Silvercrest 304610 User manual

IAN 304610
HAND-HELD WET & DRY VACUUM CLEANER
SAS 7.4 LI D3
HANDSTAUBSAUGER
Bedienungsanleitung
HAND-HELD WET & DRY
VACUUM CLEANER
Operating instructions
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΟ
ΣΚΟΥΠΑΚΙ ΧΕΙΡΟΣ
Οδηүίες χρήσης

GB/IE/NI / CY Operating instructions Page 1
GR/ CY Οδηүίες χρήσης Σελίδα 17
DE/ AT /CH Bedienungsanleitung Seite 33
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.

q
0
8
7
6
9
1 2
3
4
5

GB│IE│NI│CY │ 1 ■
SAS 7.4 LI D3
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................4
Important safety instructions.....................................4
Prior to first use................................................7
Information about the batteries ..................................7
Information on the charge indicator lamp ..........................8
Installation of the wall bracket ...................................8
Charging .....................................................9
Operation ...................................................10
Cleaning.....................................................12
Disposal .....................................................13
Kompernass Handels GmbH warranty............................14
Service................................................................15
Importer ............................................................... 15

■ 2 │ GB│IE│NI│CY SAS 7.4 LI D3
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of this
product. They contain important information on safety, usage and disposal. Before
using the product, familiarise yourself with all operating and safety instructions. Use
the product only as described and for the specified areas of application. Please also
pass on these operating instructions to any future owner.
Intended use
This handheld vacuum cleaner may only be used to vacuum dry or wet surfaces,
or dry or wet materials and liquids. Do not vacuum people or animals with this
appliance. Any other usage of or modification to the appliance is deemed to be
improper and carries a significant risk of accidents. The manufacturer accepts no
liability for damages that result from improper use of the appliance or are caused
by the incorrect operation of it. The appliance is not intended for commercial use.
Package contents
●Hand-Held Wet & Dry Vacuum Cleaner
●Crevice tool
●Wet suction nozzle
●Wall bracket
●Mounting kit
●Mains adapter
●Operating instructions
Check the package contents for completeness directly after unpacking.

GB│IE│NI│CY │ 3 ■
SAS 7.4 LI D3
Description of the appliance
1Wet suction nozzle
2Crevice nozzle
3Wall bracket
4Mains adapter
5Barrel plug
6On/off switch
7Charge indicator lamp (red/green)
8Release button
9Dust filter bag
0Dust filter
qDirt container
NOTE
► This appliance is supplied with non-charged batteries. The batteries must be
charged before first use.

■ 4 │ GB│IE│NI│CY SAS 7.4 LI D3
Technical data
Mains adapter 4
Input voltage/current 100–240 V ∼(alternating current), 50/60 Hz
0,2 A
Output voltage/current 9,6 V (direct current), 500 mA
Protection class II / (double insulation)
Protection type IP20: Protection against solid objects with
a diameter of more than 12.5 mm
Efficiency class 5
Nominal ambient tempera-
ture (ta) 40°C
Polarity
Manufacturer E-TEK Electronics Manufactory Ltd.
Type designation ZDM096050BS-C
Appliance
Input voltage 9,6 V (direct current), 500 mA
Polarity
Rechargeable batteries
Capacity 2200 mAh
Rechargeable battery 7.4 V (2 x 3.7 V Lithium-ion rechargeable
batteries)
Important safety instructions
DANGER – ELECTRIC SHOCK!
► Do not charge or use the appliance outdoors.
► Never use the handheld vacuum cleaner if the cable, plug
or casing are damaged.
► To avoid risks, arrange to have damaged power cables and/
or plugs replaced as soon as possible by a qualified specialist.

GB│IE│NI│CY │ 5 ■
SAS 7.4 LI D3
DANGER – ELECTRIC SHOCK!
► Have all repairs carried out by a specialist workshop. Under
no circumstances should you open the appliance yourself.
Repairs that are not carried out by a specialist workshop
could lead to physical injuries.
► Before switching on the appliance, make sure that the mains
voltage corresponds to the voltage indicated in the technical
data for the appliance.
► Never touch the mains adapter or the appliance with wet or
damp hands.
► Do not use the mains adapter with an extension cable; connect
the mains adapter directly to a power socket.
WARNING! RISK OF INJURY!
► Do not change any accessories while the appliance is
switched on.
► Do not use the handheld vacuum cleaner for vacuuming up
sharp objects or glass shards.
► Never vacuum up burning matches, glowing ashes or ciga-
rette butts.
► Do not use the handheld vacuum cleaner for vacuuming up
chemical products, stone dust, gypsum, cement or similar
particles.
► This appliance is not suitable for use with inflammable and
explosive substances or chemical and aggressive liquids.
► Always store the appliance indoors. To prevent accidents,
keep the appliance in a dry location when not in use.
► Under extreme conditions, leaks in the battery cells may
occur. In the event that battery fluid comes into contact with
skin or eyes, the affected area must be rinsed off with water
immediately. Contact a physician.

■ 6 │ GB│IE│NI│CY SAS 7.4 LI D3
WARNING! RISK OF INJURY!
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance tasks may not be carried
out by children unless they are supervised.
► This appliance may be used by children aged 8 years and
above and by persons with limited physical, sensory or mental
capabilities or lack of experience and knowledge, provided
that they are under supervision or have been told how to use
the appliance safely and are aware of the potential risks.
► Take special care when using the handheld vacuum cleaner
on stairs.
CAUTION! PROPERTY DAMAGE!
► Use only accessories recommended by the manufacturer.
► The mains adapter may not be used for other purposes.
Never carry the wall bracket or the mains adapter by the
cable. Do not pull on the cable when you want to move the
appliance.
► Always grip the power plug to disconnect the appliance
from the power supply.
► Always be sure to keep the handheld vacuum cleaner away
from heating elements, ovens or other heated appliances
and surfaces.
► Make sure that the ventilation slits are never obstructed.
A blocked ventilation circuit can result in overheating and
damage to the appliance.
► The appliance is not protected against splashes. You should
therefore only vacuum liquid up until the dirt container is
filled to the MAX mark!

GB│IE│NI│CY │ 7 ■
SAS 7.4 LI D3
CAUTION! PROPERTY DAMAGE!
► This product contains rechargeable batteries. Do not throw
the batteries into a fire and do not subject them to high
temperatures. There is a risk of explosion!
► Do not use the handheld vacuum cleaner without the dust
filter inserted.
► Do not use the mains adapter for a different product and
do not attempt to charge this appliance with a different
mains adapter. Use only the mains adapter supplied with
this appliance.
► Never attempt to recharge non-rechargeable batteries.
► The batteries in this appliance cannot be replaced.
Prior to first use
1) Remove all packaging materials from the appliance.
2) Press the dust filter bag 9and the dust filter 0a little way into the dirt
container q. They might have loosened during transport and thus not be
positioned correctly inside the dirt container q.
3) Place the dirt container qon the motor unit:
–Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
–Press the release button 8 and push the dirt container qonto the motor
unit at the same time.
–Let go of the release button 8so that the restraint engages in the recess.
The dirt container qis now firmly seated on the motor unit.
Information about the batteries
■ This handheld vacuum cleaner is powered by rechargeable lithium-ion batteries.
The batteries must be charged for around 5 hours before using the handheld
vacuum cleaner for the first time.
■ For care of the batteries, we recommend the following: Once the batteries have
been charged, disconnect the mains adapter 4from the mains socket. Do not
plug the mains adapter 4back into the mains socket until the vacuuming perfor-
mance drops noticeably and the charge indicator lamp 7flashes green.
■ When the batteries are completely discharged, the appliance switches off
and the charge indicator lamp 7flashes green/red alternately for approx.
60 seconds. Start charging the appliance.

■ 8 │ GB│IE│NI│CY SAS 7.4 LI D3
Information on the charge indicator lamp
The charge indicator lamp 7supplies the following information:
The charge indicator light 7…Meaning
Flashing red the batteries are charging.
Flashing green the batteries are low and should be
charged soon.
Flashing alternately green/red the batteries are completely discharged
and should be charged.
Lights up green the batteries are fully charged.
the appliance is in operation.
Installation of the wall bracket
DANGER – ELECTRIC SHOCK!
► Ensure that there are no power cables or other conduits or pipes in the wall
at the location where you intend to bore the holes for the wall bracket 3.
Drilling into a current-carrying electric cable can be potentially fatal!
1) Insert the barrel plug 5on the mains adapter 4into the wall bracket 3as
shown in the following diagram:
First, feed the cable through the cable routing and then push the barrel plug
5into the opening in the wall bracket 3so that it is firmly in place. Secure
the barrel plug 5by turning it.
2) Select a suitable installation location for the wall bracket 3:
It must be possible to remove the handheld vacuum cleaner easily and there
must be an accessible mains power socket for the mains adapter 4.
3) Drill two holes about 60 mm apart. Use the wall bracket 3to mark the holes,
to ensure the correct spacing. The drill holes must be suitable for 6 mm wall
plugs.

GB│IE│NI│CY │ 9 ■
SAS 7.4 LI D3
4) Push the wall plugs into the holes and then screw the wall bracket 3firmly
into place using the screws.
5) You can place the nozzles on the accessories holder on the side.
6) Connect the mains adapter 4to a mains power socket.
Charging
NOTE
► Check to ensure that the on/off switch 6has been pushed back (to the
position "0") before starting the charging process.
■ Place the handheld vacuum cleaner from above into the wall bracket 3so
that the barrel plug 5slips into the socket on the handheld vacuum cleaner.
The charge indicator lamp 7lights up red and the charging process begins.
■Important: The charge indicator lamp 7lights up green once the
handheld vacuum cleaner is charged enough to vacuum again. This does
not mean that all the batteries are completely charged. When the charge
indicator lamp 7lights up green, the batteries are charged to around 80%.
■ When charging is complete, which can take around 5 hours with fully dis-
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function). Nevertheless, in order to avoid possible damage
to the batteries, do not leave the appliance permanently connected to the
mains adapter 4.
■ Do not recharge the batteries again until the handheld vacuum cleaner's suc-
tion power becomes appreciably weaker and the charge indicator
lamp 7flashes green.
NOTE
► If the battery is completely discharged, the appliance switches off and
the charge indicator lamp 7flashes green/red alternately for approx.
60 seconds. Start charging the appliance.
► The handheld vacuum cleaner can also be charged directly via the mains
adapter 4. To do this, remove the barrel plug 5with a slight twist from
the wall bracket 3and the cable from the cable routing. Insert the barrel
plug 5into the socket on the handheld vacuum cleaner.

■ 10 │ GB│IE│NI│CY SAS 7.4 LI D3
Operation
CAUTION!
► The suction opening must always be open and may not be blocked.
Blockages lead to overheating and damage to the motor.
► The appliance is not protected against splashes. You should therefore only
vacuum liquid up until the dirt container qis filled to the MAX mark!
NOTICES
► Make certain that the dust filter 0is always inserted before using the
appliance.
1) Remove the handheld vacuum cleaner from the wall bracket 3or, if you are
not using the wall bracket 3remove the barrel plug 5from the socket.
2) If required, place the appropriate nozzle in the suction opening:
–the crevice nozzle 2, to clean narrow and difficult to reach locations.
–the wet suction nozzle 1to vacuum up liquids.
NOTE
► After you have vacuumed up liquids, immediately clean the dirt container q.
Otherwise, bacteria or mould will build up inside! Ensure that the dust filter
bag 9is completely dry before using the appliance again.
3) To switch the appliance on, slide the on/off switch 6forwards. The charge
indicator lamp 7lights up green.
4) When you have finished using the appliance, slide the on/off switch 6to
the rear.

GB│IE│NI│CY │ 11 ■
SAS 7.4 LI D3
NOTE
► If you have vacuumed liquids, always carry the appliance with the wet
suction nozzle 1pointing downwards:
► If you carry the appliance horizontally or with the wet suction nozzle 1
pointing upwards, it is possible that liquid can leak out:
NOTE
► Place the handheld vacuum cleaner in the wall bracket 3and start the
charging process once the vacuum power has become noticeably weaker
and the charge indicator lamp 7flashes green.

■ 12 │ GB│IE│NI│CY SAS 7.4 LI D3
Cleaning
To achieve the best results, empty the dirt container qand clean the dust filter 0
after every use.
CAUTION! MATERIAL DAMAGE!
► Do not use aggressive, chemical or abrasive cleaning agents. These could
damage the outer surfaces of the appliance.
1) To open the dirt container q, press the release button 8and remove the
dirt container q.
2) Remove the dust filter 0from the dirt container q.
3) Empty the dirt container q.
4) Pull the dust filter bag 9 with its holder out of the dust filter 0.
5) Rinse the dust filter bag 9out in cold water and wait until it is completely
dry before reinserting it into the dust filter 0. Do not dry it with hot air.
6) Reinsert the dust filter 0into the dirt container q. When doing so, ensure
that the dust filter 0is seated squarely and that the rubber lip seals the dirt
container q.
7) Replace the dirt container qon the motor unit again:
–Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
–Press the release button 8and push the dirt container qonto the motor
unit at the same time.
–Let go of the release button 8so that the restraint engages in the recess.
The dirt container qis now firmly seated on the motor unit.
8) Clean the housing and both nozzles with a lightly moistened cloth. For stubborn
soiling use a mild detergent on the cloth.
9) Dry all parts thoroughly before using the appliance again or storing it.

GB│IE│NI│CY │ 13 ■
SAS 7.4 LI D3
Disposal
NOTE
► The integrated rechargeable battery in this appliance cannot be removed
for disposal.
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of European Directive
2012/19/EU.
Dispose of the appliance through an approved disposal facility or your municipal
waste facility. Please observe the currently applicable regulations. Please contact
your waste disposal facility if you are in any doubt.
Your local community or municipal authorities can provide information on how to
dispose of the worn-out product.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings:
1–7: Plastics,
20–22: Paper and cardboard,
80–98: Composites.
Dispose of all packaging materials in an environmentally friendly manner.

■ 14 │ GB│IE│NI│CY SAS 7.4 LI D3
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase. If this product
has any faults, you, the buyer, have certain statutory rights. Your statutory rights
are not restricted in any way by the warranty described below.
Warranty conditions
The validity period of the warranty starts from the date of purchase. Please keep
your original receipt in a safe place. This document will be required as proof of
purchase.
If any material or production fault occurs within three years of the date of purchase
of the product, we will either repair or replace the product for you at our discretion.
This warranty service is dependent on you presenting the defective appliance
and the proof of purchase (receipt) and a short written description of the fault
and its time of occurrence.
If the defect is covered by the warranty, your product will either be repaired or
replaced by us. The repair or replacement of a product does not signify the begin-
ning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty.
This also applies to replaced and repaired components. Any damage and defects
present at the time of purchase must be reported immediately after unpacking.
Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured in accordance with strict quality guidelines
and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not
extend to product parts subject to normal wear and tear or fragile parts such as
switches, batteries, baking moulds or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used
or improperly maintained. The directions in the operating instructions for the product
regarding proper use of the product are to be strictly followed. Uses and actions
that are discouraged in the operating instructions or which are warned against
must be avoided.
This product is intended solely for private use and not for commercial purposes.
The warranty shall be deemed void in cases of misuse or improper handling, use
of force and modifications/repairs which have not been carried out by one of
our authorised Service centres.

GB│IE│NI│CY │ 15 ■
SAS 7.4 LI D3
Warranty claim procedure
To ensure quick processing of your case, please observe the following instructions:
■ Please have the till receipt and the item number (e.g. IAN 12345) available
as proof of purchase.
■ You will find the item number on the type plate, an engraving on the front
page of the instructions (bottom left), or as a sticker on the rear or bottom of
the appliance.
■ If functional or other defects occur, please contact the service department
listed either by telephone or by e-mail.
■ You can return a defective product to us free of charge to the service address
that will be provided to you. Ensure that you enclose the proof of purchase
(till receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals,
product videos and software on www.lidl-service.com.
Service
Service Great Britain
Tel.: [phone]
E-Mail: kom[email protected]
Service Ireland
Tel.: [phone]
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kom[email protected]
CY Service Cyprus
Tel.: [phone]
E-Mail: kom[email protected]
IAN 304610
Importer
Please note that the following address is not the service address. Please use the
service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
DE- 44867 BOCHUM
GERMANY
www.kompernass.com

■ 16 │ GB│IE│NI│CY SAS 7.4 LI D3

GR│CY │ 17 ■
SAS 7.4 LI D3
Περιεχόμενα
Εισαγωγή ....................................................18
Προβλεπόμενη χρήση..........................................18
Παραδοτέος εξοπλισμός........................................18
Περιγραφή συσκευής ..........................................19
Τεχνικά χαρακτηριστικά........................................20
Σημαντικές υποδείξεις ασφαλείας ................................21
Πριν από την πρώτη θέση σε λειτουργία ...........................24
Πληροφορίες για τους συσσωρευτές ..............................24
Πληροφορίες για τη λυχνία ελέγχου φόρτισης......................25
Συναρμολόγηση του επιτοίχιου στηρίγματος.......................25
Φόρτιση .....................................................26
Χειρισμός ....................................................27
Καθαρισμός..................................................29
Απόρριψη ...................................................30
Εγγύηση της Kompernass Handels GmbH .........................31
Σέρβις ................................................................32
Εισαγωγέας ............................................................32
