Silvercrest SND 3600 A1 User manual

Slide & Negative Scanner SND 3600 A1
3
KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SND 3600 A1-12/10-V3
IAN: 55973
Slide & Negative Scanner
Operating instructions
Negatiivien digitointilaite
Käyttöohje
Scanner för negativ
Bruksanvisning
Negativ scanner
Betjeningsvejledning
CV_55973_SND3600A1_LB3.indd 1-4CV_55973_SND3600A1_LB3.indd 1-4 21.01.2011 11:36:19 Uhr21.01.2011 11:36:19 Uhr

SND 3600 A1
12
3
4
5
6
7
2 x
2 x
CV_55973_SND3600A1_LB3.indd 5-8CV_55973_SND3600A1_LB3.indd 5-8 21.01.2011 11:36:20 Uhr21.01.2011 11:36:20 Uhr

1
SND 3600 A1
GB
IE
Index
Introduction . . . . . . . . .2
Information for these
operating instructions . . . . . 2
Copyright . . . . . . . . . . . . . . 2
Limited liability . . . . . . . . . . 2
Warnings . . . . . . . . . . . . . . 3
Proper use . . . . . . . . . . . . . 3
Safety. . . . . . . . . . . . . .4
Basic Safety Instructions . . . 4
Setting up and
connecting . . . . . . . . . .6
Safety instructions. . . . . . . . 6
Package contents and
transport inspection . . . . . . 6
Disposal of the packaging . 7
Requirements for the set-up
location . . . . . . . . . . . . . . . 7
Connecting to a computer . 8
Operating
components . . . . . . . .14
Handling and
operation . . . . . . . . . .14
Inserting film strips . . . . . . 14
Inserting slides . . . . . . . . . 14
Starting the ArcSoft
MediaImpression 2
programme . . . . . . . . . . . 15
ArcSoft MediaImpression 2
programme. . . . . . . . . . . . 15
Scanning with the ArcSoft
MediaImpression 2
programme . . . . . . . . . . . 16
After Use . . . . . . . . . . . . . 19
Cleaning . . . . . . . . . .20
Safety instructions. . . . . . . 20
Cleaning. . . . . . . . . . . . . . 20
Troubleshooting . . . .21
Safety instructions. . . . . . . 21
Malfunction causes and
remedies. . . . . . . . . . . . . . 21
Storage/Disposal . . .22
Storage. . . . . . . . . . . . . . . 22
Disposal of the device . . . 22
Appendix . . . . . . . . . .23
Technical data . . . . . . . . . 23
Note regarding the
conformity declaration . . . 24
Warranty . . . . . . . . . . . . . 24
Service . . . . . . . . . . . . . . . 25
Importer . . . . . . . . . . . . . . 25

Introduction
GB
IE
2SND 3600 A1
Introduction
Information for these operating instructions
These operating instructions are a component of the Slide & Negative
Scanner SND 3600 A1 (henceforth designated as the device) and
supplies you with important information for intended use, safety and
connection as well as operation of the device.
The operating instructions must be constantly kept available close to
the device. They are to be read and used by anyone assigned to the
operation and repairing of the device. Keep these operating instruc-
tions and hand them over with the device to any future owners.
Copyright
This documentation is copyright protected.
Any copying and/or printing, including partial copying/printing,
as well as reproductions of the diagrams, even in an altered state is
only allowed with written permission from the manufacturer.
Limited liability
All technical information, data and information for connection and
operation, contained in these operating instructions correspond to
the latest at the time of printing and, to the best of our knowledge,
take into account our previous experience and know-how.
No claims can be derived from the details, illustrations and descriptions
in these instructions.
The manufacturer assumes no responsibility for damage caused
by failure to observe the instructions, improper use, inappropriate
repairs, making unauthorized changes or for using unapproved
replacement parts.

Introduction
3
SND 3600 A1
GB
IE
Warnings
In the current operation instructions the following warnings are used:
WARNING
A warning of this danger level signifies a possible
dangerous situation.
If the dangerous situation is not avoided it can lead to injuries.
The directives in this warning are there to avoid personal►
injuries.
IMPORTANT
A warning of this danger level signifies possible
property damage.
If the situation is not avoided it can lead to property damage.
The directives in this warning are there to avoid property►
damage.
NOTICE
A notice signifies additional information that assists in the►
handling of the device.
Proper use
This device is intended exclusively for the non-commercial use of
scanning and digitizing film negatives and slides.
This device is not intended for any other use or for uses beyond those
mentioned.

Safety
GB
IE
4SND 3600 A1
WARNING
Danger from unintended use!
Danger can come from the device if used for unintended purposes
and/or other types of use.
Use the device exclusively for intended purposes.►
Observe the procedures described in these operating instructions.►
Claims of any kind for damage resulting from unintended use will not
be excepted.
The operator alone bears liability.
Safety
In this chapter you receive important safety information regarding
handling of the device.
This device complies with the statutory safety regulations. Improper
use can lead to personal injury and property damage.
Basic Safety Instructions
For safe handling of the device observe the following safety information:
Before use check the device for visible external damage. Do not■
put into operation a device that is damaged or has been dropped.
Damaged cables or connections should be replaced by authorized■
qualified persons or by the customer service department.

Safety
5
SND 3600 A1
GB
IE
Persons who, due to their physical, intellectual or motor abilities,■
are incapable of operating the device safely may only use the
device under supervision or direction from a responsible person.
Only permit children to use the device under supervision.■
Repairs should only be carried out by authorized specialist com-■
panies or by the customer service department. Incorrect repairs
can result in signifi
cant dangers for the user. In addition warranty
claims become void.
A repair to the device during the warranty period may only be■
carried out by a customer service department authorized by the
manufacturer otherwise no additional warranty claims can be
considered for subsequent damages.
Defective components may only be replaced with original■
replacement parts. Only by using original replacement parts can
you guarantee that the safety requirements are complied with.
Do not carry out any unauthorised reconstructions or alterations■
to the device.
Protect the device from moisture and liquid penetration.■
Do not operate the device in the vicinity of open flames.■

Setting up and connecting
GB
IE
6SND 3600 A1
Setting up and connecting
Safety instructions
WARNING
Personal injury and property damage can occur
during initial operation of the device!
Observe the following safety information to avoid danger:
Packaging material should not be used as a play thing.►
There is a risk of suffocation!
Package contents and transport inspection
The device is delivered with the following components as standard:
Scanner▯
2 x Slide holder▯
2 x Negative holder▯
Programme CD▯
Cleaning brush▯
Operating instructions▯
NOTICE
Check the contents to make sure everything is there and for►
visible damage.
If the contents are not complete or are damaged due to►
defective packaging or through transportation contact the
service hotline (see the section “Service”).

Setting up and connecting
7
SND 3600 A1
GB
IE
Disposal of the packaging
The packaging protects the device from transport damage. The packag-
ing materials are selected from the point of view of their environmental
friendliness and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit
saves on raw material and reduces generated waste.
Dispose of packaging material that is no longer needed
according to the regionally established regulations.
NOTICE
If possible preserve the device's original packaging during►
the warranty period so that in the case of a warranty claim
you can package the device properly for return.
Requirements for the set-up location
For safe and faultless operation of the device the set-up location must
fulfill the following provisions:
The device must be placed on a firm, flat and level surface.■
Do not place the device in a hot, wet or very damp environment■
or in the vicinity of flammable materials.
Place the device so that it is not subjected to direct sunlight.■

Setting up and connecting
GB
IE
8SND 3600 A1
Connecting to a computer
System prerequisites
You will need a computer with a vacant USB port and with the♦
operating system Windows®XP, Windows®Vista or Windows®
7 from the Microsoft®corporation.
Installation of the ArcSoft MediaImpression 2 programme
NOTICE
In these operating instructions only the programme sections►
are described that you will need for scanning your slides
and/or film negatives. You can find further information in the
programme's on-line help.
The illustrations and descriptions refer to the operating►
system Microsoft®Windows®7. The illustration depictions
can differ, depending on the display settings, with other
operating systems.
Insert the supplied programme CD into your computer’s CD drive.♦
The window “Automatic playback” will be displayed.
Click on the button “run autorun.exe”.♦
The installation begins and the start window is displayed.

Setting up and connecting
9
SND 3600 A1
GB
IE
NOTICE
If you have switched off the autostart function and the installa-►
tion process does not begin automatically you can start the
installation process by double clicking on the file "autorun.exe"
in the CD's main directory.
Click on the button “Arcsoft Software” to install the “ArcSoft♦
MediaImpression 2“ programme.
The installation wizard will be configured.

Setting up and connecting
GB
IE
10 SND 3600 A1
The start window of the installation wizard will be displayed.
Click on the button “Continue♦ >”.
The window “License agreement” will be displayed.
Click on the button “Yes”.♦

Setting up and connecting
11
SND 3600 A1
GB
IE
The window for the selection of the installation directory will be
displayed.
Select the desired installation directory and click on the button♦
“Continue >”.
The window for the selection of the programme folders (Entry in
the Windows start menu) will be displayed.
Select the desired programme folder and click on the button♦
“Continue >”.

Setting up and connecting
GB
IE
12 SND 3600 A1
The programme will be installed and the installation progress
will be displayed.
The window “Associated file formats” will be displayed.
Select the file format that is to be associated with the programme♦
and click on the button “Continue >”.

Setting up and connecting
13
SND 3600 A1
GB
IE
The display will show that the installation has been completed.
Click on the button “Finish”.♦
The start window will be displayed again.
Click on the button “Exit Installation” to exit the installation♦
programme.
Connection
Connect the USB cable♦ 4to a USB port on your computer.

Operating components/Handling …
GB
IE
14 SND 3600 A1
Operating components
LED PWR
2SCAN button.
3Slot for film and/or slide holders.
4USB connection cable.
5Film holder.
6Slide holder.
7Cleaning brush
Handling and operation
In this chapter you receive important information for the handling
and operation of the device.
Inserting film strips
Release the fastener on the front of the film holder♦ 5and open
the holder.
Insert the film strip into the holder correctly orientated.♦
Close the holder making sure that the cover locks into place.♦
Inserting slides
Release the fastener on the front of the slide holder♦ 6and
open the holder.
Insert a maximum of 3 framed slides, correctly orientated, into♦
the holder.
Close the holder making sure that the cover locks into place.♦

Handling and operation
15
SND 3600 A1
GB
IE
Starting the ArcSoft MediaImpression 2 programme
Start the ArcSoft MediaImpression 2 programme by double♦
clicking on the programme icon on the desktop or select the
corresponding input from the start menu.
ArcSoft MediaImpression 2 programme
There are four options available:
1. Image: Open an available image on the computer or memory
medium.
2. Capture: For the scanning of new images
3. Simple reproduction: Fast image editing
4. Image editing tools: Detailed image editing
NOTICE
In these operating instructions only the programme sections►
are described that you will need for scanning your slides
and/or film negatives. You can find further information in
the programme's online help.
12
3
4

Handling and operation
GB
IE
16 SND 3600 A1
Scanning with the ArcSoft MediaImpression 2 programme
Connect the device. The LED♦ PWR lights up.
Start the ArcSoft MediaImpression 2 programme.♦
Click on the button “Capture”.♦
When the programme is first started after the installation a cali-
bration and data collection process takes place. Make sure that
no slide or negative holders are inserted into the device.
In the displayed information window click on the button “OK”♦
to start calibration and data collection. The first calibration and
data collection process can take several minutes.
The calibration progress will be displayed.
After completion of the calibration the programme window will
be displayed.

Handling and operation
17
SND 3600 A1
GB
IE
The window “Capture from scanner” will be displayed.
Carry out the necessary settings:♦
File format, quality (only with JPG files), memory location, film
type, colour depth, scan resolution
NOTICE
The colour depth is defined as 24 Bit. A scan with 1600 DPI►
has a resolution of 2520 x 1680 Pixel and a scan with
3600 DPI has a resolution of 5040 x 3360 Pixel.
Click on the button “Capture”.♦
The “Capture” window is displayed.

Handling and operation
GB
IE
18 SND 3600 A1
Slide the holder with the negatives and/or slides to be scanned♦
into the slot 3on the device until it locks into place.
The scan motif will be displayed in the preview field .
NOTICE
A holder that has been inserted into the device cannot be pulled►
out again, it has to be pushed completely through the device.
Adjust the holder, if required, until the scan motif is displayed♦
optimally in the preview window.
If necessary, you can set the electrical balance (Balance), the♦
exposure (Exposure), the brightness (Brightness), the contrast
(Contrast) and the saturation (Saturation) by pressing on the
button “Adjust”.
A settings window will be opened.
Click on♦ to increase the corresponding value and on to
decrease the corresponding value.
Use the slide controller to adjust the electrical balance (Colour
balance).
Click on the “OK” button to accept the setting and return to the♦
“Capture” window.
