Silent Alert CH3A-2205-IN User manual

Quick start guide CH3A-2205-IN
Alarm clock charger
CCM3A-2216-EU-PIR-MKX
MOVEMENT MONITOR 11/12/13
USE MAINS POWER SUPPLY
PS3A-2207-UK ONLY
SILENT ALERT SA3000 SYSTEM
WWW.SILENT-ALERT.CO.UK CLOFIELD LTD. UK
TEL [phone]
MOVE KEY DOWN
TO SWITCH ON
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
1 = System Code 1 2= System Code 2 3 = System Code 3 4 = System Code 4 5 = Audio Monitoring 6 = Zone Multiplier (7-12) 7 = Short Audio Delay 8 = Medium Audio Delay 7 & 8 = Long Audio Delay 9 = PIR Delay 5 Mins 10= PIR Delay 10 Mins 9& 10 = PIR Delay 15 mins 11= Zone 6 12= Zone 5 13= Zone 4 14= Zone 3 15= Zone 2 16= Zone 1
MOVE KEY DOWN
TO SWITCH ON
Any questions? Call us on 01246 450789
We recommend a full 24 hour charge before using our equipment.
In an emergency a few hours charge may be sufficient for short time use but this is not advised.
2. 3.
Dock the pager in to the charger.
The battery key on the pager & the
snooze key on the charger will light green
briefly upon docking confirming the pager
is docked correctly.
If a pillow pad is fitted it will vibrate three
times when the pager is docked.
Silent
TM
Fire
Compatible
Silent
Alert
TM
12:14
SNZ
PM
Z Z
1. Connect the power
supply to the unit and
the plug adaptor into a
13 Amp mains socket.
The pillow pad
should be fitted at
this stage if required.
Use the strain relief
in the charger base
to secure.
12:14
SNZ
PM
Z Z
Pillow pad Socket
Power socket
Charging jack
Clock display
Clock keys
Strain relief
12:14
SNZ
PM
Alarm clock control keys
Hour
Advance
Minute
Advance
Time
Set
Alarm
Set
Alarm
ON/OFF
Snooze
Z Z
Z Z
Setting the alarm
Press and hold the
"alarm set" key.
The pillow pad will vibrate 3 times
when the alarm is switched on. Also,
the bell & snz symbols will display
on the clock.
If the pillow pad is not fitted the
charger will beep three times.
Setting the alarm time
Use the "hour advance" and "minute
advance" keys to enter the
desired alarm time.
Press and hold the
"alarm set" key.
Release the "alarm set" key to finalise
the setting.
07:00
AM
Setting the time
Use the "hour advance" and "minute
advance" keys to enter the
correct time.
Press and hold the
"time set" key.
Release the "time set" key to finalise
the setting.
10:25
AM
Alarm set
07:00
SNZ
AM
To deactivate the alarm
press the alarm
ON/OFF button.
To delay the alarm for
4 minutes press
the snooze button
When the alarm goes off
the charger will beep and
the pillow pad will vibrate.
The display will switch on and the
charger will power up.
Use the strain relief in the
charger base to secure.
CH3A-2205-IN Alarm Clock Charger
Use with Mains Adaptor (PS3A-2207-UK),
or National Equivalent ONLY
BATCH NUMBER 18/03/14
www.silent-alert.co.ukClofield Ltd.,
19 The Bridge Business Centre,
Dunston Road, Chesterfield, S41 9FG
Tel:[phone]
9V DC 300mA2.7VA
WARNING! Your device and its accessories are not toys. They may contain small parts. Keep them out of the reach of small children.
TM
Alert
Silent

Quick start guide CH3A-2205-IN
Alarm clock charger
CCM3A-2216-EU-PIR-MKX
MOVEMENT MONITOR 11/12/13
USE MAINS POWER SUPPLY
PS3A-2207-UK ONLY
SILENT ALERT SA3000 SYSTEM
WWW.SILENT-ALERT.CO.UK CLOFIELD LTD. UK
TEL [phone]
MOVE KEY DOWN
TO SWITCH ON
1
2
3
4
5
6
7
8
1 = System Code 1 2= System Code 2 3 = System Code 3 4 = System Code 4 5 = Audio Monitoring 6 = Zone Multiplier (7-12) 7 = Short Audio Delay 8 = Medium Audio Delay 7 & 8 = Long Audio Delay 9 = PIR Delay 5 Mins 10= PIR Delay 10 Mins 9& 10 = PIR Delay 15 mins 11= Zone 6 12= Zone 5 13= Zone 4 14= Zone 3 15= Zone 2 16= Zone 1
MOVE KEY DOWN
TO SWITCH ON
12:14
SNZ
PM
Do not disassemble
WARNING! Your device and its accessories are not toys. They may contain small parts. Keep them out of the
reach of small children.
Do not subject the unit to excessive mechanical shock. The Charger should be placed on a smooth, hard surface and
away from other objects to ensure correct ventilation. Do not cover the unit or place on soft or
carpeted surfaces.
Do not immerse the Charger in water or any other liquid.
Do not disassemble.
Only use with the Silent Alert PS3A-2204-EU Power supply.
The Pillow Pad socket is for use with the Silent Alert VP3A-2211-IN only. Do not connect any other device
to this socket as it may result in damage to the unit.
Do not short circuit or connect any other device to the charging pin in the dock as this may damage the unit.
!
!
!
!
Any questions? Call us on 01246 450789
