Model ST-18
Headset Instructions
The ST-18 series headset is adjusted at the factory for immediate use. The headset
is equipped with a single plug and a coiled cord.
The headband is adjustable through a full range of motion, and the locking nuts
may be tightened to allow you to custom t the headphone. Place the headphone
over your head and adjust the slides up until minimum pressure is felt on the top
of your head. For maximum noise attenuation, the clamping pressure of the head-
band has been set at the factory. Releasing the clamping pressure by bending the
headband is not advised, because loss of attenuation will result.
The microphone boom is fully adjustable and will rotate 180 degrees for use on
the left or right side of the head.
Make sure you are speaking into the side of the mic labeled “Talk” or substantial
loss of gain will occur. Microphone placement should be at the corner of the
mouth, approximately ¼” from the lips.
When you rst connect the headset, turn the volume control on the headset up
to the full clockwise position, then adjust the listening volume with the audio
control of either your radio or intercom as appropriate. If applicable, crew mem-
bers should also turn their individual headset volumes up fully. Doing this allows
for a full range of adjustment for each passenger, since those with the most acute
hearing can turn their headset volume down, if necessary.
continued on back…
The headset parts may be cleaned with mild soap and water using a soft cloth.
Then dry immediately. Caution: Do Not immerse any part of the headset in water
or any other liquid. Be especially careful not to allow the microphone to become
wet! Exposure to moisture may cause internal corrosion and failure and will void
your manufacturers warranty.
Cleaning will help the headset maintain its “like new” condition for many years.
WINDSCREEN
The microphone windscreen will reduce annoying wind noise and breath pops
picked up by headset microphones. It also protects the microphone element
from dirt and moisture. The windscreen should be washed regularly to maintain
hygiene and avoid clogging. Wash in warm water and mild soap. Rinse thoroughly
and make sure it is completely dry before putting it back on.
To remove the windscreen, carefully grasp the windscreen lightly along its entire
length and remove from the microphone element being careful not to twist the
element itself.
Put the windscreen on the microphone by gently pulling from the open end. Do
not pull it so tightly that it stretches against the end of the microphone.
WARRANTY
Your headset is covered by a limited two-year parts and labor warranty. Please see
the enclosed warranty card for details.
You may refer to the parts list on the reverse side, if you choose to replace parts
yourself. The parts list describes parts for this particular headset only. Parts lists
for other models are available on our Web Site or can be obtained by contacting
Sigtronics Corporation.
Sigtronics Corporation
178 East Arrow Highway
San Dimas, CA 91773
Phone: [phone]
E-mail: [e-mail]
Web Site: www.sigtronics.com









 




 
















SIGTRONICS ST-18 HEADSET PARTS IDENTIFICATION BREAKDOWN
ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION ITEM P/N DESCRIPTION
1800192 PREAMP 12 100744 SCREW, 8-32 X 3/8, PHILLIPS HEAD, BLACK 23 100379 FOAM, SOUND ATTENUATING, RECEIVER COVER, 1/4 INCH
2100769 KNOB, 1/2 INCH, BLACK, VOLUME, TACTICAL 13 100597 NUT, HEX, 3/8-24, FLEX BOOM ADAPTER 24 100258 CLIP, HEADBAND GUIDE, PLASTIC
3100077 POTENTIOMETER 14 100603 YOKE, EAR CUP MOUNT, METAL, BLACK 25 100393 CLIP, ANTI-ROTATION, YOKE, PLASTIC
4100858 RECEIVER AND MOUNT, 300 OHM, MONO 15 100604 BRACKET, YOKE SUPPORT WITH TANG, BLACK 26 100613 HEADBAND, METAL, LARGE, BLACK
5100108 SCREW, 4-40 X 1/4, THREAD FORMING 16 100369 EAR SEAL, FOAM FILLED 27 800035 CABLE, HEADSET, STEREO, COILED
6800193 MICROPHONE & FLEX BOOM ASSEMBLY 17 800223 HEADPAD ASSEMBLY, SIDE, WITH CUSHION, ST-18 28 100612 O-RING, WINDSCREEN RETAINER, ST-18
7100743 E-RING, EAR CUP TO YOKE RETAINER, BLACK 18 800222 HEADPAD WITH CUSHION, TOP, ST-18 29 90 0111 WINDSCREEN, MICROPHONE, FOAM, PACKAGED
8100742 NUT, HEX, 8-32, LOCKING, BLACK 19 100373 SLIDE, YOKE BRACKET, LONG, NYLON 30 10 0611 WINDSCREEN, MICROPHONE, FOAM, BULK
9100770 EAR CUP, BLACK, PRINTED AND DRILLED 20 100374 FOAM, SOUND ATTENUATING. NOTCHED, 1/2 INCH 31 100402 OPTIONAL – EAR SEAL, GEL FILLED
10 100221 WIRE, #22, 19 STRAND, 4 INCH 21 100376 FOAM, SOUND ATTENUATING. RECEIVER HOLE, 1/2 INCH
11 100745 SCREW, 8-32 X 1/2, PHILLIPS HEAD, BLACK 22 100568 STRAIN RELIEF, CABLE
