SilverStone EC05 User manual

EC05
PCI Express Card with 2 SATA 6Gbps internal ports
MANUAL

EC05
PCI Express Card with 2 SATA 6Gbps internal ports
Introduction
Features
Specifications
Model No.
Form factor
SATAIII controller
Ports
Function mode
Transfer speed
Drive Support
Port Interface
OS Support
SST-EC05
Low profile single lane (X1) PCI Express 2.0
Marvell 88SE9130
SATA 6Gbps internal ports x2
HyperDuo (capacity), HyperDuo (safe), RAID0, RAID1
Up to 5Gbps via PCI Express 2.0 1X slot
SATA HDD or SSD
SATA 6Gbps backwards compatible with SATA 3Gbps / 1.5Gbps
Windows XP, Vista, 7(32bit/64bit)
1
SilverStone created an excellent expansion card product, the EC05, which connects to the
motherboard via single lane PCI Express 2.0 slot to support two internal SATA 6Gbps
interface with maximum compatibility and stability. The EC05 can be configured to “HyperDuo
mode” with one SSD and one HDD to support boost speed with SSD. It can also be config-
ured to “RAID0” to boost HDD transfer speed with 2 HDDs in addition to backing up valuable
data through “RAID1.”
PCI Express 2.0 with single lane (x1) throughput 5Gbit/s.
Supports simultaneous operation of multiple SATA 6Gbps/SATA 3Gbps devices.
Adds two internal SATA 6Gbps ports to the system.
Supports HyperDuo (capacity), HyperDuo (safe), RAID0, RAID1

INSTALLATION 1
Install EC05 onto PCIe slot of Motherboard.
(refer to PIC1)
Установите плату EC05 вгнездо PCIe
материнской платы. (см. рисунок 1)
Installieren Sie die EC05 im PCIe-Steckplatz
des Motherboards. (vgl. Abb. 1) 將EC05 安裝於主機板上的PCI-E插槽。
（請參考圖一）
Installez le EC05 dans un emplacement PCIe
de la carte mère. (voir image 1)
将EC05 安装于主机板上的PCI-E插槽。
（请参考图一）
Instale el EC05 en el zócalo PCIe de la placa
base. (consulte la IMAGEN1)
EC05 をマザーボードのPCIeスロットにインスト
ールします
。 (図1.参照)
Inserisci EC05 nello slot PCIe della scheda
madre. (fare riferimento alla PIC1)
EC05 을 메인보드의 PCIe 슬롯에 장착합니다.
(PIC 1 참조)
2
EC05
PCI Express Card with 2 SATA 6Gbps internal ports
PIC1
SATA connector SATA connector

INSTALLATION 2
Install the Marvell 9130 driver. Установите драйвер Marvell 9130.
Installieren Sie den Marvell 9130-Treiber. 安裝Marvell 9130驅動程式 ）
Installez le pilote de Marvell 9130. 安装Marvell 9130驱动程序
Instalar el controlador Marvell 9130. Marvell 9130ドライバをインストールします
Installare il driver Marvell 9130. Marvell 9130 드라이브를 설치합니다.
3
EC05
PCI Express Card with 2 SATA 6Gbps internal ports

INSTALLATION 3
4
EC05
PCI Express Card with 2 SATA 6Gbps internal ports
After the driver is installed, “Marvell 91xx
SATA 6G Controller” will appear under
Device Manager(refer to PIC2)
После установки драйвера вдиспетчере
устройств отобразится пункт "Marvell
91xx SATA 6G Controller"
驅動程式安裝完成後，在裝置管理員中可看
見Marvell 91xx SATA 6G Controller
驱动程序安装完成后，在装置管理员中可看
见Marvell 91xx SATA 6G Controller
ドライバをインストールした後、デバイスマネー
ジャの下に「Marvell 91xx SATA 6Gコントロー
ラ」が表示されます
드라이브가 설치되면, “Marvell 91xx
SATA 6G Controller”가 장치 관리자에
표시됩니다.
Nach Installation des Treibers wird im
Geräte-Manager „Marvell 91xx SATA 6G
Controller“ angezeigt.(vgl.Abb.2)
Lorsque le pilote a été installé, “Marvell
91xx SATA 6G Controller” apparaîtra dans
Gestionnaire des périphériques.(voir image
2)
Una vez instalado el controlador, “Controla-
dor Marvell 91xx SATA 6G” aparecerá bajo
Administrador de dispositivos.
Dopo avere installato il driver, sotto Device
Manager (Gestione periferiche) apparirà la
voce “Marvell 91xx SATA 6G
Controller”.(fare riferimento alla PIC2)

5
EC05
PCI Express Card with 2 SATA 6Gbps internal ports
PLEASE SEE EXAMPLE BELOW
PIC2

INSTALLATION 4
6
EC05
PCI Express Card with 2 SATA 6Gbps internal ports
Connect your SATAIII hard drive onto the
EC05 to complete the installation. Подключите жесткий диск SATAIII кEC05 инаслаждайтесь высокой скоростью!
將您的SATAIII硬碟連接至EC05開始享受高
速傳輸速度。
将您的SATAIII硬盘连接至EC05开始享受高
速传输速度。
SATAIIIハードドライブをEC05に接続すると、高
速な動作をお楽しみいただけます!
SATAIII 하드 드라이브를 EC05에
연결하고 빨라진 속도를 즐기십시오!
Verbinden Sie Ihre SATA III-Festplatte mit
dem EC05 und genießen Sie High-Speed!
Connectez votre disque dur SATAIII au
EC05 pour avoir accès à la haute vitesse !
Conecte su unidad de disco duro SATAIII al
EC05 y disfrute de la alta velocidad!
Collegare il disco rigido SATAIII a EC05
ottenendo il massimo rendimento!

March, 2012
