WINE CABINET SWTS 65 A1
WINE CABINET
Operating instructions
WEINTEMPERIERSCHRANK
Bedienungsanleitung
IAN 323171_1901
GB/IE/NI Operating instructions Page 1
DE/AT/CH Bedienungsanleitung Seite 21
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
B
A
..
GB│IE│NI │ 1 ■
SWTS 65 A1
Contents
Introduction...................................................2
Information about these operating instructions...................................2
Limitation of liability .......................................................2
Proper use ..............................................................2
Warning notices ..........................................................3
Safety information .............................................4
Check package contents ........................................8
Appliance description...........................................9
Technical specifications..........................................9
Operating the appliance .......................................10
Operation ...................................................11
Saving energy ..........................................................11
Setting the temperature unit ................................................11
Setting the temperature ...................................................12
Inserting/removing bottles .................................................12
Switching the light on and off...............................................13
Recommended temperatures ...............................................13
After use ...............................................................14
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting ..............................................15
Disposal.....................................................16
Disposal of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Disposal of the packaging .................................................16
Appendix....................................................17
Energy label ............................................................17
Kompernass Handels GmbH warranty .......................................18
Service ................................................................19
Importer...............................................................19
■ 2 │ GB│IE│NI SWTS 65 A1
Introduction
Information about these operating instructions
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of
this product. They contain important information on safety, usage and disposal.
Before using the product, please familiarise yourself with all operating and safety
instructions. Use the product only as described and for the range of applications
specified. Please also pass these operating instructions on to any future owner.
Limitation of liability
All the technical information, data and instructions regarding installation, connec-
tion and operation contained in these operating instructions correspond to the
latest information available to us at the time of printing and takes our previous
experience and know-how into account.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to
observe these instructions, improper use, incompetent repairs, unauthorised
modifications or for the use of non-approved replacement parts.
Proper use
This appliance is intended exclusively for maintaining closed beverage bottles
(wine, lemonade, mineral water, etc.) and packaged food at a constant tempera-
ture in private households. The appliance is not intended for commercial or
industrial use.
The appliance is not suitable for storing open bottles, unpacked or open foodstuffs.
Food may only be packaged or stored in closed containers inside the appliance.
The appliance is not intended for any other purpose nor for use beyond the
scope described. No claims of any kind will be accepted for damage arising
as a result of incorrect use. The risk is borne solely by the user.
GB│IE│NI │ 3 ■
SWTS 65 A1
Warning notices
The following warnings are used in these operating instructions:
DANGER!
A warning notice at this hazard level indicates an imminently
hazardous situation.
If the hazardous situation is not avoided, it could result in death or serious
physical injury.
► Follow the instructions in this warning to prevent a fatality or serious personal
injury.
WARNING!
A warning at this hazard level indicates a potentially hazardous
situation.
Failure to avoid this hazardous situation could result in injury.
► Follow the instructions in this warning to prevent physical injury.
CAUTION!
A warning notice at this hazard level indicates a risk of property
damage.
Failure to avoid this situation could result in property damage.
► Follow the instructions in this warning notice to prevent property damage.
NOTE
► A note provides additional information which will assist you in using the
appliance.
■ 4 │ GB│IE│NI SWTS 65 A1
Safety information
DANGER!
► Check the appliance for visible external damage before use.
Do not operate an appliance that has been damaged or
dropped.
► Never open any parts of the housing. There are no servicea-
ble parts whatsoever inside.
► Arrange for defective power plugs and/or cables to be
replaced as soon as possible by a qualified technician or by
our Customer Service Department to avoid the risk of injury.
► The appliance must be connected to a correctly installed
and earthed mains power socket supplying a suitable volt-
age. The mains voltage must correspond to the appliance
technical data.
► Do not kink or crush the power cable. Keep the power cable
well away from sources of heat.
► Use the appliance only in dry indoor areas.
►
Never immerse the appliance in water or any other
liquid!
► Ensure that the power cable never becomes wet or damp
when the appliance is in use. Route the cable so that it can-
not be trapped or damaged in any way.
► Never handle the plug or the power cable with wet or damp
hands.
► Protect the appliance from water droplets or spray. Do not
set up the appliance near water and do not place objects
filled with liquids (e.g. vases) on the appliance.
► Do not place household appliances such as food processors
or microwaves on top of the appliance.
GB│IE│NI │ 5 ■
SWTS 65 A1
WARNING –RISK OF INJURY!
► Never open the appliance housing. None of the components
in the appliance can be serviced or replaced by the user.
► Do not make any unauthorised modifications or alterations
to the appliance.
► All repairs must be carried out by authorised specialist
companies or by the Customer Service department.
Improper repairs may put the user at risk. It will also invalidate
any warranty claims.
► This appliance may be used by children aged 8 years or more
and by persons with reduced physical, sensory or mental
capabilities or lack of experience and/or knowledge if they
are supervised, or have been instructed in the safe use of the
appliance and have understood the potential risks.
► The appliance may not be used as a plaything by children.
► Cleaning and user maintenance must not be carried out by
children without supervision unless they are 8 years of age
or older and are supervised.
► Children younger than 8 years old must be kept away from
the appliance and its connecting cable.
► Install the appliance near a power outlet which is easily
accessible. In an emergency, the plug must be quickly and
easily accessible.
► Always remove the plug from the mains power socket before
moving or cleaning the appliance, or when it is not in use or
malfunctioning. Never pull on the mains cable, always pull
on the mains plug.
■ 6 │ GB│IE│NI SWTS 65 A1
WARNING –RISK OF INJURY!
► If you notice any unusual noises, a smell of fire or smoke
during operation, immediately unplug the power cable from
the wall outlet. Have the appliance checked by a qualified
specialist before using it again.
► Do not store toxic, flammable, explosive or corrosive objects,
such as spray cans, lighter fuel, acetate, alcohol, petrol, paint,
adhesives or propane gas, etc. in this appliance.
► Do not store any medicines or chemical substances in this
appliance. Temperature-sensitive materials should generally
not be stored in the appliance. They could spoil or trigger
unexpected reactions and pose a risk.
CAUTION – PROPERTY DAMAGE!
► Only transport the appliance when it is empty. Remove all
containers before transport.
► Ensure a firm footing and a level surface. Use the two adjust-
able front feet to stabilise the appliance.
► Do not place the appliance near naked flames or other sources
of heat (heating, direct sunlight, gas stoves, etc.). Otherwise,
it may become overheated and irreparably damaged.
► Observe the minimum total space requirement of the appli-
ance (200 cm) to ensure adequate ventilation. Never place
the appliance in a built-in cabinet, in a narrow niche or similar.
► Make sure that the ventilation slots are not covered during
operation to ensure sufficient air circulation. Risk of overheat-
ing! Set up the appliance so that a minimum distance of 10
cm to the top and back and 5 cm to the sides is maintained.
GB│IE│NI │ 7 ■
SWTS 65 A1
CAUTION – PROPERTY DAMAGE!
► Do not operate the appliance in rooms with high humidity
(bathrooms etc.) or rooms in which explosives or easily-flam-
mable materials or gases are stored. Rooms with poor air
circulation, e.g. garages, are also not suitable.
► The appliance is designed for climate class N, i.e. an ambient
temperature of 16 to 32°C. Do not operate the appliance in
excessively deviating ambient temperatures.
► Connect the appliance individually to a mains socket; do not
use a multiple socket strip or multiple socket.
► Do not use an external timer switch or a separate remote
control system to operate the appliance.
► Do not place burning candles on or next to the appliance.
► Do not use abrasive or caustic cleaning agents. These can
attack the surface and irreparably damage it.
► Do not operate any electronic appliances inside the appliance.
Both appliances can be irreparably damaged.
■ 8 │ GB│IE│NI SWTS 65 A1
Check package contents
Observe the following symbols on the packaging:
Never stack more than 4 boxes/packages on top of each other!
Protect the packaging from moisture!
This side upwards only!
Treat the packaging carefully!
The appliance is supplied with the following components as standard:
Wine cabinet
3 shelves
Operating instructions
DANGER – RISK OF SUFFOCATION!
► Do not allow children to play with packaging materials. There is a risk of
suffocation.
ƇRemove all parts of the appliance and the operating instructions from the
carton.
ƇRemove all packing material and any adhesive strips or protective films from
the appliance.
NOTE
► Check the package for completeness and signs of visible damage.
► If the delivery is incomplete or damage has occurred as a result of defec-
tive packaging or during transport, contact the service hotline (see section
Service).
GB│IE│NI │ 9 ■
SWTS 65 A1
Appliance description
(See fold-out page for illustrations)
Figure A:
Deactivate key lock
Switch lighting on/off; change temperature unit
°
C
|
°
F
Display
Increase temperature
Reduce temperature
Figure B:
Light
Door
Door handle
Drip tray for condensation water
Adjustable feet
- Removable shelves
Technical specifications
Input voltage 220–240 V ∼ (AC), 50/60 Hz
Rated power 65 W
Airborne noise emission 33 dB
Climate class
N
(This appliance is designed to operate at an
ambient temperature between 16 and 32°C.)
Heat insulating material Cyclopentane
Energy consumption 0.273 kWh/24 h,
100 kWh/year
Energy efficiency class A+
Net/usable capacity 21 l
Gross capacity 25 l
Dimensions approx. 25.2 x 50.0 x 45.3 cm (WxDxH)
Adjustable temperature
range 7–18°C (45–64°F)
Nominal power interior
light 1 W / 4 LEDS
■ 10 │ GB│IE│NI SWTS 65 A1
Operating the appliance
ƇBefore using for the first time, clean all parts as described in the section
"Cleaning".
ƇSelect a suitable installation location:
–The mains socket must be easily accessible.
–Choose a location that is preferably cool, out of direct sunlight and not
near any heat sources.
NOTE
► The appliance cools down by a maximum of 18°C from the ambient
temperature. The lowest attainable temperature is 7°C (45°F). This
means that if you want to cool down to 7°C, the ambient temperature
must not exceed 25°C (77°F).
–Avoid humidity.
–Maintain a minimum distance of 10 cm from other objects and walls
to the top and back and 5 cm from the sides. Please also note that the
appliance door must be opened by more than 90 degrees in order to
be able to pull out the shelves -.
The following room dimensions must be available:
~
74
cm
~45 cm
+5 cm
+10 cm
ƇEnsure that the appliance is stable and level. Compensate for any unevenness
in the floor with the two front adjustable feet .
GB│IE│NI │ 11 ■
SWTS 65 A1
ƇCheck that the shelves -are correctly positioned in the guide rails. The two
locking appliances on the sides of the shelves -must point downwards at
the rear.
ƇInsert the plug into the mains power socket.
You will hear a beep and the display shows the current temperature of
the interior of the appliance. The appliance starts the cooling process, a
temperature of 18°C is preset by default.
The appliance is now ready for use.
Operation
Saving energy
Please observe the following tips to achieve optimum cooling performance with
the lowest possible energy consumption:
■ Do not select a temperature which is colder than necessary. The colder the
set temperature, the more energy the appliance consumes.
■ The cooler the ambient air, the less energy the appliance needs to produce
to reach the desired temperature. Do not place the appliance near heat
sources such as radiators, dishwashers or cookers and avoid direct sunlight.
Ensure that there is adequate ventilation.
■ Make sure that the door is always properly closed.
■ Do not leave the door open for a long period of time to prevent the cold
from escaping.
Setting the temperature unit
The appliance can display the temperature in either °C (Celsius) or °F (Fahrenheit).
By default, the temperature is shown in °C on the display .
ƇTo change the unit, press and hold
°
C
|
°
F
button until the temperature shown
on the display changes.
NOTE
► The same button is also used to operate the light . Press the
°
C
|
°
F
but-
tonbriefly again, if necessary, to switch the light on or off again.
The light switches off automatically after 10 minutes.
► If you are not sure which temperature unit is currently being shown, change
the display again. The higher value is the temperature in °F and the lower
value is the temperature in °C.
■ 12 │ GB│IE│NI SWTS 65 A1
Setting the temperature
You can set a temperature between 7 and 18°C (45–64°F).
NOTE
► The appliance is equipped with an automatic key lock. If no button is
pressed for approx. 20 seconds, the and buttons are locked.
To deactivate the key lock, hold down the button for approx. 3sec-
onds until you hear a second beep.
► The appliance cannot be used for heating. If the ambient temperature is
cooler than the set temperature, the cooling switches off. The temperature
in the interior then reaches the ambient temperature at most.
ƇPress button or button to increase or decrease the desired
temperature by 1°C or °F respectively. The display flashes and shows the
programmed temperature. If you do not press another button, the flashing stops
and the display shows the current temperature inside the appliance again.
The appliance now cools down slowly to the set temperature.
Inserting/removing bottles
The appliance is designed for a maximum of eight standard beverage bottles
with a maximum length of approx. 33 cm.
NOTE
► It is usually somewhat cooler in the lower part than in the upper part of
the appliance. Therefore, always fill the appliance from bottom to top and
place the bottles or foods which require most cooling in the lower area.
► Taller bottles and containers with a maximum overall height of approx.
34 cm can also be placed upright in the appliance. To do this, remove
the shelves -.
You can pull out the shelves -to make it easier to insert and remove the bottles:
ƇTo do this, pull the shelves -out of the appliance until the two locking
appliances stop the shelves -in the rail.
ƇPush the shelves -back into the appliance as far as the stops.
GB│IE│NI │ 13 ■
SWTS 65 A1
Switching the light on and off
CAUTION – PROPERTY DAMAGE!
► Since the LEDs have a very long service life, it is not necessary or possible to
change them. Do not attempt to open the light under any circumstances,
as this will cause irreparable damage to the appliance!
The interior of the appliance is equipped with an LED light .
ƇPress the
°
C
|
°
F
button to switch the light on or off.
NOTE
► The light switches off automatically after 10 minutes.
Press the
°
C
|
°
F
button again to switch the light on again.
Recommended temperatures
The following table provides an overview of the recommended drinking temper-
atures for various types of wine. These are only recommendations – please note
any additional information on the label of the wine bottle. In the end, the right
drinking temperature is also a question of personal taste.
Drink Property
Recom-
mended
temperature
Sparkling wine 7 to 9°C
Rosé The stronger, the warmer. 7 to 12°C
White wine Young, light, dry, acidic, simple white
table wines 8 to 10°C
White wine Aromatic, spicy, fruity, ripe, Spätlese,
Auslese 10 to 12°C
White wine Semi-dry, sweet, ice wine,
Trockenbeerenauslese 12 to 14°C
Red wine Very fruity, young, sweet, simple red
table wines 10 to 14°C
Red wine Light to full-bodied, fruity, dry 14 to 16°C
Red wine Medium strong, everyday wines 16 to 18°C
Red wine Powerful, aromatic, heavy 18°C
NOTE
► As wine heats up quickly in the glass, it is better to serve it a little too cool
rather than too warm.
■ 14 │ GB│IE│NI SWTS 65 A1
After use
ƇRemove all stored bottles and containers and, if necessary, provide other
cooling.
ƇDisconnect the mains plug from the mains socket to switch off the appliance.
ƇClean the appliance as described in the section "Cleaning".
ƇLeave the door slightly open to prevent mould from forming inside.
ƇStore the appliance in a dry and dust-free place.
Cleaning
DANGER – ELECTRIC SHOCK!
► Before cleaning the appliance, disconnect the power plug from the mains
power socket!
Never immerse the appliance in water or any other liquid!
CAUTION – PROPERTY DAMAGE!
► Do not use abrasive or caustic cleaning agents. These can attack the
surface and irreparably damage it.
► Do not use any greasy or oily substances to clean the door seal. This can
make it porous.
ƇRemove the plug from the mains power socket.
ƇRemove all containers and shelves -from the appliance.
ƇClean the shelves -in warm water with a mild detergent. Then rinse the
parts with clear water and dry them.
ƇClean the inside and outside of the appliance with a damp cloth.
For stubborn dirt, add a little mild detergent to the cloth. Afterwards, wipe off
with a cloth moistened only with water and dry all surfaces thoroughly.
ƇIf necessary, clean the door seal only with a cloth moistened with water and
dry it well afterwards.
NOTE
► Condensation may form inside the appliance depending on the ambient
temperature and humidity. Wipe it off with a dry cloth. Part of the conden-
sation water may flow through the water drain into the drip tray at the
rear of the appliance where it evaporates. This means you do not have to
dispose of the condensation water.
GB│IE│NI │ 15 ■
SWTS 65 A1
Troubleshooting
The following table will help you to identify and rectify minor malfunctions. If these steps do
not solve the problem, please contact Customer Service.
Problem Possible causes Possible solutions
The appliance is
not working.
The appliance is not connect-
ed to a mains power socket. Insert the plug into a mains power socket.
The appliance is defective. Contact the Customer Service depart-
ment.
The mains power socket is
defective. Use a different mains power socket.
The appliance
does not cool/
the set tem-
perature is not
reached.
You have not allowed
sufficient time for the desired
temperature to be achieved.
Check the temperature again later. It may
take a while for the appliance to reach
the set temperature, especially if the
appliance is heavily filled.
The temperature is incorrectly
programmed. Check the programmed temperature.
The ambient temperature is
too high. Place the appliance in a cooler location.
The door is not properly
closed.
Make sure that the door is always
properly closed.
The door
does not close
properly or
does not close
at all.
The shelves -or the bottles
aren't inserted properly.
Check the correct seating of the
shelves-or the bottles.
The bottles are too big to fit
inside.
Place bottles with a maximum length of
33 cm in the appliance.
The appliance is standing on
an uneven surface.
Compensate for any unevenness in the
floor with the two front adjustable feet .
The appliance
vibrates and
shakes.
The appliance is standing on
an uneven surface.
Compensate for any unevenness in the
floor with the two front adjustable feet .
The ventilation
of the appliance
runs frequently
or continuously.
The door is not properly
closed.
Make sure that the door is always
properly closed.
The difference between the
set temperature and the ambi-
ent temperature is very large.
The appliance cools for longer and more
frequently to reach and maintain the set
temperature. This is not a fault.
■ 16 │ GB│IE│NI SWTS 65 A1
Disposal
Disposal of the appliance
Never dispose of the appliance in your normal domestic waste.
This product is subject to the provisions of the European WEEE
(Waste Electrical and Electronic Equipment) Directive 2012/19/EU.
Dispose of the appliance via an approved disposal company or your municipal
waste facility. Please comply with all applicable regulations. Please contact your
waste disposal facility if you are in any doubt.
When disposing of the appliance, note that it contains the combustible expanded
insulation gas cyclopentane.
Your local community or municipal authorities can provide information on the
available options for disposing of the worn-out product.
Disposal of the packaging
Dispose of the packaging in an environmentally-friendly manner.
Note the labelling on the packaging and separate the packaging material
components for disposal if necessary. The packaging material is labelled with
abbreviations (a) and numbers (b) with the following meanings: 1–7: plastics,
20–22: paper and cardboard, 80–98: composites.
Returning the packaging to the material cycle conserves raw materials and
reduces the amount of waste generated. Dispose of packaging materials which
are no longer needed in accordance with applicable local regulations.
GB│IE│NI │ 17 ■
SWTS 65 A1
Appendix
Energy label
Other manuals for SWTS 65 A1
1
This manual suits for next models
1
Table of contents
Languages:
Other Silvercrest Wine Cooler manuals
