SIIG Full HD 1080P HDMI Wireless Transmitter and Receiver... User manual

1
Full HD 1080P HDMI Wireless
Transmitter and Receiver Kit
Quick Installation Guide
Introduction
The Wireless HDMI Kit provides a plug-and-play method of extending HD
video and full digital and analog audio wirelessly up to 25 meters, with
virtually perfect replication, for connecting to HDTV sources. Features
such as advanced Wireless N technology allows wireless signals to transmit
through walls to accommodate multiple room installations, and data
transfer rates up to 300 Mbps make this Wireless HDMI Kit the perfect
solution to improve, enhance, and satisfy your audio/video enjoyment.
Features and Benefits
Auto tracing - smart antenna
Real-time, visually lossless HD compression
Transmission distance up to 25 meters indoor
Fully compliant with IEEE 802.11n draft 2.0 and IEEE 802.11a standard
Works with HDMI and Wireless compliant devices
Works with HDMI & HDCP 1.1/1.2 compliant devices
Plug-n-Play installation
System Requirements
PC Computers or A/V Sources with an available HDMI port
HDMI display
04-0696A

2
Package Contents
HDMI Transmitter (TX)
HDMI Receiver (RX)
USB DC 5V Power Supply
IR emitter cable
IR receiver cable
HDMI Cable
Quick installation guide
Specifications
Supports 1080P/25Hz non-compressing image
Transmission speed: 300Mbps
Frequency: 5.18~5.32, 5.50~5.70 and 5.745~5.825GHz (ISM 5 GHz)
Wireless: Antenna 2T3R MIMO
Connector: HDMI 19-pin typeA female
Operating temperature: 0~50C ambient temperature
Storage Temperature: -20~60C
Operation Humidity: 15%~80% (Non-condensing)
Storage Humidity: 15%~70% (Non-condensing)
Power supply: 5VDC 2A output
Transmitter Receiver
I/O Connector
1x HDMI 19pin input
1x USB Power Connector
1x IR connector
1x Power button
1x HDMI 19pin output
1x USB Power Connector
1x IR connector
1x Power button
Resolution Support
640x480 @ 85 fps；800x600 @ 85 fps
1024x768 @ 75 fps；1280x1024 @ 30 fps
1600x1200 @ 30 fps；1440x900 @ 30 fps
1680x1050 @ 30 fps；1920x1080 @ 30 fps
HDMI version HDMI 1.3
HDCP version HDCP 1.1/1.2
LED Power on/off Signal Link

3
Layout
Figure 1: Transmitter (TX)
1
Active LED Indicator
2 Power LED Indicator
3 USB Power Connector
4 HDMI Input
5 IR emitter connector
6 Reset Button
7 Power Button
1 2
3
457 6

4
Figure 2: Receiver (RX)
1 IR Sensor
2 Active LED Indicator
3 Power Light LED Indicator
4 USB Power Connector
5 HDMI Output
6 IR receiver connector
7 Reset Button
8 Power Button
12 3
86 5 4
7

5
Figure 3: IR Emitter Figure 4: IR Receiver
Application
Installation
1. Connect your HDMI source to the Wireless transmitter (TX).
2. Connect the IR emitter cable to the Wireless transmitter and point the
emitter directly to the IR of the HDMI source.
Please ensure that you place the IR emitter in close proximity to the display device
and the IR Sensor in an area accessible to the remote control’s infrared signal.
3. Plug the USB power adapter into the Wireless transmitter’s USB port,
then plug the power adapter into a reliable power source.
4. Connect your HDMI display to the Wireless receiver (RX).
5. Connect the IR receiver cable to the Wireless receiver, and point the IR
receiver directly to the IR of the HDMI display.
6. Plug the USB power adapter into the Wireless receiver’s USB port, then
plug the power adapter into a reliable power source.

6
Blank Page

7
Technical Support and Warranty:
QUESTIONS? SIIG’s Online Support has answers! Simply visit our website
at www.siig.com and click on Support. Our online support database is updated
daily with new drivers and solutions. Answers to your questions could be just a
few clicks away. You can also submit questions online and one of our technical
support analysts will promptly respond.
SIIG offers one year manufacturer warranty with this product. Please see our
web site for more warranty details. If you encounter any problems with this
product, please follow the procedures below.
A) If it is within the store's return policy period, please return the product to
the store where you purchased from.
B) If your purchase has passed the store's return policy period, please follow
these steps to have the product repaired or replaced.
Step 1: Submit your RMA request.
Go to www.siig.com, click Support, then RMA to submit a request to SIIG
RMA or fax a request to 510-657-5962. Your RMA request will be
processed, if the product is determined to be defective, an RMA number
will be issued.
Step 2: After obtaining an RMA number, ship the product.
Properly pack the product for shipping. All software, cable(s) and any
other accessories that came with the original package must be included.
Clearly write your RMA number on the top of the returned package.
SIIG will refuse to accept any shipping package, and will not be
responsible for a product returned without an RMA number posted on
the outside of the shipping carton.
You are responsible for the cost of shipping the product to SIIG at the
following address:
SIIG, Inc.
6078 Stewart Avenue
Fremont, CA 94538-3152, USA
RMA #:____________________
SIIG will ship the repaired or replaced product via Ground in the U.S.
and International Economy outside of the U.S. at no cost to the
customer.

8
About SIIG, Inc.
Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity
solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB,
and legacy I/O adapters) that bridge the connection between Desktop/
Notebook systems and external peripherals. SIIG continues to grow by
adding A/V and Digital Signage connectivity solutions to our extensive
portfolio. All centered around the distribution and switching of A/V signals
over CAT5/6, these products include matrix switches, distribution amplifiers,
extenders, converters, splitters, cabling, and more.
SIIG is the premier one-stop source of upgrades and is committed to
providing high quality products while keeping economical and competitive
prices. High-quality control standards are evident by one of the lowest
defective return rates in the industry. Our products offer comprehensive
user manuals, user-friendly features, and most products are backed by a
lifetime warranty.
SIIG products can be found in many computer retail stores, mail order
catalogs, and e-commerce sites in the Americas, as well as through major
distributors, system integrators, and VARs.
Full HD 1080P HDMI Wireless Transmitter and Receiver Kit is a trademark of SIIG, Inc.
SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Other names used in this
publication are for identification only and may be trademarks of their respective companies.
March, 2011 Copyright © 2011 by SIIG, Inc. All rights reserved.
