SIIG CE-H20111-S1 User manual

1
IntroducingtheHDMIoverCAT5eReceiver
The HDMI over CAT5e Receiver provides a cost effective
solution by which high definition video and high quality
audio can be transmitted to different locations over long
distances using inexpensive CAT5e/6 cable.
FeaturesandBenefits
• HDMI 1.2a compliant and HDCP compatible
• Regenerates HDMI signal
• Receives signals from a tranmitter or transceiver,
then connects to an HDMI display
• Works with all transmitters & transceivers
TechnicalSpecifications
• Data rate: 1.65Gbps (max)
• Input: 1x RJ45
• Output: 1x HDMI (19-pin male)
• Supports distances up to 60m/200ft @ 720p/1080i
or 40m/130ft @ 1080p with CAT5e cable
PackageContents
•HDMI over CAT5e Receiver
• Power adapter (5V DC)
• Quick Installation Guide
04-0503A
HDMI over CAT5e Receiver
Quick Installation Guide

2
• EQ: adjusts the equilization of the received signal
from 0 (strongest) to 7 (weakest). It is recommended
to try each setting, from 0 to 7, to find the optimal
visual experience
• HDMI out: connects to your HDMI enabled display
with an HDMI M-M cable (not included)
• RJ45 In: connects to your transmitter/transceiver
via CAT5e cable (not included)
• LED: the LEDs will be on when the unit is powered
up
• Power Jack: connect the power supply here
Hardware Installation
1. Turn the power off to your HDMI display.
2. ConnectyourHDMIdisplay tothe HDMI Out ofthe
HDMI over CAT5e Receiver.
3. Connect your CAT5e cable from a transmitter/
transceiver to the RJ45 In.
4. Plug the power adapter into the HDMI over CAT5e
Receiver then plug the power supply into a reliable
power source.
5. Power on your HDMI display.
Layout
RJ45 InHDMI Out
LED
Figure 1: Front Panel Figure 2: Back Panel
EQ Power Jack

3
Technical Support and Warranty
QUESTIONS? SIIG’sOnline Support has answers! Simplyvisit our
web site at www.siig.com and click Support. Our online support
database is updated daily with new drivers and solutions. Answers
toyour questionscould bejust afew clicks away. You can alsosubmit
questions online and a technical support analysts will promptly
respond.
SIIGoffers a 2-year manufacturer warrantywith thisproduct. Please
see our web site for more warranty details. If you encounter any
problems with this product, please follow the procedures below.
A) If it is within the store's return policy period, please return the
product to the store where you purchased from.
B) Ifyour purchasehas passedthe store'sreturn policyperiod, please
follow these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a
request to SIIG RMA. If the product is determined to be
defective, an RMA number will be issued.
Step 2: After obtaining an RMA number, ship the product.
•Properly pack the product for shipping. All software, cable(s)
and any other accessories that came with the original package
must be included.
•Clearly write your RMA number on the top of the returned
package. SIIG will refuse to accept any shipping package, and
will not be responsible for a product returned without an
RMA number posted on the outside of the shipping carton.
•You are responsible for the cost of shipping. Ship the product
to the following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:
•SIIG will ship the repaired or replaced product via Ground
in the U.S. and International Economy outside of the U.S. at
no cost to the customer.

HDMI over CAT5e Receiver is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered
trademarks of SIIG, Inc. Other names used in this publication are for identification only and may be
trademarksoftheirrespectivecompanies.
September, 2008 Copyright © 2008 by SIIG, Inc. All rights reserved.
