Silvercrest 359294 2010 Technical specifications

2-IN-1 CORDLESS VACUUM CLEANER
2-IN-1 CORDLESS VACUUM CLEANER
Assembly, operating and safety instructions
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΗ ΗΛΕΚΤΡΙΚΗ
ΣΚΟΎΠΑ 2 ΣΕ 1
Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας
2-IN-1 AKKU-STAUBSAUGER
Montage-, Bedienungs- und Sicherheitshinweise
IAN 359294_2010

GB/IE/NI/CY Assembly, operating and safety instructions Page 5
GR/CY Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας Σελίδα 25
DE/AT / CH Montage-, Bedienungs- und Sicherheitshinweise Seite 49
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και εξοικειωθείτε με όλες τις
λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend
mit allen Funktionen des Gerätes vertraut.

A1 2
3
4
4a
14
16a
6 7
5
20
16
15
14a
13
8
12 11
9
1718
19 21
10
12a

B C
D E
5
4
1
9
3 2 22b 2b 2a
7
5
6
6

5GB/IE/NI/CY
List of pictograms used........................................................................................................Page 6
Introduction...................................................................................................................................Page 6
Intended use........................................................................................................................................Page 6
Parts description..................................................................................................................................Page 7
Scope of delivery................................................................................................................................Page 7
Technical data.....................................................................................................................................Page 7
Safety instructions...................................................................................................................Page 8
Safety instructions for batteries/rechargeable batteries .................................................................Page 11
Before first use............................................................................................................................Page 12
Installing the wall bracket...................................................................................................................Page 12
Charging the rechargeable battery...................................................................................................Page 13
Meaning of the rechargeable battery control display .....................................................................Page 14
Initial use.........................................................................................................................................Page 14
Selecting, assembling and disassembling accessories.....................................................................Page 14
Vacuuming.....................................................................................................................................Page 17
After use...........................................................................................................................................Page 17
Cleaning, care and maintenance ................................................................................Page 18
Emptying the dust collector.................................................................................................................Page 18
Cleaning the filters and dust collector ...............................................................................................Page 19
Cleaning the accessory parts.............................................................................................................Page 20
Storage .............................................................................................................................................Page 21
Troubleshooting/ Problem solving ...........................................................................Page 22
Disposal............................................................................................................................................Page 23
Warranty/ Service centre .................................................................................................Page 24
Declaration of conformity.................................................................................................Page 24

6 GB/IE/NI/CY
List of pictograms used
Observe the warnings and safety
information!
SMPS (Switched Mode Power
Supply)
Read the instructions! Polarity of the mains connection
This product is only suitable for use
indoors, in dry and enclosed spaces. Caution! Danger of explosion!
Direct current/voltage Safety gloves - Wear safety
gloves
Alternating current/voltage EU compliant
Never leave children unsupervised with
the packaging material or the product. 20
PAP
Dispose of the packaging in an
environmentally-friendly manner!
Warning! Danger of electric shock! 36-month warranty
Short-circuit-proof safety transformer TÜV SÜD/GS certified
UKCA mark indicates conformity with
relevant Great Britain regulations
applicable for this product.
(The UKCA mark logo is valid in Great
Britain only.)
2-in-1 Cordless Vacuum Cleaner
Introduction
We congratulate you on the purchase of your new
product. You have chosen a high quality product.
The instructions for use are part of the product. They
contain important information concerning safety, use
and disposal. Before using the product, please famil-
iarise yourself with all of the safety information and
in
structions for use. Only use the product as describ ed
and for the specified applications. If you pass the
product on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended use
This product is suitable for vacuuming up
loose, dry dirt, such as dust, lint or crumbs
on smooth flooring and carpets. This product
can be used as a hand-held or floor vacuum cleaner.
Only use the product indoors. This product is only

7GB/IE/NI/CY
intended for private, non-commercial use. Only use
the product for the intended purpose. Any use not
specified above or product modification is prohib-
ited and can result in injuries and/or damage. The
manufacturer assumes no liability for damage due
to improper use.
Parts description
1Handle
2Rechargeable battery
2a Release button (rechargeable battery)
2b Rechargeable battery control display
3Charging socket (rechargeable battery)
4Main unit
4a Opening on the main unit (for connecting the
accessory parts directly to the main unit)
5Wall bracket
6Screw
7Wall plug
8Mains adapter
9Mains cable connector plug
10 Accessory holder (for attaching to the
aluminium suction tube)
11 Small brush
12 Dust brush (2-in-1 brush)
12a Release button (dust brush)
13 Crevice nozzle
14 Electric floor brush
14a Rotating brush roller
14b Locking mechanism (rotating brush roller)
14c Fixing screw (locking mechanism for the
rotating brush roller)
15 Release button (aluminium suction tube)
16 Aluminium suction tube
16a Opening on the aluminium suction tube (for
connecting the accessory parts on the bottom
of the aluminium suction tube)
17 ECO button
18 MAX button
19 On/Off button
20 Release button (main unit)
21 Dust collector
21b Base flap (dust collector)
22 Release button (to disconnect dust collector
from main unit)
23 Release lever (to open the base flap on the
dust collector)
24 Cover (dust collector)
25 HEPA filter
26 Filter carrier
27 Stainless steel filter
Scope of delivery
Immediately after unpacking, check that all the
items are present and that the product is in perfect
condition.
1 main unit with dust collector
1 aluminium suction tube
1 mains adapter with mains cable
1 rechargeable battery
1 electric floor brush
1 crevice nozzle
1 dust brush (2-in-1 brush)
1 small brush
1 wall bracket incl. mounting materials (2 wall
plugs, 2 screws)
1 accessory holder
1 set of assembly instructions and instructions for
use
Technical data
Model: SHAZ 22.2 D5
Rated voltage: 22.2V
Input: 100‒240V~50/60Hz
Output: 26V , 500mA
Power: max. 130W
Rechargeable battery: Li-ion rechargeable battery
(22.2 V, 2500 mAh),
removable
Charging time: 4–5 hours
Suction levels: MAX mode and ECO
mode
Runtime 25 minutes in MAX mode,
45 minutes in ECO mode
Volume
Dust collector: 0.6 l
Noise level: max. 75dB

8 GB/IE/NI/CY
Safety instructions
KEEP ALL SAFETY INFORMA-
TION AND INSTRUCTIONS FOR
FUTURE REFERENCE!
DANGER TO LIFE
AND RISK OF ACCIDENTS
FOR INFANTS AND CHIL-
DREN! Never leave children
unsupervised with the packaging
material. There is a danger of
suffocation. Keep children away
from the product.
This product may be used by
children aged 8 years and up, as
well as by persons with reduced
physical, sensory or mental ca-
pacities or lacking experience
and knowledge, so long as they
are supervised or instructed in
the safe use of the product and
understand the associated risks.
Do not let children play with the
product. Cleaning and user main-
tenance must not be performed
by children without supervision.
Do not leave the product or pack-
aging material lying unattended.
Plastic film or bags, polystyrene
foam etc. can turn into dangerous
toys for children.
Avoid the risk of fatal
injury from electric
shock
Regularly check all parts of the
product for any damage before
use. Never use the product if
you identify damage to the hous-
ing, mains adapter with mains
cable or the rechargeable battery.
Ensure that the power supply
voltage matches that specified in
the chapter “Technical data”.
Only plug the mains adapter
into a properly installed, easy to
access mains socket. The mains
socket must also be easily acces-
sible after the product has been
plugged in.
Never open any of the electrical
equipment or insert any objects
into this equipment. Such inter-
ferences pose a risk of fatal
injury from electric shock.
Do not insert any objects (except
the accessory parts provided for
this purpose) into the openings
on the product.
Handle the power cable with
care to avoid damage.
Protect the mains cable from
sharp edges, mechanical loads
and hot surfaces.

9GB/IE/NI/CY
Immediately remove the mains
adapter from the mains socket
in the event of the mains cable
becoming damaged.
Always pull on the mains adapter
and never on the mains cable to
avoid disconnecting the product
from the power supply.
Do not use the mains cable to
move or pull the product. Never
use the mains cable as a carrying
handle. Keep the mains cable
away from heat sources.
If the mains cable is damaged, it
must be replaced by a qualified
service technician to avoid
dangers.
Do not use the product if it can’t
work properly due to
- falls,
- damage,
- ingress water,
- outdoor use.
Have the product repaired by
the manufacturer or its customer
service department.
Do not use the product if it has
been dropped or has visible
damage.
Discontinue using the product if
the plastic parts are cracked or
deformed. Always replace dam-
aged parts with genuine spare
parts.
Do not immerse the product, the
mains cable or the mains adapter
in water or other liquids.
Ensure that the mains cable never
becomes wet or moist.
Protect the appliance from mois-
ture, droplets or spraying water.
Only use the product in dry rooms,
never outdoors or in damp envi-
ronments.
Do not use the product on wet
or damp floors.
Do not allow any liquids or damp
dirt to be vacuumed up.
If liquids get into the product, im-
mediately switch it off and pull
out the mains adapter. Have the
product checked for damage
before using it again.
Never touch the mains adapter
with moist or wet hands, espe-
cially when you plug it into the
socket or pull it out of the socket.
Do not use the product with wet
hands.
Do not place objects filled with
liquids, e.g. vases on or near the
product.
Switch off the product and remove
the mains adapter from the mains
socket,
- if there is a malfunction,
- when you are not charging the
rechargeable battery,

10 GB/IE/NI/CY
- during thunder,
- before assembling or disassem-
bling the device,
- before changing the filters,
- before removing blockages
and before cleaning the
product.
Only use the original mains
adapter with mains cable to
charge the rechargeable battery.
Remove the rechargeable battery
from the product before cleaning.
Prevent fire and injury
hazards
Do not cover the product with
any objects while it is in use or
when charging the rechargeable
battery. Excessive heat build-up
can result in fire.
Do not use the product near
open fire.
Do not expose the product to
direct sunlight or heat.
Do not install the wall bracket
near hot surfaces, e.g. radiators.
Store the product and install the
wall bracket in an easy to reach
location and ensure that the
product is not covered by objects.
Always leave a minimum distance
of 10 cm around the product to
ensure it is sufficiently ventilated.
Do not allow the product to
vacuum up flammable materials,
for example fuel or toner from
printers or photocopiers.
Do not allow the product to
vacuum up burning items, for
example cigarettes, matches,
ashes or other objects which
could cause a fire.
Do not use the product in tem-
peratures over +40 °C or below
+10°C.
Keep hair, clothing and fingers
away from the openings and
moving operating parts of the
product. Risk of injury!
Electrical products may pose a
hazard to animals. Animals can
also damage the product. Always
keep animals away from electrical
products.
Lay the mains cable in such a
way that nobody will step on,
get caught on or trip over it.
Switch the product off before
changing the accessory parts
which move during operation.
Danger of damage to
property
Do not use the product if the suc-
tion opening is blocked. Remove
dust, hair, cotton wool, etc., to

11GB/IE/NI/CY
allow air to flow freely in the
suction opening.
Do not allow the product to vac-
uum up items which could clog
the product, for example stones,
paper waste, etc.
Do not allow the product to vac-
uum up hard or sharp objects,
for example glass shards, nails,
screws or coins. This could
damage the product.
Remove any obstacles prior to
use, for example power cables,
toys and other objects.
Regularly check and clean the
filters and the dust collector to
extend the life of your product.
Discontinue using the product if
you detect damage or deforma-
tions to the filters. Please contact
customer service if this happens.
Failure to do so may cause dam-
age to the product, for example
due to the motor overheating as
a result of blocked or defective
filters.
Never use the product without
filters to prevent damaging the
motor and shortening the life of
the product.
Always switch off the product
before transporting it.
Fully charge the product at least
once a month to prevent deep
discharge and thus battery dam-
age.
Install the wall bracket securely
on the wall. Check whether the
mounting material included is
suitable for the chosen wall. If
necessary, consult a professional
to procure suitable mounting
material.
Before drilling, check that there
are no water pipes or power
cables where you intend to drill.
Do not use harsh or aggressive
cleaning agents (see chapter
“Cleaning, care and mainte-
nance”). This could damage the
product.
Only use the original accessories.
Safety instructions
for batteries/
rechargeable
batteries
DANGER TO LIFE! Keep bat-
teries/rechargeable batteries out
of reach of children. If acciden-
tally swallowed seek immediate
medical attention.
DANGER OF EXPLO-
SION! Never recharge
non-rechargeable batteries. Do
not short-circuit

12 GB/IE/NI/CY
batteries/rech argeable batteries
and/or open them. Overheat-
ing, fire or bursting can be the
result.
Never throw batteries/recharge-
able batteries into fire or water.
Do not exert mechanical loads to
batteries/rechargeable batteries.
Risk of leakage of batteries/
rechargeable batteries
Avoid extreme environmental
conditions and temperatures,
which could affect batteries/
rechargeable batteries, e.g.
radiators /direct sunlight.
If batteries/rechargeable batteries
have leaked, avoid contact with
skin, eyes and mucous membranes
with the chemicals! Flush imme-
diately the affected areas with
fresh water and seek medical
attention!
WEAR PROTECTIVE
GLOVES! Leaked or
damaged batteries/ rechargea-
ble batteries can cause burns on
contact with the skin. Wear suit-
able protective gloves at all times
if such an event occurs.
In the event of a leakage of bat-
teries/ rechargeable batteries,
immediately remove them from
the product to prevent damage.
Remove batteries/rechargeable
batteries if the product will not
be used for a longer period.
This product has a built-in re-
chargeable battery which cannot
be replaced by the user. The re-
moval or replacement of the re-
chargeable battery may only be
carried out by the manufacturer
or his customer service or by a
similarly qualified person in order
to avoid hazards. When dispos-
ing of the product, it should be
noted that this product contains
a rechargeable battery.
Before first use
Installing the wall bracket
DANGER OF ELEC-
TRIC SHOCK! Before drilling,
ensure there are no electrical
lines or pipes in the area where
you will be drilling.
Read the operating and safety
instructions for your drill carefully.
When choosing your installation
site, make sure that a properly
installed and easy to access
plug socket is located in close
proximity.

13GB/IE/NI/CY
Before assembly, check whether
the assembly material provided
is suitable for your circumstances
(e.g. wall condition). If necessary,
consult a professional to procure
suitable mounting material.
Mark the drill holes using the holes in the wall
bracket 5intended for the screws 6.
Now drill the fastening holes in the wall and
put the wall plugs 7into the holes.
Mount the wall bracket 5with the screws 6
included in the delivery (see Fig. B). Ensure that
the wall bracket 5is securely tightened.
Hang the main unit 4with the back on the
hook on the wall bracket 5intended for this
purpose (see Fig. C).
Charging the rechargeable
battery
Note: Charge the rechargeable battery 2fully
(approx. 4 to 5 hours) prior to first use.
Hang up the main unit 4with
aluminium suction tube 16 to
charge on the wall bracket 5or
place it out of the reach of children
and pets in a protected location
where no one can trip over or
step on the main unit 4with
aluminium suction tube or the
mains cable.
Insert the connection plug of the mains cable 9
into the charging socket 3on the rechargeable
battery 2(see Fig. D).
Insert the mains adapter 8into the mains
socket. The LEDs on the rechargeable battery
control display 2b show the charge level of the
rechargeable battery 2(see chapter “Mean-
ing of the rechargeable battery control display”).
Note: During the charging process, the mains
adapter 8may warm up. This is normal and
does not indicate that the product is defective.
Remove the mains adapter 8from the mains
socket and the mains cable connector plug 9
from the charging socket 3when the recharge-
able battery 2is fully charged. The LEDs on
the rechargeable battery control display 2b go
out.
Charging the rechargeable battery out-
side of the main unit:
Charge the rechargeable battery
2in a protected location and
outside the reach of children
and pets.
You can remove the rechargeable battery 2
to charge it outside of the main unit 4. Press
the release button 2a and pull the rechargeable
battery 2out of the holder on the handle 1
of the main unit 4(see Fig. E).
Insert the mains cable connector plug 9into
the charging socket 3of the rechargeable
battery 2(see Fig. F).
Insert the mains adapter 8into the mains
socket. The LEDs on the rechargeable battery
control display 2b show the charge level of the
rechargeable battery 2(see chapter “Mean-
ing of the rechargeable battery control display”).
Once the rechargeable battery 2is fully
charged, the LEDs on the rechargeable battery
control display 2b light up continuously.
Remove the mains adapter 8from the mains
socket and the mains cable connector plug 9
from the charging socket 3of the rechargeable
battery 2. The LEDs on the rechargeable bat-
tery control display 2b go out.
Put the charged rechargeable battery 2back
in the main unit 4by pushing it into the holder
in the handle 1of the main unit 4until it
locks into place.

14 GB/IE/NI/CY
Meaning of the rechargeable
battery control display
The 4 LEDs on the rechargeable battery control dis-
play 2b show the charge level of the rechargeable
battery 2.
Display in operation:
- When the rechargeable battery 2is fully
charged, the LEDs on the rechargeable battery
control display 2b light up continuously.
- If the LEDs go out during operation, this shows
that the rechargeable battery 2is gradually
running out of charge.
- The rechargeable battery 2is almost com-
pletely out of charge when only one LED is
illuminated.
Charge the rechargeable battery 2immedi-
ately. The main unit 4automatically switches
off when the level of charge in the rechargea-
ble battery is too low for continued operation.
Display during the charging process:
- The lit LEDs show the charging progress (already
charged proportion).
- Once all the LEDs are continuously lit, the
rechargeable battery 2is fully charged.
The rechargeable battery control display 2b goes
out when the charging process is complete and
you remove the mains adapter 8from the mains
socket or pull the mains cable connector plug 9
out of the charging socket 3of the rechargeable
battery 2.
Once the main unit 4is switched on using the On/
Off button 19 , the LEDs on the rechargeable
battery control display 2b light up and show the
charge level of the rechargeable battery 2.
Initial use
Selecting, assembling and
disassembling accessories
Aluminium suction tube:
The aluminium suction tube 16 serves as an exten-
sion, for example, to access hard-to-reach spots
with the crevice nozzle 13 and as a connection
piece between the electric floor brush 14 and the
main unit 4.
You can attach all the included accessory parts at
the bottom end of the aluminium suction tube 16 .
Insert the aluminium suction tube 16 from
below into the opening on the main unit 4a in-
tended for this purpose until it audibly clicks
into place.
Remove the aluminium suction tube 16 from
the main unit 4by pushing the upper release
button 20 and removing the aluminium suction
tube 16 from the main unit 4.
16
16a
15
16
20
4a
21
4

15GB/IE/NI/CY
Electric floor brush:
The electric floor brush 14 is suitable both for vacu-
uming smooth floors and carpets. It has a rotating
brush roller 14 a for taking in hair and fluff.
Attach the aluminium suction tube 16 to the
main unit 4as previously described.
Insert the electric floor brush 14 into the open-
ing on the aluminium tube 16 a intended for this
purpose or alternatively directly into the opening
on the main unit 4a intended for this purpose.
The electric floor brush 14 must audibly click
into place; only then is it properly attached.
Press the release button 15 (aluminium suction
tube 16 ) or 20 (main unit 4) to remove the
electric floor brush and pull the electric floor
brush 14 out of the aluminium suction tube 16 /
the main unit 4.
14
16
15
16a
14
14a
Crevice nozzle:
The crevice nozzle 13 is suitable for vacuuming
hard-to-reach spots, e.g. corners, cracks, seams,
recesses, crevices in upholstered furniture and for
cleaning the inside of cars.
Insert the crevice nozzle 13 into the opening
on the aluminium suction tube 16 a intended for
this purpose, for example to acess hard-to-reach
spots when vacuuming, or directly into the open-
ing on the main unit 4a intended for this pur-
pose. The crevice nozzle 13 must audibly click
into place when installing it on the aluminium
suction tube 16 /main unit 4.
Remove the crevice nozzle 13 from the alumin-
ium suction tube 16 /main unit 4by pushing
the release button 15 (aluminium suction tube
16 ) or 20 (main unit 4) and removing the
crevice nozzle 13 from the aluminium suction
tube/main unit 4.
13
16a
15
16
Dust brush:
The dust brush 12 is suitable for vacuuming uphol-
stery and other textiles, but also for dusting sensitive
objects, e.g. keyboards, picture frames, books etc.
Insert the upper end of the dust brush 12 into
the opening on the aluminium suction tube 16 a
intended for this purpose or the opening on the
main unit 4a intended for this purpose until it
audibly clicks into place.

16 GB/IE/NI/CY
Remove the dust brush 12 from the aluminium
suction tube 16 /main unit 4by pushing the
release button 15 (aluminium suction tube 16 )
or 20 (main unit 4) and removing the dust
brush 12 from the aluminium suction tube 16 /
main unit 4.
16a
15
16
12
The dust brush 12 has two functions:
You can use the dust brush 12 either with the brush
attachment or with the corner nozzle attachment.
Press the release button 12a to push the brush
attachment of the dust brush 12 downwards to
vacuum upholstered furniture, for example.
12
12a
Press the release button 12a again to push the
brush attachment of the dust brush 12 upwards.
The corner nozzle attachment of the dust brush
12 is suitable for vacuuming picture frames or
books, for example.
12
12a
Small brush:
The small brush 11 is suitable for vacuuming uphol-
stery and other textiles, but also for dusting sensitive
objects, e.g. keyboards, picture frames, books etc.
Insert the upper end of the small brush 11 into
the opening on the aluminium suction tube 16a
intended for this purpose or the opening on the
main unit 4a intended for this purpose until it
audibly clicks into place.
Remove the small brush 11 from the aluminium
suction tube 16 /main unit 4by pushing the
release button 15 (aluminium suction tube 16 )
or 20 (main unit 4) and removing the small
brush 11 from the aluminium suction tube 16 /
main unit 4.
15
16
11
16a

17GB/IE/NI/CY
Vacuuming
Before vacuuming, ensure that
the dust collector 21 with the fil-
ters (HEPA filter 25 and stainless
steel filter 27 ) is correctly installed
(see chapter “Emptying the dust
collector”/“Cleaning the filters
and dust collector”).
Ensure that the rechargeable
battery 2is charged and in-
stalled before use (see chapter
“Charging the rechargeable
battery”).
Before vacuuming, ensure that
no large, sharp or pointed objects
are lying on the surface to be
cleaned.
Make sure that the surface to be
cleaned is dry.
Note: Switch the main unit 4
off after cleaning each surface to
conserve the operating time of the
rechargeable battery 2. Charge
the rechargeable battery 2after
use (see chapter “Charging the
rechargeable battery”).
When vacuuming, be aware
of your surroundings to avoid
damage to the product and
other objects.
Choose the suitable accessory if needed (see
chapter “Selecting, assembling and disassem-
bling accessories”).
Press and hold down the On/Off button 19
for approx. 2-3 seconds (see Fig. A) and start
vacuuming.
Now select one of the two vacuuming levels by
pressing the MAX button 18 or the ECO button
17 (see Fig. A).
MAX mode: full vacuuming power, runtime
approx. 25 minutes.
ECO mode: reduced vacuuming power,
runtime approx. 45 minutes.
Press the On/Off button 19 again to switch
the product off (see Fig. A).
After use
Store the main unit 4after use
either by hanging it on the wall
bracket 5(see Fig. C) or lying it
out of the reach of children and
pets in a protected location where
no one can trip over or step on
the main unit 4with aluminium
suction tube 16 or the mains
cable.
Charge the rechargeable battery 2again after
use (see chapter “Charging the rechargeable
battery”).
The aluminium suction tube 16 and the electric
floor brush 14 can be left attached to the main
unit 4during storage.
Storing the accessories:
Insert the small brush 11 , dust brush 12 and
crevice nozzle 13 in the accessory holder 10
for storage (see figure).
Put the accessory holder 10 on the aluminium
suction tube 16 .

18 GB/IE/NI/CY
16
111210
13
16
111210
13
Then either hang the main unit 4on the wall
bracket 5(see Fig. C) or place it out of the
reach of children and pets in a protected
location.
Note: Before vacuuming, remove the accessory
holder 10 from the aluminium suction tube 16
to prevent the accessory parts coming loose
from the accessory holder 10 unintentionally
during operation.
Put the accessory holder 10 back on the alu-
minium suction tube 16 after vacuuming.
Cleaning, care and
maintenance
Emptying the dust collector
To empty the dust collector 21 , it must be removed
from the main unit 4.
First remove the aluminium suction tube 16 or the
accessory part you were using (see chapter “Select-
ing, assembling and disassembling accessories”).
Proceed as follows to empty the dust collector 21 :
Switch the product off using the On / Off
button 19 (see Fig. A).
Remove the dust collector 21 from the main
unit 4by pushing the release button 22 on
the base of the dust collector 21 (see Fig. G)
and carefully removing the dust collector 21 as
shown in figure H.
Hold the dust collector 21 over a waste bin.
The distance to the dust collector should be as
small as possible so that the dust does not un-
necessarily shake out and distribute itself in the
surrounding area.
Pull the release lever 23 downwards (towards
the user) to open the base flap 21 b on the dust
collector 21 (see Figure I).
If needed, remove hair and dust, which have
become stuck to the dust collector 21 by hand.
Close the base flap 21 b again by pushing it
back into the opening of the dust collector 21
and pushing the release lever 23 upwards
(towards the dust collector 21 ) until it audibly
clicks into place (see Fig. J).
Replace the dust collector 21 on the main unit
4by lining up the dust collector 21 and the
cover 24 precisely in the corresponding re-
cesses in the main unit 4(see Fig. K). The
dust collector 21 must audibly click into place,
it is only properly installed if it does so (see
Fig. L).

19GB/IE/NI/CY
Cleaning the filters
and dust collector
Clean the filters (HEPA filter 25
and stainless steel filter 27 ) after
every two or three uses. Other-
wise the vacuum function will be
reduced and the product could
be damaged.
Do not wash the filters (HEPA
filter 25 and stainless steel filter
27 ) in the dishwasher or wash-
ing machine.
Do not clean the HEPA filter 25
under running water.
Do not clean the dust collector
21 in the dishwasher.
Allow the stainless steel filter 27
to air dry thoroughly after clean-
ing.
Do not put the stainless steel
filter 27 in the dryer or on the
stove to dry.
IMPORTANT: Allow all parts
of the product to dry thoroughly
after cleaning. If the stainless
steel filter 27 is not fully dry, wa-
ter may seep into the product
and damage it!
To clean the filters, follow these steps:
Switch the product off using the On / Off
button 19 (see Fig. A).
Remove the aluminium suction tube 16 from
the main unit 4by pushing the upper release
button 20 and removing the aluminium suction
tube 16 from the main unit 4.
Remove the dust collector 21 from the main
unit by pushing the release button 22 on the
base of the dust collector 21 and carefully
removing the dust collector 21 (see Fig. H).
Ensure that the dust collector 21 is empty (see
chapter “Emptying the dust collector”). Tap the
dust collector 21 out again over a waste bin if
needed.
Remove the cover 24 of the dust collector 21
by turning it to the right until the marking on the
cover 24 is above the - symbol. Remove the
cover 24 , pulling it upwards.
24
Take the entire filter unit out of the dust collec-
tor 21 .
Remove the HEPA filter 25 from the filter carrier
26 by pulling it out upwards on the flap.

20 GB/IE/NI/CY
24
25
26
27
21
Clean the HEPA filter 25 by tapping it out.
Only clean with a paintbrush or soft brush.
Do not clean the HEPA filter 25
with water!
Rinse the stainless steel filter 27 with the filter
carrier 26 under clear water.
Clean the dust collector 21 thoroughly using a
damp cloth.
Leave the dust collector 21 and the stainless
steel filter 27 with filter carrier 26 to dry thor-
oughly before you put all the parts back in the
reverse order.
Replace the cover 24 of the dust collector 21
and secure it by turning it to the left until the
marking on the cover 24 is above the - symbol.
24
Note: Check the filters (HEPA filter 25 and
stainless steel filter 27 ) regularly when clean-
ing for damage or deformations. Filters, which
indicate damage or deformations or which can
no longer be cleaned must be replaced. Please
contact customer service if this happens.
Cleaning the accessory parts
DANGER OF
ELECTRIC SHOCK! Always switch
off the product before cleaning and
remove the mains adapter 8from
the mains socket.
DANGER OF
ELECTRIC SHOCK! Do not im-
merse the product, the rechargeable
battery 2, the mains cable or the
mains adapter 8in water or other
liquids to clean it.
Do not clean the product when it
is charging.
Let the product cool before you
clean it.
Remove the rechargeable battery
2before cleaning.
