Ruijie RG-S6000C-48GT4XS-E Installation and operating manual

Ruijie RG-S6000C-48GT4XS-E Switch
Hardware Installation and Reference Guide
Document Version: V2.0
Date: August 31, 2023
Copyright © 2023 Ruijie Networks

Copyright
Copyright © 2023 Ruijie Networks
All rights are reserved in this document and this statement.
Any reproduction, excerption, backup, modification, transmission, translation or commercial
use of this document or any portion of this document, in any form or by any means, without the
prior written consent of Ruijie Networks is prohibited.
Trademark and are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their
respective owners.
Disclaimer
The products, services, or features you purchase are subject to commercial contracts and
terms. Some or all of the products, services or features described in this document may not be
within the scope of your purchase or use. Unless otherwise agreed in the contract, Ruijie
Networks does not make any express or implied statement or guarantee for the content of this
document.
Due to product version upgrades or other reasons, the content of this document will be
updated from time to time. Ruijie Networks reserves the right to modify the content of the
document without any notice or prompt.
This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and
will not shoulder any responsibility for losses and damages caused due to content omissions,
inaccuracies or errors.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Technical support website: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Technical support email: [e-mail]
Live chat: https://www.ruijienetworks.com/rita
Conventions
1. Signs
The signs used in this document are described as follows:
Danger
An alert that contains important safety instructions. Before you work on any equipment, be
aware of the hazards involved and be familiar with standard practices for preventing
accidents.
Warning
An alert that calls attention to important rules and information that if not understood or followed
can result in data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result
in function failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or
followed will not lead to serious consequences.

II
Specification
An alert that contains a description of product or version support.
2. Note
The manual offers configuration information (including model, port type and command line
interface) for indicative purpose only. In case of any discrepancy or inconsistency between the
manual and the actual version, the actual version prevails.

i
Contents
Preface.................................................................................................................................................. I
1Overview ........................................................................................................................................... 1
1.1 About the RG-S6000C-48GT4XS-E..........................................................................................1
1.2 Component Modules..................................................................................................................1
1.3 Chassis ......................................................................................................................................2
1.3.1 Appearance....................................................................................................................2
1.3.2 LEDs ..............................................................................................................................4
1.3.3 Ports...............................................................................................................................6
1.3.4 Cooling...........................................................................................................................8
1.3.5 Technical Specifications.................................................................................................9
1.3.6 Nameplate....................................................................................................................13
1.4 Power Modules........................................................................................................................13
1.4.1 RG-PA70I.....................................................................................................................14
1.4.2 RG-PD70I.....................................................................................................................17
1.5 Fan Module..............................................................................................................................19
1.5.1 M6000E-FAN-F............................................................................................................19
1.6 Cables......................................................................................................................................21
1.6.1 Console Cable .............................................................................................................21
1.6.2 Ethernet Cable.............................................................................................................22
1.6.3 Power Cord..................................................................................................................23
1.6.4 Grounding Wire............................................................................................................25
1.7 Pluggable Modules..................................................................................................................26
2Preparing for Installation................................................................................................................. 27

ii
2.1 Safety Guidelines.....................................................................................................................27
2.1.1 General Precautions....................................................................................................27
2.1.2 Chassis-Lifting Guidelines...........................................................................................27
2.1.3 Electricity Safety ..........................................................................................................28
2.1.4 Preventing ESD Damage.............................................................................................28
2.1.5 Laser Safety.................................................................................................................29
2.1.6 Storage Guidelines......................................................................................................29
2.2 Site Requirements...................................................................................................................29
2.2.1 Floor Loading...............................................................................................................29
2.2.2 Airflow...........................................................................................................................29
2.2.3 Space...........................................................................................................................29
2.2.4 Temperature.................................................................................................................30
2.2.5 Humidity.......................................................................................................................30
2.2.6 Cleanliness...................................................................................................................30
2.2.7 System Grounding.......................................................................................................31
2.2.8 Preventing Electromagnetic Interference ....................................................................32
2.2.9 Surge Protection..........................................................................................................33
2.3 Rack-Mounting Guidelines.......................................................................................................33
2.4 Tools ........................................................................................................................................34
2.5 Unpacking the Switch..............................................................................................................34
2.5.1 Verifying the Shipped Content.....................................................................................34
2.5.2 Unpacking the Container.............................................................................................35
3Installing the Switch ........................................................................................................................ 37
3.1 Installation Procedure..............................................................................................................38

iii
3.2 Installing the Rack....................................................................................................................39
3.2.1 Installation Guidelines..................................................................................................39
3.2.2 Procedure.....................................................................................................................39
3.3 Installing the Chassis...............................................................................................................40
3.3.1 Installation Guidelines..................................................................................................40
3.3.2 Mounting the Brackets.................................................................................................40
3.3.3 Mounting the Chassis on the Rack..............................................................................41
3.3.4 Mounting the Chassis on the Wall...............................................................................41
3.3.5 Mounting the Chassis on the Workbench....................................................................42
3.4 Installing the Protective Grounding Wire.................................................................................42
3.4.1 Installation Guidelines..................................................................................................42
3.4.2 Procedure.....................................................................................................................43
3.5 Installing and Removing the Fan Module................................................................................43
3.5.1 Installing the Fan Module.............................................................................................43
3.5.2 Removing the Fan Module...........................................................................................44
3.6 Installing and Removing the Expansion Module.....................................................................45
3.6.1 Installing the Expansion Module..................................................................................45
3.6.2 Removing the Expansion Module................................................................................46
3.7 Installing and Removing the Power Module............................................................................47
3.7.1 Installing the RG-PA70I................................................................................................47
3.7.2 Installing the RG-PHD550I-F.......................................................................................50
3.7.3 Installing the RG-PD70I...............................................................................................51
3.7.4 Removing the Power Module.......................................................................................53
3.8 Installing the Pluggable Module...............................................................................................54

iv
3.9 Verifying Installation.................................................................................................................54
3.10 Connecting the Power Cord ..................................................................................................55
4Commissioning................................................................................................................................ 55
4.1 Setting Up the Configuration Environment..............................................................................55
4.2 Powering on the Device...........................................................................................................57
4.2.1 Checklist Before Power-on..........................................................................................57
4.2.2 Power-on......................................................................................................................58
4.2.3 Checklist Before Power-on..........................................................................................58
5Monitoring and Maintenance........................................................................................................... 59
5.1 Monitoring................................................................................................................................59
5.1.1 Monitoring the LEDs....................................................................................................59
5.1.2 Running the CLI Commands .......................................................................................59
5.2 Maintenance ............................................................................................................................60
5.2.1 Replacing the Power Module.......................................................................................60
5.2.2 Replacing the Fan Module...........................................................................................60
5.2.3 Replacing the Lithium Battery......................................................................................60
5.2.4 Replacing the Fuse......................................................................................................61
6 Troubleshooting............................................................................................................................ 62
6.1 Flowchart..................................................................................................................................62
6.2 Common Issues.......................................................................................................................63
6.2.1 Forgetting Login Password..........................................................................................63
6.2.2 AC Power Module Failure............................................................................................63
6.2.3 Fan Module Not Rotating.............................................................................................63
6.2.4 No Output on the Console...........................................................................................63

v
6.2.5 Garbled Output on the Console...................................................................................64
6.2.6 Optical Port Linkdown..................................................................................................64
7 Appendix........................................................................................................................................ 64
7.1 Labeling Process.....................................................................................................................64
7.1.1 Hand Writing on Labels................................................................................................64
7.1.2 Pasting Labels .............................................................................................................65
7.1.3 Label Contents.............................................................................................................66
7.2 Connectors and Media.............................................................................................................67
7.2.1 100BASE-TX/10BASE-T Port......................................................................................67
7.2.2 1000BASE-T Port ........................................................................................................67
7.3 Surge Protection......................................................................................................................69
7.3.1 Installing an AC PowerArrester...................................................................................69
7.3.2 Installing an Ethernet PortArrester..............................................................................71
7.4 Site Selection...........................................................................................................................72
7.5 Recommended Cabling...........................................................................................................73

Hardware Installation and Reference Guide Overview
1
1 Overview
1.1 About the RG-S6000C-48GT4XS-E
The RG-S6000C-48GT4XS-E switch is a Gigabit switch featuring high-density and low-latency
launched by Ruijie Networks for data centers and high-end campuses. The RG-S6000C-
48GT4XS-E switch provides high-density Gigabit access, 10GE uplink ports, and diverse data
center features. It can be used with Ruijie’s RG-N18000-X and RG-S6920-4C switches for a
high-performance and high-reliability data center network.
Table 1-1 RG-S6000C-48GT4XS-E Overview
Chassis
1000BAS
E-T Ports
10GE SFP+
Ports
Expansion
Module
Slots
Power
Redundancy
Fan Module Slots
RG-S6000C-
48GT4XS-E
48
8
1
1+1
1
Note
The product images involved in this manual are for indicative purpose only. The appearance is
subject to the actual equipment.
1.2 Component Modules
The RG-S6000C-48GT4XS-E adopts the modular design. Compliant with industry standards,
the design differentiates modules and integrates module interfaces to ensure an integrated
system with independent function modules.
Table 1-2 Component Modules
Chassis
Expansion
Module
Power Module
Fan Module
RG-S6000C-
48GT4XS-E
-
RG-PA70I
M6000E-FAN-F
RG-PD70I

Hardware Installation and Reference Guide Overview
2
Caution
Different power modules are interchangeable. That is, the switch allows concurrentAC and DC
input. For example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted
Power Supply (UPS) DC power.
1.3 Chassis
The RG-S6000C-48GT4XS-E hardware system consists of a chassis, a power supply system,
and a cooling system.
Power supply system: provides two power module slots and supports 1+1 power
redundancy.
Cooling system: provides one fan module slot.
1.3.1 Appearance
1. Appearance
Figure 1-1 Front View of the RG-S6000C-48GT4XS-E

Hardware Installation and Reference Guide Overview
3
Figure 1-2 Rear View of the RG-S6000C-48GT4XS-E
2. Structure
Figure 1-3 Front Panel Structure
Table 1-3 Front Panel Components
No.
Component
1
Status LED
2
PWR1 status LED
3
PWR2 status LED
4
Management port LED
5
Fan status LED
6
Console port
7
1000BASE-T port

Hardware Installation and Reference Guide Overview
4
8
1000BASE-T port status
9
USB port
10
Mini-USB port
11
Management port
12
10GE SFP+ port
Figure 1-4 Rear Panel Structure
Table 1-4 Rear Panel Components
No.
Component
1
Grounding stud
2
Expansion module slot
3
Fan module slot
4
PWR1 module slot
5
PWR2 module slot
1.3.2 LEDs
Table 1-5 LEDs
Silkscreen
Label
LED
Description
Status
Status LED
Solid green: The system is operating normally.
Blinking green at 3 Hz: The system is starting up.
Continuous blinking indicates an anomaly.
Blinking green at 10 Hz: The system is being located.

Hardware Installation and Reference Guide Overview
5
Silkscreen
Label
LED
Description
Solid red: The system (including all modules) is not
functioning properly.
Solid yellow: The temperature exceeds the limit or the
power consumption is not enough.
Off: The system is not receiving power or not
operating even after receiving power.
PWR1/PWR2
Power status
LED
Solid green: The power module is operating normally.
Solid yellow: The power module model can be read
but cannot be identified.
Solid red: The redundant power module is not
functioning properly or not connected with the AC
power cord.
Off: The power module is not connected or not
functioning properly after being connected.
FAN
Fan status
LED
Solid green: The fan module is operating normally.
Solid yellow: One fan module is not functioning
properly, which does not affect heat dissipation.
Solid red:At least two fan modules are not
functioning properly, which affects heat dissipation.
Off: The fan module is not connected or not
functioning properly after being connected.
1F to 48F
1000BASE-T
port LED
Solid yellow: The port has made a successful 10/100
Mbps link.
Blinking yellow: The port is sending and receiving
traffic at 10/100 Mbps.
Solid green: The port has made a successful 1,000
Mbps link.
Blinking green: The port is sending and receiving
traffic at 1,000 Mbps.
Off: No link is detected for the port.
49F to 52F
SFP+ port
LED
Solid green: The port has made a successful 1/10
Gbps link.
Blinking green: The port is sending and receiving

Hardware Installation and Reference Guide Overview
6
Silkscreen
Label
LED
Description
traffic at 1/10 Gbps.
Off: No link is detected for the port.
LINK/ACT
Management
port LED
Solid yellow: The port has made a successful 10/100
Mbps link.
Blinking yellow: The port is sending and receiving
traffic at 10/100 Mbps.
Solid green: The port has made a successful 1,000
Mbps link.
Blinking green: The port is sending and receiving
traffic at 1,000 Mbps.
Off: No link is detected for the port.
1.3.3 Ports
Table 1-6 Ports
Port
Connector Type
Description
Accessory
1000BASE-T port
RJ45
The 1000BASE-T port is
backward compatible with
100BASE-T and 10BASE-T
for downlink data
transmission.
Standards compliance:
IEEE802.3ab
Working mode: Full-
duplex
CAT5 or higher
cable
10GE SFP+ port
Subject to the
optical module
The 10GE SFP+ port is
aligned to IEEE 10GBase-R
specifications. It is backward
compatible and can
accommodate the
1000BASE-X module for
uplink data transmission.
Standards compliance:
1GE optical module
10GE optical
module
AOC

Hardware Installation and Reference Guide Overview
7
Port
Connector Type
Description
Accessory
IEEE802.3ae
Working mode: Full-
duplex
Optical attributes:
Subject to the module or
cable
Management port
RJ45
The management port is
used to set up the onsite or
remote configuration
environment.
Standards compliance:
IEEE802.3ab
Working mode:
10/100/1000 Mbps with
auto-negotiation and full-
duplex
CAT5 or higher
cable
USB port
USB
The USB port is connected
with a USB flash drive for
configuration backup and
firmware upgrade.
USB 2.0
FAT32 file format
USB 2.0 flash drive
Console port
RJ45
The console port is
connected to a console for
onsite configuration.
Standards compliance:
RS-232
Working mode: Duplex
Universal Asynchronous
Receiver/Transmitter
(UART)
Baud rate:
○Range: 9,600 bit/s to
115,200 bit/s
○Default value: 9,600
Console cable

Hardware Installation and Reference Guide Overview
8
Port
Connector Type
Description
Accessory
bit/s
Mini-USB port
Mini-B
The virtual USB port
integrates the serial-to-USB
chip for virtual serial port
communication. It is used for
system debugging,
configuration, maintenance,
management, and software
uploading.
USB 2.0
Note
The serial port is the
console port by
default.After the USB
cable is plugged into
the mini-USB port, the
mini-USB port
functions as the serial
port.After the USB
cable is disconnected,
the serial port
switches back to the
console port again.
USB mini-B cable
1.3.4 Cooling
1. Overview
The RG-S6000C-48GT4XS-E adopts the front-to-rear airflow. Air flows in through the ports and
out through the power module, as shown in Figure 1-5.
Caution
Maintain a minimum clearance of 200 mm (7.87 in.) around the equipment for air
circulation.
At least three fan modules are required. If any slot is unoccupied, install a filler panel to
enable proper airflow and to keep dust out of the chassis.
Dust the equipment every three months to avoid blocking the ventilation openings on the
housing.

Hardware Installation and Reference Guide Overview
9
2. Airflow
Figure 1-5 Front-to-Rear Airflow
1.3.5 Technical Specifications
Table 1-7 Technical Specifications
Class
Item
Specification
Technical
indicators
CPU
1.0 GHz dual-core
Memory
1 GB, SDRAM
Flash memory
NOR flash: 8 MB (for BootROM)
NAND flash: 512 MB
Physical
characteristics
Dimensions
(W x D x H)
Without packing materials: 440 mm x 300 mm x
44 mm (17.32 in. x 11.81 in. x 1.73 in., 1 RU)
With packing materials: 593 mm x 427 mm x 172
mm (23.35 in. x 16.81 in. x 6.77 in.)
Weight
Chassis and modules (one fan module and two
power modules) without packing materials: 4.8 kg
(10.58 lbs.)
Structure
Integrated chassis without expansion module slots

Hardware Installation and Reference Guide Overview
10
Class
Item
Specification
Two power module slots
One fan module slot
Ports
Downlink port
48 x Gigabit ports, aligned to IEEE 1000BASE-T
specifications, backward compatible with 100BASE-T
and 10BASE-T
Uplink port
4 x 10GE SFP+ ports, aligned to IEEE 10GBase-R
specifications, backward compatible with 1000BASE-
X
Console port
1 x RJ45 port
USB port
1 x UBS 2.0 port
Management port
1 x Gigabit RJ45 port supporting backward
compatibility
Mini-USB port
1 x Mini-USB port, compliant with USB 2.0
specifications
Environment
Altitude
Operating altitude: 0–5,000 m (16,404.20 ft.)
Storage altitude: 0–5,000 m (16,404.20 ft.)
Temperature
Operating temperature: 0°C to 50°C (32°F to
122°F) at an altitude in the range of 0–2,000 m
(0–6,561.68 ft.)
Note
At an altitude in the range of 2,000–5,000 m
(6,561.68–16,404.20 ft.), every time the
altitude increases by 200 m (656.17 ft.), the
maximum temperature decreases by 1°C
(1.8°F).
Storage temperature: –40°C to +70°C (–40°F to
+158°F)
Humidity
Operating humidly: 10% RH to 90% RH (non-
condensing)
Storage humidity: 5% RH to 95% RH (non-

Hardware Installation and Reference Guide Overview
11
Class
Item
Specification
condensing)
Noise
Sound pressure level at 27°C(80.6°F): < 78 dB
Surge protection
AC power protection
Common mode: 2 kV
Differential mode: 1 kV
Power supply
Power supply
mode
AC
DC
High-voltage DC (HVDC)
Power connector
Three-pin connector, subject to the power module
Power consumption
Max: 60 W
Typical: 50 W
Static: 34.2 W
Voltage
AC: 100 V AC to 240 V AC, 50 Hz to 60 Hz
DC: –36 V DC to –72 V DC
HVDC: 160 V DC to 400 V DC
AC input
RG-PA70I:
○Rated voltage: 110 V AC/220 V AC
○Rated voltage range: 100 V AC to 120 V AC/
200 V AC to 240 V AC (50 Hz to 60 Hz)
○Max. voltage range: 90 VAC to 264 VAC (47
Hz to 63 Hz)
○Max. current: 2 A
DC input
RG-PA70I:
○HVDC range: 120 V DC to 340 V DC
○Rated voltage: 240 V DC
○Max current: 2 A
RG-PD70I:
○HVDC range: –48 V DC to –78 V DC
