SilverStar SR-5000 User manual

Silver Steamer
USER MANUAL
Industrial steam lron

It is also called as ¡°Electric Unwrinkle¡±, and is used to unwrinkle displayed dress
wrinkles in department stores or other clothing stores. Different from general ironing
using normal iron, it is used while clothes are displayed in hanger. It is a convenient
ironing tool for any place where it needs to unwrinkle.
Model Voltage Power Consumption Product Weight Product Size
SR-5000 120V/220V 1350W 8.5Kg 400×260×320H
SR-5000 127V/230V 1500W 8.5Kg 400×260×320H
SR-8000 120V/220V 1350W 8.5Kg 400×280×320H
SR-8000 127V/230V 1500W 8.5Kg 400×280×320H
2
Product Part Names
Size and Specifications
What is steamer?
Water Tank
Power Cable
Steamer
Body
Steam Brush
Steam Hose Set
Hanger Set
Water Tank
Power Cable
Silver Steamer

V: Voltage (AC120V, 230V), S/W1: Switch1, S/W2: Switch2, H1: Heater1, H2: Heater2,
EG: Earth Ground, R1: Resistor1, R2: Resistor2, L1: Lamp 1, L2: Lamp 2, BZ: Buzzer,
TS: Temperature Controller, TF: Temperature Fuse
3
Circuit Diagrams
S/W1
H1
R2
S/W2
TS
R1
BZ
L1
H2
L2
TF
V
EG
BZ
Installation and Operation
1. Assemble hanger
rod
• Pull out hanger rod 1
to the end and fix it by
rotating 1. Assemble
hanger rod 1 & 2, and
fix it by rotating the
round part.
5. Connect to power
supply
• Insert plug to power
socket and turn on the
switch.
6. Operate
• It is ready to use
when steam is sprayed
after 1 minute and 30
second.
4. Insert water tank
• Fill water tank with
water, close water tank
cap and place it to
steamer.
3. Hose set assemble
• SR~5000 Assemble
hose set and steamer
using accompanied
spanner.
SR~8000 Insert nipple of
hose to steamer,then
turn right .
• Be careful to tighten
the joint during
assemble.
2. Assemble hanger
rod and steamer
• Assemble hanger rod
set from item 1 with
steamer.
Silver Steamer

♣Please observe following safety regulations to prevent any danger or accidents.
1. Do not touch power plug with wet hands when plugging in to removing from power socket.
2. Do not remove the plug from the power socket by pulling on the cord.
3. Do not place excessive stress on the power cord by bending or tying.
4. Do not place heavy items over power cord or prevent it pressed by product.
5. Connect the product to a socket with at least 10A rated current, and do not share
the socket with other products.
6. Assemble the steam hose set tightly to the product using the provided spanner.
7. Check the rated voltage before using
it.
8. Do not disassemble or modify the product.
9. Do not spray steam directly to a person or touch steam when using it.
10. Be careful not to stumble and fall over the power cord.
11. Make sure the steam nozzle does not fall on the floor during or after use.
12. Product should be used only for ironing purpose.
13. Be sure to pull out plug when cleaning the iron after use.
14. Do not place heavy items over the product when storing it after use.
15. Use clean water that does not contain minerals, if possible.
16. Use iron only on a flat and leveled floor without slope.
17.This appliance can be used by children aged from 8 years and above persons with reduced
physical,sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
18.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
19.This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
20.Children should be supervised to ensure that they do not play with the appliance.
21.care should be taken when using the appliance due to the emission of steam;
22.unplug the appliance during filling and cleaning.
1. After using the product, remove the power plug and completely remove water
inside the steamer and water tank.
2. When cleaning, wipe it with slightly wet towel, and then wipe it with dry towel before storing it.
4
Safety Regulations
Maintenance and Storage
Silver Steamer

♣ Clean the product as described following procedure when steam does not come
out well during using it.
♣ When cleaning, make sure that the power plug has been removed from the power
socket before proceeding.
5
Simple Cleaning Methods
1. Separate hanger
rod and steam hose.
6. After above
cleaning procedure
is completed,
assemble the
product and use it.
5. Remove scale in
the cap.
4. Place water jar
and pour water to
the pointed holes to
remove scale inside
the product.
3. Open cap under
the steamer bottom.
2. Take water tank
out of the body, and
remove water inside
the steamer.
wate
r
wat
er
