Silver 5 Thread User manual

Instruction Manual
Cover & Overlock

Important safety instructions
1
When using an electrical appliance, basic safety should always be followed, including the
following:
Read all instructions before using this sewing machine.
-To reduce the ris of electric shoc :
1. An appliance should never be left unattended when plugged in.
2. Always unplug this appliance from the electric outlet immediately after using and before
cleaning.
3. The sewing machine is equipped with a LED lamp. If the LED lamp is bro en, it must be
replaced by the manufacturer or its service agent in order to avoid a hazard.
-To reduce the ris of burns, fire, electric shoc , or injury to persons:
Never use the sewing machine if the air vents are bloc ed. Keep the air vents of the sewing
machine and the food pedal free from dust, fusel and leftovers.
21. Always unplug the sewing machine if you leave it unattended, in order to avoid injuries by
inadvertently switching on the sewing machine.
22. Don't use the sewing machine if it's wet or in humid environment.
23. Keep the instructions at a suitable place close to the sewing machine and hand it over if you
give the sewing machine to a third party.
This sewing machine is intended for household use only.
DANGER
WARNING
SAVE THESE INSTRUCTIONS
1. Do not allow to be used as a toy. Close attention is necessary when this appliance is used by
or near children.
2. Use this appliance only for its intended use as described in this manual. Use only the
attachments recommended by the manufacturer as contained in this manual.
3. Never operate this appliance if it has a damaged cord or plug, if it is not wor ing properly, if it
has been dropped or damaged, or dropped into water. Return the appliance to the nearest
authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
4.
5. Keep fingers away from all moving parts. Special care is required around the sewing machine
needle.
6. Always use the proper needle plate, a wrong needle plate can cause the needle to brea .
7. Do not use bent needles.
8. Do not pull or push fabric while stitching. It may deflect the needle causing it to brea .
9. Switch the sewing machine off ("O") when ma ing any adjustments in the needle area, such as
threading needle, changing needle, threading bobbin, or changing presser foot, and the light.
10. Always unplug sewing machine from the electrical outlet when removing covers, lubricating,
or when ma ing any other user servicing adjustments mentioned in the instruction manual.
11. Never drop or insert any object into any opening.
12. Do not use outdoors.
13. Do not operate where aerosol spray products are being used or where oxygen is being
administered.
14. To disconnect, turn all controls to the off ("O") position, then remove plug from outlet.
15. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
16. The sound pressure level under normal operating conditions is 75dB(A).
17. Please turn off the machine or unplug when the machine is not operating properly.
18. Never place anything on the foot controller.
19. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lac of experience and nowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
20. Children should be supervised to ensure that they do not play with the appliance.

Principal parts of the machine ...........................................................................3-5
Accessories ...........................................................................................................6
Looper cover/ Waste container.............................................................................7
Telescopic thread guide/ Foam pads/ Cone holders/ Thread net/
Thread unreeling disc ..........................................................................................8
Needle position .....................................................................................................9
Presser foot lifting lever ........................................................................................9
Changing a needle..............................................................................................10
Connecting the machine to the power source....................................................11
Starting sewing....................................................................................................12
Adjusting presser foot pressure ..........................................................................12
Threading the thread guides...............................................................................13
Threading the upper overedge looper ................................................................14
Threading the lower overedge looper.................................................................15
Double chainstitch and cover stitch looper....................................................16-17
Threading the needles ...................................................................................18-20
Needle threader ..................................................................................................21
Summary of threading paths and threading sequences ...............................22-24
Thread cutter/ Chec spring for edging the thread chain/ Waste container ......25
Disengage the upper nife..................................................................................26
Swiveling stitch width latch .................................................................................27
2-thread converter...............................................................................................28
Disengage the upper looper ...............................................................................29
Adjusting the stitch length/ Differential feed .......................................................30
Remove nife guard............................................................................................31
Set seam width ...................................................................................................32
Attaching the presser foot holder........................................................................33
Care and solving machine ..................................................................................34
Replacing the upper nife..........................................................................35
Care of the machine .............................................................................36-37
Cover stitch, important notes on sewing .......................................................38-41
2
Contents

3
Principal parts of the machine
1. Upper needle-thread tension
2. Upper needle-thread tension
3. Thread tension/ upper looper thread
4. Thread tension/ lower looper thread
5. Thread tension/ two-thread chainstitch looper/ cover stitch looper
6. Adjusting nob for presser foot pressure
7. Needle holder
8. Standard presser foot
9. Needle plate
10. Adjusting nob for seam width
11. Seam width viewing window
12. Swivel plate
13. Looper disengaging lever
14. Blade guard (for Overedge/ Overloc )
15. Looper cover
16. Presser foot lever
17. Thread chain cutter
12 3 4 5
7
6
16
8
9
10 12
11
13
14
15
17

Principal parts of the machine
4
18. Thread guides
19. Telescoping thread guide
20. Thread spool pin
21. Cone thread adapter
22. Spool disc
23. Thread spool stand
24. Rear thread guides
25. Stitch length adjustment nob
26. Regulator wheel for differential feed
27. Handwheel
28. Electrical power master switch
29. Machine soc et, foot control
18
19
23
20
22
21
24
25
26
27
28 29

Principal parts of the machine
5
30. Upper overedge looper
31. Lower overedge looper
32. Double chainstitch and cover stitch looper
33. Swiveling stitch width latch
34.
35. Threading aid for double chainstitch and cover-stitch looper
36. Knob for lowering the upper nife
37. Fixed lower nife
Movable upper nife
* Pull the cover to the right and open it towards you.
30
3131
3232
33333434
3535
3636 3737

Accessories
6
1. Sewing table (for Coverstitch/ Chainstitch)
2. Thread (5X)
3. Cone holder (5X)
4. Thread nets (5X)
5. Spool cap - large (5X)
6. Pac of needle
7. Thread disc (5X)
8. Waste container
9. Needle threader
10. Needle inserting tool
11. Upper blade
12. Wrench
13. Oil bottle
14. Edge/ Quilting guide
15. Screwdriver
16. Hex Wrench
17. Tweezers
18. Cleaning brush
19. Blade guard
20. Accessory box
21. Soft cover
* In the Accessory Box.
1
2
3
4
5
6
7
8
910 11
12
13
14
15
16
17 18
19
20
21

To remove the waste container, repeat this procedure
in the reverse order.
Waste Container
Insert the upper latch of the waste container into the
upper slot of the looper cover. Apply pressure to the
lower part of the container until the lower latches fic
into place in the lower slots of the looper cover.
Looper Cover
Push the looper cover fully to the right and then
swivel it down.
Looper cover/ Waste container
7

Thread Unreeling Disc
The thread unreeling disc (in the accessory box) is
used for small spools/spools with notched or rough
ends. Place the spool on the spool pin. Place the
thread unreeling disc on top of the spool. Ma e sure
the spool dise is used under the spool.
Thread Net
Synthetic threads generally unwind too quic ly from
the thread spool. Thread nets have been included to
allow easy use of these threads. Pull the thread net
(located in the accessory box) over the spool from
below. Place the spool on the spool holder catching
the bottom of the thread net with the spool pin.
Foam Pads/ Cone Holders
If you are using large cones (5,000 10,000 mm), the
foam pads and the cone holders will be helpful to you.
With synthetic threads, the foam pads catch threads
that have slipped down and help to advance the
thread flawlessly.
Cone holders serve to ensure that large cones are
well positioned.
Telescopic Thread Guide
Pull the telescopic thread guide upwards to its highest
position.
To ensure optimum thread feed, turn the telescopic
parts slowly until you hear the loc ing balls fic into
place.
8
Telescopic thread guide/ Foam pads/ Cone holders
/ Thread net/ Thread unreeling disc

The offers a choice of 5 needle positions. You can
sew with as many as 3 needles simultaneously. The
needle positions are L1, L2, L3, R1 and R2. A
retaining screw is provided above each needle.
Please Note: If the needles are inserted at R1
and R2 the left needle is slightly higher than the
right.
Please Note: Presser foot should be lowered
when sewing.
Needle position
9
If the needles are inserted at L2 and L3, the left
needle is slightly lower than the right.
If the needles are inserted at L1 and L3, the left
needle is also lower than the right.
If the needles are inserted at L1, L2 and L3, the left
needle is at the lowest point.
L3
L2
L1
R1
R2
The presser foot can be up or down position by using
the presser foot lifting lever.
Presser foot lifting lever

To insert: Insert the needle in hole A of the needle
changing tool so that the flat side B of the needle is
opposite face of the tool. Insert the needle as far as it
will go into the needle holder (you may have to push
a little harder by hand) and tighten the retaining
screw. Remove the needle changing tool.
Lower the presser foot and raise the
needle(s) to its/their highest position. Ta e the needle
changing tool out of the accessory box and push it up
over the needle as far as it will go. Loosen (but do not
remove) the needle s retaining screw with the allen
ey and pull the needle out from below.
To remove:
10
Changing a needle
Turn off at the power switch
A
B
The uses EL X 705 CF overloc needles.

Connecting the machine
Before connecting the power supply, ma e sure that the voltage and frequency shown on the
machine is conforming with your electrical power.
Place machine on a stable surface.
1. Connect the power line cord to the machine by inserting the 3 pin plug into the power cord
soc et.
2. Connect the power line plug to the electric outlet.
3. Turn on the power switch.
4. The sewing lamp will light up when the switch is turned on.
To disconnect, turn the power switch to the off position, then remove plug from outlet.
Caution: Always ma e sure that the machine is unplugged from power source and the main
switch is on "O" when the machine is not in use and before inserting or removing parts.
ON
OFF
Connecting the machine to the power source
11
Polarized plug information
This appliance has a polarized plug (one blade wider than the other),
to reduce the ris of electrical shoc ; this plug will fit in a polarized
outlet only one way. If the plug does not fit fully in the outlet, reverse
the plug. If it still does not fit, contact a qualified electrician. Do not
modify the plug in any way.

Attention: Consult a qualified electrician if in doubt as how to connect the machine to
the power source. Unplug the power cord when the machine is not in use.
Unplug power cord when machine is not in use.
The foot control must be used with the appliance by 4C-316B (110-120V area) / 4C-
326G (220-240V area).
With the sewing machine turned off, insert the foot
control plug into its connector on the sewing machine.
Turn on the sewing machine, and then slowly
depress the foot control to start sewing.
Release the foot control to stop the sewing machine.
Foot control
The preset presser foot pressure on the machine is
suitable for medium fabrics. For most fabrics, the
presser foot pressure does not need to be altered. If
you intend to wor with lighter or heavier fabrics,
however, it may be necessary to reset the pressure.
In this case, you can choose from six positions; ma e
your selection with the presser foot pressure
adjustment nob. The standard setting is N .
Lower the presser foot before
turning the presser foot pressure adjustment knob.
This makes the knob easier to turn.
Please Note:
12
Starting sewing
Adjusting presser foot pressure

Place the spools on the spool pins. For notes on the
spool net, the thread run-off disc, the foam pads and
the cone holders. Thread the threads from the bac
to the front through the thread guides as indicated by
the codes.
Please Note: Thread in a sequence of 1 to 5.
Threading the thread guides
13
3
1 2
5
4
After threading the thread guide bar, slip the thread
into the first guide on the machine. To do this, pull the
thread down with both hands until it slips under the
thread guide. Pass the thread between the tension
discs and pull it down so that it is between the tension
discs.

Upper looper (green)
Turn the hand wheel towards you until the upper
looper reaches its highest position.
From the front, pass the thread through the eye 9 of
the upper looper. Pull about 10cm (5 inches) of
thread through the hoo and place it facing to the left
under the presser foot.
Thread the thread in thread guides 1 to 7. Pass the
thread over the top of guide 8 from above and pull it
down and to the left until it slips into the guide.
Thread the threads in order from 1 to 9. Some of the
thread guides are mar ed with a green dot.
14
Threading the upper overedge looper
5
6
7
8
9
8
1
2
3
4
5
6
7
8
9

(a)
(b) (c)
Push lever (a) down and hoo the thread on the
guide (b). Pass the thread from front to bac through
the hole (c) on far right end of the looper. Draw the
thread bac to the left under the presser foot, leaving
a 10cm (4 inches) tail.
Threading Lower Looper (pin )
Turn the hand wheel towards you until the lower
looper is as far to the right as possible.
Thread the thread in order from 1 to 9. Some of the
thread guides are mar ed with a pin dot.
15
Threading the lower overedge looper
5
6
7
8
9
1
2
3
4
5
6
7
8
9
3

10
11
12
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
11
12
Double chainstitch(blue)
Turn the hand wheel towards you until the double
chainstitch and coverstitch looper is as far to the right
as possible.
Thread the thread in order from 1 to 12. Some of the
thread guides are mar ed with a purple square.
Thread the thread in the guides from 1 to 8. Pull the
thread under latch 9 and into thread guide 10.
Please Note: In the case of thread guides 6 and
7 the thread is simply placed on top of them not
threaded through.
16
Double chainstitch and cover stitch looper

Press lever A up and hoo the thread into slot B. The
illustration right shows how to do this.
Please Note: The lever will return to its original
position as soon as you start to sew.
From the front, pass the thread through eye C of the
double chain stitch and cover stitch looper.
Pull about 10 cm (4 inches) of thread through the
looper and place it to the left under the presser foot.
17
Double chainstitch and cover stitch looper
B
A
C
B
A

18
Threading the needles
The thread must pass through the lower slot in thread
guide 6.
Pull the thread about 10 cm (4 inches) through the
eye of the needle and place it facing to the left under
the presser foot.
If you sew with the needles L1, L2, or L3 you have to
use the thread guide A.
Thread the thread in order from 1 to 10.
1
2
3
54
6
7
8
9
10
5
6
8
7
A
3
