Instruction Manual
PathLight Solar Street & Parking Lot Light

(12W)



InnovativeSolarSolutionsLLC|2917StateHwy7,Bainbridge,N.Y.13733|Ph:800.786.0329|www.SiliconSolar.com
Overview:
Our PathLight solar street light which integrates the efficient solar panel, LED light and the Li-Fe
battery into a single product. It operates with human intelligence induction system to become the
solution of low-energy, durable, high-luminance and free maintenance.
Purpose:
For garden, residential area, courtyard, streets, walkways, parking lots, docks & piers, remote and
rural area, etc. The high efficient solar panel absorb solar energy at day time, charge the battery
which provide energy for the light at night.
Components:
- High efficient solar panel (Built-into the Fixture/Box)
- Li-Fe battery (Built-into the Fixture/Box)
- LED light (Built-into the Fixture/Box)
- MPPT controller (Built-into the Fixture/Box)
- Human intelligence induction system/motion sensor (Built-into the Fixture/Box)
- Bracket (For Mounting)
How it works?
The solar panel converts sunlight into electricity and stored in Li-Fe battery via controller, the LED
light will work at night automatically under the light sensor control, and provide light for the different
areas. And there are two modes for the light, they are full power mode and power saving mode.
When the motion sensor senses movement, it will operate in full power mode. It will operate in power
saving mode when it does not senses any movement around.



InnovativeSolarSolutionsLLC|2917StateHwy7,Bainbridge,N.Y.13733|Ph:800.786.0329|www.SiliconSolar.com
Data and Specification:
Model PathLight-12W
Specifications
Light source 12W LED
Solar panel 18W(Poly)
Battery 12.8V 15AH
Motion sensing YES
Dimension 20.3" X 12.6" X 2"
Net weight 12.57 LBS
Light efficiency
Luminous Full load
working 1200 - 1320lm
Flux Less load
working 440lm
Visual angle 120°
Color temperature
□3000k-3500k
□6000k-6500k
Work time
Full power ~10Hr
Saving
mode ~20Hr
Operating temperature
Work temperature -22 - 158 Degree
Fahrenheit
Recommended Placement Info.
Recommended mounting
height 3 – 4m from ground level
Recommended Distance
(Light to Light) 28ft – 35ft



InnovativeSolarSolutionsLLC|2917StateHwy7,Bainbridge,N.Y.13733|Ph:800.786.0329|www.SiliconSolar.com
Assembling and Installation:
Step 1:
Open the box and prepare all the parts you need.


Step 2:
Connect the bracket with the light fixture/box with different accessories.






InnovativeSolarSolutionsLLC|2917StateHwy7,Bainbridge,N.Y.13733|Ph:800.786.0329|www.SiliconSolar.com
Step 3:
Mount the light fixture on the pole. You will not need the curved bracket when you mount it on a flat wall.

Step 5:
Turn on the switch. And this is how it looks when it is installed on a pole.





InnovativeSolarSolutionsLLC|2917StateHwy7,Bainbridge,N.Y.13733|Ph:800.786.0329|www.SiliconSolar.com
Reminder:
 PathLight solar street light adopts the long life Lithium battery for storing energy, charging temperature
at day time is between: 0°C～+60°C，when temperature goes lower than 0°C ，the control system will
stop automatically to protect the battery, and it will revive to charge the battery while temperature goes
higher than 0°C. Discharging temperature at night is between: -20°C～+60°C，any ambient beyond
will bring damage to the battery. Please confirm your local extreme temperature is suitable for above
while selecting the street light.。
 Battery of the light can be stored for 6 months long after full charged, and please examine, charge it
periodically after long time transportation to prevent damage.
 Keep clearing the surface of the PathLight solar street light with normal detergent to get maximum
power generation, clear the dust or tree leaves or any grease.
 While installing in Northern Hemisphere, please make sure the surface of the solar panel is facing the
South to absorb maximum sunshine radiation. While installing in Southern Hemisphere, please make
sure the surface of the solar panel is facing the North to absorb maximum sunshine radiation. At the
same time, please keep it away from any shadow of house, trees etc. Meanwhile, you can adjust the
angel between the lamp head and level (as follows), you’d better reconcile the lamp head with local
latitude.
