Signet 8350-1 User manual

CAUTION!
• Remove power to unit before wiring input and output connections.
• Follow instructions carefully to avoid personal injury.
Signet 8350-1 Temperature Transmitter
2. Installation
• ProcessPro transmitters are available in two styles: panel mount and field mount. The panel mount is supplied with the necessary
hardware to install the transmitter. This manual includes complete panel mounting instructions.
• Field mounting requires one of two separate mounting kits. The 3-8052 integral kit joins the sensor and instrument together into a
single package. The 3-8050 Universal kit enables the transmitter to be installed virtually anywhere.
• Detailed instructions for integral mounting or other field installation options are included with the 3-8052 Integral kit or the 3-8050
Universal kit.
1. Specifications
General
Compatibility: Signet 2350 Temperature sensors
System accuracy: ±0.5 ºC with 2350 sensors
Enclosure:
• Case: PBT
• Panel case gasket: Neoprene
• Window: Polyurethane coated polycarbonate
• Keypad: Sealed 4-key silicone rubber
• Weight: Approx. 325 g (12 oz.)
Display:
• Alphanumeric 2 x 16 LCD
• Display update rate: 1 second
• Contrast: User selected, 5 levels
Electrical
Power: 12 to 24 VDC ±10% regulated,
21 mA max current
Current output: 4 to 20 mA, isolated, fully adjustable
and reversible
Max loop impedance: 50 Ωmax. @ 12V
325 Ωmax. @ 18V
600 Ωmax. @ 24V
• Update rate: 200 ms
• Output accuracy: ±0.03 mA
Open-collector output:
• Optically isolated, 50 mA max. sink
• 30 VDC maximum pull-up voltage.
• Programmable for:
• High, Low with adjustable hysteresis
• Pulse operation (maximum pulse rate: 400 pulses/min).
Environmental
• Operating temperature: -10 to 70 °C (14 to 158 °F)
• Storage temperature: -15 to 80 °C (5 to 176 °F)
• Relative humidity: 0 to 95%, non-condensing
• Maximum altitude: 2000 m (6562 ft)
• Insulation category: II
• Pollution degree: 2
• Rating: NEMA 4X/IP65 front
Standards and Approvals:
• CE, UL listed
• Immunity: EN50082-2
• Emissions: EN55011 Class B
• Manufactured under ISO 9001 and ISO 14001
Contents
1. Specifications
2. Installation
3. Electrical Connections
4. Menu Functions
*3-8350.090-1*
3-8350.090-1 Rev. H 01/12 English
Temperature
27.9 ºC
ENTER
Signet Temperature
Transmitter
English
92 mm
(3.6 in.)
97 mm
(3.8 in.)
56 mm
(2.2 in.)
41 mm
(1.6 in.)
Optional
Rear
Cover
96 mm
(3.8 in.)
96 mm
(3.8 in.)
106 mm
(4.18 in.)
82 mm
(3.23 in.)
SIDE VIEW
Field Mount w/
8052 Inte
g
ral kit
107 mm
(4.2 in.)
96 mm
(3.8 in.)
Panel Mount
SIDE VIEW
FRONT VIEW
Field Mount &
Panel Mount
SIDE VIEW
Field Mount w/
8050 Universal base
• China RoHS (Go to www.gfsignet.com for details)

28350-1 Temperature Transmitter
2
14
3
7
6
5
Output -
Output +
System Pwr
Loop -
System Pwr
Loop + Sensr Gnd
(WHITE)
Sensr IN
(RED)
Sensr V+
(BLACK)
Terminals 3 and 4: Open-Collector Output
• Transistor output, programmable (see CALIBRATE menu) as
High or Low setpoint with adjustable hysteresis.
• May be disabled (Off) if not used.
Terminals 5-7: Digital sensor input
See Wiring Tips for more information.
Terminals 1 and 2: System Loop Power
12-24 VDC ±10% system power and current loop output.
Max. loop impedance:
50 Ωmax. @ 12 V
325 Ωmax. @ 18 V
600 Ωmax. @ 24 V
15
S
D
Internal open-collector
output circuit
Output --
Output +
Isolation
2.1. Panel Installation
1. The panel mount transmitter is designed for installation using a 1/4 DIN Punch. For manual
panel cutout, an adhesive template is provided as an installation guide. The cutout must be
92 mm x 92 mm. Recommended clearance on all sides between instruments is 25 mm/1 in.
2. Slide the instrument into the cutout from the front of the panel.
3. Slide the mounting bracket over back of instrument until quick-clips snap into latches on
side of instrument.
4. To remove, secure instrument temporarily with tape from front or grip from rear of
instrument. DO NOT RELEASE.
Press quick-clips outward and remove.
Output -
Output +
System Pwr
Loop -
System Pwr
Loop +
2
14
3
Sensr Gnd
(SHIELD)
Sensr IN
(RED)
Sensr V+
(BLACK)
7
6
5
quick-clips
gasket panel
terminals mounting
bracket
latch
Panel Mount
Installation Detail
3. Electrical Connections
Caution: Failure to fully open terminal jaws before removing wire may permanently damage instrument.
Wiring Procedure
1. Remove 0.5 - 0.625 in. (13-16 mm) of insulation from wire end.
2. Press the orange terminal lever downward with a small screwdriver to open terminal jaws.
3. Insert exposed (non-insulated) wire end in terminal hole until it bottoms out.
4. Release orange terminal lever to secure wire in place. Gently pull on each wire to ensure a good connection.
Wiring Removal Procedure
1. Press the orange terminal lever downward with a small screwdriver to open terminal jaws.
2. When fully open, remove wire from terminal.
Wiring Tips:
• Do not route sensor cable in conduit containing AC power wiring. Electrical noise may interfere with sensor signal.
• Routing sensor cable in grounded metal conduit will help prevent electrical noise and mechanical damage.
• Seal cable entry points to prevent moisture damage.
• Only one wire should be inserted into a terminal. Splice double wires outside the terminal.
• The cable length from the sensor to the transmitter must not exceed 400 ft (122 m).
• For best performance, ground the sensor SHIELD wire to a local earth ground at a point near the sensor.
2
1

8350-1 Temperature Transmitter 3
-
+
2
1
2
1
-
+
+
-
+
-
-
+
+
-
+
-
-
+
4
3
4
3
4
3
4
3
2
1
2
1
2
1
2
1
System Pwr Loop -
System Pwr Loop +
System Pwr Loop -
System Pwr Loop +
System Pwr Loop -
System Pwr Loop +
System Pwr Loop -
System Pwr Loop +
System Pwr Loop -
System Pwr Loop +
Loop Input
4-20 mA
Channel 1
4-20 mA in
Channel 2
4-20 mA in
Loop Input
4-20 mA
Transmitter
Terminals
Power
Supply
12-24 VDC
Internal
PLC
Connection
PLC or Recorder
Power
Supply
12-24 VDC
PLC or Recorder
PLC Terminals
Power
Supply
12-24 VDC
Power
Supply
12-24 VDC
Stand-alone application, no current loop used
Connection to a PLC with built-in power supply Connection to a PLC/Recorder, separate supply
Example: Two transmitters connected to PLC/Recorder with separate power supply
Transmitter
Terminals
Transmitter 1
Terminals Transmitter 2 Terminals
Transmitter
Terminals
7
6
5
TerminalsWhite (Gnd)
Red (IN)
Black (V+)
Signet 2350
Temperature
Sensors
3.2 System Power/Loop Connections
3.1 Sensor Input Connections
Temperature
27.9 ºC
ENTER
Signet Temperature
Transmitter
Transmitter
400 ft. (122 m)

48350-1 Temperature Transmitter
Temperature
27.9 ºC
ENTER
Signet Temperature
Transmitter
• During normal operation, ProcessPro displays the VIEW menu.
• When editing CALIBRATE or OPTIONS menus, ProcessPro returns to the VIEW menu if no activity occurs for
10 minutes.
• To select a VIEW display, press the ▲or ▼keys. The selections will scroll in a continuous loop.
• Changing the display selection does not interrupt system operations.
• No key code is necessary to change display selection.
• Output settings cannot be edited from the VIEW menu.
• Proportional Pulsing
The Open Collector output will generate a 100 mS pulse at the
rate defined by settings in the CALIBRATE menu (see page 6).
In the example below:
• The output will be 0 pulses/min. at temperatures less than 5º.
• The output will be 50 pulses/min. at 7.5º.
• The output will be 100 pulses/min. at temperatures above 10º.
The starting point, endpoint and maximum pulse rate are
selectable in the menu.
Hysteresis
Time
Low Setpoint
Process
Relay energized
Relay de-energized
Hysteresis
Time
High Setpoint
Process
10
5
Open Collector Output Rate:
0 to 100 Pulses/min.
endpoint
Pulse rate
0 pulses
100 pulses
Starting point
View Menu
3.3 Open Collector Output
The Open Collector output can be used as a switch that responds
when the process value moves above or below a setpoint, or it
can be used to generate a pulsing signal with a rate proportional
to the process value. The output can be disabled when not in use.
• Low:
Output energizes when process variable is less than the setpoint.
The output de-energizes when the process variable moves above
the setpoint plus the hysteresis value.
• High:
Output energizes when process variable is greater than the
setpoint. The output de-energizes when the process variable
moves below the setpoint plus the hysteresis value.
Display Description
Temperature:
27.9 °C
Monitor the temperature input from the sensor.
This is the permanent display.
The displays below are temporary. After 10 minutes the display returns to the permanent display.
Loop Output:
12.00 mA Monitor the 4 to 20 mA Loop output.
Last CAL:
02-10-09
Monitor date for scheduled maintenance or date of last calibration.
(See description in Calibrate Menu.)
4. Menu Functions

8350-1 Temperature Transmitter 5
Output Setpnt:
2 0.00 °C
Output Setpnt:
1 0.00 °C
ENTER
Output Setpnt:
1
0 .00
°C
Output Setpnt:
1
9
.00 °C
Output Setpnt:
Saving
Output Setpnt:
19.00 °C >
Notes on Steps 5 and 6:
• All output functions remain active during editing.
• Only the flashing element can be edited.
• ►key advances the flashing element in a continuous loop.
• Edited value is effective immediately after pressing ENTER key.
• If no key is pressed for 10 minutes unit will restore the last saved value and return to step 3.
• Step 6 (pressing ENTER key) always returns you to Step 3.
• Repeat steps 3-6 until all editing is completed.
Notes on Step 2:
If no key is pressed for 5 minutes while display is showing "Enter
Key Code", the display will return to the VIEW menu.
Notes on Steps 3 and 4:
• Refer to pages 6 and 7 for complete listing of menu items and their use.
• From the Step 3 display, pressing the ▲and ▼keys simultaneously will return
the display to the VIEW menu.
• If no key is pressed for 10 minutes, display will also return to the VIEW menu.
ProcessPro Editing Procedure:
Step 1. Press and hold ENTER:
• 2 seconds to select the CALIBRATE menu
• 5 seconds to select the OPTIONS menu.
Step 2. The Key Code is ▲-▲-▲-▼keys in sequence.
• After entering the Key Code, the display will show the first item in the selected menu.
Step 3. Scroll menu with ▲or ▼arrow keys.
Step 4. Press ►to select menu item to be edited.
• The first display element will begin flashing.
Step 5. Press ▲or ▼keys to edit the flashing element.
•►advances the flashing element.
Step 6. Press ENTER to save the new setting and return to Step 3.
2s 5s
ENTER
OPTIONS
CALIBRATE
VIEW
Press &
hold for
access:
Step 5
Step 6
Notes on Step 1:
• The View Menu is normally displayed.
• The CALIBRATE and OPTIONS menus require a KEY CODE.
Step 4
First item in
CALIBRATE menu
Step 3
Step 3: Finished Editing?
Press the ▲and ▼keys simultaneously after saving
the last setting to return to normal operation.
Press the ▲and ▼keys simultaneously while
any element is flashing. This will recall the last
saved value of the item being edited and return
you to Step 3.
Step 5: Made an Error?
CALIBRATE: ----
Enter Key Code
CALIBRATE: *---
Enter Key Code
CALIBRATE: **--
Enter Key Code
CALIBRATE: ***-
Enter Key Code
°C >
Temp Units:
20.0 °C >
Output Setpnt:
°C >
Temp Units:

68350-1 Temperature Transmitter
Calibrate Menu
Display
(Factory settings shown) Description
Temp Units:
°C > Select Temperature units: °C or °F.
Set:
Temperature
Provides a maximum 20 °C offset to match 8350 to external reference.
Enter “-999” to restore the original Factory calibration value.
Changes to this setting will become effective when the display exits the Calibrate menu.
Loop Range: °C
0.0 →100.0 >
Check the 2350 Sensor instructions for the range capability of your sensor.
Be sure to modify this setting if you change the Temperature Units.
Output Mode:
Low >
Select the desired mode of operation for the Open Collector output. Options available are Off,
Low, High or Pulse. The signal may be disabled (Off) if not used.
Output Setpnt:
25.0 °C >
In Low or High Mode, the Open Collector output will be activated when the temperature
reaches this value. Be sure to modify this setting if you change the Temperature Units.
Output Hys:
°C >
The Open Collector output will be de-energized at Setpoint ± Hysteresis, depending on High
or Low Setpoint selection.
Output Range:
25.0-45.0 >
If the output is in PULSE mode, set the start and end point of the range and also set the
maximum pulse rate. (The maximum PULSE rate setting is 400 pulses per minute.)
The combined Output Range and Pulse rate settings shown here indicate:
"Start pulsing when the process value is 25° and increase the pulse rate up to the maximum
of 120 pulses per minute when the process value reaches 45°"
Output PlsRate:
120 Pulses/Min >
Last CAL:
2-10-09
Use this “note pad” to record important dates, such as annual recertification or scheduled
maintenance.

8350-1 Temperature Transmitter 7
Options Menu
Display
(Factory settings shown) Description
Contrast:
3 >
Adjust the LCD contrast for best viewing. A setting of 1 is lowest contrast, 5 is highest. Select
lower contrast if the display is in warmer ambient surroundings.
Averaging
Off >
OFF provides the quickest output response to changes in temperature. Longer averaging
period produces more stable display and output response.
Output Active
Low >
Active HIGH: This setting is used to turn a device (pump, valve) ON at the setpoint.
Active LOW: This setting is used to turn a device OFF at the setpoint.
Loop Adjust
4.00 mA >
Adjust the minimum and maximum current output. Use this setting to match the system output
to any external device. The display value represents the precise current output.
Adjustment limits:
• 3.80 mA < 4.00 mA > 5.00 mA
• 19.00 mA < 20.00 mA > 21.00 mA
Loop Adjust
20.00 mA >
Test Loop:
>
Press ▲or ▼keys to manually order any output current value from 3.6 mA to
21.00 mA to test current loop output.
Test Output:
>
Press ▲or ▼keys to manually toggle the state of open collector output.

Troubleshooting
Georg Fischer Signet LLC, 3401 Aerojet Avenue, El Monte, CA 91731-2882 U.S.A. • Tel. [phone] • Fax [phone]
For Worldwide Sales and Service, visit our website: www.gfsignet.com • Or call (in the U.S.): [phone]
For the most up-to-date information, please refer to our website at www.gfsignet.com
3-8350.090-1 Rev. H 01/12 English © Georg Fischer Signet LLC 2012
Ordering Information
Mfr. Part No. Code Description
3-8350-1 159 000 192 Temperature transmitter Field mount
3-8350-1P 159 000 193 Temperature transmitter Panel mount
3-8350-2 159 000 194 Temperature transmitter Field mount with relays
3-8350-2P 159 000 195 Temperature transmitter Panel mount with relays
3-8350-3 159 000 196 Temperature transmitter Field mount with dual input/output
3-8350-3P 159 000 197 Temperature transmitter Panel mount with dual input/output
Accessories
Mfr. Part No. Code Description
3-8050 159 000 184 Universal mounting kit
3-8052 159 000 188 3/4” Integral mounting kit
3-8052-1 159 000 755 3/4" NPT mount junction box
3-8050.395 159 000 186 Splashproof rear cover
3-8050.396 159 000 617 RC Filter kit (for relay use)
3-0000.596 159 000 641 Heavy duty wall mount bracket
3-5000.598 198 840 225 Surface Mount Bracket
3-9000.392 159 000 368 Liquid tight connector kit for rear cover (includes 3 connectors)
3-9000.392-1 159 000 839 Liquid tight connector kit, NPT (1 piece)
3-9000.392-2 159 000 841 Liquid tight connector kit, PG13.5 (1 piece)
3-9900.396 159 001 701 Angle Adjustment Adapter Kit
Display Condition Possible Causes Suggested Solutions
Check Sensor?
• Sensor not wired properly.
• Sensor connected to 8350 while power
is on.
• Defective sensor.
• Correct sensor wiring.
• Recycle power with all sensors connected.
• Replace defective sensor.
Too much error
CHECK SENSOR
The value entered in Set Temperature
field is greater than 20 °C (36 °F)
deviation from sensor input. (The 8350
allows a maximum of 20 °C offset.).
• Confirm calibration values.
• Replace defective sensor.
Reset to Factory
Calibration
Value in SET TEMPERATURE field
is -999.
Entering "-999" in this field will remove all user
calibration input and restore the factory values.
Open Collector is always
activated
• Hysteresis value too large.
• Defective transmitter.
• Change the hysteresis value
• Replace transmitter
Value must be
400 or less
Value entered in Output PlsRate field is
greater than 400.
Select a maximum pulse rate of 400 pulses per
minute or less.
