Silvercrest SDBS 2400 B2 User manual

IAN 306479
STEAM GENERATOR IRON SDBS 2400 B2
STEAM GENERATOR IRON
Operating instructions
ΑΤΜΟΣΊΔΕΡΟ ΜΕ ΜΠΟΙΛΕΡ
Οδηүίες χρήσης
DAMPFBÜGELSTATION
Bedienungsanleitung

GB/IE/NI/CY Operating instructions Page 1
GR/CY Οδηүίες χρήσης Σελίδα 23
DE/AT / CH Bedienungsanleitung Seite 45
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

A
BC

SDBS 2400 B2 GB│IE│NI│CY │ 1 ■
Contents
Introduction ..............................................2
Information about these operating instructions..............................2
Intended use........................................................2
Warnings ..........................................................2
Safety information .........................................3
Technical data .............................................7
Appliance description ......................................8
Setting up and connecting ...................................9
Package contents and transport inspection ................................9
Unpacking .........................................................9
Requirements for the set-up location ......................................9
Transport..........................................................10
Handling and operation ...................................10
Filling the water tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Before first use .....................................................11
Ironing without steam ................................................12
Steam ironing ......................................................13
Vertical steam ironing................................................14
Refilling with water ..................................................14
Cleaning and maintenance .................................15
Self-cleaning function ................................................15
Replacing the limescale filter ..........................................15
Cleaning the appliance ..............................................16
Troubleshooting ..........................................17
Storage .................................................18
Disposal.................................................19
Disposal of the appliance.............................................19
Disposal of packaging ...............................................19
Kompernass Handels GmbH warranty .......................20
Service ...........................................................21
Importer ..........................................................21
Ordering replacement parts ................................22

SDBS 2400 B2
■ 2 │ GB│IE│NI│CY
Introduction
Information about these operating instructions
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part
of this product. They contain important information about safety, usage and
disposal. Before using the product, please familiarise yourself with all operating
and safety instructions. Use the product only as described and for the range of
applications specified. Please also pass these operating instructions on to any
future owner.
Intended use
This appliance is only intended for the dry ironing or steam ironing of all types of
clothing, curtains and fabrics (including hanging). The appliance is not intended
for any other purpose, nor for use beyond the scope described. The appliance is
not intended for use in commercial or industrial environments.
The manufacturer accepts no responsibility for damage caused by failure to
observe these instructions, improper use or repairs, unauthorised modifications
or the use of unapproved replacement parts. The user bears sole liability.
Warnings
The following warnings are used in these operating instructions:
DANGER
A warning notice at this hazard level indicates an imminently
hazardous situation.
If the hazardous situation is not avoided, it could result in death or serious
physical injury.
► Follow the instructions in this warning to avoid a fatality or serious personal
injury.
WARNING
A warning at this hazard level indicates a potentially hazard-
ous situation.
Failure to avoid this hazardous situation could result in injury.
► Follow the instructions in this warning notice to prevent injury.

SDBS 2400 B2 GB│IE│NI│CY │ 3 ■
CAUTION
A warning notice at this hazard level indicates a risk of property
damage.
Failure to avoid this situation could result in property damage.
► Follow the instructions in this warning to prevent material damage.
NOTE
► A note provides additional information which will assist you in using the
appliance.
Safety information
The appliance complies with statutory safety regulations.
Improper use may result in personal injury and property
damage.
To ensure safe operation of the appliance, follow the safety
guidelines set out below:
■ The appliance may not be used if it has fallen down, if it
shows visible damage or is leaking.
■ Arrange for defective power plugs and/or cables to be
replaced as soon as possible by a qualified technician or
by our Customer Service Department to avoid any risk of
injury.
■ All repairs must be carried out by authorised specialist
workshops or by the Customer Service department.
Improper repairs may put the user at risk. They will also
invalidate any warranty claims.
■ Repairs to the appliance during the warranty period may
only be carried out by a customer service department
authorised by the manufacturer. Otherwise, no warranty
claims will be held for any subsequent damages.

SDBS 2400 B2
■ 4 │ GB│IE│NI│CY
■ Defective components must always be replaced with original
replacement parts. Compliance with safety requirements
can only be guaranteed if original replacement parts are
used.
■ This appliance may be used by children aged 8 years or
more and by persons with reduced physical, sensory or
mental capabilities or lack of experience and/or knowledge
if they are supervised, or have been instructed in the safe
use of the appliance and have understood the potential
risks. Do not allow children to play with the appliance.
Cleaning and user maintenance must not be carried out by
children unless they are supervised.
■ When it is switched on or cooling down, the appliance and
its power cable must be kept out of the reach of children
who are younger than 8 years old.
■ Do not allow children to use the appliance as a toy.
■ Do not place any objects on the appliance, especially not
on the connecting hose between the base station and the
iron.
■ Do not operate or place the appliance close to an open
flame (e.g. candles).

SDBS 2400 B2 GB│IE│NI│CY │ 5 ■
RISK OF ELECTRICAL SHOCK!
► The appliance should only be connected to correctly in-
stalled and earthed mains power sockets. Ensure that the rat-
ing for your local power supply corresponds with the details
on the rating plate of the appliance.
► Arrange for customer service to repair or replace connecting
cables and/or appliances that are not functioning properly
or have been damaged.
► Stop using the appliance if the anti-kink protection on the
power cable is damaged!
► Never immerse the appliance in water. Wipe it only with a
slightly damp cloth.
► Do not expose the appliance to rain, and never use it in a
humid or wet environment.
► Always hold the plug when handling the power cable and
never pull on the cable itself.
► Never touch the power cable or the plug with wet hands.
► Do not place the appliance itself or furniture etc. on the
power cable and ensure that it is not jammed.
► Ensure that the power cable never becomes wet or moist
during operation.
► Do not open the appliance housing or attempt to repair or
modify the appliance. If the housing is opened or improper
modifications are made, you run the risk of receiving a
potentially fatal electric shock and the warranty will be
void.
► Protect the appliance from water droplets or spray. Do not
place any vessels containing liquid (e.g. flower vases) on or
near the appliance.

SDBS 2400 B2
■ 6 │ GB│IE│NI│CY
RISK OF ELECTRICAL SHOCK!
► Always pull the plug out of the power socket after completing
ironing and before cleaning the appliance.
► You must always pull the plug out of the power socket before
filling the water tank with water.
RISK OF SCALDING OR BURNING!
Caution, hot surface!
► While the iron is turned on and a few minutes after the power
is turned off, the sole of the iron remains very hot. Never
touch the sole of the iron!
► When the iron is hot, hold it only by the handle .
► Children should be supervised to ensure that they do not
play with the appliance.
► Never place your hands in the steam spray or on the hot
metal parts.
► Do not aim the steam jet at people or animals!
► Never iron or steam clothes or other fabrics while they are
being worn or held by others.
WARNING! RISK OF INJURY!
► Always put the iron on the stand of the base station. Pull the
plug from the mains socket if you take a break from ironing.

SDBS 2400 B2 GB│IE│NI│CY │ 7 ■
CAUTION PROPERTY DAMAGE
► Never leave the appliance unattended while it is connected
to the mains power supply.
► Do not use carbonated water in the appliance.
► Do not operate the appliance without water, otherwise the
pump could burn out.
► Ensure that neither the power cable or the connection hose
come into contact with the hot sole of the iron.
► Do not scratch the sole of the iron. Avoid contact between
the sole of the iron and metal parts such as buttons or zips.
► Operate the appliance only on a stable and level working
surface.
Technical data
Steam iron station
Power supply 220–240V~ (AC) /50/60Hz
Power consumption 2000–2400 W
Max. fill level of the water tank 1.5 l
Steam production (Max.) approx. 120g/min. ± 10%
Heating time (steam ironing) approx. 2 minutes
Boiler pressure 5bar

SDBS 2400 B2
■ 8 │ GB│IE│NI│CY
Appliance description
Figure A:
1button for releasing the carrying handle
2Connecting hose
3Heat-up indicator lamp
4Temperature control
5Steam button
6Sole of the iron
7Stand
8Carrying handle
9Water tank grip
0Water tank
qBase station
wOn/off switch with integrated control lamp
Figure B:
eLimescale filter
rFiller opening
Figure C:
t"ECO" button
z"MAX" button
u"Anti calc" button
i"Self clean" button

SDBS 2400 B2 GB│IE│NI│CY │ 9 ■
Setting up and connecting
Package contents and transport inspection
The appliance is supplied with the following components as a standard:
● Steam Generator Iron
● Velcro tape for fastening the power cable
● Operating instructions
NOTE
► Check the package for completeness and signs of visible damage.
► If the delivery is incomplete or damage has occurred as a result of defec-
tive packaging or during transport, contact the Service hotline (see section
Service).
Unpacking
WARNING
Risk of suffocation!
► Do not allow children to play with packaging materials.
There is a risk of suffocation.
♦ Remove all parts of the appliance and the operating instructions from the
box.
♦ Remove all packaging material.
Requirements for the set-up location
The surface on which you set up the base station qmust be stable, level and
heat resistant.

SDBS 2400 B2
■ 10 │ GB│IE│NI│CY
Transport
WARNING
Risk of injury!
► Do not transport the appliance while it is in use. Allow the appliance to
cool down completely before moving it.
► Transport the appliance carefully and try to avoid swinging it excessively.
The iron could fall down.
NOTE
► Do not tip or swivel the appliance when the water tank 0is full.
Otherwise, water could drip from the filler opening r.
Use the carrying handle 8to transport the appliance.
♦ Fold the carrying handle 8upwards until it audibly engages.
The carrying handle 8is then fixed in this position .
♦ When you have finished using the carrying handle 8, hold down the
button1and then push the carrying handle 8 back downwards.
Handling and operation
WARNING
Risk of injury!
► While the iron is turned on and a few minutes after the power is turned off,
the sole of the iron 6remains very hot. Never touch the sole of the iron 6.
► Transport the appliance carefully and try to avoid swinging it excessively.
The iron could fall down.
CAUTION! PROPERTY DAMAGE!
► If the clothing care instructions forbid ironing, ( symbol), the clothing
item may not be ironed. Ignoring this warning could lead to permanent
damage to the clothing item.
Always note the care instructions in your clothes and comply with them.

SDBS 2400 B2 GB│IE│NI│CY │ 11 ■
Filling the water tank
NOTE
Use only tap water or distilled water.
If the mains water in your location is rated as hard, it is recommended that you
mix the mains water with some distilled water. Otherwise limescale deposits
can adversely affect the appliance functions.
Mix the tap water with distilled water as described in the table below:
Water hardness Ratio of distilled water to
tap water
very soft/soft -
medium 1:1
hard 2:1
very hard 3:1
Do not add water with any additives (such as starch, perfume, softeners or
other chemicals) to the water tank 0. These could damage the appliance as
residues can form in the steam chamber. The residues could contaminate the
clothing if they come out of the steam outlets.
♦ Pull the water tank 0by the grip 9out of the base station q.
♦ Fill the water tank 0with tap water via the filler opening r.
Do not fill above the MAX marking in the water tank 0.
♦ Push the water tank 0back into the base station quntil it clicks into place.
NOTE
► Do not tip or swivel the appliance when the water tank 0is full.
Otherwise, water could drip from the filler opening r.
Before first use
♦ Clean the sole of the iron 6using a slightly moist cloth.
♦ To remove any production residues, iron several times over an old, clean
cloth. Press the steam button 5a few times.

SDBS 2400 B2
■ 12 │ GB│IE│NI│CY
Ironing without steam
NOTE
Always set the temperature control 4to the lowest level (min) before switching
the appliance on. The symbols on the temperature control 4correspond to
the following settings:
Symbol Material Temperature
(approx.)
min – Synthetics 70–120°C
Silk 70–120°C
Wool 100–160°C
(– max) Cotton/linen 140–210°C
♦ Insert the plug into a mains power socket.
♦ Set the On/Off switch wto the position "1" to switch the appliance on. The
integrated control lamp in the On/Off switch w and the heat-up indicator
lamp 3light up, the "MAX" button z flashes.
♦ Turn the temperature control 4to set the required ironing temperature.
♦ The heat-up indicator lamp 3lights up during heating. As soon as the heat-
up indicator lamp 3goes out, the set temperature has been reached and
you can start ironing.
♦ Put the iron down on the stand 7on the base station qafter ironing.
Set the temperature control 4to "min".
♦ Set the On/Off switch wto the position "0" to switch the appliance off. The
integrated control lamp in the On/Off switch w and the "MAX" button z
go out.
♦ Pull the plug out of the
mains socket.

SDBS 2400 B2 GB│IE│NI│CY │ 13 ■
Steam ironing
♦ Fill the water tank 0with water if necessary.
♦ Insert the plug into a mains power socket.
♦ Set the On/Off switch wto the position "1" to switch the appliance on. The
integrated control lamp in the On/Off switch w and the heat-up indicator
lamp 3light up, the "MAX" button z flashes.
♦ Turn the temperature control 4to set the required ironing temperature. The
temperature control 4must be set within the range to produce steam.
♦ The heat-up indicator lamp 3lights up during heating. As soon as the set
temperature has been reached, the heat-up indicator lamp 3goes out.
♦ Adjust the steam power:
–Press the "MAX" button zto create maximum steam.
–Press the "ECO" button tto make the appliance produce less steam.
♦ As soon as the "MAX" z or "ECO" button tlights up continuously
(depending on the setting), you can start steam ironing.
♦ While you are ironing, you can now press and hold the steam button 5to
continuously spray steam onto the items being ironed from the sole of the
iron 6. Release the steam button5to stop producing steam.
NOTE
When you press the steam button 5, it can take a few seconds until steam
comes out of the sole of the iron 6.
♦ Put the iron down on the stand 7on the base station qafter ironing.
Set the temperature control 4to "min".
♦ Set the On/Off switch wto the position "0" to switch the appliance off. The
integrated control lamp in the On/Off switch w and the steam control lamp
"MAX" z or "ECO" tgo out.
♦ Pull the plug out of the mains socket.

SDBS 2400 B2
■ 14 │ GB│IE│NI│CY
Vertical steam ironing
♦ Hang the fabric to be ironed on a clothes hanger which is hung against a
heat-resistant surface.
♦ Insert the plug into a mains power socket.
♦ Set the On/Off switch wto the position "1" to switch the appliance on. The
integrated control lamp in the On/Off switch w and the heat-up indicator
lamp 3light up, the "MAX" button z flashes.
♦ Turn the temperature control 4to set the required ironing temperature. The
temperature control 4must be set within the range to produce steam.
♦ The heat-up indicator lamp 3lights up during heating. As soon as the set
temperature has been reached, the heat-up indicator lamp 3goes out.
♦ Adjust the steam power:
–Press the "MAX" button zto create maximum steam.
–Press the "ECO" button tto produce less steam.
♦ As soon as the "MAX" z or "ECO" button tlights up continuously
(depending on the setting), you can start steam ironing.
♦ Hold the steam iron in a vertical position and press the steam button 5.
♦ Touch the fabric lightly with the sole of the iron 6 and steam it to remove
creases.
♦ Release the steam button 5to stop the appliance producing steam.
♦ Put the iron down on the stand 7on the base station qafter ironing.
Set the temperature control 4to "min".
♦ Set the On/Off switch wto the position "0" to switch the appliance off. The
integrated control lamp in the On/Off switch w and the steam control lamp
"MAX" z or "ECO" tgo out.
♦ Pull the plug out of the mains socket.
Refilling with water
You can refill the appliance with water while it is switched on.
♦ Put the iron down on the stand 7on the base station q.
♦ Refill the water as described in the section "Filling the water tank".

SDBS 2400 B2 GB│IE│NI│CY │ 15 ■
Cleaning and maintenance
WARNING!
Risk of injury!
► Before cleaning the appliance, disconnect the plug from the mains power
socket!
► Allow the appliance to cool down completely if necessary.
► Never immerse the appliance in water to clean it.
CAUTION
Damage to the appliance!
► To avoid irreparable damage to the appliance, ensure that no moisture can
penetrate the appliance during cleaning.
► Do not use aggressive scouring cleaners or solvents, or a wire brush or
other abrasive objects to clean the surfaces.
Self-cleaning function
♦ Fill the water tank 0with water if necessary.
♦ If the appliance is switched on, set the temperature control 4to "MAX" and
wait until the appliance has heated up.
♦ Hold the iron horizontally over a suitable container or sink.
♦ Press the "Self clean" button ifor about 5 seconds. The self-cleaning
process starts and the "Self clean" button iflashes. Steam flows from
the steam exit holes in the sole of the iron 6. Any impurities that may be
present are flushed out.
♦ As soon as the self-cleaning process is complete (after about 80 seconds),
the "Self clean" buttonistops flashing.
Replacing the limescale filter
After pressing the steam button 5for a total of around 11 hours, it is time to
replace the limescale filter e.
The appliance will notify you when the time comes: As soon as the "Anti calc"
button u flashes, you need to change the limescale filter e.
Proceed as follows:
♦ Set the On/Off switch wto the position "0" to switch the appliance off.
♦ Pull the water tank 0by the grip 9out of the base station q.
♦ Pull the limescale filter eupwards out of the limescale filter shaft.
♦ Place the new limescale filter ein the limescale filter shaft and press it
down until it is firmly in place.

SDBS 2400 B2
■ 16 │ GB│IE│NI│CY
♦ Push the water tank 0back into the base station quntil it clicks into place.
♦ Set the On/Off switch wto the position "1" to switch the appliance on.
♦ Press the "Anti calc" button u. The "Anti calc" button u goes out.
You have now completed replacement of the limescale filter e.
NOTE
► After replacing the limescale filter e, it takes about 90 seconds until steam
starts coming out of the sole of the iron 6again the next time you use the
appliance.
NOTES
Note the following when handling the limescale filter e:
Not suitable for consumption/drinking!
Keep the limescale filter eout of the reach of children.
Store the spare limescale filter in a cool, dry location.
If the appliance is used regularly, it is advisable to always have a replacement
limescale filter available. This means that you can replace the limescale filter
eimmediately as soon as the "Anti calc" button u lights up.
You can order new limescale filters efrom our service department (see
section Ordering replacement parts).
Cleaning the appliance
♦ Remove the power plug from the mains power socket if the appliance is
plugged in.
♦ If necessary, allow the appliance to cool down before cleaning it.
♦ Clean the surfaces of the iron and the base station qwith a soft, damp
cloth only.
♦ Clean the sole of the iron 6 with a soft, damp cloth. Ensure that the sole of
the iron 6is not scratched.
♦ Pour out the residual water in the water tank 0:
–Pull the water tank 0 out of the base station q and tip the remaining
water into the wash basin.
–Push the water tank 0back into the base station quntil it clicks into
place.
♦ The appliance must be completely dry before further use.

SDBS 2400 B2 GB│IE│NI│CY │ 17 ■
Troubleshooting
Fault Possible cause Remedy
The appliance is
not working.
Fault with the power supply. Check whether the mains plug
is firmly in the mains socket.
The appliance is not switched on. Set the On/Off switch wto
the position "1" to switch the
appliance on.
The appliance
produces no/too
little steam.
There is not enough water in the
water tank 0.
Fill the water tank with water 0.
The appliance is not sufficiently
hot.
Wait until the temperature
indicator lamp goes out.
The temperature control 4has
been set in the –
range.
Set a temperature suitable for
steam ironing (setting range ).
The steam unit has not been used
for a long time or is being used
for the first time.
Hold the steam button 5down a
little longer. The steam takes a little
time until it comes out of the sole of
the iron 6.
Water drips out
of the sole of the
iron 6.
If steam ironing is paused briefly,
the cooling steam condenses in
the connecting hose 2.
This can lead to drips.
This is normal. Hold the iron over
a collecting cloth or container
and press the steam button 5.
Steam will discharge from the
sole of the iron 6instead of
water after a few seconds.
Then you can continue ironing.
The set temperature is too low for
steam ironing.
Set a temperature suitable for
steam ironing (setting range ).
Wet patches occur
on the items being
ironed.
Such areas can be caused by
steam condensing on the ironing
board.
Wipe the wetness from the
ironing board and iron the wet
patches dry (without steam).
NOTE
► If you are unable to resolve the problem by taking any of the aforementioned steps,
please contact the service department.
