Silvercrest SRR 3.7 B1 User manual

ROTARY SHAVER SRR 3.7 B1
ROTARY SHAVER
Operating instructions
ROTACIJSKI BRIVNIK
Navodilo za uporabo
HOLIACI STROJČEK
Návod na obsluhu
KÖRKÉSES BOROTVA
Kezelési útmutató
HOLICÍ STROJEK
Návod k obsluze
ROTATIONSRASIERER
Bedienungsanleitung
IAN 278224
NAS278224_Rotationsrasierer_LB4.indd 2 24.11.16 10:53

English.................................................... 2
Magyar ................................................ 26
Slovenšêina .......................................... 54
éesky ................................................... 76
Slovenêina.......................................... 100
Deutsch .............................................. 124
ID: SRR 3.7 B1_16_V1.5
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

Overview / Áttekintés / Pregled / Pįehled /
PrehĘad / Übersicht
15
|5
7
8
3
B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
3
2
16
C
A
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

2 GB
Contents
1. Overview .........................................................3
2. Intended purpose .............................................5
3. Safety instructions ............................................5
4. Items supplied ...............................................10
5. Charging ........................................................11
6. Operation ......................................................12
6.1 Before switching on for the first time................... 12
6.2 Transport lock ................................................. 12
6.3 Changing the shaving/beard trimmer attachment 13
6.4 Pushing on/removing the comb attachment......... 13
6.5 Shaving.......................................................... 14
6.6 Cutting hairlines and beard .............................. 15
7. Cleaning and care ..........................................16
7.1 Shaver ........................................................... 16
7.2 Shaving attachment / blade unit ....................... 16
7.3 Beard trimmer attachment................................. 18
8. Disposal .........................................................19
9. Troubleshooting .............................................20
10.Technical specifications ...................................21
11.Ordering accessories ......................................22
12.Warranty of the HOYER Handel|GmbH ...........23
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

3
GB
1. Overview
1Adjustable comb attachment for the beard
trimmer attachment
23 4 5 6 mm Marking on comb attachment
3Beard trimmer attachment
4Blade unit with shaving heads (3x)
5Shaving attachment
6Release button of the shaving attachment
7Motor unit for attachments
8Shaver
9On/off switch
10 00/... /100% Status display of the battery capacity
11 Plug symbol
flashing red: battery almost empty
is lit red during charging process: the bat-
tery is being charged
12 Lock symbol flashes: shows the transport
lock
13 Cleaning symbol: is lit briefly when
switched on / flashes after 30 minutes of
shaving time as a reminder of the required
regular cleaning
14 Connection for power unit
15 Protective cap
16 SMarking at the beard trimmer attachment
Rear fold-out page:
17 Locking wheel
18 Holder for shaving heads
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

4 GB
Not shown:
19 Power unit
20 Cleaning brush
21 storage pouch
Thank you for your trust!
Congratulations on your new rotary shaver.
For a safe handling of the device and in order to get to know the
entire scope of features:
• Thoroughly read these user instructions prior to
initial use.
• Above all, observe the safety instructions!
• The device should only be used as described in
these user instructions.
• Keep these user instructions for reference.
• If you pass the device on to someone else, please
include this copy of the user instructions.
We hope you enjoy your new rotary shaver!
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

5
GB
Symbols on your device
Suitable for washing under running water.
2. Intended purpose
The rotary shaver is intended exclusively for cutting human hair.
Only use the device for dry hair.
The device is designed for private home use and must not be used
for commercial purposes. The device must only be used indoors.
Foreseeable misuse
WARNING! Risk of material damage!
~ Do not use the device to cut artificial hair or animal hair.
3. Safety instructions
Warnings
If necessary, the following warnings will be used in these user in-
structions:
DANGER! High risk: failure to observe this warning
may result in injury to life and limb.
WARNING! Moderate risk: failure to observe this warning may
result in injury or serious material damage.
CAUTION: low risk: failure to observe this warning may result
in minor injury or material damage.
NOTE: circumstances and specifics that must be observed when
handling the device.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

6 GB
Instructions for safe operation
~This device can be used by children from the
age of 8 and people with restricted physical,
sensory or intellectual abilities or people
without adequate experience and/or under-
standing, if they are supervised or instructed
on how to use this device safely and if they
are aware of the resulting hazards. Children
must not play with the device. Cleaning and
maintenance by the user must not be per-
formed by children without supervision.
~Keep children under the age of 8 away from
the device and the power cable.
~This symbol indicates that you can
clean the shaver under running water.
DANGER! Disconnect the device from
the plug-in power unit prior to doing
so. Only use the included original pow-
er unit for mains operation.
WARNING!
~Keep the power unit and the cable dry!
~The hand-held part must be disconnected
from the power cable before it is cleaned in
water.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

7
GB
DANGER for children
~Children must not play with packing material. Do not allow
children to play with plastic bags. There is a risk of suffoca-
tion.
~Keep the device out of the reach of children.
DANGER to and from pets and livestock
~Electrical devices can represent a hazard to pets and live-
stock. In addition, animals can also cause damage to the
device. For this reason you should keep animals away from
electrical devices at all times.
DANGER! Risk of electric shock due to
moisture
These safety instructions apply to the power unit and the device
connected to the power unit. In battery mode, the shaver is pro-
tected against strong jets of water (protection type IPX6), but must
not be immersed in water.
~Do not use this device in the vicinity of bathtubs, showers,
washbasins or other vessels containing water.
~Protect the device from moisture, water drops and water
splashes.
~Never touch the device with wet hands.
~
The device, the cable and the power unit must not fall into water
or other liquids and must not be rinsed under running water.
~If the device has fallen into water, pull out the power unit im-
mediately, and only then remove the device from the water.
Do not use the device again, but have this checked by a spe-
cialist.
~Should liquid enter the device, have it checked before start-
ing the device up again.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

8 GB
~If the device is used in a bathroom, the power unit must be
pulled out after use, as the proximity of water represents a
hazard, even when the device is switched off.
~Installation of a residual current device (FI/RCD) with a rat-
ed residual operating current of no more than 30 mA is rec-
ommended to provide additional protection. Ask your
electrician for advice. The installation should only be carried
out by a qualified electrician.
DANGER! Risk of electric shock
~Never put the device into operation if there are visible dam-
ages to the device, the power unit or the cable or if the de-
vice has been dropped before.
~Connect the cable to the device before plugging the power
unit into a wall socket.
~
Only connect the power unit to a properly installed, easily ac-
cessible wall socket, the voltage of which corresponds to the
specifications on the rating plate. The wall socket must contin-
ue to be easily accessible after the device is plugged in.
~Ensure that the cable cannot be damaged by sharp edges or
hot surfaces.
~Ensure that the cable is not trapped or crushed.
~When removing the power unit from the wall socket, always
pull the power unit and never the cable.
~Pull the power unit out of the wall socket, …
… after every use,
… after each charging process,
… if there is a fault,
… before connecting the device to the cable,
… before you clean the device and
… during thunderstorms.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

9
GB
~To avoid any risk, do not make modifications to the device.
Repairs must be carried out by a specialist workshop or the
Service Centre.
DANGER from batteries
~Protect the battery against mechanical damages. Fire
hazard!
~Do not expose the device to direct sunshine or heat. The am-
bient temperature should not be lower than -10 °C and high-
er than +40 °C.
~The charge contacts on the device must not be connected by
metallic objects.
~The battery may only be charged with the original accessory
(power unit).
~Should the electrolyte solution leak out of the battery, avoid
contact with eyes, mucous membranes and skin. Rinse imme-
diately with plenty of clean water and consult a doctor. The
electrolyte solution can cause irritation.
WARNING! Risk of injury from cutting
~The points of the beard trimmer attachment are sharp. Han-
dle with care.
~Do not use the device if the attachment shows damages.
~Switch off the device before pinning up or changing the at-
tachments and each time before cleaning.
WARNING! Risk of injury
~Place the cable in such a way that no one trips over it or
steps on it.
~Do not use the device on open wounds, cuts, sunburn or blis-
ters.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

10 GB
WARNING! Risk of material damage
~Use the original accessories only.
~Never place the device on hot surfaces (e.g. hot plates) or
near heat sources or open fire.
~Do not cover the power unit to prevent overheating.
~The blade unit of the shaving attachment can be cleaned us-
ing water. Do not use any other liquids.
~Do not use any astringent or abrasive cleaning agents.
4. Items supplied
1shaver|8
1 power unit|19
1 shaving attachment|5
1 beard trimmer attachment|3
1 adjustable (3, 4, 5, 6 mm) comb attachment|1for the beard
trimmer attachment|3
1 cleaning brush|20
1 storage pouch|21
1 protective cap|15
1 copy of the user instructions
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

11
GB
5. Charging
NOTES:
• Before the device is used for the first time, and during the fol-
lowing three charging procedures, the device should be
charged for 90 minutes in each case.
• The capacity/charging state of the battery|10 is displayed
in percent (00, 05, 10, ... ,100% in increments of 5%).
• When the batteries are almost empty, the plug symbol|11
flashes in red. The device can then only be used for a short
time without being connected to the electricity supply.
• It takes about 5 minutes to charge the device sufficiently for
one shave.
• When the battery is fully charged, the device can be used
for approximately 60 minutes without being connected to the
power supply.
1. Switch off the device with the on/off switch|9if necessary.
2. Connect the power unit|19 to the connection|14 at the de-
vice.
3. Insert the power unit|19 into a readily accessible wall sock-
et whose voltage matches the voltage stated on the rating
plate.
4. The plug symbol|11 is lit red and the battery is charged.
When the battery is fully charged, 100% is displayed.
When the battery is fully charged, the device can be used
for approximately 60 minutes without being connected to
the power supply.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

12 GB
6. Operation
6.1 Before switching on for the first time
CAUTION:
~After unpacking, there could still be oil residues on the shav-
ing heads|4of the shaving attachment|5. Remove these with
an absorbent, lint-free cloth before using the device for the
first time.
Regardless of the charging state of the battery, the rotary shaver
can always be used in mains operation.
1. Before switching to mains operation, ensure that the device
is switched off.
2. Connect the power unit|19 to the connection|14 at the de-
vice.
3. Insert the power unit|19 into a readily accessible wall sock-
et whose voltage matches the voltage stated on the rating
plate.
4. Figure A: push the protective cap|15 downwards off the
shaving attachment|5.
5. Switch on the device with the on/off switch|9.
6.2 Transport lock
If the transport lock is activated, the lock symbol|12 flashes.
• Press and hold the on/off switch|9for approx. 4 seconds, in
order to switch the transport lock on/off.
• Connecting the power unit| 19 deactivates the transport lock,
which cannot be activated during mains operation.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

13
GB
6.3 Changing the shaving/beard trimmer
attachment
WARNING! Risk of injury!
~Switch off the shaver|8, before you attach or remove the at-
tachments.
1. Figure A: slide the protective cap|15 onto the shaving at-
tachment|5from below, with the opening first.
2. Figure B: remove the attachment|3or|5from the shaver|8.
3. Figure B: insert the guide (see dotted line) of the attach-
ments|3or|5into the recess of the motor unit for attach-
ments|7, and press the attachment onto the shaver|8until it
audibly clicks firmly into place.
6.4 Pushing on/removing the comb
attachment
WARNING! Risk of injury!
~Switch off the device before replacing or changing a comb
attachment|1.
Pushing on
• In order to attach the comb attachment|1, push it over the
guide rails on the side of the device onto the beard trimmer
attachment|3, until it is heard to click into place.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

14 GB
Removing
1. Push the comb attachment|1upwards using a moderate
amount of force. The comb attachment|1separates from the
beard trimmer attachment|3.
2. Remove the comb attachment|1.
6.5 Shaving
DANGER! Risk of electric shock due to moisture!
~The shaver|8and the power unit|19 are not waterproof and
are therefore not allowed to be used in a shower/bath.
WARNING!
~Do not use the device on open wounds, cuts, sunburn or blis-
ters.
~Do not place excessive pressure on the shaving heads|4.
They are thin and can be damaged easily.
NOTES:
• Shaving is possible both in battery mode and in mains oper-
ation.
• Initial use may cause temporary irritation or redness of the
skin, as the skin has to adjust to shaving. This is normal and
usually lasts between 2 to 4 weeks.
• Hold the blade unit|4parallel to the surface of the skin, and
gently move it over your face using circular motions.
• Shave against the direction of your beard growth.
• Stretch your skin in complicated areas, such as the chin, to
achieve better results.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

15
GB
• Switch off the device after shaving, clean the parts carefully
(Chapter "Cleaning and care" on page 16) and to protect
the shaving heads|4, slide the protective cap|15 onto the
shaving attachment|5from below.
6.6 Cutting hairlines and beard
WARNING! Risk of injury!
~The points of the beard trimmer attachment|3are sharp.
Handle with care.
•Figure C: adjust the cutting length at the comb attach-
ment|1according to the desired hair length. Read the cut-
ting length on the side of the comb attachment|1at the
marking|2. The arrow symbol S|16 indicates which cutting
length is set. Now, shorten your beard step-by-step.
NOTE: ensure that the comb attachment|1is still firmly attached
to the device after adjustment.
• Use the device only with the beard trimmer attachment|3
and without comb attachment|1, to cut beard and hairline.
In this way you can cut hair lengths of 1-2 mm evenly.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

16 GB
7. Cleaning and care
DANGER! Risk of electric shock!
~The hand-held part must be disconnected from the power ca-
ble before it is cleaned in water.
WARNING! Risk of injury!
~Always switch off the device before cleaning it.
WARNING! Risk of material damage!
~The blade unit|4of the shaving attachment|5can be
cleaned using water. Do not use any other liquids.
~Do not use any astringent or abrasive cleaning agents.
NOTE: clean the device after every use.
7.1 Shaver
• Wipe down the housing of the shaver|8with a damp cloth.
7.2 Shaving attachment / blade unit
Dry cleaning of the shaving attachment
1. Clean the 3 shaving heads|4after each shave using the
cleaning brush|20.
2. Press the release button|6on the shaving attachment|5, so
that the blade unit|4opens.
3. Carefully tap the blade unit|4to empty it.
4. Remove the hair remnants by using the cleaning brush|20.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

17
GB
Wet cleaning of the blade unit
The shaving heads|4of the shaving attachment|5can be
cleaned with water.
1. Press the release button|6on the shaving attachment|5, so
that the blade unit|4opens.
2. Clean the blade unit|4under running water. Allow the water
to flow through the shaving heads|4from the inside to the
outside.
3. Allow the parts to dry completely.
4. Close the blade unit|4, so that it clicks into place.
Thorough cleaning of the blade unit
An integrated timer in the device adds up shaving times. After a
shaving period of 30 minutes, the cleaning symbol|13 starts
flashing. It reminds you of the thorough cleaning that you should
regularly perform. If you switch off the device while the cleaning
symbol is flashing, the timer will start counting shaving times
again from the beginning.
1. Press the release button|6on the shaving attachment|5, so
that the blade unit|4opens.
2. Figure D: pull the blade unit|4off the shaving attach-
ment|5by overextending it.
3. Figure E: carefully turn the locking wheel|17 marked with
arrows against the direction of the arrows, until the holder of
the shaving heads|18 can be lifted off.
4. Clean all parts under running water, and then allow them to
dry completely.
5. Reassemble the blade unit|4.
6. Figure F: carefully turn the locking wheel|17 in the direc-
tion of the arrows, until the holder of the shaving heads|18
can no longer be lifted off.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU

18 GB
7. Push the blade unit|4and the shaving attachment|5back to-
gether and close the blade unit|4, so that it clicks into place.
8. Push the shaving attachment| 5back onto the shaver|8 , and
ensure that it clicks firmly into place.
NOTE: for thorough cleaning, an ultrasonic bath is recommended.
7.3 Beard trimmer attachment
• Remove the comb attachment|1. Rinse the comb attach-
ment|1with water and let it dry before reattaching it to the
device.
• Remove the hair remnants from the beard trimmer attach-
ment|3by using the cleaning brush|20 included in the deliv-
ery.
• Every 6 months or so, apply a few drops of oil to the cutting
edge of the beard trimmer attachment|3. Using a soft, lint-
free cloth, wipe off the surplus oil, if necessary. Only use
acid-free oil, such as e.g. sewing machine oil.
BB1$6B%ERRN6HLWH'LHQVWDJ1RYHPEHU
