Silicon Graphics 1200 User manual

SGI™1200-Family of Servers
User’s Guide
Document Number 007-4248-001

SGI™1200-Family of Servers User’s Guide
Document Number 007-4248-001
CONTRIBUTORS
Written by Carl Strasen and Mark Schwenden
Illustrated by Kwong Liew and Dan Young
Production by Kam Kashani, David Clarke, and Amy Swenson
SGI Engineering contributions by Mike Koken, Kunnau Chen, Courtney Carr, David
Sakamoto, John Jones, Marty Matthews, and Bob Housholder.
© 2000, Silicon Graphics, Inc.— All Rights Reserved
The contents of this document may not be copied or duplicated in any form, in whole
or in part, without the prior written permission of Silicon Graphics, Inc.
LIMITED AND RESTRICTED RIGHTS LEGEND
Use, duplication, or disclosure by the Government is subject to restrictions as set
forth in the Rights in Data clause at FAR 52.227-14 and/or in similar or successor
clauses in the FAR, or in the DOD, DOE, or NASA FAR Supplements. Unpublished
rights reserved under the Copyright Laws of the United States.
Contractor/manufacturer is Silicon Graphics, Inc., 1600 Amphitheatre Pkwy.,
Mountain View, CA 94043-1351.
Silicon Graphics is a registered trademark, and SGI and the SGI logo are trademarks
of Silicon Graphics, Inc. Cirrus Logic is a registered trademark of Cirrus Logic Inc.
Intel, Pentium, and LANDesk are registered trademarks of the Intel Corporation.
Linux is a registered trademark of Linus Torvalds. Magic Packet is a trademark of
Advanced Micro Devices, Inc. Microsoft and Windows are trademarks of the
Microsoft Corporation. MMX and Xeon are trademarks of the Intel Corporation.
Symbios is a registered trademark of the LSI Logic Corporation. All other third party
brands and names mentioned in this document are the property of their respective
owners.

007-4248-001 iii
Contents
Figures ..........................vii
Tables ..........................ix
About This Guide.......................xi
ProductFeatures.......................xi
WheretoFindMoreInformation..................xii
ConventionsandTerminology...................xiii
ReaderComments.......................xiv
1. Site Preparation and Technical Specifications ..............1
SitePreparation.......................1
TechnicalSpecifications.....................3
2. Hardware Overview ......................5
TheoryofOperations......................5
Processors........................8
Memory........................8
I/OSubsystem......................8
Midplane........................10

iv 007-4248-001
Contents
ChassisTour ........................11
ChassisLEDs,ButtonsandConnectors................13
FrontACPowerPushButton.................13
ResetPushButton.....................14
BlueACPowerLed....................15
GreenDiskLED.....................15
EthernetActivityLED...................15
AmberGlobalFailureLED..................15
HardDriveCarrierLEDs ..................16
PowerSupplyLEDs....................17
BackPanelConnectors...................18
3. Mounting the Server in a Rack ...................19
MountingtheSysteminaRack...................19
SlideRailMount......................20
CenterMount.......................23
ConnectingEverythingtoGetStarted.................25
4. Peripheral Use ........................27
OpeningtheCDandFloppyCover..................27
Hot-swapDriveUse......................28
HardDriveUpgradeStrategies..................33

Contents
007-4248-001 v
A. Regulatory Specifications ....................37
Manufacturer’sRegulatoryDeclarations...............37
ServerModelNumber....................37
SeriesNumber.......................37
Manufacturer’sDeclarationofConformity..............38
UpgradeRegulatoryLabel...................38
ClassACompliance.....................38
ElectromagneticEmissions...................39
VCCINotice(JapanOnly)...................39
NOM024Information(MexicoOnly)................39
ChineseClassARegulatoryNotice.................40
IndustryCanadaNotice(CanadaOnly)...............40
CENotice........................40
KoreanClassARegulatoryNotice.................41
ShieldedCables......................41
ElectrostaticDischarge....................41
Index ..........................43

007-4248-001 vii
Figures
Figure i FrontPanelofSGI1200withOptionalHardDrives.....xii
Figure ii InjuryorDeathWarningIcon............xiii
Figure iii EquipmentDamageorDataLossWarningIcon......xiii
Figure 1-1 SGI1200ServerChassisAirflowDiagram........2
Figure 2-1 Internal View of SGI 1200 Server with Optional RAID Controller . 7
Figure 2-2 MidplaneandChassisFans............8
Figure 2-3 SCSI Cabling Route to Midplane with Optional RAID Controller . 9
Figure 2-4 SCSI Cabling to Midplane without Optional RAID Controller . . 10
Figure 2-5 Midplane-AssignedSCSIIDs............11
Figure 2-6 ExplodedViewofSGI1200ServerChassis........12
Figure 2-7 FrontPanelPushButtons(CoverRemoved).......13
Figure 2-8 FrontPanelLEDs...............14
Figure 2-9 HardDriveCarrierLEDs.............16
Figure 2-10 PowerSupplyLEDs..............17
Figure 2-11 ConnectorsontheSGI1200ServerBackPanel.......18
Figure 3-1 SlideRailInstallation..............22
Figure 3-2 InstallingtheChassisintoaCenterMountRack......24
Figure 4-1 OpeningtheCDandFloppyFrontCover........27
Figure 4-2 SCSIDriveNumbering .............29
Figure 4-3 ReleasingaHardDiskDrive............30
Figure 4-4 RemovingaHardDrive.............31
Figure 4-5 ReplacingaHardDiskDrive............32

007-4248-001 ix
Tables
Table 1-1 CoolingandPowerRequirements..........1
Table 1-2 PhysicalandEnvironmentalSpecifications........3
Table 2-1 FrontPanelLEDStateSummary...........16
Table 2-2 HardDriveCarrierLEDStateSummary ........17
Table 2-3 PowerSupplyLEDStateSummary..........18
Table 3-1 RackInstallationHardwareforSlideRailMount......20
Table 3-2 RackInstallationHardwareforCenterMount.......23
Table 4-1 SGI1200ServerExternalSCSIConnectionChoices.....33
Table 4-2 SGI1200RAIDConfigurations...........34
Table 4-3 RAID5HardDriveUpgradeStrategy.........35

xi
About This Guide
This guide provides you with information on using and administering your SGI 1200
server. Although there are a number of models in the SGI 1200-family of servers, this
document refers to the products generically as SGI 1200 servers. The following section
describesthisproduct’sfeatures.
Product Features
The SGI 1200 server has one or two processors, and the chassis is built in a 2U form factor.
Some of the server’s features include:
• 2U (3.48-inch) height for convenient placement in a 19-inch EIA rack
• One or two Intel Pentium III processors
• Ultra2 SCSI controller, S-VGA video, serial, parallel ports and 10/100-BaseT
Ethernet on the motherboard
•Upto2GBofECCSDRAM
The SGI 1200 has four hard disk bays and an SCA (Single Connector Attachment)
midplane for easy drive removal, replacement and chassis monitoring. The server can
support hot-swap drives with an optional SGI 1200 server RAID controller. Other
features include:
• Remote Server Management Port
• 400 watt autoranging power supply
The following topics are covered in this manual:
• Chapter 1, “Site Preparation and Technical Specifications” provides environmental
and technical infomation needed to properly set up and configure the SGI 1200
server system.

007-4248-001 xii
• Chapter 2, “Hardware Overview” lists information on the server’s chassis,
connectors, motherboard, LEDs, drives and other hardware components.
• Chapter 3, “Mounting the Server in a Rack” gives information on the proper
procedures for mounting the SGI 1200 server system into a rack. Basic power and
I/O connections for starting the system are covered.
• Chapter 4, “Peripheral Use” describes how to access, use, and replace the server’s
peripheral components.
• Appendix A, “Regulatory Specifications” lists all regulatory information related to
the use of the server in the United States and other countries.
Figure i shows the front of an SGI 1200 server with the CD/floppy drive cover removed.
Figure i Front Panel of SGI 1200 with Optional Hard Drives
Where to Find More Information
SGI makes its manuals available in a variety of formats via the World Wide Web (WWW).
Using your Web browser, open the following URL:
http://techpubs.sgi.com/library
Enter a keyword search, or search by title to find the information or manual you need.
Blue AC power LED
Amber global failure LED
Green Ethernet activity LED
Green disk activity LED

xiii
Conventions and Terminology
This guide uses the following conventions:
• References to document titles are in italics.
• Commands and names of files appear in text as italics.
• References to other chapters and sections within this guide are in quotation marks.
• Anything that you type on your keyboard is in Courier bold.
• Anything displayed on the screen is in Courier.
• Steps to perform tasks are in numbered sentences. When a numbered step needs
more explanation, the explanation follows the step and is preceded by a square
bullet.
• Warning text that describes conditions that could cause injury or death is
highlighted with a lightening bolt icon in the left margin.
Figure ii Injury or Death Warning Icon
• Warning or caution text that describes conditions that could cause equipment
damage or major data loss is highlighted with a explanation mark in the left margin.
Figure iii Equipment Damage or Data Loss Warning Icon
In addition, the term “hot-swap” in text with a RAID controller indicates that a hard
drive can be removed and replaced while the server is running without data loss in a
RAID configuration. Otherwise, the term “hot-swap” indicates that hard drives are
conveniently removed and replaced for service and drive expansion, however no data
redundancy occurs.

007-4248-001 xiv
Reader Comments
If you have comments about the technical accuracy, content, or organization of this
document,pleasetellus.Besuretoincludethetitleandpartnumberofthedocument
with your comments. (Online, the document number is located in the front matter of the
manual. In printed manuals, the document number can be found on the back cover.)
You can contact us in any of the following ways:
• Send e-mail to the following address:
[email protected]
• Use the Feedback option on the Technical Publications Library World Wide Web
page:
http://techpubs.sgi.com
• Contact your customer service representative and ask that an incident be filed in the
SGI incident tracking system.
• Send mail to the following address:
Technical Publications
SGI
1600 Amphitheatre Pkwy.
Mountain View, California, 94043-1351
• Send a fax to the attention of “Technical Publications” at:
[phone]
We value your comments and will respond to them promptly.

007-4248-001 1
Chapter 1
1. Site Preparation and Technical Specifications
TheSGI1200serverisshippedinarack,orreadyforrackmounting.
Site Preparation
Table 1-1 provides site preparation information for a single SGI 1200 chassis.
Table 1-1 Cooling and Power Requirements
Specification Value Per Server
Cooling Requirements
Minimum configuration
Maximum configuration
730 BTU/hour
859 BTU/hour
Air Conditioning Load 0.0718 tons maximum
Power Consumption
Minimum configuration
Maximum configuration
214 Watts
252 Watts
Volt-Amp Rating for a UPS 600 VA

2007-4248-001
1: Site Preparation and Technical Specifications
As shown in Figure 1-1, the airflow in the server chassis flows through the mesh grill at
the front of the chassis through the power supply, and over the motherboard. The hot air
exhausts out the back of the chassis.
Caution: Always keep at least 2 inches (5.1 cm) of clearance at the back of the chassis for
cooling.
Figure 1-1 SGI 1200 Server Chassis Airflow Diagram

Technical Specifications
007-4248-001 3
Technical Specifications
Table 1-2 lists physical and environmental specifications.
Table 1-2 Physical and Environmental Specifications
Specification Value Per Server
Dimensions
Chassis 3.48” height (2U) x 17.1” width x 23.92” length (8.85 cm height
(2U) x 43.43 cm width x 60.76 cm length)
Weight
Installed
In packaging
42.0 lb (19.1 kg) maximum
70.0 lb (31.8 kg) maximum
Installation Orientation Any, with 2” (5.1 cm) clearance at back
Heat Dissipation 859 BTU per hour maximum
Acoustic Noise 50 dBA bystander position measurement as per ISO 7779
Air Temperature
Operating
In packaging
+41 to +95 °F (+5 to +35 °C)
-40 to +149 °F (-40 to +65 °C)
Thermal Gradient
Installed
In packaging
18 °F(10°C) per hour (maximum)
108 °F(60°C) per hour (maximum)
Altitude
Installed
In packaging
10,000 ft (3,048 m) MSL (maximum)
40,000 ft (12,192 m) MSL (maximum)
Relative Humidity
Operating
In packaging
10% to 85%, noncondensing at +95 °F(35°C)
5% to 95%, noncondensing at +149 °F(65°C)

4007-4248-001
1: Site Preparation and Technical Specifications
Mechanical shock
Operating
Nonoperating
In packaging
1G.11msecduration,1/2sinewave
10 Gs. 11 msec duration, 1/2 sine wave
Adheres to Impact Specifications in ISTA specification
Mechanical vibration
Operating
Nonoperating
In packaging
0.25 Gs. @ 5-350 Hz (peak to peak)
0.7 Gs. @ 5-500 Hz
Adheres to Random Vibration in ISTA specification
Table 1-2 (continued) Physical and Environmental Specifications
Specification Value Per Server

007-4248-001 5
Chapter 2
2. Hardware Overview
This chapter provides information about the SGI 1200 server’s hardware. In the first
section, information about the motherboard is presented, and in the following sections,
the text and supporting illustrations provide information about chassis internals,
connectors and LEDs.
Theory of Operations
The SGI 1200 server uses an Intel motherboard with the following features:
• MP (Multi-Processor) ready processor host bus interface support
• Dual or single Intel Pentium III processors
• Support for up to 2 GB of ECC memory
• Supports the ACPI (Advanced Configuration and Power Interface) power
management specification
• L2 cache configurations of 512 KB
• Embedded dual function SCSI controller provides both Ultra2 (LVDS) wide and
UltrawideSCSIinterfacesastwoindependentPCIbusmasters
• Fast IDE controller support for removable media drives
• 10/100 Base-T ethernet support at burst rates of up to 132 MB/sec from the PCI bus
to the ethernet controller
When you first boot your system you will see an Intel mother board identification
number listed (for example L440GX+). If you need specific technical information
regarding your server’s mother board you can access the Intel documentation directly at:
http://support.intel.com/support/motherboards/server/

6007-4248-001
2: Hardware Overview
The SGI 1200 server has four hard disk bays and a midplane for easy drive removal,
replacement, and chassis monitoring. It supports hot-swap drives with an optional SGI
1200 server RAID controller. Two removable media drives are supported.
Figure 2-1 shows a top view of the chassis internals for an SGI 1200 server with a
midplane and optional RAID controller.
In Figure 2-1, note the following:
• A dual processor motherboard (in single processor systems the secondary processor
location must have a terminator board installed)
• The DIMM locations are numbered from one to four moving from left to right.
• The midplane is connected to the optional RAID controller by way of a SCSI cable:
– The optional RAID controller PCI card enables hot-swap capability.
– In configurations with an SCA midplane but without the RAID controller, the
drivebayshavenohot-swapdataredundancy.
