Silvercrest 331979 1907 User manual

STEAM IRON SDB 2400 F4
DAMPFBÜGELEISEN
Bedienungsanleitung
IAN 331979_1907
STEAM IRON
Operating instructions
ΑΤΜΟΣΊΔΕΡΟ
Οδηүίες χρήσης

GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 15
DE/AT/CH Bedienungsanleitung Seite 29
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

A
B

SDB 2400 F4 GB│IE│NI│CY │ 1 ■
Contents
Introduction...................................................2
Intended use ..................................................2
Package contents ..............................................2
Safety information .............................................2
Operating elements ............................................6
Before first use ................................................6
Filling the water tank ...........................................7
Plugging in and ironing .........................................7
Steam ironing .................................................8
Ironing with steam blast ........................................9
Pausing operation of the steam iron...............................9
After use .....................................................9
Drip-stop function ..............................................9
Automatic switch-off ...........................................10
Cleaning.....................................................10
Self-cleaning function.....................................................10
Housing and sole of the iron ...............................................11
Storage .....................................................11
Troubleshooting ..............................................11
Technical data ................................................12
Disposal .....................................................12
Kompernass Handels GmbH warranty............................13
Service................................................................14
Importer ............................................................... 14
Read these operating instructions carefully before using the appliance for the
first time, and retain them for future reference. Please pass these operating
instructions on to any future owner(s) of the appliance.

SDB 2400 F4
■ 2 │ GB│IE│NI│CY
Introduction
Congratulations on the purchase of your new appliance!
You have chosen a modern, high-quality product. These operating instructions
are part of the product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself with all
operating and safety instructions. This appliance may only be used as described
and for the purposes indicated. Please also pass these operating instructions on
to any future owner.
Intended use
The steam iron is intended exclusively for the ironing of textiles. The iron may
only be used indoors and in domestic households. All other use is deemed to be
improper use. It is not suitable for commercial use!
Package contents
▯ Steam Iron
▯ Measuring beaker
▯ Operating instructions
Safety information
DANGER! ELECTRIC SHOCK!
► The voltage of the power source must correspond with the
details given on the type plate of the appliance.
► To avoid potential risks, arrange for a defective appliance
to be checked and possibly repaired by qualified technicians,
or contact our Customer Service Department.
► To prevent accidents, have defective plugs and/or power
cables replaced immediately by an authorised specialist
technician or our Customer Service department.
► When disconnecting the appliance from the power source,
pull only on the plug itself, never on the cable.
► Never bend (kink) or crush the power cable, always route
it in such a way that it cannot come into contact with hot
surfaces and such that no one can step on or trip over it.

SDB 2400 F4 GB│IE│NI│CY │ 3 ■
DANGER! ELECTRIC SHOCK!
► After every use, before cleaning and when refilling with tap
water, always remove the plug from the mains power socket.
► Always unroll the power cable fully before switching on and
do not use an extension cable.
► Never touch the power cable or the plug with wet hands.
► Never use the steam iron adjacent to water contained in a
bath, shower, wash basin or other vessels. The proximity of
water is hazardous, even if the appliance is switched off.
► Under no circumstances should you immerse the steam iron
in any liquid or permit liquids to penetrate into the housing
of the steam iron. Do not expose the appliance to humidity
and do not use it outdoors. If any liquid gets into the housing,
disconnect the appliance from the mains power socket
immediately and have it repaired by a qualified technician.
► Do not open the steam iron housing. Have a defective steam
iron repaired only by an authorised technician.
► Do not use the appliance if it shows visible signs of damage,
has fallen or leaks water. Arrange for it to be repaired by
qualified specialists.
► Stop using the appliance if the anti-kink protection on the
power cable is damaged!
► You must always pull the plug out of the power socket
before filling the water tank with water.
► This appliance may be used by children aged 8 years or more
and by persons with reduced physical, sensory or mental
capabilities or lack of experience and/or knowledge if they
are supervised, or have been instructed in the safe use of the
appliance and have understood the potential risks. Do not
allow children to use the appliance as a plaything. Cleaning
and user maintenance may not be carried out by children
unless they are supervised.

SDB 2400 F4
■ 4 │ GB│IE│NI│CY
RISK OF INJURY!
► When the steam iron is hot, hold it only by the handle.
► Children should be supervised to ensure that they do not
play with the appliance.
► Never place your hands in the steam spray or on hot metal
parts.
► Do not open the filler opening for the water tank while the
iron is in use. Allow the steam iron to cool down first and
remove the plug from the power socket.
► The iron and its connecting cable must be kept out of the
reach of children under the age of than 8 while the iron is
switched on or cooling down.
► This steam iron should only be used and set down on stable
surfaces.
► Place the iron only on a level and heat-resistant surface.
The iron must be stable.
► When you want to put the steam iron down, always place it
on its base.

SDB 2400 F4 GB│IE│NI│CY │ 5 ■
RISK OF FIRE!
► Never leave a hot steam iron unattended if it is switched on
or connected to the mains power supply.
► Do not put the steam iron away until it has cooled down
completely.
► Do not clean the steam iron with solvents, alcohol or abrasive
cleaning agents.
These could damage it.
CAUTION! PROPERTY DAMAGE!
► If the clothing care instructions forbid ironing ( symbol),
the clothing item must not be ironed. Ignoring this warning
could lead to permanent damage to the clothing item.
► Use only the ironing temperatures stated in the care instructions
as suitable for the material. Otherwise, you could damage
the textiles. If you do not know the correct care instructions,
start with the lowest temperature setting.
► The water tank should be filled only with mains or distilled
water. Otherwise you will damage the steam iron.
► Do not clean the steam iron with solvents, alcohol or abrasive
cleaning agents.
These could damage it.

SDB 2400 F4
■ 6 │ GB│IE│NI│CY
Operating elements
Figure A:
1Water jet
2Filler opening for the water tank
3Steam control
4Steam blast button
5Spray button
6Control lamp for the automatic switch-off
7Temperature control lamp
8Temperature regulator
9Power cable with anti-kink protection
0Base
qSole of the iron
wSelf-clean button
Figure B:
eMeasuring beaker
Before first use
1) Remove the steam iron from the packaging.
RISK OF SUFFOCATION!
► Plastic bags may pose a risk. To avoid the risks of asphyxiation, keep
plastic bags out of the reach of toddlers and small children.
2) Fill the water tank with water (See the section Filling the water tank).
3) Insert the plug into a mains power socket supplying an electrical current as
detailed on the rating plate.
4) Move the temperature control 8to the "MAX" position.
5) Heat the steam iron up for several minutes at the highest setting.
6) Activate the steam blast button 4a couple of times so that steam comes
out of the sole of the iron q.
7) Then iron over a piece of old piece of material to remove any residues that
may remain on the sole of the iron q.

SDB 2400 F4 GB│IE│NI│CY │ 7 ■
Filling the water tank
1) Hold the iron in your hand at an angle.
2) Open the cover of the filler opening for the water tank 2.
3) Using the measuring beaker e, fill the water tank with water to the "MAX"
marking, but no further.
4) Close the cover of the filler opening for the water tank 2.
NOTE
► If the mains water in your location is rated as hard, we recommend that
you mix the mains water with some distilled water. Otherwise, the jets for
the steam blast function could become blocked with limescale prematurely.
To extend the optimal steam blast function, mix mains water with distilled
water according to the table.
Water hardness Ratio of distilled water to tap water
very soft/soft 0
medium 1: 1
hard 2: 1
very hard 3: 1
The water hardness level can be queried at your local water works.
Plugging in and ironing
Dry ironing without steam is possible at all temperatures, steam ironing is only
possible from the setting range on the temperature control 8.
1) Insert the plug into a mains power socket.
CAUTION! PROPERTY DAMAGE!
► If the clothing care instructions forbid ironing ( ), the garment must not
be ironed. Ignoring this warning could lead to permanent damage to the
clothing item.

SDB 2400 F4
■ 8 │ GB│IE│NI│CY
2) Check the care instructions on the labels in garments to see if they are suitable
for being ironed, and at which temperature setting.
Temperature control
symbol 8Material type
Synthetics
Silk, wool
Cotton, linen
3) Select the appropriate temperature setting with the temperature control 8.
NOTE
► Always place the iron on the base 0while it heats up. If you place the
iron on the sole of the iron qand do not move it, the automatic switch-off
will be activated after 30 seconds (see section Automatic switch-off)
and the appliance stops heating up.
■ The temperature control lamp 7lights up. When the set temperature has been
reached, the temperature control lamp 7goes out.
4) Wait until the temperature control lamp 7goes out.
■ To moisten the laundry, press the spray button 5.
■ This function is suitable for very dry and very crumpled garments.
Steam ironing
1) Set the steam control 3to the desired steam setting.
2) The temperature control 8must be set to at least the setting.
Otherwise no steam will be produced.

SDB 2400 F4 GB│IE│NI│CY │ 9 ■
Ironing with steam blast
■ The steam blast function is especially suitable for smoothing difficult-to-reach
parts of a garment.
NOTE
► The temperature control 8must be turned to at least the setting range .
Otherwise no steam will be produced.
1) Raise the steam iron slightly.
2) For a steam blast, press the steam blast button 4. You can also use the
steam blast function to smooth hanging textiles.
3) Hold the iron vertically and press the steam blast button 4.
Pausing operation of the steam iron
WARNING! RISK OF FIRE!
► Never leave a hot steam iron unattended if it is switched on or connected
to the mains power supply.
1) Move the temperature control 8to the "MIN" position.
2) Stand the steam iron only on the base 0.
After use
■ Remove the plug from the mains power socket.
■ Empty the water tank and clean the sole of the iron q.
■ Place the cooled-down steam iron on the base 0.
Drip-stop function
With conventional steam irons, water can drip from the sole of the iron qat low
temperatures. This iron however, possesses a new feature, the DRIP-STOP function
( ). At low temperatures, the iron automatically switches off the steam-
blast function. When this happens, you will hear a "CLICK". Then set a suitable
temperature with the temperature control 8. As soon as this is reached, steam
production is resumed.

SDB 2400 F4
■ 10 │ GB│IE│NI│CY
Automatic switch-off
This steam iron is fitted with an automatic switch-off system. This stops the iron
from heating up.
If the iron is resting on the sole of the iron qand is not moved for about
30 seconds, you will hear a warning beep and the control lamp for the
automatic switch-off 6will flash. The iron will stop heating up. To deactivate
the automatic switch-off, lift up the iron and move it gently from side to side.
The control lamp for the automatic switch-off 6goes out and the iron will heat
up again.
If the iron is on its base 0and is not moved for about 8 minutes, there will be a
warning beep and the control lamp for the automatic switch-off 6flashes. The iron
will stop heating up. To deactivate the automatic switch-off, lift up the iron and
move it gently from side to side. The control lamp for the automatic switch-off 6
goes out and the iron will heat up again.
NOTE
► The automatic switch-off is not intended as a substitute for removing the
plug from the mains power! This is merely intended to reduce the fire hazard
if you forget to switch off the iron!
Cleaning
Self-cleaning function
1) Fill the water tank to the "MAX" marking.
2) Insert the plug into the mains power socket.
3) Move the temperature control 8to the "MAX" position.
4) Set the steam control 3to maximum steam power.
5) Allow the steam iron to heat up until the temperature control lamp 7goes out
and then lights up again.
6) Hold the steam iron horizontally over a suitable container.
7) Press the self-clean button wand keep it pressed. Move the steam iron back
and forth a little. Steam and boiling water will flow from the steam exit holes in
the sole of the iron q. Any impurities that may be present are flushed out.
8) Release the self-clean button was soon as all of the water in the water tank is
used up.
9) Dry the sole of the iron qthoroughly. To do this, move the sole of the iron q
back and forth several times over a towel or an old piece of material.
10) Allow the steam iron to cool down before placing it in storage.

SDB 2400 F4 GB│IE│NI│CY │ 11 ■
Housing and sole of the iron
RISK OF ELECTROCUTION!
► Remove the plug before cleaning the device. There is a risk of electric shock!
RISK OF INJURY!
► Allow the appliance to cool down before cleaning it. Otherwise, there is
risk of burns!
CAUTION! PROPERTY DAMAGE!
► Do not use abrasive, aggressive or chemical cleaning agents. They can
damage the surface and also lead to irreparable damage to the appliance.
■ Clean the housing with a soft, dry cloth only.
■ Clean the sole of the iron qusing a damp cloth and a mild, non-scouring
detergent.
Storage
■ Store the cooled-down appliance in a clean, dust-free and dry location.
Troubleshooting
Problem Cause Solution
The steam iron blasts
out no steam/very
little steam
The reserves of tap
water in the steam
iron are depleted.
Fill the water tank with tap
water (See Filling the
water tank).
The steam iron does
not get hot.
The steam iron is
not plugged in or
is not switched on.
Insert the plug into a wall
power socket and adjust the
temperature control 8to the
desired ironing temperature.
The steam iron is
defective.
Arrange for the steam iron
to be repaired by qualified
specialists.

SDB 2400 F4
■ 12 │ GB│IE│NI│CY
Technical data
Supply voltage 220–240 V ∼ (alternating current), 50/60 Hz
Power consumption 2020–2400 W
Disposal
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal facility or your municipal
waste facility. Please observe the currently applicable regulations. Please contact
your waste disposal facility if you are in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
Dispose of all packaging materials in an environmentally friendly manner.

SDB 2400 F4 GB│IE│NI│CY │ 13 ■
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a
safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the date of
purchase of the product, we will either repair or replace the product for you or
refund the purchase price (at our discretion). This warranty service requires that
you present the defective appliance and the proof of purchase (receipt) within
the three-year warranty period, along with a brief written description of the fault
and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired
or replaced by us. The repair or replacement of a product does not signify the
beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and
defects present at the time of purchase must be reported immediately after un-
packing. Repairs carried out after expiry of the warranty period shall be subject
to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guide-
lines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or to fragile parts which
could be considered as consumable parts such as switches, batteries or parts
made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the
product regarding proper use of the product are to be strictly followed. Uses and
actions that are discouraged in the operating instructions or which are warned
against must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications/ repairs which have not been carried out by one of
our authorised Service centres.

SDB 2400 F4
■ 14 │ GB│IE│NI│CY
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g.IAN12345) available
as proof of purchase.
■ You will find the item number on the type plate on the product, an engraving
on the product, on the front page of the operating instructions (below left) or
on the sticker on the rear or bottom of the product.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase (till
receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product
videos and installation software at www.lidl-service.com.
This QR code will take you directly to the Lidl service page
(www.lidl-service.com) where you can open your operating instructions
by entering the item number (IAN) 123456.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: kom[email protected]
IAN 331979_1907
Importer
Please note that the following address is not the service address. Please use the
service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com

SDB 2400 F4 GR│CY │ 15 ■
Περιεχόμενα
Εισαγωγή ....................................................16
Προβλεπόμενη χρήση..........................................16
Περιεχόμενο συσκευασίας ......................................16
Υποδείξεις ασφαλείας ..........................................16
Στοιχεία χειρισμού ............................................20
Πριν από την πρώτη χρήση .....................................20
Πλήρωση δοχείου νερού .......................................21
Σύνδεση και σιδέρωμα .........................................21
Σιδέρωμα με ατμό .............................................22
Σιδέρωμα με ώθηση ατμού ......................................23
Προσωρινή απενεργοποίηση του ατμοσίδερου .....................23
Θέση εκτός λειτουργίας του ατμοσίδερου ..........................23
Λειτουργία διακοπής σταξίματος ................................23
Αυτόματη απενεργοποίηση .....................................24
Καθαρισμός..................................................24
Λειτουργία αυτοκαθαρισμού............................................... 24
Περίβλημα και επιφάνεια σίδερου........................................... 25
Φύλαξη .....................................................25
Διόρθωση δυσλειτουργιών .....................................25
Τεχνικά χαρακτηριστικά........................................26
Απόρριψη ...................................................26
Εγγύηση της Kompernass Handels GmbH .........................27
Σέρβις ................................................................28
Εισαγωγέας ............................................................28
Διαβάστε προσεκτικά τις οδηγίες χρήσης πριν από την πρώτη χρήση και
φυλάξτε τις για μελλοντική χρήση. Σε περίπτωση παράδοσης της συσκευής
σετρίτους, παραδώστε μαζί και τις οδηγίες χρήσης.

SDB 2400 F4
■ 16 │ GR│CY
Εισαγωγή
Συγχαρητήρια για την αγορά της νέας σας συσκευής!
Το προϊόν που αποκτήσατε είναι ένα σύγχρονο προϊόν υψηλής ποιότητας.
Οι οδηγίες χρήσης αποτελούν τμήμα αυτού του προϊόντος. Περιλαμβάνουν
σημαντικές υποδείξεις για την ασφάλεια, τη χρήση και την απόρριψη. Πριν
από τη χρήση του προϊόντος, εξοικειωθείτε με όλες τις υποδείξεις χειρισμού και
ασφάλειας. Χρησιμοποιείτε το προϊόν μόνο όπως περιγράφεται και για τα αναφε-
ρόμενα πεδία χρήσης. Παραδώστε όλα τα έγγραφα σε περίπτωση παράδοσης
του προϊόντος σε τρίτους.
Προβλεπόμενη χρήση
Το ατμοσίδερο προορίζεται αποκλειστικά για το σιδέρωμα ρούχων. Επιτρέπεται
να το χρησιμοποιείτε μόνο εντός κλειστών χώρων και σε ιδιωτικά νοικοκυριά.
Όλες οι άλλες χρήσεις ισχύουν ως μη σύμφωνες με τους κανονισμούς. Μην το
χρησιμοποιείτε για επαγγελματικό σκοπό!
Περιεχόμενο συσκευασίας
▯ Ατμοσίδερο
▯ Δοχείο μέτρησης
▯ Οδηγίες χρήσης
Υποδείξεις ασφαλείας
ΚΊΝΔΥΝΟΣ ΗΛΕΚΤΡΟΠΛΗΞΊΑΣ!
► Η τάση της πηγής ρεύματος πρέπει να συμφωνεί με τις πλη-
ροφορίες επάνω στην πινακίδα τύπου της συσκευής.
► Η επισκευή μίας ελαττωματικής συσκευής πρέπει να γίνεται
εγκαίρως από ένα εξουσιοδοτημένο συνεργείο ή θα πρέπει
να απευθύνεστε στην υπηρεσία εξυπηρέτησης πελατών, για
να αποφεύγετε κινδύνους.
► Τα βύσματα ή τα καλώδια που έχουν υποστεί ζημιά πρέπει
να αντικαθίστανται άμεσα από εξουσιοδοτημένο εξειδικευμένο
προσωπικό ή από το τμήμα εξυπηρέτησης πελατών, ώστε να
αποφεύγονται τυχόν κίνδυνοι.
► Τραβάτε πάντα μόνο από το βύσμα, ποτέ από το καλώδιο.

SDB 2400 F4 GR│CY │ 17 ■
ΚΊΝΔΥΝΟΣ ΗΛΕΚΤΡΟΠΛΗΞΊΑΣ!
► Μην κάμπτετε ή συμπιέζετε το καλώδιο και τοποθετείτε το
έτσι ώστε να μην έρχεται σε επαφή με καυτές επιφάνειες και
να μην μπορεί κανείς να πατήσει ή να σκοντάψει επάνω σε
αυτό.
► Τραβάτε το βύσμα από την πρίζα πριν από τον καθαρισμό,
κατά την πλήρωση με νερό της βρύσης και μετά από κάθε
χρήση.
► Πριν από την ενεργοποίηση ξετυλίγετε πάντα εντελώς το
καλώδιο και μη χρησιμοποιείτε καλώδια επέκτασης.
► Ποτέ μην πιάνετε το καλώδιο ή το βύσμα με βρεγμένα χέρια.
► Σε καμία περίπτωση μη χρησιμοποιείτε το ατμοσίδερο κοντά
σε νερό, το οποίο βρίσκεται σε μπανιέρες, ντους, νιπτήρες ή
σε άλλα δοχεία. Υπάρχει κίνδυνος από την ύπαρξη νερού,
ακόμα και όταν η συσκευή είναι εκτός ρεύματος.
► Σε καμία περίπτωση δεν επιτρέπεται να βυθίζετε το ατμοσίδερο
σε υγρά και δεν επιτρέπεται να αφήνετε να εισχωρούν υγρά
στο περίβλημά του. Απαγορεύεται η έκθεση της συσκευής
σε υγρασία, καθώς και η χρήση της σε εξωτερικούς χώρους.
Στην περίπτωση που εισχωρήσει πάντως υγρό στο περίβλημα
της συσκευής, αποσυνδέστε αμέσως το βύσμα της συσκευής
από την πρίζα και αναθέστε την επισκευή σε εξειδικευμένο
προσωπικό.
► Δεν επιτρέπεται να ανοίγετε το περίβλημα του ατμοσίδερου.
Το ελαττωματικό ατμοσίδερο επιτρέπεται να επισκευάζεται
μόνο από εξουσιοδοτημένο προσωπικό.
► Μη χρησιμοποιείτε το ατμοσίδερο σε καμία περίπτωση όταν
έχει εμφανείς φθορές, εάν έχει πέσει κάτω ή εάν τρέχει νερό.
Πρέπει πρώτα να γίνει επισκευή από εξουσιοδοτημένο προ-
σωπικό.
► Μη συνεχίζετε τη χρήση της συσκευής, εάν η προστασία
συστροφής του καλωδίου έχει φθαρεί!
