appliance must be grounded. Connect only to properly grounded outlet. See
GROUNDING INSTRUCTIONS found on page 3 of this manual .
•Install or locate this appliance only in accordance with the provided installation
instructions.
•Some products, such as whole eggs and sealed containers – for example, closed glass
jars are able to explode and should not be heated in this oven.
•Use this appliance only for its intended use as described in the manual. Do not use
corrosive chemicals or vapors in this appliance. This type of oven is specifically
designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.
•As with any appliance, close supervision is necessary when used by children.
•Do not operate this appliance if it has a damaged cord or plug, if it is not working
properly, or if it has been damaged or dropped.
•This appliance should be serviced only by qualified service personnel. Contact the
nearest authorized service facility for examination, repair, or adjustment.
•Do not cover or block any openings on the appliance.
•Do not store this appliance outdoors. Do not use this product near water – for example,
near a kitchen sink, in a wet basement, near a swimming pool, or similar location.
•Do not immerse cord or plug in water.
•Keep cord away from heated surfaces.
•Do not let cord hang over the edge of a table or counter.
•When cleaning surfaces of door and oven that come together on closing the door, use
only mild, nonabrasive soaps or detergents applied with a sponge or soft cloth.

5
IMPORTANT SAFETY INSTRUCTIONS
WARNING
•To reduce the risk of fire in the oven cavity:
– Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
– Remove wire twist-ties from paper or plastic bags before placing bag in oven.
– If materials inside the oven ignite, KEEP OVEN DOOR CLOSED, turn oven off, and
disconnect the power cord or shut off power at the fuse or circuit breaker panel.
– Do not use the cavity for storage purposes. Do not leave paper products, cooking
utensils, or food in the cavity when not in use.
•Liquids such as water, coffee, or tea are able to be overheated beyond the boiling
point without appearing to be boiling. Visible bubbling or boiling when the container
is removed from the microwave oven is not always present. THIS COULD RESULT
IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS
DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.
To reduce the risk of injury to persons; 1) Do not overheat the liquid. 2) Stir the liquid
both before and halfway through heating it. 3) Do not use straight-sided containers with
narrow necks. 4) After heating, allow the container to stand in the microwave oven for a
short time before removing the container. 5) Use extreme care when inserting a spoon
or other utensil into the container.
•Avoid heating small-necked containers such as syrup bottles.
•Avoid using corrosive and vapors, such as sulfide and chloride.
•Liquids heated in certain shaped containers (especially cylindrical-shaped containers)
may become overheated. The liquid may splash out with a loud noise during or after
heating or when adding ingredients (instant coffee, etc.), resulting in harm to the oven
and possible injury. In all containers, for best results, stir the liquid several times before
heating. Always stir liquid several times between reheatings.
SAVE THESE INSTRUCTIONS
Thank you for purchasing a
SIGNATURE KITCHEN SUITE microwave oven.
Please record the model number and serial Model No:
number of this unit for future reference. We also Serial No:
suggest you record the details of your contact with
SIGNATURE KITCHEN SUITE concerning this Dealer:
unit.
Dealer Phone No:
Staple your receipt here to prove your retail Customer Relations
purchase. SIGNATURE KITCHEN SUITE U.S.A., Inc.
Service Division Bldg. #3
201 James Record Rd.
Huntsville, AL 35824-0126

6PRODUCT OVERVIEW
PRODUCT OVERVIEW
Parts
Door Seal
Window
Safety Door Lock System
Door Open Button
Control Panel
Display Window
Oven Front Plate
Accessories
Turntable Rotating ring Owner's Manual
NOTE
•This microwave oven is designed for household use only. It is not recommended for commercial use.
WARNING
•Do not operate the oven when empty or without the glass tray. It is best to leave a glass water in the oven
when not in use. The water will safely absorb all microwave energy, if the oven is accidentally started.

7
INSTALLATION
INSTALLATION
Product Specifications
Model UPRM3010**
Power Supply 120 V AC, 60 Hz
Rated Power Consumption 1650 W
Microwave Output *1200 W
Frequency 2450 MHz
Rated Current 14.0 A
Overall Dimensions 23
7
/
8
"(W) x 13
9
/
16
"(H) x 19
13
/
16
"(D) (60.6 cm x 34.4 cm x 50.3 cm)
Oven Cavity Dimensions 16
11
/
16
"(W) x 11
1
/
4
"(H) x 18
1
/
16
"(D) (42.4 cm x 28.6 cm x 45.9 cm)
Capacity of Oven Cavity 2.0 Cu.ft. (0.057 m³)
*IEC 60705 RATING STANDARD
Specifications subject to change without prior notice.

8INSTALLATION
Installation Requirements
Circuits
For safety purposes this oven must be plugged into
a 15 or 20 Amp circuit. No other electrical appliances
or lighting circuits should be on this line. If in doubt,
consult a licensed electrician.
Voltage Warning
The voltage used at the wall receptacle must be the
same as specified on the oven name plate located
on the back or on the side of the control panel of the
oven. Use of a higher voltage is dangerous and may
result in a fire or damage to the oven. Low voltage will
Placement of the Oven
Place the oven on a flat surface such as a kitchen
countertop or a specially designed microwave oven
cart. Do not place oven above a gas or electric range.
Free air flow around the oven is important. Allow at
least 4 inches of space at the top, sides, and back of
the oven for proper ventilation.
Air Vents
Radio Interference
•Microwave oven operation may interfere with TV or
radio reception.
•When there is interference, it may be reduced or
eliminated by taking the following measures:
– Clean the door and the sealing surfaces of the
oven.
– Reorient the receiving antenna of radio or
television.
– Relocate the microwave oven in relation to the
TV or radio.
– Move the microwave oven away from the
receiver.
– Plug the microwave oven into a different outlet so
that microwave oven and receiver are on different
branch circuits.
cause slow cooking.If the oven is cooking slowly despite
use of proper voltage, unplug it and check the plug and
cord for damage.
Do not block air vents while the oven is operating.
Blocked air vents could cause the oven to overheat,
tripping a safety device which automatically turns the
oven off. You will not be able to use the oven until it
has cooled sufficiently.

9
OPERATION
OPERATION
Control Panel Overview
1
2
3
7
12
17
14
15
6
10
13
18
16
4
8
5
9
11
30sec.

10 OPERATION
NOTE
•The display turns off after being idle for about 5 minutes. (Exact time may vary by model.)
1
Display
2
Sensor Touch
3
Custom Set
Change settings for sound (on/off), clock (on/off),
scroll speed (slow/normal/fast), and units (lb./kg).
4
Auto Cook
Select preprogrammed cook settings for common
food items.
5
Less
6
More
7
Auto Defrost
Preprogrammed defrosting for meat, poultry and
fish up to 6.0 lbs or 4.0 kg.
8
Express Defrost
Quickly defrost 1 lb. of food.
9
Soften
10
Melt
Melt butter, margarine, chocolate, cheese, or
marshmallows.
11
Number Pads
Enter the cooking time, power level, quantities, or
weights.
12
Time Cook
Set the desired cooking time.
13
Power Level
Set the desired cooking power.
14
Kitchen Timer
Use the microwave oven as a kitchen timer.
15
Clock
Set the time of day.
16
Add 30sec.
17
Start / Enter
18
Stop / Clear
Touch to stop cooking or clear settings.
The display indicates the time of day, set cooking
time, and selected cooking functions.
Cook some of your favorite foods without having
to select cooking times and power levels.
Subtract ten seconds from the cooking time with
each touch of this button.
Add ten seconds of cooking time with each touch
of this button.
Soften butter, ice cream, cream cheese, or frozen
juice.
Cook at 100% cook power for 30 seconds.
Each touch adds 30 seconds up to 3 minutes
30 seconds, after which each touch adds 1
minute up to 99 minutes 59 seconds.
Touch to start cooking or enter settings.
Press and hold to turn Child Lock on/off.
