Simagic Alpha User manual

User Manual
*PD-20-01*
Welcome to the Direct Drive Revolution.
ALPHA

1. Users can visit SIMAGIC global website www.simagic.com to browse product information or
obtain product support；
2. Simagic official website information publishing site Uniform name：Simagic official
YouTube
Facebook
Twitter
3. China's information channel
* For more convenient and quick use of Alpha base, please read thisBefore installation and use,
please read the instruction manual carefully, which contains important product and safety
information; please make sure to keep this manual for future reference.
* The product contains many advanced technologies, including custom overspeed motors,
integrated electronics, wireless modules, etc. and is PC compatible.
* Pd-19-01 is a trial version, simagic reserves the right to modify it without prior notice, based
on factors such as product and user feedback.
* This instruction manual is a general instruction manual for a single product (including
different configurations and categories under a single product).
Getting information

Contents
About Simagic··········································································· 2
Product Profile
basic introduction······························································4
Base introduction······························································ 5
Fuselage data··································································· 6
technical introduction························································· 7
Safety Suggestion······································································9
Packing Brief······································································· 11
Quick release······································································· 12
Adapter steering wheel······························································14
Race manager
Download and install······························································· 17
Installation steps···································································· 17
Interface introduction······························································18
Firmware Update······································································· 23
Warranty description································································· 25
Additional explanation······························································ 27

Simagic Alpha Base User Manual
１
About SIMAGIC
T
This section introduces
Simagic brand and Simagic Tech.

Simagic Alpha Base User Manual
２
Simagic brand direct drive simulator is the first three-phase hybrid direct drive motor simulator
designed independently in China. The steering wheel is directly connected with the motor shaft,
eliminating the traditional belt and gear sensors, bringing a more pure and immersive direct
driving experience.
Simagic takes users as the center, develops the direct drive revolution with all its strength and
strives to build the world's top direct drive simulator, and promotes the development of racing
E-sports from keyboard Entertainment (1.0) to simulator Entertainment (2.0).
The first direct drive simulator host achieves real-time, accurate and extremely accurate
reproduction of driving road conditions, physical feedback of the action effect in the racing game,
and a new human-computer interaction experience.
Shenzhen Simagic Tech Co., Ltd is the first company based on the field of simulation driving
equipment in China, adhering to the company concept of "committed to the development of new
culture of simulation driving", to create the best racing equipment and best competitive
experience for racing game enthusiasts, and create a new application mode of simulation driving
for the driving industry.
As a new generation team of China's racing E-sports culture, with the initiative of simagic brand
direct drive equipment, we are at the forefront of simulation racing equipment technology,
insisting on the product concept of continuously innovating technology and optimizing product
design, "leading the trend of simulation driving with innovative technology", and filling the gap in
the field of China's racing E-sports with the advanced technology level of international racing
simulation driving equipment.
Fast simagic technology adheres to the enterprise spirit of "technology leading, extremely
intelligent first", actively practices the concept of product development through scientific and
technological exploration, integrates unlimited possibilities into every experience detail, and
develops the new simulation driving culture of China's intelligent manufacturing.
Simagic Brand
Simagic Tech

Simagic Alpha Base User Manual
３
Product Profile
This section describes the specific
functions of Alpha so that you can
quickly understand and use it

Simagic Alpha Base User Manual
４
*Special surface treatment of the body casing resulting in sleeker and more premium feel.
*Bright black body color gives the body a more robust and automotive component feel .
*The whole body is integrated design, and the adaptive control software replaces the multi line
socket.
*Unique top laser logo.
Introduction

Simagic Alpha Base User Manual
５
Alpha base is made of integrated design, with clean body and less ports.
Base introduction
Safety switch
Can Bus Peripheral
Interface
Usb-b port: use the
factory equipped usb-b
data cable to connect
the PC end.
Power Supply

Simagic Alpha Base User Manual
６
Fuselage data
Mounting bracket

Simagic Alpha Base User Manual
７
Technical Highlights
The three CPUs respectively implement motor control, game effect
presentation, and USB real-time communication. Give the entire system real-time, fast
and complete presentation of every force feedback detail
New design servo motor, for smoother and softer response; smaller body size,
maximum continuous torque of 15nm.
Equipped with self-developed control software, Race Manager has feature rich yet
simple and user friendly functions that adjust data according to different personal needs.
In the drift game, the unique drift mode adjustment: the force feedback size
and return speed can be set separately, perfectly balancing the strength and return
speed, which can bring a new real car drift experience.
Supports a variety of peripherals, making the simulation process more realistic.
The built-in encoder has a resolution of 262144 PPR, providing more detailed
game feedback.
The built-in wireless power supply and wireless communication system are
continued to remove the cumbersome and inefficient physical connection.
Equipped with simagic custom quick release, it adapts to the steering wheel
without gap.

Simagic Alpha Base User Manual
８
Safety Suggestion
This page introduces the safety
suggestions for the steering wheel
of the direct drive simulator in use,
which is very important

Simagic Alpha Base User Manual
９
* Alpha power on instructions:Always check to make sure the power connector is switched OFF
before plugging in or unplugging the wheelbase. It is forbidden to plug and unplug the power
connector at the base end while power is switched on.
* Equipment and power supply shall not be exposed to rain or other liquids or humid environment
to avoid short circuit and leakage, which may cause damage and failure of equipment and fire.
* The suitable operating temperature is 15 ℃ - 35 ℃.
* It is suggested that the game time of power feedback is 1 hour, and overuse may lead to health
risks; we suggest to take 5 minutes off every 20 minutes, and the maximum driving time per
person per day is 2 hours.
* Although the product can adjust the force feedback data, the children under 13 years old must
be supervised by their parents to adjust the force feedback parameters of children's model and
use the device under their supervision.
* When users use it for the first time, please adjust the force feedback from small to appropriate
strength.
* In the game, if the feedback force adjustment is too large to control, please stop the game
immediately and adjust the feedback force parameters in time.
* This product contains small parts, and the magnetic light sensitive shift paddle adopts strong
magnetic magnet, which is not suitable for children under 13 years old to operate alone.
* The hub contains circuits and other parts that cannot be repaired by the user. It is forbidden for
the user to open the equipment shell to avoid greater damage to the equipment.
* It is forbidden for the user to open the hub without authorization or professional guidance,
which may cause irreparable injury to the equipment and the user will not receive simagic's
warranty policy service.
* The steering wheel must be installed on the simagic main engine to ensure proper matching
power supply.
* The factory fitted USB cable must be used when upgrading the steering wheel.
* In order to ensure relevant safety, parts replacement can only be sent out or repaired by an
officially authorized maintenance center.
* If it is not used for a long time, please pull out the steering wheel and disconnect it from the
main engine.
* In case of any abnormality, please stop using immediately and ask simagic official or relevant
authorized Center for help.
* Please follow simagic website and public platform for the latest product information.
* This product is only limited to simulation driving related activities.
Please distinguish simulation games from reality and drive safely！
Proper Use
Electricity Safety

Simagic Alpha Base User Manual
１０
Packaging Brief
This section introduces the packaging
content of Alpha. Alpha is designed
and manufactured with integrated
design and convenient operation

Simagic Alpha Base User Manual
１１
Package Contents
Mounting screw pack
power supply
USB data cable
Quick release
Warranty Card

Simagic Alpha Base User Manual
１２
Simagic custom quick release adopts the design of high precision upper six balls and lower four
balls, and the access base needs to align the steel ball hole position. It can be disassembled
without any tools.
The quick release logo shell is the first lock. Hold the red part of the shell when removing it.
Pull out the quick release to remove it.
To fit it back in, just push the QR back on the shaft and rotate the shaft till it clicks and locks in,
ensuring that the ball bearings fully seated in the shaft ring of the base.
Operation Explanation

Simagic Alpha Base User Manual
１３
Adapter steering wheel
This section introduces M10 compatible
steering wheel, two simagic GT1, one gt4
steering wheel

Simagic Alpha Base User Manual
１４
D wheel
Round wheel
SIMAGIC steering wheel
GT1
GT4
* This section is not limited to simagic single host. More simagic products can be found on simagic official website or public platform and other official

Simagic Alpha Base User Manual
１５
information release channels。
Race Manager
This section introduces the control
software of simagic direct drive simulator.
Race manager is the control center

Simagic Alpha Base User Manual
１６
* Race manager is a host control program independently designed by simagic according to the
mechanical effect of the direct drive simulator host and the source of game feedback. The interface is
simple and easy to operate, which simplifies cumbersome parameter settings and complicated
parameter relationships, and brings more direct product experience to users.
* SIMAGIC supports six types of game force, and game may not use all types. At the beginning of
the game, the type that is chosen will turn red. Users can adjust the type of game force.
The default value of game force is 100, which is the original output of the game. Users can get a
good handle by adjusting the mechanical setting coefficient.
* Race manager supports parameter saving. Users can save parameters after adjusting to the best
experience parameters for different games and scenes.
*Modify parameter method：the parameters in the parameter setting part can be modified directly by
pulling the slider and by keyboard input (press enter to take effect.
Race Manager

Simagic Alpha Base User Manual
１７
Users obtain simagic control software "race manager" as follows：
（ 1 ） Official website of simagic Technology: www.simagic.com users can go to the homepage of the
official website to navigate the "service and support" section and download the simagic
professional driver software installation package "race manager" according to the guidance.
（2）Through Simagic's designated sales outlets and channels. Please contact Simagic's official
after-sales customer service or distributor in various regions to obtain desired "service and
support" such as documents, official information release platform, etc
①Extract the "race manager" driver package to the custom path: (Note: it is recommended that all
software paths do not contain Chinese characters)
②Get the racemanager folder:
③After opening racemanager software, set parameters:
Installation steps
Download and install
